Ashland EPH30 User manual

1
• Thank you for purchasing this pump. Take the time to
read the instructions carefully before using this
product. We strongly recommend that you keep this
instruction manual in a safe place for future reference.
• Please refer to our website and the Products Center for
additional installation and operation instructions and
replacement parts information.
OPERATION, PERFORMANCE,
SPECIFICATIONS and PARTS MANUAL
EPH30
3/10 HP (High Head)
Efuent Pump
Efuent
Pump
Model
EPH30
“Danger” indicates an
imminent hazardous situation
which, if not avoided, WILL result in death or
serious injury.
“Caution” indicates a
potentially hazardous situation
which, if not avoided, MAY result in minor or
moderate injury.
MARKS AND MEANING:
WARNING
CAUTION
DANGER
“Warning” indicates an
imminent hazardous situation
which, if not avoided, MAY result in death or
serious injury.

2
DANGER
Before installation, read the following instructions care-
fully. Failure to follow instruction and safety information
could cause serious bodily injury, death and/or property
damage. Each Ashland Pump is individually factory tested
to ensure proper performance. Closely following these
instructions will eliminate potential operating problems
assuring years of trouble-free service.
Most accidents can be avoided by using common sense.
IMPORTANT - Ashland Pump is not responsible for
losses, injury or death resulting from failure to observe
these safety precautions, misuse, abuse or misapplica-
tion of pumps or equipment.
All returned products must
be cleaned, sanitized, or
decontaminated prior to shipment, to
insure employees will not be exposed to
health hazards in handling said materials.
All applicable laws and regulations shall apply.
Bronze/brass fitted pumps may
contain lead levels higher than con-
sidered safe for potable water systems. Government
agencies have determined that leaded copper alloys
should not be used in potable water applications.
Installation, wiring, and junction
connections must be in accord-
ance with the National Electric Code and all applicable
state and local codes. Requirements may vary depend-
ing on usage and location.
Installation and servicing is to be
  conductedbyqualiedpersonnelonly.
Rotating machinery, amputation
or severe lacerations can result.
Keep clear of suction and discharge
openings. DO NOT insert fingers into pump
with power connected.
Always wear eye protection when
working on pumps. Do not wear loose
clothing that may become entangled in moving parts.
Pumps build up heat and
pressure during operation.
Allow time for pumps to cool before handling or ser-
vicing.
Hazardous Voltage can shock,
burn or cause death. This pump is
not intended for use in swimming pools or
water installations where human contact with
pumped fluid is possible.
Risk of electrical shock. To
reduce risk of electrical shock,
always disconnect pump from source
before handling. Lock out power & tag.
Efuent Pumps
Model: EPH30
General Safety Information
WARNING
Do Not use these pumps in water
over 145°F. Do not exceed manu-
factures recommended maximum performance, as this
could cause the motor to overheat.
WARNING
WARNING
WARNING
WARNING
DANGER
DANGER
DANGER
These pumps are NOT to be
installed in locations classified
as hazardous in accordance with the
National Electric Code, ANSI/NFPA 70.
WARNING
Effluent pumps often handle
materials which could cause illness
or disease. Wear adequate protective clothing when
working on a used pump or piping. Never enter a ba-
sin after it has been used.
WARNING
Do not introduce into any sewer,
either directly, or through a kitchen
waste disposal unit or toilet: Seafood Shells, Aquarium
Gravel, Cat Litter, Plastic Objects, Sanitary Napkins or
Tampons, Diapers, Rags, Disposable Wipes or Cloth,
Medications, Flammable Material, Oil or Grease,
Strong Chemicals, Gasoline.
DANGER
DANGER
Do not lift, carry or hang pump by
the electrical cables. Damage to
the electrical cables can cause shock, burns or
death. Never handle connected power cords
with wet hands. Use appropriate lifting device.
DANGER
Failure to permanently ground the
pump, motor and controls before
connecting to power can cause shock, burns
or death.
DANGER
Make sure lifting handles are securely
fastened each time before lifting.
CAUTION
• Operation against a closed discharge valve will cause
premature bearing and seal failure on any pump.
• Any wiring of pumps should be performed by a
 qualiedelectrician.
• Cable should be protected at all times to avoid
punctures, cuts, bruises, and abrasions-inspect
frequently.
• Never handle connected power cords with wet hands.
• Never let cords or plugs lie in water outside the sump
pit.
• These pumps are offered in a three phase and single
 phasewiringconguration.Voltageswillvary
according to the application and can be seen in the
tables in this manual.

3
Efuent Pumps
Model: EPH30
Specications
IMPORTANT
Prior to installation, record Model Number,
MFGDate,Amps,Voltage,PhaseandHP,
from pump nameplate for future reference.
Also record the voltage and current readings
at startup:
Model Number:
MFG Date:
HP:
SN:
1 Phase Models
 Amps:  Volts:
1.65”
SPECIFICATIONS
Overall Size Pump Material
(inches) Motor
Model HP Volt Ph Amps L W H Volute Housing  Impeller Shaft
EPH30 3/10 115/230 1 7.0/3.5 8.75 6.3 9.4 Cast Iron Cast Iron Cast Iron SS
Description: To pump domestic,
commercial and light
industrial sewage
Physical Data:
DISCHARGE SIZE 1-1/2” NPT
IMPELLER TYPE  VORTEX
CABLE LENGTH 20’
Liquid Handling:
SOLIDS SIZE 3/4”
MAXIMUM LIQUID TEMP. 104°F - Intermittent,
ACCEPTABLE PH RANGE 6-8
Temperature:
MAXIMUM STATOR 120°C
Technical Data:
POWER CORD TYPE SJTW 18/3C
MOTOR HOUSING Cast Iron
VOLUTE Cast Iron
IMPELLER Cast Iron
MOTOR SHAFT SS430
HARDWARE SST
“O” RINGS NBR
SEALS Single Mechanical
Carbon Ceramic
UPPER BEARING 608-2RZ
LOWER BEARING 6202
1-1/2 NPT
91.2 [3.59]
1-1/2 NPT
6.3”
1.5” NPT
9.4”
3.6”
8.75”

