Matrix-710
Linux-Ready Cortex-A5 Industrial
IoT Gateway
Hardware Guide
Version: 1.02
2019 Nov.

Matrix-710 ardware Guide
ARTILA
2
Trademarks
The Artila logo is a registered trademark of Artila Inc. All other trademarks or
registered marks in this manual belong to their respective manufacturers.
Disclaimer
Information in this document is subject to change without notice and does not
represent a commitment on the part of Artila.
Artila provides this document as is, without warranty of any kind, either expressed or
implied, including, but not limited to its particular purpose. Artila reserves the right to
make improvements and/or changes to this manual, or to the products and/or the
programs described in this manual, at any time.
Information provided in this manual is intended to be accurate and reliable.
owever, Artila assumes no responsibility for its use, or for any infringements on the
rights of third parties that may result from its use.
This product might include unintentional technical or typographical errors.
Changes are periodically made to the information herein to correct such errors,
and these changes are incorporated into new editions of the publication.
FCC AND IC INF RMATI N:
This Class A digital apparatus complies with Part 15 of the FCC rules and with
Canadian ICES-003
peration is subject to the following two conditions:
1. This device may not cause interference and
2. This device must accept any interference. Including interference that may
cause undesired operation of the device.

Matrix-710 ardware Guide
ARTILA
3
Document Amendment History
Revision Date Remark
V 1.0 2017 July Initial
V 1.01 2017 Nov. Product Description updated to “IoT Gateway”
V 1.02 2019 Nov. FCC instruction, Spec updated

Matrix-710 ardware Guide
ARTILA
4
Table of Contents
1. Introduction .................................................................................................... 5
1.1 Features .................................................................................................. 5
1.2 Specifications ( ardware)........................................................................ 5
1.3 Specifications (Software) ......................................................................... 7
1.4 Packing List ............................................................................................. 8
1.5 Optional Accessory.................................................................................. 8
2. Layout ............................................................................................................. 9
2.1 Connector & LED Indicator ...................................................................... 9
2.2 Dimension ............................................................................................... 10
3. Pin Assignment and Definitions .................................................................... 11
3.1 Multi-function Reset Button ...................................................................... 11
3.2 LED Indicators ......................................................................................... 12
3.3 Serial Port ............................................................................................... 13
3.4 Power Connector ..................................................................................... 15
3.5 Ethernet LAN Port ................................................................................... 15
3.6 Console Port............................................................................................ 16
3.7 USB Port ................................................................................................. 16
3.8 CAN Bus Port .......................................................................................... 17
3.9 miniPCIe socket ...................................................................................... 18
3.10 SD card socket ........................................................................................ 18

Matrix-710 ardware Guide
ARTILA
5
1. Introduction
Matrix-710 based on ARM Cortex-A5, is a Linux-ready IoT gateway with highly
integrated and low power consumption. Matrix-710 provides an ideal building block
that easily integrates with a wide range of target markets, such as industrial control,
automation, mobile gateway and other applications.
1.1 Features
 ATMEL ATSAMA5D35 536M z Cortex-A5 Processor
 Linux kernel 4.19.x and file system
 Support Toolchain: gcc 8.2.0xx + glibc 2.28xx
 512MB LPDDR2 SDRAM
 8GB eMMC Flash and 8MB DataFlash for system backup
 One Gigabit and one 10/100Mbps Ethernet port
 Four USB 2.0 high speed (480Mbps) ost port
 Four Isolated RS-485 serial port and Four RS-485 serial port
 One RS232 port can be set by sharing with RS-485 port
 Two CAN port
 One microSD socket
 One full size miniPCIe socket inside
 +9 to +48VDC power input
 Ultra-low power consumption, less than 3 Watts
 Wall-mounting, Optional DIN RAIL mounting adaptor
1.2 Specifications (Hardware)
CPU / Memory
• CPU: ATMEL ATSAMA5D35 536M z w/MMU
• SDRAM: 512MB, LPDDR2
• Flash: 8GB, eMMC
• DataFlash: 8MB, for system backup
Network Interface
• Type: 1 x Gigabit and 1 x 10/100Mbps Ethernet
• Connector Type: RJ45
USB 2.0 Host Interface
• ost Ports: 4
• Supports 480Mbps hi-speed mode

