Archos Diamond Plus User manual

1
English
Congratulations for the purchase of an ARCHOS device!
This quick start guide helps you to start using your device properly.
If you have more questions concerning the use of your device,
•You can consult the frequently asked questions on our website:
go to http://faq.archos.com/
•You can send us a message on Facebook:
go to www.facebook.com/ARCHOS
•You can contact our After-sales department:
go to www.archos.com, click Support > After-sales support >
•You can consult the declaration of conformity:
go to www.archos.com, click Support > Downloads >
As we are often updating and improving our products, your device’s software may have
a slightly different appearance or modified functionality than presented in this Quick
Start Guide.
Welcome
ARCHOS Diamond Plus book.indd 1 24/11/2015 12:27:13

2
Package Contents
Check your product box for the following items:
-ARCHOS Diamond Plus
-Headset
-USB cable
-Charger
-Quick start guide
-Warranty Legal & Safety notices
The items supplied with your device and available accessories may vary depending on
your region or service provider. The supplied items are designed only for your device
and may not be compatible with other devices. Unapproved accessories may cause
your device to malfunction.
ARCHOS Diamond Plus book.indd 2 24/11/2015 12:27:13

3
1
2
3
4
5
6
2
6
3 4
1
5
English
Headset jack
Front camera
Phone speaker
Light sensor
Volume buttons
ON/OFF button
Description of the phone
ARCHOS Diamond Plus book.indd 3 24/11/2015 12:27:13

8
7 9
4
7
8
9
10 10
11
141312
11
12
13
14
Description of the phone
Noise reduction
Camera
Flash light
SIM card|Micro-SD tray
Camera button
Loudspeaker
Micro-USB port
Microphone
ARCHOS Diamond Plus book.indd 4 24/11/2015 12:27:14

5
English
ON/OFF: when the device is off,
long press to turn on. When the
device is on, short press to turn off
the screen and long press to display
options.
Volume +/-: press +/- to adjust the
volume. When you press the button,
notication options are displayed.
You can select the most appropriate
one.
Back: press to go back to the
previous screen.
Home: short press to return to the
homescreen, long press to access
Google Now.
Recent apps: press to display recent
apps.
Micro-USB port: plug the provided
cable to charge the device or to
connect it to a computer.
Headphone jack: connect the
provided earphones to make hand-
free calls.
Camera & Flash: take pictures or
make movies. To extend movies
duration, insert a micro-SD card.
Activate the ash option in a dark
environment and use it as a torch
through the quick settings.
Light sensor: it turns off the screen
when the device is close to your ear
during a call.
ARCHOS Diamond Plus book.indd 5 24/11/2015 12:27:14

6
Inserting SIM & Micro-SD cards
After you have unpacked your mobile phone box:
1. Remove the cover by using the provided tool that you insert in the cover
hole.
2. Place the card into the tray according to the direction shown.
3. Replace the tray in the right position and push it inside to close.
Getting started
4G/3G/2G slot 1 When inserting your SIM card or micro-SD card, make sure
to follow the illustration, otherwise you may damage the
slot or the card.
4G/3G/2G slot 2
Micro-SD card slot 2
ARCHOS Diamond Plus book.indd 6 24/11/2015 12:27:15

7
English
ARCHOS Diamond Plus book.indd 7 24/11/2015 12:27:15

8
Turning on
1. Plug the charging cable in the Micro-USB port and connect it to its
charger.
Before using your device for the rst time, charge its battery completely.
2. Press and hold the ON/OFF button to turn on the device.
The rst time you start up your ARCHOS, the installation wizard will help you
set up your device.
3. Follow the instructions.
If you have inserted a SIM card, you may need to enter a PIN code.
Beware of typing a wrong PIN code.
Tip:
Your device goes in standby mode when you do not use it for a specific period of
time. To wake up your device, press the ON/OFF button. To set the duration, go to
Settings > Display > Sleep.
Getting started
ARCHOS Diamond Plus book.indd 8 24/11/2015 12:27:15

5
4
1
2
3
9
English
On your homescreen
1.Swipe right to access Google Now
2.Press to access all your apps
3.Hold your nger
on an app
to move it right and create a new
homescreen.
4.Say “Ok Google” to launch the search page.
5.Touch and pull down the status bar to display it. Touch again
the bar to reveal the quick settings.
ARCHOS Diamond Plus book.indd 9 24/11/2015 12:27:17

10
5
4
3
Mobile data connection
If your mobile phone subscription includes a mobile data option, you should
be connected to the Internet without any further setup. The ARCHOS will
only have signal if you are in an area covered by your provider’s 4G or 3G
network.
Mobile Data & WiFi connection
Activating/Deactivating the mobile data
1.Touch and pull down the status bar to display it.
2.Touch again the bar to reveal the quick settings.
3.Select the Settings icon.
4.In Wireless & networks, select Data usage, then the SIM
card tab.
5.Slide the Mobile data switch to turn on/off.
