Iceland Single Bed
Assembly Instructions - Please keep for future reference 279721
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
Homebase = 0345 077 8888
Issue 1 - 06/06/14
Dimensions
Width - 101cm
Length - 203cm
Height - 112cm
279723
279724

• Check you have all the
components and tools listed on
the following pages.
• Remove all fittings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Make sure you have enough
space to layout the parts before
starting.
• During assembly do not stand
or put weight on the product, this
could cause damage.
• Assemble the item as close to
its final position (in the same
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
unit or your floor.
• Parts of the assembly will be
easier with 2 people.
• To reduce the
likelihood of
damaging your
product please
ensure that your
power drill is set on a low torque
setting.
• Unit weight: 25.18kgs.
1
Safety and Care Advice
Important - Please read these instructions fully before starting assembly
Care and maintenance
Handy Hints
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• From time to time check that
there are no loose screws on
this unit.
• This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
• Assemble all parts and bolts
loosely during assembly, only
once the product is complete
should you fully tighten the
bolts.
• Regularly check and ensure
that all bolts and fittings are
tightend properly.
Note: if required the next
page can be cut out and used
as reference throughout the
assembly. Keep this page with
these instructions for future
reference.

2
Components - Parts
Please check you have all the parts listed below
If you have damaged or missing components, call the
Customer Helpline: Homebase = 0345 077 8888
1Headboard
(101 x 112 x 8cm)
2Footboard
(101 x 94 x 8cm)
3Side rail A x 2
(95.5 x 12 x 5cm)
5Centre rail
(91 x 9 x 2.5cm)
4Side rail B x 2
(95.5 x 12 x 5cm)
7Centre leg x 2
(29 x 8 x 2.5cm)
8Side rail connector x 2
(15 x 2 x 4.5cm)
6Slat x 2
(90 x 80 x 3.5cm)

3
Components - Fittings
Please check you have all the fittings listed below
Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings
may be supplied than are required.
Ruler - Use this ruler to help correctly identify the screws
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 110 115 120 125 130 135 140 145 150 155 160 165 170
105
C
Allen key x 2
AB
M8 x 20mm Bolt x 8 M6 x 16mm Bolt x 16

4
Assembly Instructions
Step 2
3
8
3
4
BB
BB
Step 1
Assembling side rails
a: Insert the side rail
connector into the
side rail A as shown.
Align holes and fix using
bolts .
b: Then insert the side
rail B into the side rail
connector as shown.
Align holes and fix using
bolts .
Note: Fasten
bolts using allen
key but do not
fully tighten at this
stage.
Repeat above to
assemble the other side
rails & .
Attaching centre rail
Position the assembled
side rails & and
centre rail as shown.
Align holes and fix using
bolts .
Note: Fasten
bolts using allen
key but do not
fully tighten at this
stage.
C
8
8
3
4
43
43
5
B
B
3
8
4
BB
BB
3
8
4
BB
BB
8
a: b:
B
B
4
3
4
3
5
B
B
C
B
5
4
3
B
B

5
Assembly Instructions
5
Step 4
Step 3
Assembling round
centre legs
Position the round centre
legs on the centre rail
as shown. Align holes
and fix using bolts and
fully tighten with allen
key .
Attaching headboard
With the help of an
assistant, position the
assembled side rails
& and headboard
as shown. Align holes
and fix using bolts .
Note: Fasten
bolts using allen
key but do not
fully tighten at this
stage.
C
7
4
3
1
B
A
C
B
B
7
B
B
7
5
5
BB
7
4
3
3
4
A
A
A
A
1
A
A
1
4

6
Assembly Instructions
A
AA
A
4
4
2
A
A
4
2
Step 6
Attaching slats
Place the slats on top
of the siderails & .
Align and insert dowels
on the slats into holes on
siderails as shown.
3 4
6
Important:
Two persons are
required to lift the
slats.
4
6
6
6
6
3
3
4
4
Step 5
Attaching footboard
With the help of an
assistant, position the
assembled side rails
& and headboard
as shown. Align holes
and fix using bolts .
Note: Fasten
bolts using allen
key but do not
fully tighten at this
stage.
4
3
1
A
C
3
3

Note: Fully
tighten all bolts
fixed in previous
steps using allen
key .
7
Assembly Instructions
If you need help or have damaged or missing parts, call the Customer Helpline:
Homebase = 0345 077 8888
Assembly is complete.
C
Step 7
Adjusting legs
Ensure the legs are in
contact with the ground.
Turn adjustable footings
on the 2 centre legs
to adjust the height.
7
7
7
adjustable
footing
