MICRO-EPSILON thermoMETER CTVideo User manual

Instruction Manual
thermoMETER CTVideo
CTVM-1L
CTVM-1H
CTVM-1H1
CTVM-2L
CTVM-2H
CTVM-2H1
CTVM-3L
CTVM-3H
CTVM-3H1
CTVM-3H2
CTVM-3H3

MICRO-EPSILON
MESSTECHNIK
GmbH & Co. KG
Königbacher Strasse 15
94496 Ortenburg / Germany
Tel. [phone] / 168-0
Fax [phone] / 168-90
[email protected]
www.micro-epsilon.com
Certified acc. to DIN EN ISO 9001: 2008
Infrared sensor

thermoMETER CTVideo
Contents
1. Safety ........................................................................................................................................ 7
1.1 Symbols Used ................................................................................................................................................. 7
1.2 Warnings.......................................................................................................................................................... 7
1.3 Notes on CE Identification............................................................................................................................... 9
1.4 Proper Use..................................................................................................................................................... 10
1.5 Proper Environment....................................................................................................................................... 10
2. Technical Data ........................................................................................................................ 11
2.1 Functional Principle ....................................................................................................................................... 11
2.2 Sensor Models............................................................................................................................................... 12
2.3 General Specification .................................................................................................................................... 13
2.4 Electrical Specification .................................................................................................................................. 14
2.5 Measurement Specification ........................................................................................................................... 15
2.5.1 CTVM-1 Models ............................................................................................................................ 15
2.5.2 CTVM-2 Models ........................................................................................................................... 16
2.5.3 CTVM-3 Models ........................................................................................................................... 17
3. Delivery ................................................................................................................................... 18
3.1 Unpacking...................................................................................................................................................... 18
3.2 Storage .......................................................................................................................................................... 18
4. Optics...................................................................................................................................... 19
5. Mechanical Installation .......................................................................................................... 21
6. Electrical Installation.............................................................................................................. 24
6.1 Cable Connections ........................................................................................................................................ 24
6.1.1 Standard Version .......................................................................................................................... 24
6.1.2 High Temperature Version............................................................................................................ 24
6.2 Pin Assignment.............................................................................................................................................. 26
6.3 Power Supply................................................................................................................................................. 27
6.4 Cable Mounting ............................................................................................................................................. 28
6.5 Ground Connection ....................................................................................................................................... 29

thermoMETER CTVideo
7. Sensor Calibration Code ....................................................................................................... 30
8. Outputs and Inputs................................................................................................................. 31
8.1 Analog Output................................................................................................................................................ 31
8.2 Digital Interface.............................................................................................................................................. 31
8.3 Functional Inputs ........................................................................................................................................... 32
8.4 Alarms ............................................................................................................................................................ 32
8.4.1 Output Channel 1 ......................................................................................................................... 32
8.4.2 Visual Alarms ................................................................................................................................ 33
9. Operation ................................................................................................................................ 34
9.1 Restoring Factory Setting.............................................................................................................................. 34
9.2 Sensor Setup ................................................................................................................................................. 36
9.3 Explanation to the Menu Items...................................................................................................................... 37
9.4 Visor Options ................................................................................................................................................. 40
9.5 Focusing and Video Sighting ........................................................................................................................ 41
9.6 Error Messages.............................................................................................................................................. 42
10. Instructions for Operation...................................................................................................... 42
10.1 Cleaning......................................................................................................................................................... 42
11. Software.................................................................................................................................. 43
11.1 Installation...................................................................................................................................................... 43
11.2 System Requirements ................................................................................................................................... 43
11.3 Main Features ................................................................................................................................................ 43
12. Communication Settings........................................................................................................ 44
12.1 Serial Interface ............................................................................................................................................... 44
12.2 Protocol.......................................................................................................................................................... 44
12.3 ASCII Protocol ............................................................................................................................................... 44
12.4 Saving of Parameter Settings ........................................................................................................................ 45
12.5 Basics of Infrared Thermometry .................................................................................................................... 46
13. Emissivity................................................................................................................................ 47
13.1 Definition ........................................................................................................................................................ 47
13.2 Determination of Unknown Emissivity........................................................................................................... 47
13.3 Characteristic Emissivities............................................................................................................................. 48

thermoMETER CTVideo
14. Warranty ................................................................................................................................. 49
15. Service, Repair ....................................................................................................................... 50
16. Decommissioning, Disposal .................................................................................................. 50
Appendix
A 1 Accessories ............................................................................................................................ 51
A 1.1 Air Purge Collar.............................................................................................................................................. 51
A 1.2 Mounting Bracket .......................................................................................................................................... 52
A 1.3 Water Cooled Housing .................................................................................................................................. 53
A 1.4 High Temperature Cable................................................................................................................................ 53
A 1.5 Rail Mount Adapter for Controller.................................................................................................................. 54
A 2 Factory Default Settings......................................................................................................... 55
A 3 Emissivity Table Metals.......................................................................................................... 57
A 4 Emissivity Table Non Metals.................................................................................................. 60
A 5 Smart Averaging..................................................................................................................... 62

