RGN-B06 User Manual V1.12
RGN-B06
REGENERATIVE UNIT
USER MANUAL

RGN-B06 User Manual V1.12
Publisher ARKEL Elektrik Elektronik SAN. ve TİC. A.Ş.
Eyüp Sultan Mah. Şah Cihan Cad. No:69 Sancaktepe/Istanbul 34885 TURKIYE
TEL : [phone]
Fax : [phone]
E-mail: [email protected].tr
www.arkel.com.tr
Date of Issue 02.2022
Document Version V1.12
This document has been created to be a guide for Arkel customers. Reproduction, transfer, distribution or storage of part or all
of the contents in this document in any form without the prior written permission of Arkel is prohibited. Arkel reserves the
right to make changes and improvements to any of the products described in this document without prior notice.
Arkel is not responsible for those mistakes that may be found in this manual and for the damages that they may cause.

RGN-B06 User Manual V1.12
TABLE OF CONTENTS
1. INTRODUCTION ..............................................................................................................................................................4
2. TECHNICAL SPECIFICATIONS ...................................................................................................................................4
3. RGN-B06 OVERVIEW......................................................................................................................................................4
4. RGN-B06 CONNECTION TERMINALS........................................................................................................................5
5. SAFETY INSTRUCTIONS ...............................................................................................................................................5
6. POWER LINES CONNECTIONS....................................................................................................................................6
6.1. DC Input Connections.........................................................................................................................................................6
6.2. Mains Output ......................................................................................................................................................................6
6.3. Suggested Circuit Diagram.................................................................................................................................................7
7. CONTROL SIGNAL CONNECTIONS ...........................................................................................................................7
7.1. Functions of the control inputs and relay outputs ...............................................................................................................7
7.2. Control Inputs Connections.................................................................................................................................................8
7.2.1. Connection with Internal Supply ........................................................................................................................................8
7.2.2. Connection with External Supply .......................................................................................................................................8
7.3. Relay Outputs......................................................................................................................................................................8
8. USER INTERFACE AND KEYPAD................................................................................................................................8
Keypad Functions ...............................................................................................................................................................9
9. GENERAL MENU STRUCTURE....................................................................................................................................9
10. INFO SCREENS...............................................................................................................................................................10
11. PARAMETERS ................................................................................................................................................................10
12. INSTALLATION AND COMISSIONING ....................................................................................................................11
13. STARTUP SETTINGS.....................................................................................................................................................11
14. OPERATING CURVE.....................................................................................................................................................11
15. ERROR MESSAGES .......................................................................................................................................................12
16. MECHANICAL DIMENSIONS......................................................................................................................................12

RGN-B06 User Manual V1.12
1. INTRODUCTION
RGN-B06 is a safe and efficient unit that utilizes advanced technology and engineering methods to feed the energy which is
potentially to be lost on brake resistors, into current mains when motors in lift systems run as generators.
•RGN-B06 supplies the grid with true sine wave with low harmonic distortion, utilizing high resolution PWM methods
and Vector control techniques.
•It gives fast in response to grid fluctuations thanks to its optimized software.
•Can be integrated to lift control systems by control inputs, relay outputs and CANBUS port.
•Start conditions and input voltage to reach the maximum power can be configurable.
•RGN-B06 has a user interface to configure all its parameters which have been kept simple for easy installation.
•RGN-B06 saves statistics such as regenerative travel count and produced energy.
2. TECHNICAL SPECIFICATIONS
Input
DC Voltage Range
300-800Vdc
Maximum Power
8400W
Maximum Current
20A
Protection
Fuse protected (20 A)
Grid/Output Parameters
Grid Voltage
3 ~ 310/440 Vac
Nominal Output Current
10 Arms / Phase
Max. Output Current
14 Arms / Phase
Max. Output Power
8000W:1min (max.),
6000W:%50 1hour (ON:1min / OFF:1min),
5000W:%50 2hours (ON:1min / OFF:1min)
Standby Power
<10W
THD
<%5
Control Method
Vector Control
Protection
Over voltage and over current
Parallel Binding Feature
Yes, 3 units.
Output Signals
3 outputs
Error,
Ready,
Active / Inactive
Output Type
Relay with contact (Max. 3 A, 250 VAC or 30 VDC )
Input Signals
Control Signals
(Isolated by optocoupler)
Enable + 3 Spare signals
Attention! The voltage applied to the
command signals must be 24 VDC.
Input Type
Opto-coupled
User Interface
Keypad
LCD(2x16) & 4 Buttons
Language
Turkish, English
Mechanical Features
Dimensions
350 x 450 x 191 mm (Width x Length x Height)
Storage Temperature
-20°C/+60°C
Operation Ambient
-10°C/+55°C
Cooling
Fan
Standards
EMU Emission / Harmonics
EN 12015:2014 / EN 61000-3-12
EMU Immunity
EN 12016:2013 / EN 61000-3-11
3. RGN-B06 OVERVIEW
Motors in lift systems act as power generators when travelling downwards with heavy load or upwards with light load. During
the breaking period this power is even higher. This energy causes internal bus voltage to rise. Traditionally, over a safety level
of bus voltage, break resistors are used to waste this energy as heat. RGN-B06 feeds this potentially lost energy back to the
utility grid. It can be connected to the brake resistor in parallel.

