Arbor Technology FPC-3130 User manual

FPC-3130/3130V
Robust Box PC with
Intel®Atom™ D2550 Platform
User’s Manual
Version 1.1
2014.11
P/N: 4012313000110P

- 2 -
This page is intentionally left blank.

- III -
Revision History
Version Release Time Description
1.0 June 2012 Initial release
1.1 November 2014
The computer newly features a JACC1 Jumper for
automation and vehicle power mode control.
This gives rise to the following changes in this
manual:
2.1. Board Layout
2.2.2. Jumper Setting JACC1 description
added
3.7 Wiring the DC-Input Power Source divided
into Vehicle and Automation power mode
2.2.2. Jumper Setting SW1 & SW2 pin
conguration updated
The BIOS is updated and gives rise to the following
changes in this manual:
RS485 AutoFlow description added to 5.2.5
Super IO Configuration
5.2.1 ACPI Settings updated
5.3.2 South Bridge TPT section updaged

- IV -
This page is intentionally left blank.

- V -
Index
Contents
Revision History ......................................................................III
Chapter 1 - General Information..............................................1
1.1 Introduction................................................................2
1.2 Packing List................................................................3
1.3 Ordering Information.................................................3
1.4 The Installation Paths of CD Driver..........................4
1.5 Specications ............................................................5
1.6 Dimensions ................................................................7
1.7 Locating Controls and Connectors..........................8
Chapter 2 - The Engine of FPC-3130/3130V ...........................9
2.1. Board Layout...........................................................10
2.2. Jumpers and Connectors ......................................11
2.2.1. Jumpers & Connectors List................................ 11
2.2.2. Jumper Setting.....................................................12
2.2.3. Pin Assignments for Connectors .......................17
Chapter 3 - Installation and Maintenance.............................23
3.1 Memory, Mini-card & HDD Installation...................24
3.1.1 Removing Top Cover............................................24
3.1.2 Installing Memory Module....................................25
3.1.3 Installing Mini-card (optional)..............................26
3.1.4 Installing Hard Disk Drive ....................................29
3.2 How to Access CFast/SIM Card..............................30
3.3 Wall Mounting (optional).........................................31
3.4 VESA Mounting (Optional)......................................32
3.5 DIN Rail Mounting (optional) ..................................34
3.5.1 Face-Left/Right DIN Rail Mounting......................35
3.5.2 Face-Up/Down DIN Rail Mounting.......................36
3.5.3 Removing the Box PC from the DIN Rail ............37
3.6 Grounding the Box PC ............................................37
3.7 Wiring the DC-Input Power Source........................38
3.7.1 Vehicle Power Mode for FPC-3130V....................38
3.7.2 Automation Power Mode for FPC-3130...............39
Chapter 4 - Driver & AP...................................................................41

- VI -
Index
4.1 Prior to Installation..................................................42
4.2 Drivers ......................................................................43
4.2.1. CHIPSET ................................................................43
4.2.2. VGA ........................................................................46
4.2.3. Audio......................................................................50
4.2.4. LAN ........................................................................54
Chapter 5 - BIOS.....................................................................57
5.1 BIOS Main Setup......................................................58
5.2 Advanced Settings ..................................................59
5.2.1 ACPI Settings ........................................................60
5.2.2 CPU Conguration................................................61
5.2.3 IDE Conguration .................................................62
5.2.4 USB Conguration................................................63
5.2.5 Super IO Conguration ........................................64
5.2.6 H/W Monitor...........................................................65
5.3 Chipset Settings .......................................................66
5.3.1 Host Bridge ...........................................................66
5.3.2 South Bridge .........................................................68
5.4 Boot Settings ...........................................................71
5.5 Security.....................................................................72
5.6 Save & Exit ...............................................................73
Appendix .................................................................................75
Watchdog Timer (WDT) Setting.....................................76

