Armacost Lighting 723421 User manual

Slimline RGB Color LED Controller
With RF Remote Control
Model # 723421
Introduction
This LED controller is designed to drive constant voltage
RGB LED products such as LED tape light or LED
fixtures in a voltage range of 5–24 volts DC. The receiver
works with the RF wireless remote control, which allows
the user to choose between multiple colors, adjust
the LED brightness, and select dynamic effects.
Receiver & wiring
38mm
15mm
50mm
12
1. Input – from power supply
The controller input and output voltage range is
5–24 volts DC. Make sure the LED lighting voltage is
within this range and below the rated wattage of the
power supply. Connect input wires from the power
supply to the controller as indicated by the polarity
markings on the controller (+ to + and – to –).
2. Output – to LED lighting
Observe polarity indicated on the controller
when connecting to LED lighting (+ to +,
G to G, R to R, and B to B).
Make sure the voltage of the LED lighting is the
same as the power supply and the maximum
load doesn’t exceed that of the controller.
CAUTION: Shorting of output cables could cause
permanent damage to controller. Make sure
cables are well insulated from each other.
3. Wiring diagram
Connect the power supply to the controller input
and the controller output to the LED lighting.
The output voltage of the power supply must
be the same as the voltage of the LED lighting.
Make sure all power cables are conected
securely and insulated before powering on.
Remote
Control
LED
Controller
5–24V DC
Output
Power Supply
5–24V DC 5–24V DC
100/230V
AC Power
LED
Lighting
Remote Control
6
5
47
4. On / Off
Press the “|” key to turn on controller or the “0”
key to turn off. The controller will remember
the controller state when powered off, and will
return to that state when powered back on.
5. RGB color setting
Press the “COLOR+” and “COLOR–” keys to
scroll through all the color options. The colored
keys are shortcuts for preset colors. Press the
and the keys to adjust color brightness.
1
2 3
Wireless Remote
Ultra Compact
Wide Voltage Range
Memory Function
Overheat Protection

6. Dynamic effects
Press “MODE+” and “MODE–” to select the
dynamic effect mode and “SPEED+” and
“SPEED–” to adjust the effect speed.
Press the “DEMO” key to play the dynamic effects.
7. Remote indicator
When pressing keys, the indicator blinks if the remote
is working properly. If the indicator flashes slowly
when pressing keys, battery power is low and it needs
to be replaced. Replace with a CR2032 battery.
Remote control operation
8. Using the remote control
Pull out plastic battery insulation tab before use.
The RF wireless remote will work through walls
and doors. Do not install in a metal enclosure.
9. Pairing with a new remote control
The remote control and receiver are already paired,
but up to 5 remotes can be paired to one receiver.
To pair a new remote:
1. Disconnect power to receiver
and wait five seconds.
2. Reconnect power and wait ten seconds.
3. Press the “SPEED–” and “SPEED+” keys
simultaneously for about three seconds
until the remote indicator flashes quickly.
10. De-pairing remotes
To de-pair a remote control, pair the remote you
wish to continue using with the controller and
any other paired remotes will be de-paired.
Overheat protection
If the controller overheats, it will automatically
shut down until the temperature drops to a
safe range. If this occurs, check to make sure
the output current is below the rated level.
Customer support
Email: [email protected]
Phone: [phone]
Monday–Friday, 9 a.m.–5 p.m., ET
Warranty
Limited 1-year warranty. This product is for dry
location use only. Improper installation, improper
powering, abuse, or failure to use this device for
its intended purpose will void warranty. Proof of
purchase is required for all returns. Questions?
Email [email protected].
Specifications
Output mode..........................PWM constant voltage
Working voltage .......................................5–24V DC
Rated output current.........................3x2A (6A max)
Brightness levels ................................................. 5
Static colors...................................................... 30
Dynamic effects................................................. 43
Dynamic speed levels......................................... 10
PWM frequency ............................................. 1KHz
PWM physical grade................................. 256 steps
Overheat protection............................................Yes
Remote frequency.................................433.92MHz
Remote control range ....... >49 ft./15m in open areas
Controller dimensions .......... 1.97 X 0.59 X 0.28 in./
..................................................... 50 X 15 X 7mm
4 5
