Arbor Technology Rigid-770 Series User manual

1
Rigid-770 Series
Extreme Rugged Box Computer with Intel®
Core™i3-3120ME / i5-3610ME
User’s Manual
Version 1.1
2013.05P/N: 4016077000110P
70

- 2 -
This page is intentionally left blank.

- i -
Revision History
Version Release Time Description
1.0 2013 February The initial release for Rigid-772.
1.1 2013 May Rigid-770 is included in the user's manual. The
changes involved are:
• 1.1. The Product
• 1.3. Specifications
• 1.4. Inside the Package
• 1.5. Ordering Information
• 2.1. System Overview
• 4.1.6. Install SATA Storage Devices

- ii -
Contents
Revision History ............................................................................. i
Preface............................................................................................ v
Copyright Notice.................................................................................. v
Declaration of Conformity.................................................................... v
CE ............................................................................................... v
FCC Class A................................................................................ v
RoHS...........................................................................................vi
SVHC / REACH...........................................................................vi
Important Safety Instructions .............................................................vii
Warning.............................................................................................viii
Replacing Lithium Battery .................................................................viii
Technical Support..............................................................................viii
Warranty..............................................................................................ix
Chapter 1 - Introduction................................................................ 1
1.1. The Product.................................................................................. 2
1.2. About this Manual......................................................................... 2
1.3.Specications............................................................................... 3
1.4. Inside the Package....................................................................... 5
1.5. Ordering Information .................................................................... 6
1.5.1.Congure-to-OrderService............................................... 6
Chapter 2 - Getting Started........................................................... 7
2.1. System Overview ......................................................................... 8
2.1.1. Dimensions ....................................................................... 8
2.1.2. Take A Tour...................................................................... 10
2.2. Driver Installation Notes............................................................. 15
Chapter 3 - System Conguration ............................................. 17
3.1. Board Layout.............................................................................. 18
3.2. Jumpers, Connectors and DIP Switches.................................... 20
3.2.1. Jumpers .......................................................................... 20
3.2.2. DIP Switch SW9.............................................................. 24
3.2.3. Connectors...................................................................... 29
Chapter 4 - Installation and Maintenance.................................. 45
4.1. Install Hardware ......................................................................... 46
4.1.1. Open the Computer......................................................... 46
4.1.2. Install/uninstall Memory Modules.................................... 52
4.1.3. Install Memory Module with Heat Spreaders .................. 54
4.1.4. Install MiniCards.............................................................. 60
4.1.5. Install Internal USB Drives .............................................. 63
4.1.6. Install SATA Storage Devices.......................................... 64
4.1.7. Install PCI Express Cards ............................................... 70

- iii -
Contents
4.1.8. Install/uninstall CFast Card ............................................. 71
4.1.9. Install/uninstall SIM Card ................................................ 73
4.2. Mount the Computer .................................................................. 75
4.3. Ground the Computer ................................................................ 76
4.4. Wire DC-in Power Source.......................................................... 77
Chapter 5 - BIOS.......................................................................... 79
5.1. Main ........................................................................................... 82
5.2. Advanced ................................................................................... 83
5.2.1. ACPI Settings.................................................................. 84
5.2.2. SS RTC Wake Settings ................................................... 85
5.2.3.CPUConguration .......................................................... 86
5.2.4.SATAConguration ......................................................... 87
5.2.5.AMTConguration .......................................................... 88
5.2.6.USBConguration .......................................................... 89
5.2.7.F81866SuperIOConguration ...................................... 90
5.2.8. F81866 H/W Monitor....................................................... 93
5.2.9.CPUPPMConguration ................................................. 93
5.3. Chipset....................................................................................... 94
5.3.1.PCH-IOConguration ..................................................... 95
5.3.2.SystemAgent(SA)Conguration ................................... 96
5.4. Boot............................................................................................ 98
5.4.1. CSM Paramenters......................................................... 100
5.5. Security .................................................................................... 101
5.6. Save & Exit............................................................................... 102
Appendices ................................................................................ 103
A: Digital I/O Setting........................................................................ 104
B: Watchdog Timer (WDT) Setting.................................................. 106

- iv -
This page is intentionally left blank.