RGN-B06 User Manual V1.12
Figure 1 Basic Connection
(Fuses and safety devices not shown!)
4. RGN-B06 CONNECTION TERMINALS
Power Lines
PE
:Protective Earth Connection
R, S, T
: Grid Phases
DC+, DC-
: DC Input Connections
Control Inputs
IN1 ENABLE
: Enable Signal
IN2
: Spare Input Signal
IN3
:Spare Input Signal
IN4
: Spare Input Signal
COM
: Common for Inputs
GND
:(-) for internal 24VDC
+24V
:(+) for internal 24VDC
Relay Outputs
OUT1 (1A-1B)
:ERROR signal (Normally OFF)
OUT2 (2A-2B)
:READY signal (Normally OFF)
OUT3 (3A-3B-3C)
:ACTIVE signal (CO contact)
CANBUS Terminal
+24 V
:(+) 24 VDC internal supply for CANBUS
GND
:(-) 24 VDC internal supplies for CANBUS
L
:CANBUS Data (-)
H
:CANBUS Data (+)
5. SAFETY INSTRUCTIONS
•The installation and commissioning work must be performed only by qualified and authorized personnel.
•The regenerative unit must be placed in vertical upside position.
•Incorrect handling can cause to physical injuries and material damage.
•Before working on the device, it must be disconnected from input.
•Do not disconnect any cables or mechanical part when the unit is under load and running.
•Do not operate the device in conditions which do not meet the ambient values specified in this manual.

RGN-B06 User Manual V1.12
•The maintenance has to be performed only by ARKEL personnel.
•Do not remove any warning signs installed by manufacturer.
•The product must not be installed without Protective Earth connection.
•Use appropriate fuse and ground fault circuit interrupter on mains line connection.
•The device can be operated safely and normally only if it is installed and operated in accordance with this manual.
ARKEL is not responsible for any damage if these instructions are not followed.
6. POWER LINES CONNECTIONS
Figure 2 Mains Connection Terminal
6.1. DC Input Connections
This is the DC input terminal for RGN-B06 unit. DC BUS poles of the lift’s inverter system should be connected in right order
for proper operation. RGN-B06 has an internal diode in order to protect itself against wrong connection.
DC Input Conductor must have a cross section of at least 4mm2. Multi-wire cables with isolation of 1kV should be used.
Do not forget to label it as High Voltage warning!
6.2. Mains Output
Mains supply and PE connections. RGN-B06 software can identify phase orders automatically.
RGN-B06 must have a permanent PE connection!
These connections should be made with Proper fuse and leakage sensor protection!
Phase conductors must have a cross section of at least 2.5 mm2. Multi-wire cables with isolation of 500 V should be
used.

