Aruba 320 Series Access Points
Installation Guide
AP-320-IG-01 | October 2017 1
Aruba 320 Series access points (AP-324, AP-325, IAP-324, and IAP-325) support IEEE 802.11ac standards for high-
performance WLAN, and is equipped with two dual-band radios that can provide access and monitor the
network simultaneously. Multi-user, Multiple-In, Multiple-Out (MU-MIMO) technology allows this access point to
deliver high-performance 802.11n 2.4GHz and 802.11ac 5GHz functionality, while also supporting 802.11a/b/g
wireless services.
The AP-324 and AP-325 work in conjunction with an Aruba Controller, while the IAP-324 and IAP-325 can be
configured using a built-in virtual controller.
The Aruba 320 Series provides the following capabilities:
Dual wireless transceiver
IEEE 802.11a/b/g/n/ac operation as a wireless access point
IEEE 802.11a/b/g/n/ac operation as a wireless Air Monitor
IEEE 802.11a/b/g/n/ac operation as a Spectrum Analysis
Compatible with IEEE 802.3at PoE power sources
Centralized management configuration and upgrades
Integrated Bluetooth Low Energy (BLE) radio
Package Contents
The following materials are included with this product:
Aruba 320 Series access point
9/16” and 15/16” Ceiling Rail Adapters
Installation Guide (this document)
Startup Guide
Declaration of Conformity document
End-User License Agreement document
Hardware Overview
The following sections outline the hardware components of the 320 Series access point.
Inform your supplier if there are any incorrect, missing, or damaged parts. If possible, retain the carton, including
the original packing materials. Use these materials to repack and return the unit to the supplier if needed.

2Aruba 320 Series Access Points | Installation Guide
Figure 1 Aruba AP-325 (front view)
LED
The 320 Series access points have LED displays located on the front panel of the access point indicating the
following functions:
System Status
The System Status LED indicates the operating condition of the access point, See Table 1.
Table 1 System Status LEDs
Radio Status
The Radio Status LED indicates the operating mode of the access point’s radios. See Table 2.
Table 2 Radio Status LEDs
Color/State Meaning
Off Device powered off
Green- solid Device ready for use
Amber- solid Device ready; power-save mode (802.3af PoE):
Single radio
USB disabled
Green/Amber- flashing Device operating in restricted mode. Meets one of the following conditions:
Uplink negotiated in sub-optimal speed; or
Radio in non-high throughput (HT) mode
Green/Amber- alternating Device booting; not ready
Color/State Meaning
Off Device powered off, or both radios disabled
Green- solid Both radios enabled in access mode

Aruba 320 Series Access Points | Installation Guide 3
LED Display Settings
The LEDs have three operating modes that can be selected in the system management software:
Default mode: Refer to Table 1 and Table 2
Off mode: LEDs are off
Blink mode: LEDs blink green
Figure 2 320 Series Access Point (rear view)
External Antenna Connectors
The AP-324 and IAP-324 access points are equipped with four external antenna connectors located
on the front corners of the access point (see Figure 3).
Amber- solid Both radios enabled in monitor mode
Green/Amber- alternating One radio enabled in access mode, one enabled in monitor mode
Color/State Meaning
12V 2.5A . . .
12V ... 2.5A

4Aruba 320 Series Access Points | Installation Guide
Figure 3 External Antenna Connectors
Bluetooth Low Energy Radios
320 Series access points are equipped with an integrated BLE radio that provide the following capabilities:
location beacon applications
wireless console access
Console Port
The serial console port allows the user to connect the access point to a serial terminal or a laptop for direct local
management. This port is an RJ45 connector, with pin-out details in Figure 4. Connect it directly to a terminal or
terminal server using an Ethernet cable.
Figure 4 Serial Port Pin-out
Ethernet Ports
The 320 Series is equipped with two 10/100/1000 Base-T (RJ45) auto-sensing, MDI/MDX wired-network
connectivity ports. These ports support IEEE 802.3af and 802.3at Power over Ethernet (PoE) compliant sources,
ANT1 ANT0
ANT2 ANT3
!
External antennas for this device must be installed by an Aruba Certified Mobility Professional (ACMP) or other
Aruba-certified technician, using manufacturer-approved antennas only.
The Equivalent Isotropically Radiated Power (EIRP) levels for all external antenna devices must not exceed the
regulatory limit set by the host country/domain.
Installers are required to record the antenna gain for this device in the system management software.
Les antennes externes pour cet appareil doivent être installées par un professionnel de la mobilité certifié Aruba
(ACMP) ou un autre technicien certifié Aruba, en utilisant uniquement des antennes approuvées par le fabricant.
Les niveaux équivalents de puissance à rayonnement isotrope (EIRP) pour tous les périphériques d'antenne
externe ne doivent pas dépasser la limite réglementaire définie par le pays hôte / domaine.
Les installateurs doivent enregistrer le gain d'antenne pour cet appareil dans le logiciel de gestion du système.

