Argos Sophia 499/5348 User manual

Width-40cm
Depth-41.5cm
Height -67cm
Issue1 -12/05/16
Important - Pleasereadtheseinstructionsfullybeforestarting assembly
Dimensions
AssemblyInstructions- Pleasekeepfor future reference 499/5348
Sophia3Drawer Bedside
501/5320
501/1496
If you needhelporhave damagedor missingparts,call the CustomerHelpline:03456400800.
Forfurther assistancepleasevisit http://www.argos-support.co.uk/

Checkyouhaveallthe
componentsand toolslisted on
pages2and3.
Removeallfittingsfromthe
plasticbagsand separatethem
intotheirgroups.
During assemblykeepchildren
and animalsawayfromthework
area due topossible risk of injury
and small partscouldchokeif
swallowed.
Do not standorputweighton
theproduct,thiscouldcause
damage.
Assembletheitemascloseto
itsfinalposition(in thesame
room)aspossible.
Assembleon asoft level
surfacetoavoiddamagingthe
unitoryourfloor.
Partsoftheassemblywillbe
easierwith2people.
1
Safetyand CareAdvice
Important -Pleasereadtheseinstructionsfullybeforestarting assembly
Fromtimetotimecheckthat
therearenoloosescrewson
thisunit.
Thisproductshouldnot be
discardedwithhouseholdwaste.
Taketoyourlocalauthority
wastedisposalcentre.
Onlycleanusingadampcloth
and mild detergent,do no use
bleachorabrasivecleaners.
Careandmaintenance
Assemble all partsand bolts
looselyduring assembly, only
oncethe product iscomplete
should you fullytighten the bolts
HandyHints
Regularlycheckand ensure
that all boltsand fittingsare
tightend properly.
Toreduce
the likelihood of
damaging your
product please
ensurethat your
powerdrill isset on alow torgue
setting.

Top 1(40 41.5cm)
Components- Panels
2
Pleasecheckyouhaveall thepanelslistedbelow
1
Baseframe 1(40 41.5cm)
Left Side 1(43.4 38.6cm) Right Side 1(43.4 38.6cm)
4
23
Leg 4(20 4.5cm)
5
Drawerside, left 3 (30 9.5cm)
7 9
Drawerfront 3(25 14cm)
6
Back panel 1(26.6 44.5cm)
11
8
10
Drawerback 3(20.5 9.2cm)
Drawerside, right 3 (30 9.5cm)
Drawerbase 3(21.6 29.9cm)
If you havedamaged ormissing componets, call the
Customer Helpline:03456 400800.Forfurther
assistancepleasevisithttp://www.argos-support.co.uk/

Components- Fittings
0101520253035404550556065707580859095100 110115120125130135140145150155160165170
105
5
Note: Thequantitiesbelowarethecorrectamounttocompletetheassembly.Insomecasesmorefittings
maybesuppliedthanarerequired.
Phillipsscrewdriver
(medium&large)
Flatblade screwdriver
(medium)
Pleasecheckyouhaveall thefittingslistedbelow
Ruler -Usethis rulertohelpcorrectlyidentifythescrews
Toolsrequired
3
Rubber
mallet
Wooden dowel 8 Largelockingpin 12
Smalllockingpin 12
D5/32'' 7/8'' Screw 3
Handle 3
300mm Runner,
outsideleft 3
Ø3.5 15mm
Screw 42
Smalllockingnut
12
300mm Runner,
outside right 3 300mm Runner, insideleft 3
300mm Runner,
inside right 3
ABCLargelocking
nut 12
FED
G
J K
H I
L
M N O
Allenkey 1
Ø3.5 25mm
Screw 13
washer 4
PQØ640mm
Screw 4
washer 5
RWall strap
1
Backpanel
support 1
S

4
AssemblyInstructions
Step 1
Fittingdowels
a:Insert Wooden dowels
intoLeftsideand
Rightside.
b: Fix RunnerOutside
Right ontoLeftside
byusingScrews.
FixRunnerOutside
LeftontoRightside
byusingScrews.
A
3
K2
N
N
N
J
NN
K
2
K
3
12
J

Fittinglockingpins
Insert Large locking Pin
intoTop.
Note: Insert locking pin
asshown.
Do notovertighten.
1
Step 2
5
AssemblyInstructions
B
B
Fittinglockingpins
Fitting LargeLocking
pinstoBaseFram.
4
4
QPO
G
B4
5

Step 5
Step 6
6
AssemblyInstructions
C
1 2 3
B
Insertback panel
SliptheBackpanelto
thegrovesontheSides.
B
Attach theSides to Base
frame.
Attach Left Sideto
BaseFramandfixing
byLargeLockingNut
.
Repeatthisstep to
attachRightSideto
BaseFrame.
13
C
2
3
11
2
4
3
4
11

