Aruba 570EX Series Hazardous Location
Access Points
Installation Guide
Rev 02 | November 2020 1
The Aruba 570EX Series outdoor wireless access points (AP-575EX and AP-577EX) are high-performance, multi-
radio wireless devices that can be deployed in either controller-based (ArubaOS) or controllerless (Aruba Instant)
network environment.
The Aruba 570EX Series access points support IEEE 802.11ax standard, delivering high performance with the MU-
MIMO (Multi-User Multiple-Input, Multiple-Output) technology, while also supporting 802.11a/b/g/n/ac wireless
services.
Package Contents
570EX Series access point
Cable gland x 2
USB Type-C console cable x 1
Grounding lug and M4x6 screw x 1
Tools Required
Phillips screwdriver (#2 for M4x6 screw)
Flat blade screwdriver (Ethernet cable gland covers)
8mm allen or hex key (USB console cover)
The weatherproof caps for Ethernet and Console interfaces are connected to the access point, not loose in the
package.
Mounting kits for use with the 570EX Series access points are sold separately. Contact your Aruba sales
representative for details.
Inform your supplier if there are any incorrect, missing, or damaged parts. If possible, retain the carton,
including the original packing materials. Use these materials to repack and return the unit to the supplier if
needed.

2Aruba 570EX Series Hazardous Location Access Points | Installation Guide
Hardware Overview
Figure 1 AP-575EX Front View

Aruba 570EX Series Hazardous Location Access Points | Installation Guide 3
Figure 2 AP-575EX Rear View
USB Console Port
& Reset Button
E1
Grounding Point
E0
System LED

4Aruba 570EX Series Hazardous Location Access Points | Installation Guide
Figure 3 AP-577EX Front View
Figure 4 AP-577EX Rear View
USB Console Port
& Reset Button
System LED
E1Grounding Point E0

Aruba 570EX Series Hazardous Location Access Points | Installation Guide 5
LED
The 570EX Series access point is equipped with one LED that indicates the system status of the access point.
Table 1 570EX Series LED Meanings during Boot Up
Table 2 570EX Series LED Meanings during Operation
Ethernet Ports
The Aruba 570EX Series access points are equipped with two Ethernet ports (E0 and E1):
E0 port: 100/1000/2500Base-T auto-sensing MDI/MDX wired RJ45 network connectivity port
E1 port: 100/1000Base-T auto-sensing MDI/MDX wired RJ45 network connectivity port
Power
Both E0 and E1 ports support PoE-in, allowing the AP to draw power from an 802.3at/802.3bt PoE power source.
When the AP is powered by both E0 and E1 ports simultaneously, the AP can be configured by management
software to source PoE power from either port, or to combine power from both ports.
The 570EX Series access points support the Intelligent Power Monitoring (IPM) feature, to report AP power
consumption and enable intelligent management of power-save capabilities.
Table 3 lists operational restrictions when the AP is powered by different power options.
Table 3 Power Options and Operational Restrictions
LED Color/State Meaning
System LED Off No power to AP
Red Initial power-up
Green - Flashing AP booting, not ready
Green - Steady AP ready and Gigabit Ethernet connected. The LED turns off after
1200 seconds
Green - Yellow, 6 seconds
period AP ready and 10/100Mbps Ethernet link established. The LED turns off after 1200 seconds
LED Color/State Meaning
System LED Solid Red General fault - Immediate attention required
One blink off every 3
seconds Radio 0 fault (5GHz)
Two quick blink off 0.5
seconds apart cycled every
3 seconds
Radio 1 fault (2.4GHz)
Power Source IPM Restrictions
1 x 802.3bt PoE n/a No restrictions, all capabilities available.
2 x 802.3at PoE n/a No restrictions, all capabilities available.
1 x 802.3at PoE enabled AP starts up in unrestricted mode, but may dynamically
apply restrictions depending on the PoE budget and actual
power.
1 x 802.3at PoE disabled Second (other) Ethernet port disabled.
1 x 802.3af PoE n/a AP does not start up, red system LED.

