Armacost Lighting 714421 User manual

Introduction
This LED controller is designed to drive constant
voltage RGB+White LED products such as LED
tape light or LED fixtures in a voltage range of
6–24 volts DC. The receiver works with the RF
wireless remote control, which allows the user
to choose between multiple colors, adjust the
LED brightness, and select dynamic effects.
Receiver & wiring
24mm
72mm
87mm
123
1. Input – from power supply
The controller input and output voltage range is
6–24 volts DC. Make sure the LED lighting voltage is
within this range and below the rated wattage of the
power supply. Connect input wires from the power
supply to the controller as indicated by the polarity
markings on the controller (+ to + and – to –).
2. Output – to LED lighting
Observe polarity indicated on the controller
when connecting to LED lighting (+ to +,
G to G, R to R, B to B, and W to W).
Make sure the voltage of the LED lighting is the
same as the power supply and the maximum
load doesn’t exceed that of the controller.
CAUTION: Shorting of output cables could cause
permanent damage to controller. Make sure
cables are well insulated from each other.
3. Controller status indicator
This light shows the controller status as follows:
Steady yellow: Remote only mode, Wi-Fi disconnected
Steady green: Remote and Wi-Fi mode
Single green blink: Command received
Long single yellow blink: Brightness or speed limit reached
Red flash: Overload protection
Yellow flash: Overheat protection
Green flash 3 times: Setup command received
4. Wiring diagram
Connect the power supply to the controller input
and the controller output to the LED lighting.
The output voltage of the power supply must
be the same as the voltage of the LED lighting.
Make sure all power cables are conected
securely and insulated before powering on.
LED
Controller
6–24V DC
Output
Power Supply
6–24V DC 6–24V DC
100/230V
AC Power
LED
Lighting
Remote Control
6
8
512
11
9
7
10
EFFECTEFFECT
5. On / Off
Press the “|” key to turn on controller or the “0”
key to turn off. The controller will remember
the controller state when powered off, and will
return to that state when powered back on.
6. Mode selection
Press this key to switch between RGB, white, and
RGB+white mode. If the RGB mode is selected,
the white channel will be disabled, and if the white
mode is selected, RGB channel will be disabled.
In RGB+White mode all channels are enabled.
1
2 3
Wireless
Remote
Compact
Size
Wide Voltage
Range
High
Power
Full Safety
Protection
Wi-Fi
Connection
ProLine Wi-Fi RGB+W
Color LED Controller
With RF Remote Control
Model # 714421
Works with the Tuya Smart
App, available at the iOS
and Google Play stores

7. Select static RGB color
Press the “COLOR+” and “COLOR–” keys to scroll
through the preset library of colors.
8. Shortcut color keys
Press to select preset colors.
9. White brightness control
Press to increase white LED brightness and press
to decrease it.
10. RGB brightness control
Press to increase RGB LED brightness and press
to decrease it.
11. Dynamic effect
Press “MODE+” and “MODE–” to select the
dynamic effect mode and “SPEED+” and
“SPEED–” to adjust the effect speed.
12. Remote indicator
When pressing keys, the indicator blinks if the remote
is working properly. If the indicator flashes slowly
when pressing keys, battery power is low and it needs
to be replaced. Replace with a CR2032 battery.
13. Setting up a Wi-Fi connection
Install the Tuya app to set up a Wi-Fi connection.
Before setup, make sure the controller is in factory
default mode and not connected to other wireless
routers. The controller indicator should glow
yellow before it has been connected to Wi-Fi.
Remote control operation
14. Using the remote control
Pull out plastic battery insulation tab before use.
The RF wireless remote will work through walls
and doors. Do not install in a metal enclosure.
15. Pairing with a new remote control
The remote control and receiver are already paired,
but up to five remotes can be paired to one receiver.
To pair a new remote:
1. Disconnect power to receiver and wait
five seconds.
2. Reconnect power and wait ten seconds.
3. Press the and keys simultaneously
for about three seconds until the remote
indicator flashes quickly.
16. De-pairing remotes
To de-pair a remote control, pair the remote you
wish to continue using with the controller and
any other paired remotes will be de-paired.
17. Reset to factory default
To reset the Wi-Fi setting and remote control pairing:
1. Unplug the receiver. Plug in after five seconds.
2. Press the and keys simultaneously for
about three seconds, within ten seconds
of the receiver being powered on.
The indicator will flash yellow three times to confirm.
Safety Protection
The controller has a function to prevent it from
being damaged by mis-wiring, output short circuit,
overloading, or overheating. It will automatically
shut down under these extreme conditions until
safe operating conditions are restored. To avoid
shutdowns, make sure the installed LED lighting is
compatible with constant voltage driving, is in the
rated range of the controller, and the cables are well
connected and insulated. Also, install the controller
with proper ventilation and heat dissipation in mind.
Specifications
Output mode......................................PWM constant voltage
Working voltage ...................................................6–24V DC
Rated output current...................................4x3A (12A max)
Static colors........................... 30 (remote) / 16 million (app)
Brightness levels .............................10 (remote) / 100 (app)
Dynamic effect modes................................ 34 (remote only)
Dynamic speed levels................................. 10 (remote only)
Color preset keys (remote) ................................................ 7
Scene / Timing function.....................User defined (app only)
Music sensing color ....................................... Yes (app only)
PWM physical grade...........................................4000 steps
Overload/heat protection................................................ Yes
Remote frequency.............................................433.92MHz
Remote control range ................... >49 ft./15m in open areas
Wi-Fi standard......................................... IEEE 802.11a/b/g
Controller dimensions ...................... 3.43 X 0.95 X 0.59 in./
............................................................... 87 X 24 X 15mm
Remote dimensions ....................... 3.41 X 1.42 X 0.329 in./
............................................................ 86.5 X 36 X7.5mm
4 5
Customer support
Email: [email protected]
Phone: [phone]
Monday–Friday, 9 a.m.–5 p.m., ET
Warranty
Limited 1-year warranty. This product is for dry
location use only. Improper installation, improper
powering, abuse, or failure to use this device for
its intended purpose will void warranty. Proof of
purchase is required for all returns. Questions?
Email [email protected].