Step 7
Step 8
7
AssemblyInstructions
Drawer assembly
a: Insert4Smalllocking
pinintoholesshown
on back of Drawerfront
.
Note: InsertLockingpin
asfarasshown.
Do notovertighten.
AttachingTop
AttachToptotheunit.
Insert LargeLocking
Nutswhereshown and
useascrew drivertoturn
lockingnutsclockwiseto
lock.
1
1
C
E
6
b:AttachDrawersides
and todraw front .
Insert4Smalllocking
nutsintoSides.
Useascrewdrivertoturn
lockingnutsclockwise
tolock.
7
86
F
F
C
1 2 3
B

Step 9
8
AssemblyInstructions
d: FixDrawerback
ontosidesbyusing4
Screws.
e: FixHandleby
usingScrew.
I
N
H
ML
c:Slip Drawerbase
intogrooves.
f:FixRunnersand
ontotheundersideof
Drawersidesbyusing 6
Screws.
Repeata-fto finish
another2drawers.
9
10

Step10
AssemblyInstructions
FixingWallstrap
FixWallStrapbyBack
panel supportWasher
andScrew.
9
If you needhelporhave damagedor missingparts,call the CustomerHelpline:
03456 400800Retailer:Argos
Address:489-499AveburyBoulevardSaxonGateWest,CentralMiltonKeynes
Bucks,MK9,2NW
Forfurther assistancepleasevisit http://www.argos-support.co.uk/
R
D
O
Insertdrawers
Carefullyput in drawers
tothe unit.
S
Step11

Step12
AssemblyInstructions
10
If you needhelporhave damagedor missingparts,call the CustomerHelpline:
03456 400800Retailer:Argos
Address:489-499AveburyBoulevardSaxonGateWest,CentralMiltonKeynes
Bucks,MK9,2NW
Forfurther assistancepleasevisit http://www.argos-support.co.uk/
Fixingtowall
TheBedside table should
be fixedtoawall.
MoveBedside tableinto
position.
Markfixing hole on wall
and removeBedside
table.
Drill hole andinsert
wall plug.
Reposition Bedside table
and fixwall strap using
washerandscrew.
Assemblyisfinished.
Warning:
Beforedrilling,
checkwallfor
hidden pipes
andcables.
Note: wallplugsarenot
supplied.
Thecorrecttypeoffixingmust
beusedforyourwall, seek
professionaladviceindoubt.

A Guide to - Wall Mounting & Fixings
Revision 2 - 7/10/09
Important note:
Types of walls
Care &
Maintenance
No.1 “General Purpose” wall plug
No.6 “Shield Anchor” wall plug
Heavy loads
No.3 “Cavity Fixing” wall plug
No.4 “Cavity Fixing-Heavy Duty”
wall plug
No.5 “Hammer Fixing” wall plug
No.2 “Plasterboard” wall plug
Generally aerated blocks should not
be used to support heavy loads, use
a specialist tting in this case. For light
loads, general purpose wall plugs can
be used.
For use with heavier loads such as TV
& HiFi speakers and satelite dishes etc.
For use with plasterboard partitions or
hollow wooden doors.
For use when tting or supporting
heavy loads such as shelving, wall
cabinets and coat racks.
For use with walls stuck with
plasterboard. The hammer xing allows
it to be xed to the wall rather than the
plasterboard. Always check the xing
is secure to the retaining wall.
For use when attaching light loads on
to plasterboard partitions.
Safety: Always check the fitting
and location to ensure your safety
in and around the home.
Fitting: From time to time check
the fitting to ensure the wall plugs
or screws do not become loose.
You can use one of the following types of wall plug if your walls are made
of brick, breeze block, concrete, stone or wood.
Important: When drilling into walls always
check that there are no hidden wires or pipes etc.
Hints:
1: General rule: Always use a larger screw and wall plug
if you are not sure.
2: Ensure you use the recommended drill bit to match the wall
plug and hole size.
3: Ensure you drill the hole horizontally, do not force the drill or
enlarge the hole.
4: Take extra care when drilling high walls, ceilings and ceramic
tiles. Ensure wall plugs are inserted beyond the thickness of
the ceramic tiles to avoid the tiles splitting or cracking.
5: Ensure wall plugs are well tted and are a tight t in the
drilled hole.
If plastic wall plugs
are supplied with your
product:
Make sure that the screws and wall plugs being used
are suitable for supporting your unit. Consult a qualified
tradesperson if you are unsure.
- these are only suitable for
use in masonry walls.
If you are in any doubt about
the correct wall plugs for
your wall, seek professional
advice.
Failure of the product due to
using incorrect xings is the
responsibility of the installer.