Aruba 320 Series Access Points | Installation Guide 5
accepting 56V DC (nominal) as a standard defined Powered Device (PD) from a Power Sourcing Equipment (PSE),
such as a PoE midspan injector, or network infrastructure that supports PoE.
The 10/100/1000 Mbps Ethernet ports are on the bottom of the access point. These ports have RJ45 female
connectors with the pin-outs shown in Figure 5.
Figure 5 Gigabit Ethernet Port Pin-Out
Kensington Lock Slot
The 320 Series is equipped with a Kensington lock slot for additional security.
USB Interface
The 320 Series is equipped with a USB port for connectivity with cellular modems and other USV client devices.
When powered by an 802.3at or DC source the USB port can supply up to 5W. The USB is disabled with powered
by an 802.3af PoE source.
Figure 6 USB Port
Reset Button
The reset button can be used to return the access point to factory default settings. To reset the access point,
refer to the following steps:
1. Power off the access point.
2. Press and hold the push button using a small, narrow object, such as a paper clip.
3. Power-on the access point without releasing the push button. The System Status LED will flash within 5
seconds.
4. Release the reset button.
The system status LED will flash again within 15 seconds indicating that the reset is completed. The access point
will now continue to boot with the factory default settings.
Power
The E0 and E1 ports support PoE-in, allowing the device to draw power from an 802.3at source (recommended)
or an 802.3af source. When both PoE and DC power sources are available, the access point defaults to using the
DC power source.
If PoE is not available, the 320 Series has a single 12V/30W DC power jack socket to support the AP-AC-12V30UN
AC-to-DC adapter kit (sold separately).
Power Modes
The 320 Series can operate in two power modes. The modes are not configurable and are determined by the
access point based on the amount of power available.
1000Base-T Gigabit
Ethernet Port
RJ-45 Female
Pin-Out
Signal Name
1
2
3
4
5
6
7
8
BI_DC+
BI_DC-
BI_DD+
BI_DD-
BI_DA+
BI_DA-
BI_DB+
BI_DB-
Function
Bi-directional pair +C
Bi-directional pair -C
Bi-directional pair +D
Bi-directional pair -D
Bi-directional pair +A
Bi-directional pair -A
Bi-directional pair +B
Bi-directional pair -B

6Aruba 320 Series Access Points | Installation Guide
The 320 Series access points operate without restrictions when powered by a DC or 802.3at PoE source. When
powered by an 802.3af PoE source, the following restrictions apply:
Second Ethernet Port disabled
USB interface disabled
2.4 GHz in 1x1:1 mode
Before You Begin
Refer to the sections below before beginning the installation process.
Pre-Installation Checklist
Before installing your Aruba 320 Series access point, be sure that you have the following:
Cat5E UTP cable with network access installed in the wall box
One of the following network services:
IEEE 802.3at or 802.3af-compliant Power over Ethernet (PoE) source. The PoE source can be any power
source equipment (PSE) controller or midspan PSE device
Aruba APAC-DC adapter kit (sold separately)
For AP-324 and AP-325 only:
Aruba Controller provisioned on the network:
Layer 2/3 network connectivity to your access point
One of the following network services:
Aruba Discovery Protocol (ADP)
DNS server with an “A” record
DHCP Server with vendor-specific options
Pre-Installation Connectivity
Before installing access points in a network environment, make sure that they are able to locate and connect to
the controller after power on.
Specifically, verify the following conditions:
When connected to the network, each access point is assigned a valid IP address
!
FCC Statement: Improper termination of access points installed in the United States configured to non-US
model controllers will be in violation of the FCC grant of equipment authorization. Any such willful or intentional
violation may result in a requirement by the FCC for immediate termination of operation and may be subject to
forfeiture (47 CFR 1.80).
EU Statement: Low power radio LAN product operating in 2.4GHz and 5 GHz bands. Refer to the ArubaOS User
Guide/Aruba Instant User Guide for details on restrictions.
Produit réseau local radio basse puissance operant dans la bande fréquence 2.4 GHz et 5 GHz. Merci de vous
referrer au ArubaOS User Guide/Aruba Instant User Guide pour les details des restrictions.
Low Power FunkLAN Produkt, das im 2.4 GHz und im 5 GHz Band arbeitet. Weitere Informationen bezlüglich
Einschränkungen finden Sie im ArubaOS User Guide/Aruba Instant User Guide.
Apparati Radio LAN a bassa Potenza, operanti a 2.4 GHz e 5 GHz. Fare riferimento alla ArubaOS User Guide/Aruba
Instant User Guide per avere informazioni detagliate sulle restrizioni.
Aruba Networks, Inc., in compliance with governmental requirements, has designed the 320 Series access points
so that only authorized network administrators can change the settings. For more information about access
point configuration, refer to the ArubaOS Quick Start Guide/Aruba Instant Quick Start Guide and ArubaOS User
Guide/Aruba Instant User Guide.
The instructions for this section are applicable to the AP-324 and AP-325 only.

