APW Wyott XTRM-1 120V User manual

PRODUCT: QUANTITY: ITEM
Models: ¨XTRM-1 120V ¨XTRM-1 208V ¨XTRM-1 240V ¨XTRM-1 230V
Designed Smart
Built Solid
APW Wyott Design Features
X*treme™-1
Radiant Conveyor Toaster
APW Wyott Foodservice Equipment Company · 729 Third Ave., Dallas, TX 75226
[phone] · [phone] · Fax [phone] · www.apwwyott.com · [email protected]
Rev. 9/26/2008
X*TREME-1 ™RADIANT CONVEYOR
Developed for high output in tight spaces!
• The X*treme™ -1 generates up to 350 slices of toast per hour.
• Designed to fit into tight space areas on counters.
• Toasters have extended super feeder and warming area to
allow for high volume production.
• Unique warming area keeps toast at the perfect
temperature until you are ready to serve.
Maximum Versatility!
• A variable speed control for the conveyor produces
optimum results in toasting color and texture.
• Able to handle a variety of breads, bagels or muffins.
• Power saver switch allows the operator to save 50% of the
energy in between meal occasions.
Safest Toaster in the Industry!
• The only toaster that protects your employees with “Cool
Touch” exteriors…both sides and top surfaces.
• “Hand safe” front protection shield that guards against
burns as employees and customers reach for toast.
Easy to Maintain and Service!
• Conveyors and crumb trays are easily accessible and
simple to clean.
• Removable Side panel allows easy access for service.
• Handles on sides allow unit to be carried easier.
Built to Last
• Stainless Steel construction protects against kitchen wear
and tear and rust.
• Metal sheathed heating elements offer enhanced durability
and consumer safety vs. quartz tube heating elements.
Reliability backed by APW Wyott’s Warranty
• All APW Wyott toasters are backed by a 1-year parts and
labor warranty, including on-site service calls within 50 miles
of authorized service technicians.
• Certified by the following agencies:
• Stainless steel housing with painted aluminum
front corners
• Small footprint (15 3/64” x 16 3/4”) fits into tight counter
space.
• Insulated and air cooled
• Self-dispensing bread drawer slides forward for removal
of product
• Chrome coated wire feeder
• Power saver switch reduces energy consumption by 50%
• Side handles
• Removable reflector tray
• Variable speed control
• One inch adjustable legs
See reverse side for product specifications.

X*treme™-1
Radiant Conveyor Toaster
PRODUCT: QUANTITY: ITEM #:
Models: ¨XTRM-1 120V ¨XTRM-1 208V ¨XTRM-1 240V ¨XTRM-1 230V
APW Wyott Foodservice Equipment Company · 729 Third Ave., Dallas, TX 75226
[phone] · [phone] · Fax [phone] · www.apwwyott.com· [email protected]
Rev. 9/26/2008
#1718
Toasters are constructed of stainless steel and aluminum material. Range of belt speeds should be
45 to 75 seconds. Front corners and front conveyor guard should be painted. Toasters furnished with
1” adjustable legs. Infrared metal sheathed radiant heaters and on/off heat switch for heat control are
standard. Power saver switch will be supplied that reduces energy by 50%. Product opening is 1 1/2”,
motors are permanently lubricated. Units are UL listed, UL Sanitation, and Canadian UL approved.
PRODUCT SPECIFICATIONS
Construction:
Stainless steel housing augmented by front painted
aluminum corners. Metal sheathed heating elements.
MIrror polished stainless steel crumb tray. Polycarbonate
handles on sides. Stainless steel front wire guard and “cool
to the touch” protective shield. High temperature insulation
protects control panel and exteriors.
Electrical Information:
Each unit is equipped with at least a 39”, three wire
grounded power cord which terminates with a standard
three-pronged male plug. The U.S. 120V unit utilizes a
NEMA 5-15P plug and the Canadian 120V unit utilizes a
5-20P plug. The 208V, 240V, and 230V all use a
NEMA 6-20P.
Electrical Specifications:
X*TREME-1 120V: 120V, 1725W, 14.4 amps
X*TREME-1 208V: 208V, 1725W, 8.2 amps
X*TREME-1 240V: 240V, 1725W, 7.2 amps
X*TREME-1 230V: 230V, 1725W, 7.5 amps
Capacity:
Up to 350 pieces per hour.
Overall Dimensions:
13 1/4”H x 15 3/64”W x 17 3/16”D (16 3/4” w/o plug)
(33.66cm x 38.21cm x 43.66cm)
Shipping:
35 lbs (16 kg)
Freight Class 100
FOB: Dallas, TX
Consultant Specifications
*APW Wyott reserves the right to modify specifications
or discontinue models without incurring obligation.
18.015
15.191
10.5 OPENING
12.223
1.00
13.837
16.749
2.62
2.57
6.939