RGN-B06 User Manual V1.12
6.3. Suggested Circuit Diagram
Figure 3 Suggested Connection Diagram
* RCD, recommended against fire risks and insulation faults. (Ex: 300 mA)
7. CONTROL SIGNAL CONNECTIONS
Figure 4 User Interface and Control Signal Connections
7.1. Functions of the control inputs and relay outputs
INPUT
FUNCTION
INPUT1
ENABLE
INPUT2
Spare Input
INPUT3
Spare Input
INPUT4
Spare Input
OUTPUT
FUNCTION
OUT1
ERROR
OUT2
READY
OUT3
ACTIVE

RGN-B06 User Manual V1.12
7.2. Control Inputs Connections
7.2.1. Connection with Internal Supply
Figure 5 Internal 24VDC Power Supply Connection
7.2.2. Connection with External Supply
Figure 6 External 24VDC Power Supply Connection
Not: Signal inputs are isolated with bidirectional optocoupler. COM pin can be used eighter as positive or negative. Diagrams
above suppose COM to be negative.
7.3. Relay Outputs
Figure 7 Control Relays Output Connections
8. USER INTERFACE AND KEYPAD
RGN-B06 includes a 2 X 16 character LCD and four navigation buttons. Output power or Error number is shown on the
screen. Navigation buttons allows user to change the parameters and observe the current state of the device or some statistical
information.
Figure 8 RGN-B06 Keypad

RGN-B06 User Manual V1.12
Keypad Functions
SYMBOL
USAGE
Navigate between menus
Increase the value of the selected parameter
Navigate between menus
Decrease the value of the selected parameter
Enter the parameters menu
Edit the value of a parameter
See the sub items of a menu item
Set the current value to the parameter
Escape the current menu
Cancel parameter change
9. GENERAL MENU STRUCTURE
MAIN SCREEEN
NOW
INPUT VOLTAGE
INPUT CURRENT
INPUT VOLTAGE
BUS VOLTAGE
GRID VOLTAGE
FREQUENCY
OUTPUT CURRENT
OUTPUT POWER
CONTROL INPUTS
RELAY OUTPUTS
TEMPERATURE
NTC VOLTAGE
FAN DUTY PERCENT
FAN FEEDBACKS(FA- FB)
ERROR FLAGS
LAST ERROR FLAGS
SETTINGS
DİL/LANGUAGE
HIGH VOLTAGE
LOW VOLTAGE
START MARGIN
START CURRENT
FULL POWER VOLTAGE
SAVE
STATISTICS
TRIPS COUNT
TOTAL REGENERATIVE TIME
TRIPS COUNT
TOTAL ENERJI
HISTORY
TRIP (0) DURATION
TRIP (0) ENERGY
TRIP (1) DURATION
TRIP (1) ENERGY
TRIP(2) DURATION
TRIP(2) ENERGY
..
Info Screens
Info screens

RGN-B06 User Manual V1.12
10. INFO SCREENS
Use UP/DOWN buttons to reach and navigate between Info Screens. Repeatedly press ESC button to return to the main screen.
Info screens are grouped into 3 parts which have been explained below.
NOW
DESCRIPTION
VIN
Input voltage
IIN
Measured Input Current
VIN
Input voltage
VBUS
Internal bus voltage
VGRID
Mains voltage
FREQ
Mains frequency
IOUT
Output current
POUT
Output power
IN
Control inputs status
OUT
Relay output status
TEMP
Temperature of the cooling part
VNTC
Output voltage of temperature measurement circuit
FAN
Fan drive duty cycle
FBA FBB
Output of fan test circuits
ERROR
Current error flags
LAST
Last error flags which caused to stop running
STATISTICS
DESCRIPTION
TRIPS#
Number of regenerative travels since installation
SURE
Total time device produced energy since installation
TRIPS #
Number of regenerative travels since installation
ENERGY
Total energy produced since installation
HISTORY
DESCRIPTION
TRIP0
Duration of the last regenerative travel
ENERGY
Energy, produced during the last travel
RECORD(n)
Duration of the interested running period
ENERGY
Energy produced during the interested period
INFO
DESCRIPTION
VER
SW version
TIM
Time stamp of the software
11. PARAMETERS
Press ENTER key to reach the parameters. UP/DOWN buttons are used to navigate between parameters. To change the value
of a parameter presses ENTER to edit, then adjust its value using UP/DOWN buttons, then press ENTER again. Repeatedly
press ESC button to return to the main screen.
PARAMETER
DESCRIPTION
FACTORY
DIL/LANGUAGE
Screen Language
ENGLISH
TURKCE
Turkish
ENGLISH
English
HIGH VOLTAGE
Grid Over Voltage Protection Limit. Device stops running if the grid voltage is
higher than this value
440 V
[420 V, 450 V]
LOW VOLTAGE
Grid Under Voltage Protection Limit. Device stops running if the grid voltage is
lower than this value
310 V
[290 V, 340 V]
START MARGIN
Device starts running as soon as input voltage rises from the regulated grid base
+40 V
[+30 V, +110 V]
START CURRENT
The current as soon as RGN-B06 starts feeding the grid.
0.5 A
[0.5 A , 5.0 A]
FULL PW VOLT.
DC Input voltage to reach the maximum power. The output current is limited to
12,5 Arms per phase (~8200 Watts)
680 V
[630 V, 730 V]

