Arec SpacesGate SG-1 User manual

AREC Inc.© All Rights Reserved 2018. l www.spacesgate.com
All information contained in this document is Proprietary
SG-1
Media Collaboration System
Quick Installation Guide English

www.spacesgate.com
SG-1 Quick Installation Guide
FCC
Federal Communication Commission interference statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of
the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the
separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help.
RF Exposure Warning
The equipment complies with RF exposure limits set forth for an uncontrolled environment. The antenna(s) used for this
transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
You are cautioned that changes or modications not expressly approved by the party responsible for compliance could void
your authority to operate the equipment.
FCC Caution
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference and
(2) this device must accept any interference received, including interference that may cause undesired operation
This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your
body.
Notice: Any changes or modifications not expressly approved by the party responsible for compliance could void your
authority to operate the equipment.
CE
Hereby, AREC Inc., declares that this Media Station is in compliance with the essential requirements and other relevant
provisions of Directive 2014/53/EU.
01
CB
CAUTION
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
– the ventilation should not be impeded by covering the ventilation openings with items, such as newspapers,table-cloths,
curtains, etc.:
– no naked flame sources, such as lighted candles, should be placed on the apparatus;
– attention should be drawn to the environmental aspects of battery disposal;
– the use of apparatus in tropical climates.
the instructions for use shall state that the apparatus shall not be exposed to dripping or splashing and that no objects lled
with liquids, such as vases, shall be placed on the apparatus.

www.spacesgate.com
SG-1 Quick Installation Guide
02
Specications
Based on the new concept of Team Communication and Collaborative Spaces, SpacesGate SG-1, a new and innovative Media
Collaboration System, changes the way we engage in a project meeting or remote training. SG-1 system can bring people
together from different places for visual communication, presentations, knowledge sharing and collaboration in real-time,
making it is easy to solve the business challenges agilely and effectively.
Product Name Media Station
Model Name SG-1
Dimension 354mm(L) x 188.2mm(W) x 46mm(H)
Weight 1710g
Power Requirement 12V/2A
Power Consumption (Max.) 24W (Max.)
Operating Temperature / Humidity 0ºC ~ 40ºC / 90%
Maximum normal load description
Insert 1 IP CAM to LAN port and insert 2 video signals (either HDMI or VGA input).
Using external USB flash to record the transcoded video/audio. And output the
transcoded video/audio to both HDMI and VGA port.
Introduction
Package Contents
SG-1
Quick Installation Guide Power Adapter
Terminal Block
AREC Inc.© All Rights Reserved 2018. l www.spacesgate.com
All information contained in this document is Proprietary
SG-1
Media Collaboration System

www.spacesgate.com
SG-1 Quick Installation Guide
03
No. Name Brief introduction
1Record function keys Control the Record, Pause, Stop function
2Power Power on/off the device
3Front USB port 1. For external USB storage device*
2. Firmware update through USB disk
4Power port 12V / 2A
5Video input VGA / HDMI input source for PC [ ]
6Video input VGA / HDMI input source for camera [ ]
7Video output VGA / HDMI preview output
8Audio input Line audio input
9Audio input Mic audio input
10 Audio output Line audio output
11 Back USB port 1. USB interface for camera control over RS-232
2. Support HID Protocol for Interactive Projector
12 Network port RJ-45 Ethernet connector for network connection
13 Network camera input RJ-45 Ethernet connector for network camera input source
14 Setting port RJ-45 Ethernet connector for device conguration and control
15 RS-232 Captive screw connector for control over RS-232
16 Reset button Restoring devices to its factory default state
Product Appearance
NOTE: The SG-1 can detect and record to USB storage devices using FAT32, NTFS le systems.
54
1 2 3
Front
6
11
1512 13 14 7 10
9
8 16
Back

www.spacesgate.com
SG-1 Quick Installation Guide
04
Connection
Power
AREC
Network Camera
document cam
notebook
DV
amplier
networkRS-232
Audio output LAN
LAN
Video output VGA / HDMI
Video input VGA / HDMI
Audio input
USB
RS-232
USB
SpeakerInteractive projector
microphone Projector / mouse
Mic audio input
Setting PC

www.spacesgate.com
SG-1 Quick Installation Guide
05
Front Panel Buttons and Indicators
Button Display method of indicator Product status
Record / Pause / Stop
Record button glows red
continuously. Recording in progress.
Record button flashes red rapidly. Recording is paused.
Record button flashes red slowly. Recording is being nalized.
Power
Solid red. Device is powered, yet not booted up.
Green and red light flash alternately. Device is booting up.
Solid green. Boot up completed.
Fast flashing red. Device is shutting down.
Fast flashing green. Firmware updating.
Slow flashing red. Fan is abnormal.
Getting start
Connect PC to the setting port of SG-1 with standard network cable.
Open up the browser, and input 192.168.11.254 in the browser page.
Connect mobile device to SG-1, your device is added the segment
and the segment is consistent with the IP address of the SG-1. Get IP
address from About option in Setup item of the host output interface
main menu and input it in the Browser page.
Log in Administrator with default username admin and password
admin, then entering the system Administrator webpages.