Matrix-710 ardware Guide
ARTILA
6
CAN Bus Ports
• Type: 2 x CAN Bus 2.0 A/B compliant ports
• Speed: Up to 1Mbps
• Isolation: 1500Vrms
• CAN 1: 1~2 pin, CAN 2: 3~4 pin, GND: 5 pin
TTY (Serial) Ports
• 4 x Isolated RS-485 (1500Vrms isolation), P1 ~ P4
• 4 x Non-Isolated RS-485, P5 ~ P8
• Port 8 (COM), can be set to RS232 by software
• Direction Control: Auto, by hardware
• Connector: Terminal block
TTY (Serial) Port Parameters
• Baud Rate: Up to 921.6Kbps
• Parity: None, Even, Odd, Mark, Space
• Data Bits: 5, 6, 7, 8
• Stop Bits: 1, 1.5, 2
• Flow Control: RTS / CTS, XON / XOFF, None
Console / Debug Ports
• Support micro-USB console port
• Serial console port (inside the box)
SD Slot
• SD 2.0 compliant, supports SD C
• 1 x microSD socket
• Storage capacity: Support up to 64G
Expansion Slot
• 1 x miniPCIe socket
• Supports Full-size / half-size
Power Requirement
• Input Voltage: 9~48Vdc (terminal block)
• Typical Power Consumption: 230mA@12VDC

Matrix-710 ardware Guide
ARTILA
7
General
• Realtime Clock: Yes, backup by super capacitor
• Buzzer: Yes
• Watchdog: Yes
• Dimensions (W x L x ): 166 x 108 x 35mm (6.54 x 4.25 x 1.37in)
• Weight: 340g (0.75lb)
• Operating Temperature: 0~70°C (32~158°F)
• Regulation: CE Class A, FCC Class A
• Installation: Wall mounting, DIN-rail mounting (with optional kit)
1.3 Specifications (Software)
peration System
• Linux kernel 4.19.x
• Supports bootup from eMMC or SD card
• Support Backup/Restore from SD card or USB device
• Boot Loader: Barebox
• File System: EXT4
Software Development
• Toolchain: gcc 6.2.0xx + glibc 2.24xx
• Supports in-place C/C++ code compilation
Package Management
• Package repository: Artila self-maintained repository
• Command: Using standard apt-get command
Popular Packages
 Web server: Apache/Nginx/Lighttpd
 Database: MySQL/SQLite3/PostgreSQL
 Script Language: P P/Python/Perl/NodeJS
 Text editor: vim/nano/sed
 Administration: Webmin
Software perating & Utility
Please refer to “M-A5D35” SoM (System on Module) information for software
operating & utility at following: http://www.artila.com/download/A5D35/Linux/

Matrix-710 ardware Guide
ARTILA
8
1.4 Packing List
 Matrix-710: Linux-ready Cortex-A5 536M z Industrial IoT Gateway with 512MB
SDRAM, 8GB eMMC Flash
1.5 ptional Accessory
 DK-35A (36-DK35A-000): DIN RAIL Mounting Kit
 PWR-12V-1A (31-62100-000): 110~240VAC to 12VDC 1A Power Adaptor

Matrix-710 ardware Guide
ARTILA
9
2. Layout
2.1 Connector & LED Indicator
GLANLAN
Micro-USB
USB
USB
CAN1 /CAN2
Power Input
P1 ~ P4
(Isolated RS-485)
P5~ P8
(Non-Isolated RS-485)
COM (P8)

Matrix-710 ardware Guide
ARTILA
10
2.2 Dimension
Unit: mm

Matrix-710 ardware Guide
ARTILA
11
3. Pin Assignment and Definitions
3.1 Multi-function Reset Button
The Matrix-710 provides a multi-function reset button located on the right side of the
chassis shown below
The behavior of the reset button depends on how long you press the reset button.
Press and hold the reset
button
Behavior Network settings after
reboot
< 3 seconds then release will re-boot the Matrix-710 Retains last user settings
3~10 seconds then
release
will reset the network
setting to the factory
default
eth0 IP: addr. by D CP
eth1 IP: IP192.168.2.127
> 10 seconds then release
will re-boot the Matrix-710
and restore the FW image
from the SD card (If image
not exist or incorrect will
cause system boot up fail.)
eth0 IP: addr. by D CP
eth1 IP: IP192.168.2.127
Reset
Button

Matrix-710 ardware Guide
ARTILA
12
3.2 LED Indicators
The LED provides the Matrix-710 operation information. The LED status is described
as follow:
 “Ready” (Ready LED indicator): Ready LED will turn on in green color while
power is properly supplied. After system is ready for operation, Ready LED will
keep in solid orange color and a beep will be heard
 “GLAN” & “LAN” (Network LED indicator): Link and Activity LED will turn ON
when the Ethernet cable is connected. When there is network data traffic, this LED
will flash.
 “CAN_1” & “CAN_2” (CAN bus LED indicator): Link and Activity LED will turn ON
when the CAN bus is active. This LED will flash while data communicating.
 “P1 ~ P8” (Serial Port LED indicator): These eight dual color LEDs indicate the
data traffic at the serial ports. When RXD line is high then Green light is ON and
when TXD line is high, Yellow light is ON.
Ready
GLAN
LAN
CAN_1
CAN_2
P1 ~ P8