Aruba 320 Series Access Points | Installation Guide 7
Access points are able to locate the controller
Refer to the ArubaOS Quick Start Guide for instructions on locating and connecting to the controller.
Identifying Specific Installation Locations
This access point should be oriented vertically, with rubber pads facing downward to facilitate maximum
antenna gain. Mount the 320 Series on a wall or on the ceiling. Use the access point placement map generated
by Aruba RF Plan software application to determine the proper installation location(s). Each location should be
as close as possible to the center of the intended coverage area and should be free from obstructions or obvious
sources of interference. These RF absorbers/reflectors/interference sources will impact RF propagation and
should be accounted for during the planning phase and adjusted for in RF plan.
Identifying Known RF Absorbers/Reflectors/Interference Sources
Identifying known RF absorbers, reflectors, and interference sources while in the field during the installation
phase is critical. Make sure that these sources are taken into consideration when you attach an access point to its
fixed location.
RF absorbers include:
Cement/concrete—Old concrete has high levels of water dissipation, which dries out the concrete, allowing
for potential RF propagation. New concrete has high levels of water concentration in the concrete, blocking
RF signals.
Natural Items—Fish tanks, water fountains, ponds, and trees
Brick
RF reflectors include:
Metal Objects—Metal pans between floors, rebar, fire doors, air conditioning/heating ducts, mesh windows,
blinds, chain link fences (depending on aperture size), refrigerators, racks, shelves, and filing cabinets.
Do not place an access point between two air conditioning/heating ducts. Make sure that access points are
placed below ducts to avoid RF disturbances.
RF interference sources include:
Microwave ovens and other 2.4 or 5 GHz objects (such as cordless phones)
Cordless headset such as those used in call centers or lunch rooms
Access Point Installation
!
RF Radiation Exposure Statement: This equipment complies with FCC RF radiation exposure limits. This
equipment should be installed and operated with a minimum distance of 7.87 inches (20cm) between the
radiator and your body for 2.4 GHz and 5 GHz operations. This transmitter must not be co-located or operating
in conjunction with any other antenna or transmitter. When operated in 5.15 to 5.25 GHz frequency range, this
device is restricted to indoor use to reduce the potential for harmful interference with co-channel Mobile
Satellite Systems.
Déclaration sur les limites d'exposition aux radiofréquences : cet équipement est conforme aux limites
d'exposition aux rayonnements radioélectriques spécifiées par la FCC. Il doit être installé et utilisé à une distance
minimale de 20 cm par rapport à votre corps pour les fréquences de 2,4 et 5 GHz. Cet émetteur-récepteur ne
doit pas être utilisé ou situé à proximité d'autres antennes ou émetteurs-récepteurs. En cas d'utilisation dans la
plage de fréquences de 5,15 à 5,25 GHz, cet appareil doit uniquement être utilisé en intérieur afin de réduire les
risques d'interférence avec les systèmes satellites mobiles partageant le même canal.
!
All Aruba access points should be professionally installed by an Aruba-Certified Mobility Professional (ACMP).
The installer is responsible for ensuring that grounding is available and meets applicable national and electrical
codes. Failure to properly install this product may result in physical injury and/or damage to property.
Tous les points d'accès Aruba doivent impérativement être installés par un professionnel agréé. Ce dernier doit
s'assurer que l'appareil est mis à la terre et que le circuit de mise à la terre est conforme aux codes électriques
nationaux en vigueur. Le fait de ne pas installer correctement ce produit peut entraîner des blessures
corporelles et / ou des dommages matériels.