6Aruba 570EX Series Hazardous Location Access Points | Installation Guide
Grounding Point
Always remember to protect the access point by installing grounding lines. The ground connection must be
complete before connecting power to the access point enclosure.
USB Type-C Console Port
Use the included USB Type-C console cable to connect the access point to a laptop or a serial terminal for direct
management.
Reset Button
The reset button can be used to reset the access point to factory default settings or turn off/on the LED display.
There are two ways to reset the access point to factory default settings:
Reset the AP during normal operation
Press and hold down the reset button using a small, narrow object such as a paper clip for more than 10
seconds during normal operation.
Reset the AP while powering up
1. Press and hold down the reset button using a small, narrow object such as a paper clip while the access point
is not powered on via PoE.
2. Connect the power supply (PoE) to the access point while the reset button is being held down.
3. Release the reset button on the access point after 15 seconds.
To turn off/on the LED display, press and release the reset button using a small, narrow object, such as a
paperclip for less than 10 seconds during normal operation of the access point.
Before You Begin
Refer to the sections below before beginning the installation process.
Pre-Installation Checklist
Before installing your 570EX Series access point, be sure that you have the following:
Cat5E or better UTP cable with network access
A compatible PoE injector with power cord
One of the following network services:
Aruba Discovery Protocol (ADP)
DNS server with an “A” record
DHCP Server with vendor specific options
You need a proper 8mm allen or hex key to open the cover of the USB Console port.
!
FCC Statement: Improper termination of access points installed in the United States configured to non-US
model controllers will be in violation of the FCC grant of equipment authorization. Any such willful or
intentional violation may result in a requirement by the FCC for immediate termination of operation and may
be subject to forfeiture (47 CFR 1.80).
Aruba, in compliance with governmental requirements, has designed the 570EX Series access points so that
only authorized network administrators can change configuration settings. For more information about AP
configuration, refer to the AP Software Quick Start Guide.

Aruba 570EX Series Hazardous Location Access Points | Installation Guide 7
Outdoor Planning and Deployment Considerations
Prior to deploying an outdoor wireless network, the environment must be evaluated to plan for a successful
WLAN deployment. Successfully evaluating the environment enables the proper selection of routers and
antennas and assists in the determination of their placement for optimal RF coverage. This process is considered
WLAN or RF planning and Aruba’s system engineers can assist in the outdoor planning process.
Identifying Specific Installation Locations
Use the access point placement map generated by Aruba RF Plan software application to determine the proper
installation location(s). Each location should be as close as possible to the center of the intended coverage area
and should be free from obstructions or obvious sources of interference. These RF absorbers/reflectors/
interference sources will impact RF propagation and should be accounted for during the planning phase and
adjusted for in RF plan.
Identifying Known RF Absorbers/Reflectors/Interference Sources
Identifying known RF absorbers, reflectors, and interference sources while in the field during the installation
phase is critical. Make sure that these sources are taken into consideration when you attach an access point to its
fixed location.
RF absorbers include:
Cement/concrete—Old concrete has high levels of water dissipation, which dries out the concrete, allowing
for potential RF propagation. New concrete has high levels of water concentration in the concrete, blocking
RF signals.
Natural Items—Fish tanks, water fountains, ponds, and trees
Brick
RF reflectors include:
Metal Objects—Metal pans between floors, rebar, fire doors, air conditioning/heating ducts, mesh windows,
blinds, chain link fences (depending on aperture size), refrigerators, racks, shelves, and filing cabinets.
Do not place an access point between two air conditioning/heating ducts. Make sure that access points are
placed below ducts to avoid RF disturbances.
RF interference sources include:
Microwave ovens and other 2.4 or 5 GHz objects (such as cordless phones)
Cordless headset such as those used in call centers or lunch rooms
Access Point Installation
!
Access points are radio transmission devices and as such are subject to governmental regulation. Network
administrators responsible for the configuration and operation of access points must comply with local
broadcast regulations. Specifically, access points must use channel assignments appropriate to the location in
which the access point will be used.
The rules for the 5600-5650 MHz band vary by region.
!
Use of this equipment adjacent to or stacked with other equipment should be avoided because it could result in
improper operation. If such use is necessary, this equipment and the other equipment should be observed to
verify that they are operating normally.
Service to all Aruba products should be performed by trained service personnel only.