- v -
Preface
Copyright Notice
All Rights Reserved.
The information in this document is subject to change without prior notice in
order to improve the reliability, design and function. It does not represent a
commitment on the part of the manufacturer.
Under no circumstances will the manufacturer be liable for any direct, indirect,
special, incidental, or consequential damages arising from the use or inability
to use the product or documentation, even if advised of the possibility of such
damages.
This document contains proprietary information protected by copyright. All rights
are reserved. No part of this document may be reproduced by any mechanical,
electronic, or other means in any form without prior written permission of the
manufacturer.
Declaration of Conformity
CE
The CE symbol on the computer indicates that it is in compliance with the
directivesoftheUnionEuropean(EU).ACerticateofComplianceisavailable
by contacting Technical Support.
This product has passed the CE test for environmental specications when
shielded cables are used for external wiring. We recommend the use of
shielded cables. This kind of cable is available from ARBOR. Please contact
your local supplier for ordering information.
Warning
This is a class A product. In a domestic environment this product may cause
radio interference in which case the user may be required to take adequate
measures.
FCC Class A
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference
that may cause undesired operation.
Preface

- vi -
Preface
NOTE:
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user
will be required to correct the interference at his own expense.
RoHS
ARBOR Technology Corp. certies that all components in its products
are in compliance and conform to the European Union’s Restriction of Use
of Hazardous Substances in Electrical and Electronic Equipment (RoHS)
Directive 2002/95/EC.
The above mentioned directive was published on 2/13/2003. The main purpose
of the directive is to prohibit the use of lead, mercury, cadmium, hexavalent
chromium, polybrominated biphenyls (PBB), and polybrominated diphenyl
ethers (PBDE) in electrical and electronic products. Member states of the EU
are to enforce by 7/1/2006.
ARBOR Technology Corp. hereby states that the listed products do not contain
unintentional additions of lead, mercury, hex chrome, PBB or PBDB that exceed
a maximum concentration value of 0.1% by weight or for cadmium exceed
0.01%byweight,perhomogenousmaterial.Homogenousmaterialisdened
as a substance or mixture of substances with uniform composition (such as
solders, resins, plating, etc.). Lead-free solder is used for all terminations
(Sn(96-96.5%), Ag(3.0-3.5%) and Cu(0.5%)).
SVHC / REACH
To minimize the environmental impact and take more responsibility to the earth
welive,ArborherebyconrmsallproductscomplywiththerestrictionofSVHC
(Substances of Very High Concern) in (EC) 1907/2006 (REACH --Registration,
Evaluation, Authorization, and Restriction of Chemicals) regulated by the
European Union.
All substances listed in SVHC < 0.1 % by weight (1000 ppm)

- vii -
Preface
Important Safety Instructions
Read these safety instructions carefully
1. Read all cautions and warnings on the equipment.
2. Place this equipment on a reliable surface when installing. Dropping it or
letting it fall may cause damage
3. Make sure the correct voltage is connected to the equipment.
4. For pluggable equipment, the socket outlet should be near the equipment
and should be easily accessible.
5. Keep this equipment away from humidity.
6. The openings on the enclosure are for air convection and protect the
equipment from overheating. DO NOT COVER THE OPENINGS.
7. Position the power cord so that people cannot step on it. Do not place
anything over the power cord.
8. Neverpouranyliquidintoopening.Thismaycausereorelectricalshock.
9. Never open the equipment. For safety reasons, the equipment should be
openedonlybyqualiedservicepersonnel.
10. If one of the following situations arises, get the equipment checked by
service personnel:
a. The power cord or plug is damaged.
b. Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
d. The equipment does not work well, or you cannot get it to work
according to the user’s manual.
e. The equipment has been dropped or damaged.
f. The equipment has obvious signs of breakage.
11. Keep this User’s Manual for later reference.

