Aria Child Rollplay 6V R8 Spyder User manual

1
6V Audi R8 Spyder (W458AC)
Customer Service Guide
MMXV © Copyright Aria Child Inc.
All manuals and user guides at all-guides.com
all-guides.com

2
Customer Service Guide
Contents
I) Check Battery …………………………............................................. 3
II) Check Wiring Condition ……………………………..………………………. 6
III) Check Foot Pedal ………………………………………………………..….….. 11
IV) Gearbox Replacement …………………………………………..…………… 13
V) Exploded View …………….…………....…....….……….……..…….…… 20
CAUTION :
Disconnect the battery before
proceeding with any of the following
steps
All manuals and user guides at all-guides.com

3
Battery Troubleshooting: How to Access and
Check the Battery
1. Use a flat head screwdriver to unlock the seat
2. Lift the seat from the bottom to remove
3. Locate the battery, and unplug the red connectors
4. Use a volt meter to check the battery. See page 5 for volt reading tips
Step (1)
Unlock position
Turn and unlock this plastic knob
Step (2)
Lift the seat from bottom edge
then remove at headrest
2
1
All manuals and user guides at all-guides.com

4
Step (3)
Unplug the battery connector (RED) underneath seat
Battery Troubleshooting: How to Access and
Check the Battery
All manuals and user guides at all-guides.com

5
Step
(4)
Volt Meter Results: 6.0 V ~ 6.5 V –Good condition
5.6 V ~ 5.9 V –Proceed to Recharge
5.5 V –Recharged battery for 8-10 hours. If after the
charging time, voltage has not increased,
the battery needs replacement
Below 5.5 V –Battery needs a replacement
Battery Troubleshooting: How to Access and
Check the Battery
All manuals and user guides at all-guides.com

6
Check the white gearbox connections
Battery Troubleshooting: Check the Wiring
Connections
1. Check the Gearbox Connection: Follow the above
steps
to remove the seat. Locate the white gearbox
connectors in the battery compartment.
2. Disconnect and reconnect these connectors. Try
reconnecting the battery, and pressing the gas pedal
to check for power.
3. Continue with below steps if power still does not
work.
All manuals and user guides at all-guides.com
all-guides.com

7
Main function switches located inside the wiring cover
Step (1)
Unscrew these two screws to remove the cover
Step (2)
Battery Troubleshooting: Check the Wiring
Connections
1.Flip the car on its side.
2. Locate the black wiring harness. Use a screwdriver
to remove the screws on either side of the cover.
3. Check the wiring connections to ensure they are
pushed in completely and fully intact.
All manuals and user guides at all-guides.com

8
Rear side Shifter Front side
Step (3)
Red
Power switch (leave the empty blade
at the front side)
Reverse above procedures to re-assemble the vehicle
Single Blue
Single Red
Double White
Double Black
Double Black
Black
Single Red
Black
Battery Troubleshooting: Check the Wiring
Connections
All manuals and user guides at all-guides.com

9
Step (1)
Unscrew the steering wheel from right hand side
Step (1)
Liftand remove the Steering Wheel from column
Sound and Steering Troubleshooting
1. Unscrew the steering wheel screw, and remove the
steering wheel from the steering column.
2. Unscrew the screws on either side of the dashboard.
Lift up the dashboard and windshield assembly.
3. Check the wiring connection from the dashboard to
the car body to ensure the connection is secure.
All manuals and user guides at all-guides.com

10
Step (2)
Unscrew these two screws to remove the dashboard
Step (3)
Check the 2-pin plug for any loose connections
Sound and Steering Troubleshooting
All manuals and user guides at all-guides.com

11
Step (1-2)
Black (middle)
White (front)
Step (3)
Blue (rear)
Checking the Foot Pedal Connection
1. Turn the vehicle on its back and located the foot
pedal harness underneath the car.
2. Use a flat head screwdriver to snap out the foot
pedal.
3. Turn the car back over and check the wires on the
foot pedal. Ensure the wires are secure and positioned
correctly.
4. Reassemble the foot pedal.
All manuals and user guides at all-guides.com
all-guides.com

12
Step
(4)
Slide in the Foot
Pedal into Chassis
from right side
2
Snap back in place
1
Checking the Foot Pedal Connection
All manuals and user guides at all-guides.com

13
Use a flat head screwdriver to remove the wheel cap from tabs
(Rear right wheel only)
Step (1)
Replacing the Gearbox
Follow the below steps to remove and replace the
gearbox.
All manuals and user guides at all-guides.com

14
Step (2)
Use the same screwdriver to remove the snap-
pin from axle as shown
Step (3)
Slide the rim and rear wheel out from axle
Replacing the Gearbox
All manuals and user guides at all-guides.com

15
Step (4)
Step (5)
Replacing the Gearbox
All manuals and user guides at all-guides.com

16
Step (6)
Unscrew the wiring cover
Unplug the headlight connector plugs located near the front end
Step (7)
Replacing the Gearbox
Flip the car over to access the wiring harness (Follow steps on page 7)
All manuals and user guides at all-guides.com
all-guides.com

17
Step (8)
Unscrew the two wiring clips as shown
Step (9)
Cut this ziptie to release
the gearbox
Replacing the Gearbox
All manuals and user guides at all-guides.com

18
Step (10)
Slide the gearbox off axle
Replacing the Gearbox
All manuals and user guides at all-guides.com

19
Step
(11)
Reverse above procedures to replace the gearbox
2
1
Replacing the Gearbox
All manuals and user guides at all-guides.com

20
Customer Service Guide
VII)Exploded View