- i -
Copyright Notice
All Rights Reserved.
The information in this document is subject to change without prior notice in
order to improve the reliability, design and function. It does not represent a
commitment on the part of the manufacturer.
Under no circumstances will the manufacturer be liable for any direct, indirect,
special, incidental, or consequential damages arising from the use or inability
to use the product or documentation, even if advised of the possibility of such
damages.
This document contains proprietary information protected by copyright. All
rights are reserved. No part of this document may be reproduced by any me-
chanical, electronic, or other means in any form without prior written permis-
sion of the manufacturer.
Declaration of Conformity
CE
The CE symbol on your product indicates that it is in compliance with the di-
rectives of the Union European (EU). A Certicate of Compliance is available
by contacting Technical Support.
This product has passed the CE test for environmental specications when
shielded cables are used for external wiring. We recommend the use of
shielded cables. This kind of cable is available from ARBOR. Please contact
your local supplier for ordering information.
This product has passed the CE test for environmental specications when
shielded cables are used for external wiring. We recommend the use of
shielded cables. This kind of cable is available from ARBOR. Please contact
your local supplier for ordering information.
FCC Class B
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions:
(1)This device may not cause harmful interference, and
(2)This device must accept any interference received, including interference
that may cause undesired operation.
NOTE:
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. How-

- ii -
ever, there is no guarantee that interference will not occur in a particular instal-
lation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the fol-
lowing measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
RoHS
ARBOR Technology Corp. certies that all components in its products are in
compliance and conform to the European Union’s Restriction of Use of Haz-
ardous Substances in Electrical and Electronic Equipment (RoHS) Directive
2002/95/EC.
The above mentioned directive was published on 2/13/2003. The main pur-
pose of the directive is to prohibit the use of lead, mercury, cadmium, hexava-
lent chromium, polybrominated biphenyls (PBB), and polybrominated diphe-
nyl ethers (PBDE) in electrical and electronic products. Member states of the
EU are to enforce by 7/1/2006.
ARBOR Technology Corp. hereby states that the listed products do not con-
tain unintentional additions of lead, mercury, hex chrome, PBB or PBDB that
exceed a maximum concentration value of 0.1% by weight or for cadmium
exceed 0.01% by weight, per homogenous material. Homogenous material
is dened as a substance or mixture of substances with uniform composition
(such as solders, resins, plating, etc.). Lead-free solder is used for all termina-
tions (Sn(96-96.5%), Ag(3.0-3.5%) and Cu(0.5%)).
SVHC / REACH
To minimize the environmental impact and take more responsibility to the
earth we live, Arbor hereby conrms all products comply with the restriction of
SVHC (Substances of Very High Concern) in (EC) 1907/2006 (REACH --Reg-
istration, Evaluation, Authorization, and Restriction of Chemicals) regulated
by the European Union.
All substances listed in SVHC < 0.1 % by weight (1000 ppm)

- iii -
Important Safety Instructions
Read these safety instructions carefully.
1. Read all cautions and warnings on the equipment.
2. Place this equipment on a reliable surface when installing. Dropping it or
letting it fall may cause damage
3. Make sure the correct voltage is connected to the equipment.
4. For pluggable equipment, the socket outlet should be near the equipment
and should be easily accessible.
5. Keep this equipment away from humidity.
6. Theopenings ontheenclosure areforair convection andprotectthe equipment
from overheating. DO NOT COVER THE OPENINGS.
7. Position the power cord so that people cannot step on it. Do not place
anything over the power cord.
8. Never pour any liquid into opening. This may cause re or electrical shock.
9. Never open the equipment. For safety reasons, the equipment should be
opened only by qualied service personnel.
10. If one of the following situations arises, get the equipment checked by
service personnel:
a. The power cord or plug is damaged.
b. Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
d. The equipment does not work well, or you cannot get it to work according
to the user’s manual.
e. The equipment has been dropped or damaged.
f. The equipment has obvious signs of breakage.
11. Keep this User’s Manual for later reference.
About This User’s Manual
This User’s Manual is intended for experienced users and integrators with
hardware knowledge of personal computers. If you are not sure about any
description in this User’s Manual, please consult your vendor before further
handling.
Warning
The Box PC and its components contain very delicately Integrated Circuits (IC).
To protect the Box PC and its components against damage caused by static
electricity, you should always follow the precautions below when handling it:
1. Disconnect your Box PC from the power source when you want to work on
the inside.