- viii -
Preface
Warning
The Box PC and its components contain very delicately Integrated Circuits (IC).
To protect the Box PC and its components against damage caused by static
electricity, you should always follow the precautions below when handling it:
1. Disconnect your Box PC from the power source when you want to work
on the inside.
2. Use a grounded wrist strap when handling computer components.
3. Place components on a grounded antistatic pad or on the bag that came
with the Box PC, whenever components are separated from the system.
Replacing Lithium Battery
Incorrect replacement of the lithium battery may lead to a risk of explosion.
The lithium battery must be replaced with an identical battery or a battery type
recommended by the manufacturer.
Do not throw lithium batteries into the trash can. It must be disposed of in
accordance with local regulations concerning special waste.
Technical Support
Ifyouhaveanytechnicaldifculties,pleaseconsulttheuser’smanualrstat:
ftp://ftp.arbor.com.tw/pub/manual
Please do not hesitate to call or e-mail our customer service when you still
cannotndouttheanswer.
http://www.arbor.com.tw
E-mail:[e-mail]

- ix -
Preface
Warranty
This product is warranted to be in good working order for a period of one year
from the date of purchase. Should this product fail to be in good working order
at any time during this period, we will, at our option, replace or repair it at no
additional charge except as set forth in the following terms. This warranty does
notapplytoproductsdamagedbymisuse,modications,accidentordisaster.
Vendorassumesnoliabilityforanydamages,lostprots,lostsavingsorany
other incidental or consequential damage resulting from the use, misuse of, or
inability to use this product. Vendor will not be liable for any claim made by any
other related party.
Vendors disclaim all other warranties, either expressed or implied, including but
notlimitedtoimpliedwarrantiesofmerchantabilityandtnessforaparticular
purpose, with respect to the hardware, the accompanying product’s manual(s)
and written materials, and any accompanying hardware. This limited warranty
givesyouspeciclegalrights.
Return authorization must be obtained from the vendor before returned
merchandise will be accepted. Authorization can be obtained by calling or
faxing the vendor and requesting a Return Merchandise Authorization (RMA)
number. Returned goods should always be accompanied by a clear problem
description.

- x -
This page is intentionally left blank.

- 1 -
1Chapter 1
Introduction
Chapter 1 - Introduction

- 2 -
Introduction
1.1. The Product
The computer is ARBOR’s new generation of
extreme rugged box system based on Intel®
Core™i3-3120ME / i5-3610ME with chipset
Intel®QM77 to deliver low power consumption,
high performance and wide temperature
tolerance
Integrated with Intel®HD 4000 graphics, the
computer supports DirectX 11 to deliver superb video and audio. The RAID-
capable computer with dual display ports (DVI-I and DVI-D) sufces for the
sophisticated applications such as security surveillance.
The computer features the rich I/O ports including six USB 2.0 and four USB
3.0 ports, two PCIe buses, four COM ports for RS232/422/485 protocols,
three LAN ports, one SIM card socket and one MiniCard socket for powerful
networking and data connections.
The modularized mechanical design makes the computer easy-to-install
and easy-to-maintain, and the simple, sturdy and rugged design makes the
computer ideal for almost every industrial application. This computer is a
powerful and reliable system for your infrastructure to deliver uncompromised
control over your work network in harsh environment.
1.2. About this Manual
This manual is meant for the experienced users and integrators with hardware
knowledge of personal computers. If you are not sure about the description
herein, consult your vendor before further handling.
We recommend that you keep one copy of this manual for the quick reference
for any necessary maintenance in the future. Thank you for choosing ARBOR
products.