RGN-B06 User Manual V1.12
12. INSTALLATION AND COMISSIONING
Each RGN-B06 unit is tested at factory and shipped ready to install. Still it is suggested to follow the steps below for safe
installation and commissioning.
•Connect PE and Grid R-S-T cables.
•Internal circuits are fed from grid connections. Turn the grid energy on and check the grid voltage, grid frequency and
the internal bus voltage on INFO/NOW screen (Should be around 400V –50Hz –540V).
•Check the control inputs and relay outputs on INFO/NOW screen (All should be “-“).
•Change the parameters if needed.
•Turn off the grid.
•Connect DC Input cables and input-output wires.
•Turn on the grid.
•Check the DC Input Voltage at INFO/NOW screen. (Should be around 540V)
•“READY” message should appear at the screen.
13. STARTUP SETTINGS
RGN-B06 unit is configured at factory for common needs. If “BAD CONFIGURATION” message does not appear on the
screen the unit is ready to use after electrical installation. In case it is decided to change some parameters “SAVE” function
must be run to save the parameters to permanent memory. Mind the following warnings in case you change parameters.
LANGUAGE: The language that is valid on all screens is preferred.
HIGH VOLTAGE/LOW VOLTAGE: When the grid voltage runs out of these values the unit stops running. If the grid
quality is bad and device frequently stops running because of grid error, try to change these parameters, otherwise do not.
START MARGIN: RGN-B06 unit observes the difference between DC Input voltage and regulated grid voltage to decide
whether the motor is in regenerative mode or not. If the difference is higher than the configured margin it starts transferring
energy to the grid. It is not suggested to set this parameter too high since it would cause system run at high bus voltages at
every regenerative tour.
FULL POWER VOLTAGE: RGN-B06 unit’s trajectory curve is dynamically calculated such that it reaches its maximum
power at the configured voltage level. Therefore voltage level at which break resistors are activated is an appropriate selection
for this parameter.
14. OPERATING CURVE
Figure 9 Operating Curve
VA : Stop Voltage (Internal hysteresis against startup discontinuity)
VB : Start Voltage (Regulated grid voltage + Start margin)
VC : Full Power Voltage
IA : Start Current
IB : Maximum Current (~12, 5 Ampere rms/per phase)

RGN-B06 User Manual V1.12
15. ERROR MESSAGES
SCREEN
MEANING
REMEDY
STOPPED
Stopped by user intentionally.
Check the control input signals
connections. INFO/NOW In-Out values
should reflect the relevant port state
OUT CURRENT HIGH
Experienced high output current.
Check START MARGIN parameter.
Decrease the value if necessary. (to 30V –
40V)
Check START CURRENT parameter.
Decrease if necessary. (to 0.5 –1 A)
IN CURRENT HIGH
Experienced high input current
SUDDEN CHANGE I
Sudden change of output currents could not be
controlled and went out of limits.
Check grid voltage.
Decrease START MARGIN parameter to
30V 40V
SUDDEN CHANGE V
Sudden change of internal bus voltage could not
be controlled and went out of limits.
OFFSET PROBLEM
At least one current sensor has high current
offset
If does not clear itself or repeatedly met
apply ARKEL.
INPUT HIGH/LOW
Input voltage is out of limits..
Check DC input connections and level.
FAN PROBLEM
At least one of the ventilating fans does not
work properly
Fans need to be changed, Apply ARKEL.
MEASURE. PROBLEM
Cannot measure temperature correctly.
Apply ARKEL.
TEMPERATURE HIGH
Experienced high temperature.
The load is too much for one unit. Multiple
RGN-B06 units should be used together.
Apply ARKEL.
GRID PROBLEM
Cannot follow the grid.
Check grid connections and level.
SETTING REQUIRED
Settings are bad or not configured.
Should not happen. Apply ARKEL
16. MECHANICAL DIMENSIONS
Figure 10 Mechanical Measurements