- iv -
2. Use a grounded wrist strap when handling computer components.
3. Place components on a grounded antistatic pad or on the bag that came
with the Box PC, whenever components are separated from the system.
Replacing the Lithium Battery
Incorrect replacement of the lithium battery may lead to a risk of explosion.
The lithium battery must be replaced with an identical battery or a battery type
recommended by the manufacturer.
Do not throw lithium batteries into the trashcan. It must be disposed of in
accordance with local regulations concerning special waste.
Technical Support
If you have any technical difculties, please consult the user’s manual rst at:
ftp://ftp.arbor.com.tw/pub/manual
Please do not hesitate to call or e-mail our customer service when you still cannot
nd out the answer.
http://www.arbor.com.tw
E-mail:[e-mail]
Warranty
This product is warranted to be in good working order for a period of one year
from the date of purchase. Should this product fail to be in good working order
at any time during this period, we will, at our option, replace or repair it at no
additional charge except as set forth in the following terms. This warranty does
not apply to products damaged by misuse, modications, accident or disaster.
Vendor assumes no liability for any damages, lost prots, lost savings or any
other incidental or consequential damage resulting from the use, misuse of, or
inability to use this product. Vendor will not be liable for any claim made by any
other related party.
Vendors disclaim all other warranties, either expressed or implied, including but
not limited to implied warranties of merchantability and tness for a particular
purpose, with respect to the hardware, the accompanying product’s manual(s)
and written materials, and any accompanying hardware. This limited warranty
gives you specic legal rights.
Return authorization must be obtained from the vendor before returned
merchandise will be accepted. Authorization can be obtained by calling or faxing
the vendor and requesting a Return Merchandise Authorization (RMA) number.
Returned goods should always be accompanied by a clear problem description.

- 1 -
1Chapter 1
General Information

- 2 -
General Information
1.1 Introduction
The Box PC, FPC-3130/3130V is targeted at many different application elds.
By adopting it, you can pinpoint specic markets, such as Thin Client, KIOSK,
information booth, GSM Server, environment-critical and space-critical
applications.
• All-In-One Platform
The CPU, DRAM and even software are integrated to provide a plug-
and-play machine.
• Compact-sized
The kernel of FPC-3130/3130V is FMB-i2505, which is a non-standard
form factor embedded board. The whole system consumes only a few
space.
• Fanless and Modular CPU Board
By using a low power processor, the system does not have to rely on
fans, which are often unreliable and cause dust to circulate inside the
equipment. The modular design facilitates maintenance or possible
upgrades on the CPU board. Modular Box PC can be easily modied
to t many different applications according to customers' requests.
• Powerful Communication Capability
The FPC-3130/3130V provides COM, Ethernet, USB, Mini Card slot,
CFast, SIM and DVI.
• Numerous Display/Video Output
Integrated with Intel® HD Graphics core, FPC-3130/3130V improves
graphics and 3D rendering performance and supports display/video
output options includes DVI-I and DVI-D.
• Advanced Storage Solution
FPC-3130/3130V comes with SD (Secure Digital) slot, which offers
a better, faster and more cost-effective expansibilities for various
applications.
• Trustworthy
The onboard Watchdog Timer can invoke an NMI or system RESET
when your application loses control over the system.

- 3 -
General Information
1.2 Packing List
After opening the package, carefully inspect the contents. If any of the items
is missing or appears damaged, please contact your local dealer or distributor.
The package should contain the following items:
1 x FPC-3130/3130V Box PC
1 x Driver CD
1 x User’s Manual
The following items are normally optional, but some vendors may include
them as a standard package, or some vendors may not carry all the items.
Optional Accessories
PAC-B065W
65W AC/DC adapter kit
DRK-001
Din rail kit of FPC series
WMK-3100
Wall-mount kit
VMK-3100
VESA mount kit
1.3 Ordering Information
FPC-3130V Vehicle BOX Bare-bone system w/o storage device
FPC-3130 Automation Bare-bone system w/o storage device

- 4 -
General Information
1.4 The Installation Paths of CD Driver
Windows 7-32bit
Driver Path
CHIPSET \Chipset\Win7_x86
VGA \VGA\Win7_x86
LAN \LAN\Install_Win7_7048_09162011
AUDIO \Driver\Audio ALC662\Win 7(32,64 bits) Driver_R2.66
Note: FPC-3130/3130V only supports Windows 7 32bit.
CBL-7100-COM
4 x COM ports converter cable
Optional Conguration (Congure to Order Service)
SSD-25040
Intel®2.5” 40GB SATAII SSD kit
2GB SO-DIMM
DDR3-1333 2GB SDRAM
4GB SO-DIMM
DDR3-1333 4GB SDRAM
WIFI-AT2300
Atheros AR9462 WiFi module w/ 20cm internal
wiring
HSPA-SI1400
HSUPA 3.75G module kit & internal wiring
ANT-D11
1 x WiFi Dual-band 2.4G/5G antenna
ANT-H11
1 x 2dBi HSUPA antenna