8Aruba 570EX Series Hazardous Location Access Points | Installation Guide
Using Mount Kits
The 570EX Series access point can be installed on a wall or attached to a pole by using mount kits:
Grounding the Access Point
The grounding must be completed before powering up the access point. The grounding wire should be #8 AWG.
1. Peel the cover of one end of the grounding wire and place the bare grounding wire into the grounding lug
(included in the package), and press firmly with the crimping pliers.
2. Fasten the grounding lug to the grounding hole on the access point with the M4x6 screw (included in the
package). We recommend to torque the M4x6 screw to 1.5 N.m.
Connecting the Ethernet Cable
To connect the Ethernet cable to the access point, perform the following steps.
Table 4 Applicable Mount Kits for 570EX Series Access Point
Part Number Description
JW052A AP-270-MNT-V1 long mount kit for wall and vertical pole mounting, 300 mm from
vertical mounting asset.
JW053A AP-270-MNT-V2 short mount kit for wall and vertical pole mounting, 75 mm from
vertical mounting asset.
JW054A AP-270-MNT-H1 mount kit for hanging from inclined or horizontal structure.
JW055A AP-270-MNT-H2 flush mount kit for wall and ceiling mounting.
The 570EX Series access point does not ship with any mount kits. These mount kits are available as accessories
and must be ordered separately.
For installation instructions on AP-270-MNT-V1, AP-270-MNT-V2, AP-270-MNT-H1 and AP-270-MNT-H2 mount
kit, please refer to the AP-270-MNT-V1 Installation Guide, AP-270-MNT-V2 Installation Guide, AP-270-MNT-H1
Installation Guide and AP-270-MNT-H2 Installation Guide respectively.
!
This 570EX Series access point is intended for installation in a RESTRICTED ACCESS LOCATION attached to a
pole or installed on a wall. Installers should disconnect power before working with or near the access point.
!
Failure to use the included Ethernet cable glands can lead to connectivity and POE issues.
The cable is not included and must be purchased separately. Purchase a suitable UV-resistant, outdoor rated,
CAT 5E or better RJ45 cable for use with the access point.

Aruba 570EX Series Hazardous Location Access Points | Installation Guide 9
Figure 5 Cable Gland
1. Remove the dust cap from the Ethernet port.
2. It is not necessary to dismantle the cable gland any further than illustrated in Figure 5.
3. Fit the cable gland into the Ethernet port with the shroud and fully tighten the entry item.
4. Determine the conductor length required to suit the installation and prepare the cable accordingly, removing
part of the outer sheath where required to reveal the insulated conductors.
5. Slacken the seal nut to relax the seal.
6. Pass the cable through the cable gland (See Figure 6), then attach the connector to the end of the cable.
7. Insert the cable connector to the Ethernet port, then tighten the seal nut by hand until resistance is felt (when
the seal contacts the cable). Tighten with a spanner one further turn.
Figure 6 Passing a Cable through the Cable Gland
Software
For instructions on choosing operating modes and initial software configuration, refer to the AP Software Quick
Start Guide.
Verifying Post-Installation Connectivity
The integrated LEDs on the access point can be used to verify that the access point is receiving power and
initializing successfully (see Table 1 and Table 2). Refer to the AP Software Quick Start Guide for further details
on verifying post-installation network connectivity.
Electrical and Environmental Specifications
Seal NutSealEntry Item
!
Aruba access points are classified as radio transmission devices, and are subject to government regulations of
the host country. The network administrator(s) is/are responsible for ensuring that configuration and operation
of this equipment is in compliance with their country’s regulations. For a complete list of approved channels in
your country, refer to the Aruba Downloadable Regulatory Table at
https://www.arubanetworks.com/techdocs/DRT/Default.htm.