8Aruba 320 Series Access Points | Installation Guide
Using the Ceiling Rail Adapter
The 320 Series ships with two ceiling rail adapters for 9/16” and 15/16” ceiling rails. Additional wall mount
adapters and ceiling rail adapters for other rail styles are available as accessory kits.
Use the steps in this section to install the 320 Series access point.
1. Pull the necessary cables through a prepared hole in the ceiling tile near where the access point will be
placed.
2. Place the adapter against the back of the access point with the adapter at an angle of approximately 30
degrees to the tabs. See Figure 7.
3. Twist the adapter clockwise until it snaps into place in the tabs. See Figure 7.
Figure 7 Attaching the Ceiling Rail Adapter
4. If necessary, connect the console cable to the console port on the back of the access point.
5. Hold the access point next to the ceiling tile rail with the ceiling tile rail mounting slots at approximately a 30-
degree angle to the ceiling tile rail. See Figure 8. Make sure that any cable slack is above the ceiling tile.
6. Pushing toward the ceiling tile, rotate the access point clockwise until the device clicks into place on the
ceiling tile rail.
Figure 8 Mounting the Access Point
7. On the AP-324 and IAP-324, install the external antennas according to the manufacturer’s instructions, and
connect the antennas to the antenna interfaces on the access point.
Connecting Required Cables
Install cables in accordance with all applicable local and national regulations and practices.
!
The installer is responsible for securing the access point onto the ceiling tile rail in accordance with the steps
below. Failure to properly install this product may result in physical injury and/or damage to property.

Aruba 320 Series Access Points | Installation Guide 9
Software
AP-324 and AP-325 require ArubaOS 6.4.4 or higher. For additional information, refer to the ArubaOS User Guide
and ArubaOS Quick Start Guide.
IAP-324 and IAP-325 require Aruba Instant 4.2.1 or higher. For additional information, refer to the Aruba Instant
User Guide or the Aruba Instant Quick Start Guide.
Verifying Post-Installation Connectivity
The integrated LED on the access point can be used to verify that the access point access point is receiving power
and initializing successfully (see Table 1 and Table 2). Refer to the ArubaOS Quick Start Guide for further details on
verifying post-installation network connectivity.
Configuring the 320 Series
Access Point Provisioning/Reprovisioning
Provisioning parameters are unique to each access point. These local access point parameters are initially
configured on the controller, and are then pushed out to the access points and stored on the devices. Aruba
recommends that provisioning settings be configured via the ArubaOS Web UI only. Refer to the ArubaOS User
Guide for complete details.
Access Point Configuration
Configuration parameters are network or controller specific and are configured and stored on the controller.
Network configuration settings are pushed out to the access points, but remain stored on the controller.
Configuration settings can be configured via the ArubaOS Web US or ArubaOS CLI. Refer to their respective
guides for further details in the ArubaOS User Guide.
Electrical and Environmental Specifications
For additional specifications on this product, please refer to the product data sheet at arubanetworks.com.
Electrical
Ethernet:
2x 10/100/1000 Base-T auto-sensing Ethernet RJ45 Interface (E0-E1)
Maximum power consumption (excluding USB): 20W (PoE) or 18.5 W (DC)
IEEE 802.3 (10 Base-T), IEEE 802.3u (100 Base-T); IEEE 802.3ab (1000 Base-T)
Power over Ethernet (IEEE 802.3af compliant), 48VDC (nominal) or 52V DC (nominal) and 57 VDC/350mA
(maximum)
Power:
12 VDC power interface, supports powering through an AC-to-DC power adapter (AP-AC-12V36UN)
POE support on Ethernet ports: 802.3af-compliant PoE sourcing device
!
Access points are radio transmission devices and are subject to governmental regulation. Network
administrators responsible for the configuration and operation of access points must comply with local
broadcast regulations. Specifically, access points must use channel assignments appropriate to the location in
which the access point is used.
The instructions for this section are applicable to the AP-324 and AP-325 only.
If a power adapter other than the Aruba-approved adapter is used in the US or Canada, it should be NRTL listed,
with an output rated 48VDC, minimum 2A, marked “LPS” and “Class 2”, and suitable for pluggging into a standard
power receptacle in the US and Canada.