thermoMETER CTVideo

Page 7
Safety
thermoMETER CTVideo
1. Safety
The handling of the system assumes knowledge of the instruction manual.
1.1 Symbols Used
The following symbols are used in the instruction manual.
Indicates a hazardous situation which, if not avoided, may result in minor or
moderate injuries.
Indicates a situation which, if not avoided, may lead to property damage.
Indicates a user action.
iIndicates a user tip.
Measure Indicates a hardware or a button/menu in the software.
1.2 Warnings
Connect the power supply and the display/output device in accordance with the safety regulations for electri-
cal equipment.
> Danger of injury
> Damage to or destruction of the infrared sensor
Avoid shock and vibration to the infrared sensor.
> Damage to or destruction of the infrared sensor
The power supply must not exceed the specified limits.
> Damage to or destruction of the infrared sensor
Protect the USB cable against damage.
> Damage to the infrared sensor, failure of the measuring device

Page 8
Safety
thermoMETER CTVideo
No solvent-based cleaning agents may have an effect on the sensor (neither for the optics nor the housing).
> Damage to or destruction of the infrared sensor
Avoid static electricity, arc welders and induction heaters. Keep away from very strong EMF (electromagnetic
fields).
> Damage to or destruction of the infrared sensor
Avoid abrupt changes in operating temperature. If this occurs, allow 20 minutes for thermal stabilization.
> Faulty measurement
Avoid that the measurement object fills the field of optics completely.
> Faulty measurement
Never connect a supply voltage.
> Destruction of the output
Make sure to keep the optical path clear of any obstacles.
> Faulty measurement

Page 9
Safety
thermoMETER CTVideo
1.3 Notes on CE Identification
The following applies to the thermoMETER CTVideo:
- EU directive 2004/108/EC
- EU directive 2011/65/EC, “RoHS“ category 9
Products which carry the CE mark satisfy the requirements of the quoted EU directives and the European
standards (EN) listed therein. The EC declaration of conformity is kept available according to EC regulation,
article 10 by the authorities responsible at
MICRO-EPSILON MESSTECHNIK
GmbH & Co. KG
Königbacher Straße 15
94496 Ortenburg / Germany
The system is designed for use in industry and laboratory and satisfies the requirements of the standards
- EN 61326-1: 2006
- EN 61326-2-3: 2006
- EN 61010-1: 2001
The system satisfies the requirements if they comply with the regulations described in the instruction manual
for installation and operation.

Page 10
Safety
thermoMETER CTVideo
1.4 Proper Use
- The thermoMETER CTVideo is designed for use in industrial and laboratory areas. It is used for non-con-
tact temperature measurement.
- The system may only be operated within the limits specified in the technical data, see Chap. 2..
- Use the system in such a way that in case of malfunctions or failure personnel or machinery are not endan-
gered.
- Take additional precautions for safety and damage prevention for safety-related applications.
1.5 Proper Environment
- Protection class: IP 65
- Operating temperature:
Sensor: -20 ... 70 °C (-4 ... +158 °F) 1
Controller: 0 ... 85 °C (+32 ... +185 °F)
Cable sensor - controller: max. 80 °C (+176 °F) 2
- Storage temperature: -40 ... 85 °C (-40 ... +185 °F)
- Humidity: 10 - 95 %, non-condensing
- EMC acc. to: EN 61326-1: 2006
EN 61326-2-3: 2006
EN 61010-1: 2001
Avoid abrupt changes in operating temperature. If this occurs, allow 20 minutes for thermal stabilization.
> Faulty measurement
1) Laser will turn off automatically at operating temperatures > 50 °C.
2) Optional: High temperature cable: 180 °C (+356 °F), see Chap. A 1.4

Page 11
Technical Data
thermoMETER CTVideo
2. Technical Data
2.1 Functional Principle
The sensors of the thermometer CTVideo series are noncontact infrared temperature sensors.
They calculate the surface temperature based on the emitted infrared energy of objects, see Chap. 12.5. The
alignment of the sensor can be done with the integrated video sighting and crosshair laser aiming.
The sensor housing of the thermometer CTVideo sensor is made of stainless steel (IP 65/ NEMA-4 rating) –
the controller is placed in a separate box made of die casting zinc.
iThe thermometer CTVideo sensor is a sensitive optical system. Please use only the thread for mechani-
cal installation.
Avoid mechanical violence on the sensor.
> Destruction of the system