10 Aruba 570EX Series Hazardous Location Access Points | Installation Guide
Electrical
Ethernet
E0: 100/1000/2500Base-T auto-sensing Ethernet RJ-45 Interfaces
E1: 100/1000Base-T auto-sensing Ethernet RJ-45 Interfaces
Power over Ethernet (IEEE 802.3at and 802.3bt compliant): 57Vdc, 750mA
Environmental
Operating
Temperature: -40ºC to 65ºC (-40ºF to 149ºF)
Storage
Temperature: -40ºC to 70ºC (-40ºF to 158ºF)
Humidity: 5% to 93% non-condensing
For additional specifications on this product, please refer to the data sheet at www.arubanetworks.com.
Regulatory Model Number
For the purpose of regulatory compliance certifications and identification, this product has been assigned a
unique regulatory model number (RMN). The regulatory model number can be found on the product nameplate
label, along with all required approval markings and information. When requesting compliance information for
this product, always refer to this regulatory model number. The regulatory model number RMN is not the
marketing name or model number of the product.
The following regulatory model numbers apply to the 570EX Series:
AP-575EX RMN: APEX0575
AP-577EX RMN: APEX0577
Safety and Regulatory Compliance
!
RF Radiation Exposure Statement: This equipment complies with RF radiation exposure limits. This
equipment should be installed and operated with a minimum distance of 13.78 inches (35cm) between the
radiator and your body for 2.4 GHz and 5 GHz operations. This transmitter must not be co-located or operating
in conjunction with any other antenna or transmitter.
!
Déclaration de la concernant l’exposition aux rayonnements à fréquence radioélectrique (FR): Cet
appareil est conforme aux limites d’exposition aux rayonnements FR établies par la FCC. Il doit être installé et
utilisé à une distance minimale de 35 cm (13,78 pouces) entre le radiateur et votre corps, qu’il opère sur la
bande 2,4 GHz ou 5 GHz. Cet émetteur ne doit pas être installé ou utilisé à proximité immédiate d’une autre
antenne ni d’un autre transmetteur.
!
The device could automatically discontinue transmission in case of absence of information to transmit, or
operational failure. Note that this is not intended to prohibit transmission of control or signaling information
or the use of repetitive codes where required by the technology.
!
Changes or modifications to this unit not expressly approved by the party responsible for compliance could
void the user’s authority to operate this equipment.
!
Toute modification effectuée sur cet équipement sans l'autorisation expresse de la partie responsable de la
conformité est susceptible d'annuler son droit d'utilisation.

Aruba 570EX Series Hazardous Location Access Points | Installation Guide 11
United States
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the manufacturer’s instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio or TV technician for help.
Improper termination of access points installed in the United States configured to a non-US model controller is a
violation of the FCC grant of equipment authorization. Any such willful or intentional violation may result in a
requirement by the FCC for immediate termination of operation and may be subject to forfeiture (47 CFR 1.80).
Industry Canada
This Class B digital apparatus meets all of the requirements of the Canadian Interference-Causing Equipment
Regulations.
In accordance with Industry Canada regulations, this radio transmitter and receiver may only be used with an
antenna, the maximum type and gain of which must be approved by Industry Canada. To reduce potential radio
interference, the type of antenna and its gain shall be chosen so that the equivalent isotropic radiated power
(EIRP) does not exceed the values necessary for effective communication.
This device complies with Industry Canada's license-exempt RSS regulations. Operation of this device is subject
to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired operation.
When operated in 5.15 to 5.25 GHz frequency range, this device is restricted to indoor use to reduce the
potential for harmful interference with co-channel Mobile Satellite Systems.
Déclaration d’Industrie Canada
Ce périphérique est conforme aux règlements RSS exempts de licence d’Industrie Canada. L’utilisation de ce
périphérique est soumise aux deux conditions suivantes : (1) ce périphérique ne doit pas provoquer
d’interférences, et (2) ce périphérique doit accepter toute interférence, y compris les interférences susceptibles
de provoquer un dysfonctionnement.
En cas d'utilisation dans la plage de fréquences de 5,15 à 5,25 GHz, cet appareil doit uniquement être utilisé en
intérieur afin de réduire les risques d'interférence avec les systèmes satellites mobiles partageant le même
canal.
European Union Regulatory Conformance
The Declaration of Conformity made under Radio Equipment Directive 2014/53/EU is available for viewing at:
www.hpe.com/eu/certificates. Select the document that corresponds to your device’s model number as it is
indicated on the product label.
Wireless Channel Restrictions
5150-5350MHz band is limited to indoor only in the following countries; Austria (AT), Belgium (BE), Bulgaria (BG),
Croatia (HR), Cyprus (CY), Czech Republic (CZ), Denmark (DK), Estonia (EE), Finland (FI), France (FR), Germany (DE),
Greece (GR), Hungary (HU), Iceland (IS), Ireland (IE), Italy (IT), Latvia (LV), Liechtenstein (LI), Lithuania (LT),
Luxembourg (LU), Malta (MT), Netherlands (NL), Norway (NO), Poland (PL), Portugal (PT), Romania (RO), Slovakia
(SK), Slovenia (SL), Spain (ES), Sweden (SE), Switzerland (CH), Turkey (TR), United Kingdom (UK).
Radio Frequency Range MHz Max EIRP
BLE/Zigbee 2402-2480 9 dBm

