WBM-PIP - INSTALLATION QUICK GUIDE
1.DESCRIPTION
The electric vehicle charging system WBM-PIP is specially designed for use on indoor and outdoor car parks to
provide a safe charging system. It consists of a sturdy housing designed to be installed on a flat wall surface.
2.WARNINGS
Do not use cables there are not in perfect conditions.
Do not use WallBox for anything other than electric vehicle charging. Charging mode is IEC 61851-1 MODE 3.
Do not modify the WallBox. If modified, APT CONTROLS will reject all responsibility and the warranty will be
void.
Comply strictly with current safety regulations according to your country rules.
Do not make repairs or install with the device powered.
Only trained and qualified personnel should have access to low-voltage electrical parts inside the device.
Check the installation annually by qualified technician.
Remove from service any item that has a fault that could be dangerous for users (broken plugs, caps that
don’t close...).
Only use APT CONTROLS spare parts.
3.TECHNICAL CHARACTERISTICS
Input Voltage
230V AC
Single-phase
Extended temperature
range*
Heater (optional)
(-30…+60 ºC)*
Tolerance
±15%
Temperature range
-10…+60 ºC
Input frequency
50…60 Hz
Enclosure IP protection
IP54
Output Voltage
= input voltage
Socket IP Protection
IP44
Maximum consumption
7,2Kw
Box dimensions
350x442x125 mm
Maximum current output
32A
Weight
6Kg
Socket
Type II VDE-AR-E
2623-2-2 according
IEC62196-2
Anchor
4 points wall mount
Charge System
MODE 3 (IEC 61851)
Enclosure
ABS
RFID reader
ISO 14443A
RFID frequency
13,56Mhz
Energy meter
Integrated meter
Communications
10/100 Base-T
IEEE802.3u
Software Update
Via web
This is a quick WBM-PIP guide.
Before performing anymaintenance, modification, connection, repair,
etc.,disconnectthe devicefrom the power supply. When you suspect
a malfunction of the equipment or protection the equipment should
beimmediately disconnected from the powersupply.
STANDARDS
EN 61851-1: 2001 PARTE 1, IEC 61000, IEC 60884-1, IEC 60364-4-41, IEC 61010, IEC 61008-1, IEC
60529,UNE-EN55011, UNE-EN62196-1, UNE-EN61851-1, UNE-EN61851-21, UNE-EN61851-22
APT CONTROLS LTD. –The Power House, Chantry Place, Headstone Lane,
Harrow, Middlesex, HA3 6NY
Tel.: +44 (o)20 8421 2411 ; Fax.: +44 (o)2084213951
Web: www.aptcontrols-group.co.uk –E-mail: [e-mail]

WBM-PIP - INSTALLATION QUICK GUIDE
OPERATIONAL CHECK
Bellow table shows Wall Box beacon status.
STATE
Beacon
Color
Plug
available
Green
Starting
charge
Yellow
Charging
Blue
Fault
Red
INSTRUCTIONS FOR USE
UNIT DIMENSIONS
Remove 6
screws from the
cover to access
inside the units.
2
3
4
X1 Supplied
Protect the contactor when
you drill the unit. Place the
cable glands supplied.
8
5
1
Mark 4 holes taking into account the
above measurements.
Place on a flat surface.
SINGLE-PHASE ELECTRICAL WIRING AND CONNECTION WARNINGS
6
-Connect to the 230V AC single-phase as shown.
-It is important to provide the necessary electrical
protections between origin and the unit (electrical
protection not supplied).
-
MODE 3
32A Protection
-Connect unit to a power supply with
32A protection.
-It is recommended to introduce the
cables into the bottom of the right unit.
4.STEP BY STEP INSTALATION GUIDE
Top view
Bottom view
7
1. Present RFID Card.
2. Connect EV to plug.
3. WallBox start charging.
1. Present RFID Card.
2. WallBox will Stop
3. Unplug
Start Charging
Finish Charging
N
(Blue)
GROUND
L1
(Black)
Current
Cable section
32A
6mm2
XLPE or EPR recommended cable