- 5 -
General Information
System Kernel
Processor Soldered onboard Intel®Atom™ D2550 1.86GHz
processor
BIOS AMI Flash BIOS
Chipset Intel®NM10 PCH
Graphics Integrated Intel®GMA 3650
System Memory 1 x 204-pin DDR3 SO-DIMM socket, supporting
800/1066MHz SDRAM up to 4GB
Serial ATA 1 x Serial ATA port with 300MB/s HDD transfer rate
Ethernet Controller 2 x Realtek 8111 Gigabit Ethernet controllers
Watchdog Timer 1 ~ 255 levels reset
I/O Ports
Serial Port 2 x RS-232 ports & 2 x RS-232/422/485 selectable
ports with DB-44 pin connector
Expansion Bus
• 1 x Mini-card slot interconnected with SIM card
socket for optional WiFi or HSUPA module
• 1 x SIM card socket
USB Port 6 x USB 2.0 ports
LAN 2 x RJ-45 ports for Gigabit Ethernet
Video Port • 1 x DVI-I female connector for Digital Video output
• 1 x DVI-D female connector for Digital Video output
Audio Mic-in/Line-out/Line-out (6W pre-amplied)
Storage
Type • 1 x 2.5” drive bay for HDD/SSD
• 1 x CFast socket
Qualication
FCC Class B certied
CE Certied
1.5 Specications

- 6 -
General Information
Environmental
Operating Temp. -20 ~ 70°C (-4 ~ 158°F), ambient w/ air ow
Storage Temp. -40 ~85 °C (-40 ~ 185°F)
Operating
Humidity 10 ~ 95% @ 70oC (non-condensing)
Vibration 3 Grms/5 ~ 500 Hz/random operation
Shock & Crash • Operating 40G (11ms), Non-operating 80G with
CFast/SSD
Mechanical
Construction Aluminum alloy
Mounting Wall-mount/VESA-mount/Din rail mounting
Weight 1.89 kg (4.16 lb) (Bare-bone)
Dimensions
(W x D x H)
252 x 199 x 33 mm (9.92” x 7.83” x 1.3”)
Power Requirement
Power Input DC 10~28V input (w/ 1 x 3-pin DC input terminal
block)
Power
Consumption 30W (Max.)
OS Support
Windows XP Embedded / Windows XP Professional
/ Windows Embedded 7 Professional / Windows
Embedded 7 Standard

- 7 -
General Information
1.6 Dimensions
252
199
Unit: mm
33
SCALE 1:1

- 8 -
General Information
1.7 Locating Controls and Connectors
Please take a moment to identify those controls and connectors shown in the
following gures.
Front Panel
Rear Panel
Front-right View
COM1-4 USB Ports
LAN Ports
DC-IN DVI-D Line-out DVI-I
CFast & SIM Slots
MIC-in
Switch
HDD
Indicator
AntennaAntenna
USB Ports
Earphone-out

- 9 -
2Chapter 2
The Engine of
FPC-3130/3130V

- 10 -
The Engine of FPC-3130/3130V
2.1. Board Layout
The engine of FPC-3130/3130V is FMB-i2505.
16
712
DIPON
654321
916
ON
87654321
916
ON
87654321
1 6
1 1
1
1
1
1
ON
4
3
21
1
23
4
ON
1
23
41
23
4
1
23
4
ON
2
1
72 74
71 73
204
203
1
2
1715
1816
51
52
MH1 MH2
18
S1
S7
PC1
PC17
P15P1S7S1
MC1
CN2
DIMM2
USB2
PWRBT1
HDDLED
USB3
CF1
SIM1
PWRIN1DVI1 DVI2
USB1
LAN1
SATA0
SW10 SW9
SW1
JBAT1
SW2
SW4SW11 SW5SW8
JV1 JV2 JV3 JV4
JCP1
AUDIO4
AUDIO3
AUDIO2
1
JACC1