12 Aruba 570EX Series Hazardous Location Access Points | Installation Guide
Medical
1. Equipment not suitable for use in the presence of flammable mixtures.
2. Connect to only IEC 60950-1 or IEC 60601-1 certified products and power sources. The end user is
responsible for the resulting medical system complies with the requirements of IEC 60601-1.
3. Wipe with a dry cloth, no additional maintenance required.
4. No serviceable parts, the unit must be sent back to the manufacturer for repair.
5. No modifications are allowed without Aruba approval.
Taiwan
第十二條
經型式認證合格之低功率射頻電機，非經許可，公司，商號或使用者均不得擅自變更頻率、加大功率或變更原設計之特性及功能。
第十四條
低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即停用，並改善至無干擾時方得繼續使用。
前項合法通信，指依電信法規定作業之無線電通信。 低功率射頻電機須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干
擾。
1. 應避免影響附近雷達系統之操作。
2. 高增益指向性天線只得應用於固定式點對點系統
3. 電磁波暴露量 MPE 標準值 1 mW/cm2, 送測產品實測值為 : 0.97mW/cm2
Brazil
Este equipamento não tem direito à proteção contra interferência prejudicial e não pode causar interferência
em sistemas devidamente autorizados.
Japan
México
La operación de este equipo está sujeta a las siguientes dos condiciones: (1) es posible que este equipo o
dispositivo no cause interferencia perjudicial y (2) este equipo o dispositivo debeaceptar cualquier interferencia,
incluyendo la que pueda causar su operación no deseada.
Wi-Fi
2412-2472 20 dBm
5150-5250 23 dBm
5250-5350 23 dBm
5470-5725 30 dBm
5725-5850 14 dBm
Radio Frequency Range MHz Max EIRP
!
Lower power radio LAN product operating in 2.4 GHz and 5 GHz bands. Please refer to the ArubaOS User Guide/
Instant User Guide for details on restrictions.