10 Aruba 320 Series Access Points | Installation Guide
Environmental
Operating:
Temperature: 0°C to +50°C (+32°F to +122°F)
Humidity: 5% to 93% non-condensing
Storage and transport:
Temperature: -40°C to +70°C (-40°F to +158°F)
Humidity: 5% to 93% non-condensing
Proper Disposal of Aruba Equipment
Dispose of Aruba products per local regulation. For the most current information about Global Environmental
Compliance and Aruba products, see our website at www.arubanetworks.com.
Waste of Electrical and Electronic Equipment
Aruba products at end of life are subject to separate collection and treatment in the EU
Member States, Norway, and Switzerland and therefore are marked with the symbol shown at
the left (crossed-out wheelie bin). The treatment applied at end of life of these products in
these countries shall comply with the applicable national laws of countries implementing
Directive 2002/96EC on Waste of Electrical and Electronic Equipment (WEEE).
China RoHS
Aruba products also comply with China environmental declaration requirements and are packaged with the
“EFUP10” label shown below.

Aruba 320 Series Access Points | Installation Guide 11
Taiwan
European Union RoHS
Aruba products comply with the EU Restriction of Hazardous Substances Directive 2011/65/EC (RoHS). EU RoHS
restricts the use of specific hazardous materials in the manufacture of electrical and electronic equipment.
Specifically, restricted materials under the RoHS Directive are Lead (including Solder used in printed circuit
assemblies), Cadmium, Mercury, Hexavalent Chromium, and Bromine. Some Aruba products are subject to the
exemptions listed in RoHS Directive Annex 7 (Lead in solder used in printed circuit assemblies).
India RoHS
This product complies with RoHS requirements as prescribed by E-Waste (Management & Handling) Rules,
governed by the Ministry of Environment & Forests, Government of India.
Turkey RoHS
Ukraine RoHS
Regulatory Information
For the purpose of regulatory compliance certifications and identification, this product has been assigned a
unique regulatory model number. The regulatory model number can be found on the product nameplate label,
along with all required approval markings and information. When requesting compliance information for this
product, always refer to this regulatory model number. The regulatory model number is not the marketing name
or model number of the product.
AP-324/IAP-324: APIN324
AP-325/IAP-325: APIN325

12 Aruba 320 Series Access Points | Installation Guide
Federal Communication Commission
This device is electronically labeled. Use the following steps to view the FCC ID:
1. Log in to the controller WebUI.
2. Navigate to Maintenance > About
FCC Class B Part 15
This device complies with the limits of Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1)this device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit that is different from that to which the receiver is
connected.
Consult the dealer or an experienced radio or television technician for help.
This device complies with the Class B limits for radio noise emissions as set out in the interference-causing
equipment standard entitled “Digital Apparatus,” ICES-003 of Industry Canada.
Users are advised that high power Radars are allocated as primary users of the bands 5250-5350 MHz and 5650-
5850 MHz and these Radars could cause interference and/or damage to License Exempt WLAN devices.
European Union
The Declaration of Conformity made under RED Directive 2014/53/EU is available for viewing at:
arubanetworks.com, then navigate to the Declarations of Conformity > Access Point folder, select the
document that corresponds to your device’s model number as it is indicated on the product label.
Wireless Channel Restrictions
5150-5250MHz band is limited to indoor only in the following countries; Austria (AT), Belgium (BE), Bulgaria (BG),
Croatia (HR), Cyprus (CY), Czech Republic (CZ), Denmark (DK), Estonia (EE), Finland (FI), France (FR), Germany (DE),
!
Changes or modifications to this unit not expressly approved by the party responsible for regulatory compliance
could void the user’s authority to operate this equipment.
Toute modification effectuée sur cet équipement sans l'autorisation expresse de la partie responsable de la
conformité est susceptible d'annuler son droit d'utilisation.
!
Improper termination of access points installed in the United States configured to a non-US model controller is a
violation of the FCC grant of equipment authorization. Any such willful or intentional violation may result in a
requirement by the FCC for immediate termination of operation and may be subject to forfeiture (47 CFR 1.80).
The network administrator(s) is/are responsible for ensuring that this device operates in accordance with local/
regional laws of the host domain.
!
Changes or modifications to this unit not expressly approved by the part responsible for compliance could void
the user’s authority to operate this equipment.
Toute modification effectuée sur cet équipement sans l'autorisation expresse de la partie responsable de la
conformité est susceptible d'annuler son droit d'utilisation.