Page 12
Technical Data
thermoMETER CTVideo
2.2 Sensor Models
Model Measuring range Spectral response Typical applications
CTVM-1L
485 bis 2200 °C 1 μm Metals and ceramic surfacesCTVM-1H
CTVM-1H1
CTVM-2L
250 bis 2000 °C 1,6 μm Metals and ceramic surfacesCTVM-2H
CTVM-2H1
CTVM-3L
50 bis 1800 °C 2,3 μm Metals at low object tempera-
tures (from 50 °C)
CTVM-3H
CTVM-3H1
CTVM-3H2
CTVM-3H3
the following chapters of this manual you will find only the short model codes.
On the M-1, M-2, M-3 models the whole measurement range is split into several sub ranges (L, H, H1 etc.).

Page 13
Technical Data
thermoMETER CTVideo
2.3 General Specification
Sensor Controller
Protection class IP 65
Operating temperature 1-20 ... 70 °C 0 ... 85 °C
Storage temperature -40 ... 85 °C
Relative humidity 10 ... 95 %, non condensing
Material Stainless steel Die casting zinc
Dimensions 116 mm x 50 mm,
M48x1.5
89 mm x 70 mm
x 30 mm
Weight 600 g 420 g
Cable length 3 m (standard), 5 m,
10 m
Cable diameter 5 mm
Operating temperature cable Cable sensor-controller max. 80 °C 2
USB cable max. 80 °C
Vibration IEC 68-2-6: 3 G, 11 –
200 Hz, any axis
Shock IEC 68-2-27: 50 G,
11 ms, any axis
Software incl.
1) Laser swill turn off automatically at operating temperatures > 50 °C ab.
2) Optional: high temperature cable: 180 °C, see Chap. A 1.4

Page 14
Technical Data
thermoMETER CTVideo
2.4 Electrical Specification
Power supply 8 - 36 VDC
Current draw max. 160 mA
Aiming laser 635 nm, 1 mW, On/Off via programming keys software
Output/ analog selectable: 0/ 4 – 20 mA, 0 – 5/ 10 V, thermocouple (J or K) or
alarm output (Signal source: object temperature)
Alarm output Open collector output at pin AL2 (24 V/ 50 mA)
Output impedances mA max. loop resistance 500 Ω (at 8 - 36 VDC)
mV min. 100 KΩ load impedance
Thermocouple 20 Ω
Digital interface USB 2.0
Functional inputs F1 to F3; software programmable for the following functions:
- external emissivity adjustment,
- operating temperature compensation,
- Trigger (reset of hold functions)
Input impedance F2 and F3: 43 kΩ

Page 15
Technical Data
thermoMETER CTVideo
2.5 Measurement Specification
2.5.1 CTVM-1 Models
Model CTVM-1L CTVM-1H CTVM-1H1
Temperature range (scalable) 485 ... 1050 °C 650 ... 1800 °C 800 ... 2200 °C
Spectral range 1 μm 1 μm 1 μm
Optical resolution 150:1 300:1 300:1
System accuracy 1 2 ±(0.3 % of reading +2 °C) 3
Repeatability 1±(0.1 % of reading +1 °C) 3
Temperature resolution 0.1 °C 3
Exposure time (90 % signal) 1 ms 4
Emissivity / Gain 0,100 … 1,100 (adjustable via programming keys or software)
Transmissivity 0,100 … 1,100 (adjustable via programming keys or software)
Signal processing Average, peak hold, valley hold
(adjustable via programming keys or software)
1) At operating temperature 23 ± 5 °C
2) Accuracy for thermocouple output: ± 2.5 °C or ± 1 %
3) e= 1/ Response time 1 s
4) With dynamic adaptation at low signal levels

Page 16
Technical Data
thermoMETER CTVideo
2.5.2 CTVM-2 Models
Model CTVM-2L CTVM-2H CTVM-2H1
Temperature range (scalable) 250 ... 800 °C 385 ... 1600 °C 490 ... 2000 °C
Spectral range 1.6 μm 1.6 μm 1.6 μm
Optical resolution 150:1 300:1 300:1
System accuracy 1 2 ±(0.3 % of reading +2 °C) 3
Repeatability 1±(0.1 % of reading +1 °C) 3
Temperature resolution 0.1 °C 3
Exposure time (90 % signal) 1 ms 4
Emissivity / Gain 0,100 … 1,100 (adjustable via programming keys or software)
Transmissivity 0,100 … 1,100 (adjustable via programming keys or software)
Signal processing Average, peak hold, valley hold 0,100 … 1,100
(adjustable via programming keys or software)
1) At operating temperature 23 ± 5 °C
2) Accuracy for thermocouple output: ± 2.5 °C oder ± 1 %
3) e= 1/ Response time 1 s
4) With dynamic adaptation at low signal levels