www.spacesgate.com
SG-1 Quick Installation Guide
06
Setup Video inputs
The SG-1 is capable to process up to one video input. The name of the input is user congurable; by default is Cam 1.
Signal type can be selected from Network Camera, Encoder or Video port.
PTZ control : The SG-1 is highly integrated with PTZ cameras and provides two control methods, Over IP or via Serial port
and Auto-Tracking Mount.
Video port Select Video source: The SG-1 provides VGA and HDMI input options for video port.
Network Camera
Select IP address: Select from the camera ip address drop list of those available.
Note: A login authentication with the camera might be required. See Media I/O\ Camera manager for
more details.
Encoder Select Protocol: The available options are UDP, RTP, RTMP, or RTSP. Enter the primary and secondary
URL/port number.
Serial port Select this option when the appointed camera uses RS-232 PTZ control protocol. Then complete the
Serial port selection from drop list Port 1~4. See Media I/O\ PTZ control port for more details.
Over IP The option is available when the specied signal type is a network camera. Select this option if that
camera supports networking PTZ control.
Auto-Tracking
Mount
Select IP address: Select from the TP-100 ip address drop list of those available.
Select Tracking mode: off / Auto-Tracking / Auto-Tracking (pan only), the default is the Auto-
Tracking.
Note: A login authentication with the TP-100 might be required. See Media I/O\ Network device
manager for more details.

www.spacesgate.com
SG-1 Quick Installation Guide
07
Setup Network device manager
The system automatically scans and lists the network cameras and Auto-Tracking Mount connected to the SG-1 once
entering the [ Network device manager ] page. You may click Refresh button to scan again. Click Login button and the login
authentication dialog pop out.
Enter the username and password of the camera or Auto-Tracking Mount to complete the authentication. Take AREC
network camera for example,enter the default username and password admin/ admin. The status then changes to OK, which
indicates it is available for video input selection.
Note : If you fail to nd your camera by clicking on “Refresh”, please select “Signal type” to “Encoder” in the “Video Inputs” and ll in your camera
information.

www.spacesgate.com
SG-1 Quick Installation Guide
08
Setup Audio
Input volume control- Tune the recorded volume from each audio input. Congurable range of sound input is 0-125. The
nearby volume meter indicates the encoded audio current volume.
Output volume control - Adjust the audio output volume. Set Audio output loop through on/ off.
Adjust volume and select the audio input source.

www.spacesgate.com
SG-1 Quick Installation Guide
09
System settings
The basic information and initial date/time of this device are congured here.
Device identication – Set the name (host name) and description for this device.
Date and Time – Set the device date, time, and time zone manually/ be synchronized to PC, or with an external NTP (network
time protocol) server.
Boot image – Change the boot screen image. The boot screen is the image you will see when you boot up the device.
Click Browse button and select the desired le in the Open dialog box. The le name would appears with the
newly uploaded image. Click Apply button at the bottom corner to apply the settings, or click Cancel
to give it up.
Power – Choose how to turn on the device
Note: The boot screen le must be in PNG format, maximum size 1920x1080px.
Cancel

www.spacesgate.com
SG-1 Quick Installation Guide
10
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED
BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING
TO THE INSTRUCTIONS
Important Security Policy
Precautions
1. Please open the product package carefully; we commend you keep this packaging for future transport, storage or
maintenance use.
2. There are no switches or adjustment buttons required for operation inside this product, so for your safety, please do not
open the casing on your own, or vigorously rotate, shake or use any other inappropriate ways to operate this product in
order to avoid electrical shocks and voiding the warranty. You can contact a local dealer directly if you have any questions.
3. Heat will be generated during the use of this product; therefore there must be sufcient ventilation for the temperature of
the unit to remain at a stable status. So please use the product under normal environments to prolong the usage life, and
avoid installing it in the following environments.
Locations that are unstable or have incomplete planes
Locations with powerful magnetic elds
Locations where it is damp or may have water leakage
Locations that are too hot, close to heaters and air hoses, or be exposed to direct sun light for long periods of time
Locations that are dusty
Locations where there are possible shocks
Locations close to power ampliers
4. If you notice smoke or odor coming from the product, please quickly remove the power cable and send it to a maintenance
center for processing.
5. To avoid electrical shock, the plug of the adapter should be stably and completely inserted into the power outlet and
cannot be exposed; it must also have sufcient capacity to withstand the current transmission. Please do not plug the
adapter into the power outlet before connecting the cable in order to avoid danger.
6. If not used for long periods of time, please unplug the power plug, and to ensure electrical safety, when unplugging the
adapter, please hold the plastic part of the adapter with dry hands and then unplug the adapter. Please properly connect
the cables according to the printed instructions on the installation manual and the machine to ensure optimized usage
effects.

AREC Inc.© All Rights Reserved 2018. l www.spacesgate.com
All information contained in this document is Proprietary
AREC have the right to change or improve product specications, without obligation to notify any user.
Go to www.spacesgate.com get the latest information related to the product or additional information.
Made in Taiwan
Date : 2018.3.1
Version：7.1