Aruba 320 Series Access Points | Installation Guide 13
Greece (GR), Hungary (HU), Iceland (IS), Ireland (IE), Italy (IT), Latvia (LV), Liechtenstein (LI), Lithuania (LT),
Luxembourg (LU), Malta (MT), Netherlands (NL), Norway (NO), Poland (PL), Portugal (PT), Romania (RO), Slovakia
(SK), Slovenia (SL), Spain (ES), Sweden (SE), Switzerland (CH), Turkey (TR), United Kingdom (UK).
Industry Canada
This Class B digital apparatus meets all of the requirements of the Canadian Interference-Causing Equipment
Regulations.
In accordance with Industry Canada regulations, this radio transmitter and receiver may only be used with an
antenna, the maximum type and gain of which must be approved by Industry Canada. To reduce potential radio
interference, the type of antenna and its gain shall be chosen so that the equivalent isotropic radiated power
(EIRP) does not exceed the values necessary for effective communication.
This device complies with Industry Canada's license-exempt RSS regulations. Operation of this device is subject
to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired operation.
Déclaration d’Industrie Canada
Conformément aux réglementations d’Industrie Canada, cet émetteur-récepteur radio doit être utilisé
uniquement avec une antenne dont le type et le gain maximal doivent être approuvés par Industrie Canada.
Pour réduire les interférences radio potentielles, le type d’antenne et son gain doivent être choisis de façon à ce
que la puissance isotrope rayonnée équivalente (PIRE) ne dépasse pas les valeurs nécessaires à une
communication efficace.
Ce périphérique est conforme aux règlements RSS exempts de licence d’Industrie Canada. L’utilisation de ce
périphérique est soumise aux deux conditions suivantes: (1) ce périphérique ne doit pas provoquer
d’interférences, et (2) ce périphérique doit accepter toute interférence, y compris les interférences susceptibles
de provoquer un dysfonctionnement.
Frequency Range MHz Max EIRP
2412-2472 20 dbm
5150-5250 23 dbm
5250-5350 23 dbm
5470-5725 30 dbm
5725-5850 N/A for EU
!
Lower power radio LAN product operating in 2.4 GHz and 5 GHz bands. Please refer to the ArubaOS User Guide/
Instant User Guide for details on restrictions.
Produit réseau local radio basse puissance operant dans la bande fréquence 2.4 GHz et 5 GHz. Merci de vous
referrer au ArubaOS User Guide/Instant User Guide pour les details des restrictions.
Low Power FunkLAN Produkt, das im 2.4 GHz und im 5 GHz Band arbeitet. Weitere Informationen bezlüglich
Einschränkungen finden Sie imArubaOS User Guide/Instant User Guide.
Apparati Radio LAN a bassa Potenza, operanti a 2.4 GHz e 5 GHz. Fare riferimento alla ArubaOS User Guide/
Instant User Guide per avere informazioni detagliate sulle restrizioni.

14 Aruba 320 Series Access Points | Installation Guide
Japan
Brazil
Este equipamento opera em caráter secundário, isto é, não tem direito a proteção contra interferência
prejudicial, mesmo de estações do mesmo tipo, e não pode causar interferência a sistemas operando em
caráter primário.
Mexico
La operación de este equipo está sujeta a las siguientes dos condiciones: (1) es posible que este equipo o
dispositivo no cause interferencia perjudicial y (2) este equipo o dispositivo debeaceptar cualquier interferencia,
incluyendo la que pueda causar su operación no deseada.
Korean
이 기기는 업무용 환경에서 사용할 목적으로 적합성평가를 받은 기기로서 가정용 환경에서 사용하는 경우 전파간섭
의 우려가 있습니다 .
=> 사용자 안내문은 “ 업무용방송통신기자재 ’ 에만 해당된다
Taiwan
Medical
1. Equipment not suitable for use in the presence of flammable mixtures.
2. Connect to only IEC 60950-1 or IEC 60601-1 3rd edition certified products and power sources. The end user is
responsible for the resulting medical system complies with the requirements of IEC 60601-1 3rd edition.
3. Wipe with a dry cloth, no additional maintenance required.
4. No serviceable parts, the unit must be sent back to the manufacturer for repair.
5. No modifications are allowed without Aruba approval.
Expected Service Life 10 years. For additional compliance information, refer to the regulatory label on the back of
this device.