Page 17
Technical Data
thermoMETER CTVideo
2.5.3 CTVM-3 Models
Model CTVM-3L CTVM-3H CTVM-3H1 CTVM-3H2 CTVM-3H3
Temperature range (scalable) 50 ... 400 °C 1100 ... 600 °C 1150 ... 1000 °C 200 ... 1500 °C 250 ... 1800 °C
Spectral range 2.3 μm 2.3 μm 2.3 μm 2.3 μm 2.3 μm
Optical resolution 60:1 100:1 300:1 300:1 300:1
System accuracy 2 3 ±(0.3 % of reading +2 °C) 4
Repeatability 2±(0.1 % of reading +1 °C) 4
Temperature resolution 0.1 °C 4
Exposure time (90 % signal) 1 ms 5
Emissivity / Gain 0,100 … 1,100 (adjustable via programming keys or software)
Transmissivity 0,100 … 1,100 (adjustable via programming keys or software)
Signal processing Average, peak hold, valley hold (adjustable via programming keys or software)
1) TObject > THead +25 °C
2) At operating temperature 23 ± 5 °C
3) Accuracy for thermocouple output: ± 2.5 °C or ± 1 %
4) e= 1/ Response time 1 s
5) With dynamic adaptation at low signal levels

Page 18
Delivery
thermoMETER CTVideo
3. Delivery
3.1 Unpacking
1 thermoMETER CTVideo infrared sensor with connection cable and controller
1 Mounting nut and mounting bracket (fixed)
1 USB interface cable
1 CompactConnect Software-CD
1 Instruction manual
Check the delivery for completeness and shipping damage immediately after unpacking.
In case of damage or missing parts, please contact the manufacturer or supplier immediately.
You will find optional accessories in appendix, see Chap. A 1.
3.2 Storage
- Storage temperature: -40 ... 85 °C (-40 ... +185 °F)
- Humidity: 10 ... 95 %, non-condensing

Page 19
Optics
thermoMETER CTVideo
4. Optics
The vario optics of the CTVideo allows a smooth focusing of the optics to the desired distance. The sensors
are available in two optic versions:
Optics Focus adjustable in the range
SF 200 mm til infinity
CF 90 mm til 250 mm
The size of the measuring object and the optical resolution of the infrared thermometer determine the maxi-
mum distance between sensor and measuring object.
Avoid that the measurement object fills the field of optics completely.
> Measurement error
Consequently, the spot should at all times have at least the same size like the object or should be smaller
than that. The following tables show the diameter of the measuring spot for some selected distances. The
spot size refers to 90 % of the radiation energy.
The distance is always measured from the front edge of the sensor.
3L: SF optics (D:S = 60:1)
Spot size mm 3.3 5.0 7.5 11.7 18.3 26.7 41.7 83.3
Measurement
distance
mm 200 300 450 700 1100 1600 2500 5000
3L: CF optics (D:S = 60:1)
Spot size mm 1.5 2.0 2.5 3.0 3.5 4.2
Measurement
distance
mm 90 120 150 180 210 250
3H: SF optics (D:S = 100:1)
Spot size mm 2.0 3.0 4.5 7.0 11.0 16.0 25.0 50.0
Measurement
distance
mm 200 300 450 700 1100 1600 2500 5000

Page 20
Optics
thermoMETER CTVideo
3H: CF optics (D:S = 100:1)
Spot size mm 0.9 1.2 1.5 1.8 2.1 2.5
Measurement
distance
mm 90 120 150 180 210 250
1L/2L: SF optics (D:S = 150:1)
Spot size mm 1.3 2.0 3.0 4.7 7.3 10.7 16.7 33.3
Measurement
distance
mm 200 300 450 700 1100 1600 2500 5000
1L/2L: CF optics (D:S = 150:1)
Spot size mm 0.6 0.8 1.0 1.2 1.4 1.7
Measurement
distance
mm 90 120 150 180 210 250
1H-H1/2H-H1/3H1-H3: SF optics (D:S = 300:1)
Spot size mm 0.7 1.0 1.5 2.3 3.7 5.3 8.3 16.7
Measurement
distance
mm 200 300 450 700 1100 1600 2500 5000
1H-H1/2H-H1/3H1-H3: CF optics (D:S = 300:1)
Spot size mm 0.3 0.4 0.5 0.6 0.7 0.8
Measurement
distance
mm 90 120 150 180 210 250