- 3 -
Introduction
1.3. Specications
System Kernel
Processor Intel®Core™i3-3120ME (by default)
Intel®Core™ i5-3610ME (dual-core) (rPGA988B) (by OEM request)
BIOS AMI Flash BIOS
Chipset Intel®QM77
Graphics Integrated Intel®HD 4000
System Memory
2 x 204-pin DDR3 SO-DIMM sockets supporting up to 16GB at
1333/1600 MHz
4GB wide-temperature DDR3 memory module installed (as
default)
Serial ATA 2 x Serial ATA ports for RAID
2 x eSATA
Ethernet Controller
2 x Intel®WG82583V Gigabit Ethernet controllers
1 x Intel®WG82579LM Gigabit Ethernet controller, supporting
iAMT
Watchdog Timer 1 ~ 255 levels reset
I/O Ports
Serial Port
1 x DB-44 female connector
COM1/2 are RS-232 w/ 5v power output
COM3/4 are RS-232/422/485 selectable, w/ 2.5 kv isolation
protection.
*Selectable Port 1 x DB25 connector for 1 x DIO (8 x IN, 8 x OUT) port or 1 x LPT
port (Either one, DIO is the default, but changeable to LPT)
USB Port
6 x USB 2.0 ports, 4 x USB 3.0/2.0 ports
2 x internal USB dongle for software license key (congure-to-
order only)
LAN Port 3 x RJ-45 ports for Gigabit Ethernet
Video Port 1 x DVI-I female connector for digital/analog video output
1 x DVI-D female connector for digital video output
Audio Mic-in/Line-out
Expansion Bus
1 x MiniCard socket for optional Wi-Fi or HSUPA module
1 x SIM slot / 1 x CFast slot (both outside accessible)
• No slot expansion (for Rigid-770)
• 1 x PCIe x16 slot and 1 x PCIe x8 slot (for Rigid-772)

- 4 -
Introduction
Storage
Type 2 x 2.5” drive bays
1 x CFast slot
Qualification
Certication CE, FCC Class A
Environment
Operating Temp. -40~70°C(-40~158°F),ambiencew/airow
Storage Temp. -40 ~ 85°C (-40 ~ 185°F)
Operating Humidity 10 ~ 95% @ 70°C (non-condensing)
Vibration 3 Grms/5 ~ 500Hz/random operation w/ SSD
Shock Operating 20G (11ms); Non-operating 40G with HDD
Operating 50G (11ms); Non-operating 80G with SSD
Mechanical
Construction Aluminum alloy
Mounting Wall mounting
Weight 7 kg (15.43 lb)
Dimensions
(W x D x H) 225 x 267 x 120 mm
Power Requirement
Power Input DC 9~36V input w/ 4-pin terminal block
Power
Consumption 1.86A/19V, 36W (i3-3120ME)

- 5 -
Introduction
1.4. Inside the Package
Upon opening the package, carefully inspect the contents. If any of the items
is missing or appears damaged, contact your local dealer or distributor. The
package should contain the following items:
or
1 x Rigid-770 Series
Extreme Rugged Box
System
1 x Driver CD
1 x User’s Manual
1 x 120W AC/DC adapter kit
PAC-B120W-FSP
1 x Wall-Mount Kit
WMK-7000
1 x COM converter cable
CBL-7100-COM

- 6 -
Introduction
1.5. Ordering Information
Rigid-770 Fanless embedded controller
Rigid-772 Fanless embedded controller, w/ PCIe x16 slot and PCIe x8 slot
1.5.1. Congure-to-Order Service
Make the computer more tailored to your needs by selecting one or more
components from the list below to be fabricated to the computer.
SSD-25040
Intel®2.5” 40GB SATAII SSD kit
HSPA-SI1400
HSUPA 3.75G module kit & internal wiring
WIFI-IN1300
Intel®Centrino® Advanced-N 6205 WiFi module w/ 20cm internal
wiring
ANT-H11
2dBi HSUPA antenna kit
ANT-D11
1 x WiFi Dual-band 2.4G/5G antenna
MK-3I-4G-2
Industrial DDR3 4GB SDRAM DIMM2 kit
MK-3I-8G-2
Industrial DDR3 8GB SDRAM DIMM2 kit
UDK-7702
Internal USB dongle kit

- 7 -
2Chapter 2
Getting Started
Chapter 2 - Getting Started

- 8 -
Getting Started
2.1. System Overview
This section will give an overview of the computer.
2.1.1. Dimensions
The following illustration shows the dimensions of the computer, with the
measurements in width, depth, and height called out.
Rigid-770
Unit: mm
225.00
267.00
90.00
96.00
21.50 112.00 112.00
92.00 92.00
238.00
250.00
4.00
6.00
NUT UNC#6-32
