Asco 146 User manual

Surge Protective Devices Installation & Operation Manual
Model 146

© 2020 ASCO Power Technologies. All Rights Reserved
2
IO-75016
01/2020
For access to self-service tools and chat support visit se.com/us/en/work/support or call 1-888-778-2733 for technical assistance
ASCO Model 146 (Edco PLP-S Series)
Surge Protective Device (SPD)
Safety Information
Important Information
Read these instructions carefully and look at the equipment to become
familiar with the device before trying to install, operate, service or maintain it.
The following special messages may appear throughout thisbulletin or on the
equipment to warn of potential hazards or to call attention to information that
clarifies or simplifies a procedure.
The addition of either symbol to a “Danger”or “Warning” safety label
indicates that an electrical hazard exists which will result inpersonal
injury if the instructions are not followed.
This is the safety alert symbol. It is used to alert you to potential
personal injury hazards. Obey all safety messagesthat follow this
symbol to avoid possible injury or death.
DANGER
DANGER indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
WARNING
WARNING indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
CAUTION
CAUTION indicates a hazardous situation which, if not avoided,
could result in minor or moderateinjury.
NOTICE
NOTICE is used to address practices not related to physical injury. The safety
alert symbol shall not be used with this signal word.
Please Note
Electrical equipment should be installed, operated, serviced, and maintained only
by qualified personnel. No responsibility is assumed by ASCO Power Technologies
for any consequences arising out of the use of this material.
A qualified person is one who has skills and knowledge related to the
construction, installation, and operation of electrical equipment andhas received
safety training to recognize and avoid the hazards involved.

© 2020 ASCO Power Technologies. All Rights Reserved 3
IO-75016
01/2020
For access to self-service tools and chat support visit se.com/us/en/work/support or call 1-888-778-2733 for technical assistance
ASCO Model 146 (Edco PLP-S Series)
Surge Protective Device (SPD)
Introduction The ASCO Model 146 helps to protect your equipment from harmful power
surges and transients.
Model 146 provides isolated power loop circuit protection in applications
where higher current is required, such as re alarm and security systems.
HAZARD OF ELECTRIC SHOCK, EXPLOSION, OR ARC FLASH
• Apply appropriate personal protective equipment (PPE) and follow safe
electrical work practices. See NFPA 70E, NOM-029-STPS or CSA Z462.
• This equipment must only be installed and serviced by qualied electri-
cal personnel.
• Turn o󰀨 all power supplying this equipment before working on or inside
equipment.
• Always use a properly rated voltage sensing device to conrm power is o󰀨.
• Replace all devices, doors and covers before turning on power to this
equipment.
• This equipment must be e󰀨ectively grounded per all applicable codes.
Use an equipment-grounding conductor to connect this equipment to the
power system ground.
• Do not supply more than 7A AC to Surge Protective Device
• Conrm that the Surge Protective Device voltage rating on the module
or nameplate label is not less than the operating voltage.
• This equipment must be installed indoor on loop circuits which have
been isolated from Public Switched Telephone Networks. The loop
circuits shall not be exposed to accidental contact with electric light or
power conductors, (National Electric Code, Article 800).
Failure to follow these instructions will result in death or serious injury.
WARNING: This product can expose you to chemicals including
DINP, which is known to the State of California to cause cancer, and
DIDP which is known to the State of California to cause birth defects
or other reproductive harm. For more information go to: www.
P65Warnings.ca.gov.
NOTICE
LOSS OF SURGE SUPPRESSION
• Make certain that Surge Protective Device is disconnected from the
circuit it is protecting before conducting high potential insulation testing.
Failure to follow these instructions can result in equipment damage.
DANGER

© 2020 ASCO Power Technologies. All Rights Reserved
4
IO-75016
01/2020
For access to self-service tools and chat support visit se.com/us/en/work/support or call 1-888-778-2733 for technical assistance
Installation 1. Turn o󰀨 all power supplying this equipment before working on or inside
equipment.
2. Conrm that the unit has the same voltage rating and conguration as
the power system voltage and power system voltage to which it will be
connected.
3. This SPD has mounting feet provided with two holes,3/16 diameter,
spaced 3.5 apart. Using two screws or bolts (size #6 to #10) install the
unit and cables as close as possible to the protected equipment and
secure.
4. Connect a 12 - 16 AWG ground wire using a crimp-on ring terminal from
the SPD ground terminal to the equipment chassis ground.
5. Complete the circuit by connecting cables from the load of the SPD to
the protected equipment.
6. Check that all connections are secure. Remove all tools and discarded
hardware from the unit.
7. Replace the barrier, cover/door and/or trim to the equipment.
8. Equipment may be re-energized after all the above steps are complete.
Ground
Protected
Pair 2
Unprotected
Pair 2
Protected
Pair 1
Unprotected
Pair 1
} }
}
}
Figure 1: Wiring Diagram
ASCO Model 146 (Edco PLP-S Series)
Surge Protective Device (SPD)

© 2020 ASCO Power Technologies. All Rights Reserved 5
IO-75016
01/2020
For access to self-service tools and chat support visit se.com/us/en/work/support or call 1-888-778-2733 for technical assistance
General Technical
Specications
Operating Voltage 30 - 200 VDC
Clamping Voltage 33 - 211 VDC
Operating Current 7 Amp
Peak Surge Current 400 A
Operating Frequency DC - 30 MHz
Series Impedance <0.10 Ohms (<0.20 Ohms/pair)
SPD Technology Silicon Avalanche Diode (SAD)
Modes of Protection L-G
Connection Type Wire Clamp Terminals
Operating Temperature -40°C to +60°C
Dimensions (in / mm) 2.0 x 3.0 x 1.5 in.
[50.8 x 76.2 x 38.1 mm.]
Weight (lb / kg) 0.15 lb [0.07 kg]
Certications UL 497B
Limited warranty 5 Years
ASCO Model 146 (Edco PLP-S Series)
Surge Protective Device (SPD)

© 2020 ASCO Power Technologies. All Rights Reserved
6
IO-75016
01/2020
For access to self-service tools and chat support visit se.com/us/en/work/support or call 1-888-778-2733 for technical assistance
MODEL
Former Model Name
OPERATING
VOLTAGE
CLAMPING
VOLTAGE
146D033S400SN4N0
Edco PLP-42S 30 VDC 33 VDC
146D067S400SN4N0
Edco PLP-43S 60 VDC 67 VDC
146D150S400SN4N0
Edco PLP-44S 140 VDC 150 VDC
146D211S400SN4N0
Edco PLP-45S 200 VDC 211 VDC
Model Cross Reference
ASCO Model 146 (Edco PLP-S Series)
Surge Protective Device (SPD)

© 2020 ASCO Power Technologies. All Rights Reserved 7
IO-75016
01/2020
For access to self-service tools and chat support visit se.com/us/en/work/support or call 1-888-778-2733 for technical assistance
ASCO Model 146 (Edco PLP-S Series)
Surge Protective Device (SPD)

IO-75016 Rev- 01-20
14550 58th Street North
Clearwater, Florida 33760
se.com/us/en/work/support
1-888-778-2733
While every precaution has been taken to ensure accuracy and
completeness in this literature, Schneider Electric assumes no
responsibility, and disclaims all liability for damages resulting from
use of this information or for any errors or omissions.