Aruba 570EX Series Hazardous Location Access Points | Installation Guide 13
Нормативные требования Евразийского Экономического Союза
HPE Russia: ООО "Хьюлетт Паккард Энтерпрайз" Российская Федерация, 125171, г.
Москва, Ленинградское шоссе, 16А, стр.3, Телефон: [phone] Факс: [phone]
4677
'HPE Kazakhstan': TOO «Хьюлетт-Паккард (К)», Республика Казахстан, 050040, г.
Алматы, Бостандыкский район, проспект Аль-Фараби, 77/7, Телефон/факс: + 7 727
355 35 50
Kazakhstan
ЖШС "Хьюлетт Паккард Энтерпрайз" Ресей Федерациясы, 125171, Мәскеу, Ленинград тас жолы, 16A блок
3, Телефон: [phone] Факс: [phone]
ЖШС «Хьюлетт-Паккард (К)», Қазақстан Республикасы, 050040, Алматы к., Бостандык ауданы, Әл-Фараби
даңғ ылы, 77/7, Телефон/факс: [phone]
Ukraine
Hereby, Hewlett Packard Enterprise Company declares that the radio equipment type [The Regulatory Model
Number [RMN] for this device can be found in the Regulatory Model Number section of this document] is in
compliance with Ukrainian Technical Regulation on Radio Equipment, approved by resolution of the CABINET OF
MINISTERS OF UKRAINE dated May 24, 2017, No. 355. The full text of the UA declaration of conformity is
available at the following internet address: https://certificates.ext.hpe.com/public/certificates.html
Х’ЮЛЕТТ ПАКАРД ЕНТЕРПРАЗ, 6280 АМЕРИКА ЦЕНТР Д-Р, САН-ХОСЕ, КАЛІФОРНІЯ 95002, США
Special Conditions for Safe Use
WARNING – DO NOT OPEN WHEN AN EXPLOSIVE ATMOSPHERE IS PRESENT
The connections on this equipment are not intended to be connected or disconnected when an explosive
atmosphere is present.
Only qualified Ex person are allowed for on-site installation and electrical connections of equipment.
Manual switch TS4V-2PL-R are protected by minimum IP66 enclosure, it is not allowed to operate the switch
in hazardous area.
Required protection shall be applied to avoid the mechanical damage of high risk occurred by the final
installation.
The equipment must be installed and used in an area of at least pollution degree 2,as defined in IEC 60664-1.
Only ATEX/IECEx cable glands as specified in the instruction to be installed and used on the enclosure,and
IEC/EN 60079-14 shall be observed when installing. Suitable type of protection Cable gland to be selected
with spec: M20x1.5 with minimum IP66 rating.
Type-C USB port is not used in hazardous area.
Damaged Protective Vents have to be replaced immediately.
Earthing system shall be finished in accordance with user manual before use.
Use cable gland, stopping plug, conduit fitting or similar device with ingress of protection of IP66, and the
installation shall meet the requirements of CEC (for Canada) and NEC (for USA) for wiring method in Division
2 and is subjected to acceptance of local authorities having jurisdiction.
Wipe with a wet cloth and use PPE for routine maintenance.
Standard Compliance
EN 60079-0:2018
EN 60079-7:2015/A1:2018
IEC 60079-0:2017 Edition 7.0
IEC 60079-7:2015+A1:2017 Edition 5.1
CSA C22.2 No.213-17
UL 121201 ninth edition

14 Aruba 570EX Series Hazardous Location Access Points | Installation Guide
ATEX Certificate Number and Marking
TÜV 20 ATEX 8562 X
IECEx Certificate Number and Marking
IECEx TUR 20.0044X
Ex ec IIC T4 Gc
cCSAus Ex Marking
Class I, Division 2, Groups A, B, C and D T4
The equipment is intended to use in outdoor and environmentally challenging locations such as oil rigs, mining
facilities, and industrial plants, networks need to be protected from extreme temperatures, flammable gases
or vapors, and dust concentrations.
The equipment to be used in Zone 2 or CID2 hazardous area only with gas group IIC or Groups A, B,C and D.

Aruba 570EX Series Hazardous Location Access Points | Installation Guide 15
Contact Aruba
Copyright
© Copyright 2020 Hewlett Packard Enterprise Development LP
Open Source Code
This product includes code licensed under the GNU General PublicLicense, the GNU Lesser General Public License, and/or
certain other open source licenses.
A complete machine-readable copy of the source code corresponding to such code is available upon request. This offer is valid
to anyone in receipt of this information and shall expire three years following the date of the final distribution of this product
version by Hewlett Packard Enterprise Company.
To obtain such source code, send a check or money order in the amount of US $10.00 to:
Hewlett Packard Enterprise Company
Attn: General Counsel
6280 America Center Drive
San Jose, CA 94089
USA
Warranty
This hardware product is protected by an Aruba warranty. For more details, visit www.hpe.com/us/en/support.html
Main Site https://www.arubanetworks.com
Support Site https://asp.arubanetworks.com
Airheads Social Forums and Knowledge Base https://community.arubanetworks.com/
North America Telephone [phone]
1-408-754-1200
International Telephone https://www.arubanetworks.com/support-services/contact-support/
Software Licensing Site https://www.hpe.com/networking/support
End-of-Life Information https://www.arubanetworks.com/support-services/end-of-life/
Security Incident Response Team (SIRT) https://www.arubanetworks.com/support-service/security-bulletins/
Email: [email protected]