Matrix-710 ardware Guide
ARTILA
13
3.3 Serial Port
The Matrix-710 provide total eight RS-485 ports with automatic direction control.
P1 to P4: RS485 with 1500Vrms isolation protection.
P5 to P8: RS485 without isolation.
Meanwhile, P8 can be set as RS-232 using the connector labeled ‘COM’.
The pin assignment is shown as following table.
Port No. P1 P2 P3 P4 P5 P6 P7 P8
RS-485 1500Vrms Isolation protection Non-Isolation
RS-232 - - - - - - - Yes
Device
Mapping
ttyS1 ttyS2 ttyS3 ttyS4 ttyUSB0 ttyUSB1 ttyUSB2 ttyUSB3
Pin assignment of RS-485
Pin assignment of RS-232 (Port P8 only)
1 2 3 4 5 6 7 8 9
DCD Rx Tx DTR GND DSR RTS CTS N/A
P1 P2 P3 P4 P5 P6 P7 P8
D+ D- D+ D- D+ D- D+ D- D+ D- D+ D- D+ D- D+ D-
P1 ~ P4 P5 ~ P8 P8 (R -232)

Matrix-710 ardware Guide
ARTILA
14
Enable/Disable Termination resistor for RS-485
The Matrix-710 provides on-board 120Ohm termination resistor for each RS-485 port.
To enable the termination resistor, please remove the upper cover of the Matrix-710,
and the adjust the associated jumper to short position1 and position 2, shown below:
Port No. P1 P2 P3 P4 P5 P6 P7 P8
Jumper No. J2 J3 J4 J5 J7 J8 J9 J10
Termination Resistor Disabled (default)
Termination Resistor Enabled
(J2)
1 2 3
1 2 3
1 2 3

Matrix-710 ardware Guide
ARTILA
15
3.4 Power Connector
Connecting +9 ~ +48VDC power line to the Power in terminal block. In the meantime,
“READY LED” will turn on in green color while power is properly supplied,
After system is ready for operation, “READY LED” will keep in solid orange color and
a beep will be heard.
3.5 Ethernet LAN Port
The Ethernet Port use RJ45 connector for both 10/100LAN port and GigaLAN port.
Pin definition of 10/100Base-T LAN port
PIN Signal
1 ETX +
2 ETX -
3 ERX +
6 ERX -
Pin definition of GigaLAN port
PIN Signal
1 TP0 +
2 TP0 -
3 TP1 +
6 TP1 -
4 TP2 +
5 TP2 -
7 TP3 +
8 TP3 -

Matrix-710 ardware Guide
ARTILA
16
3.6 Console Port
There are two serial console ports for use:
• Micro-USB connector which is USB client acts as serial console port.
• Debug Console: There is a 4-pin wafer box header (JP3) inside the box.
Pin assignment is: RX, TX, +3.3V, GND.
Therefore, you need to open the upper metal case and prepare or purchase a
serial console cable to use the serial console port.
Or, it can be purchased “Console Cable” from Artila, P/N is CB-P DF9-050.
3.7 USB Port
Four type-A USB 2.0 ports are built for operation.
1
2
3
4
RX
TX
+3.3V
GND

Matrix-710 ardware Guide
ARTILA
17
3.8 CAN Bus Port
The Matrix-710 comes with two CAN bus ports. Users can open the CAN bus ports as
network sockets, the socket names are ‘can0’ and ‘can1’ respectively.
Port Label. CAN1 CAN2
Socket Mapping can0 can1
Pin assignment of CAN Bus Port
Enable/Disable Termination resistor for CAN bus
The Matrix-710 provides on-board 120Ohm termination resistor for each CAN bus
port. To enable the termination resistor, please remove the upper cover of the
Matrix-710, and the adjust the associated jumper to short position1 and position 2,
shown below:
CAN Port No. CAN2 CAN1
Jumper No. JP5 JP4
Termination Resistor
Disabled (Default)
Termination Resistor
Enabled
Pin 5 4 3 2 1
Signal GND CAN2_Lo CAN2_ i CAN1_Lo CAN1_ i
GND, CAN2_Lo, CAN2_ i, CAN1_Lo,
1 2 3
1 2 3

Matrix-710 ardware Guide
ARTILA
18
3.9 miniPCIe socket
The Matrix-710 comes with a miniPCIe socket also SIM card socket reserved for
communication/networking functionality.
3.10 SD card socket
There is a SD card socket inside as data storage. It can be accessed by opening top
cover.
Full Size
Half size
SD Card
Socket