4
Efuent Pumps
Model: EPH30
Specications and Performance
EPH30 PERFORMANCE CHART
Total
Lift(feet) 10 15 20 25 30 34
GPM 45 40 32 24 11 0
HEAD - FEET
40
35
30
25
20
15
10
5
0
0 10 20 30 40 50
GALLONS PER MINUTE

5
Efuent Pumps
Model: EPH30
Receiving and Installation
Receiving Inspection
Upon receiving the pump, it should be inspected for
damageorshortages.Ifdamagehasoccurred,leaclaim
immediately with the company that delivered the pump.
If the manual is removed from the packaging, do not lose
or misplace.
Storage
Any product that is stored for a period longer than six (6)
months from the date of purchase should be bench
tested prior to installation. A bench test consists of,
checking the impeller to assure it is free turning and a run
test to assure the motor (and switch if provided) operate
properly. Do not pump out of liquid.
IMPORTANT! A clearance under the
pump for entrance of sewage solids
must be a minimum of 2 inches to a maximum of 3.5
inches.
Submergence
The pump should always be operated in the submerged
condition. The minimum sump liquid level should never
belessthanabovethepump’smotor(seeg.1),unless
verybriey.
Installation
The sump or basin shall be sealed and vented in accor-
dance with local plumbing codes. This pump is designed
to pump domestic wastewater, nonexplosive and non-
corrosive liquids and shall NOT be installed in locations
classiedashazardousinaccordancewiththe
National Electrical Code (NEC) ANSI/ NFPA 70 or Cana-
dian Electric Code
(CEC). The pump
should never be
installed in a
trench, ditch,
or hole with
a dirt bottom.
The legs will
sink into the
dirt and the
suction will
become
plugged.
Discharge Piping
Install discharge piping or hose assembly to the pump.
Discharge piping should be as short as possible and sized no
smaller than the pump discharge. Do not reduce the dis-
charge pipe size below that which is provided on the pump.
Both a check valve and a shut-off valve are recommended
foreachpump.Thecheckvalveisusedtopreventbackow
into the sump. The shut-off valve is used to manually stop
systemowduringpumpservicing.Besurethedischarge
pipe has a 1/8” diameter hole approx. 5” from end nearest
volute and oriented towards the pump body.
Control Panel
SinglephaseseriesefuentpumpsDONOTrequireacon-
trol panel, but do require a level control with a piggy back
plug,see“Piggy-backPlug,gure2”below.
WARNING
Motor: Each motor is provided with heat sensor thermo-
stats attached directly to the motor windings. The
thermostats open if the motor windings see excessive heat
and, in turn, open the motor contactor in the control panel
when used, breaking the power to the pump. When the
motor is stopped due to an overheated condition, it will
not start until the motor has cooled.
FIGURE 1
Minimum
Submergance
Pre-operation
CHECK VOLTAGE AND PHASE
Before operating pump, check to make sure that voltage
andphaseinformationstampedonthepump’sidentica-
tion plate matches the available power.
CHECK PUMP ROTATION
Beforeputtingpumpintoserviceforthersttime,the
motor rotation must be checked. Improper motor rota-
tion can result in poor pump performance and
can damage the motor and/or pump.
IDENTIFICATION PLATE
Notethenumbersonthepumpsidenticationplateand
record in this manual for future reference.
Electrical Connections
Turn circuit breaker off before
plugging or unplugging the
switch and/or pump.
AlwaysrelyuponaCertiedElectricianforinstallation.
Piggy-Back Plug Plug the
level control plug into a
115Vreceptacle,thenplug
the pump into the piggy-back
plug (See Figure 2). It is
recommended that this circuit
have a 15 AMP breaker. One
cycle of operation should be
observed, so that any potential
problems can be corrected. FIGURE 2
Automatic
Manual

6
Efuent Pumps
Model: EPH30
Receiving and Installation
Itisrecommendedthatthelevelcontroloatshouldbe
set to insure that the liquid in the sump never drops
below the top of the motor housing. The level control
should have adequate clearance so it cannot hang up in
it’s swing and that the pump is completely submerged
when the level control is in the “Off ” mode. Minimum
tether length is 3.50”.
By adjusting the cord tether the control level can be
changed. DO NOT USE THE POWER CABLE TO LIFT
PUMP.
Pump-Down Test - Be sure pump has been plugged in,
lowered into the basin or sump, check the system by
llingwithliquidandallowingthepumptooperate 
through its pumping cycle. The time needed to
empty the system, or pump-down time along with the
volume of water, should be recorded.
Thermal Protection
The normally closed (N/C) over temperature sensor is
embedded in the motor windings and will detect exces-
sive heat in the event an overload condition occurs.
The thermal sensor will trip when the windings become
too hot and will automatically reset when the pump
motor cools to a safe temperature.
In the event of an over temperature, the source of this con-
dition should be determined and repaired immediately. Ther-
mal protection shall not be used as a motor overload device.
Maintenance
Minimal maintenance is required. Perform the following
checks when pump is removed from operation or when
pump performance deteriorates:
a). Inspect motor chambers for oil level and
contamination.
b). Inspect impeller and body for excessive build-up or
clogging.
c). Inspect motor and bearings.
d). Inspect seal for wear or leakage.
Servicing
Cooling Oil - Anytime the pump is removed from
operation, the cooling oil in the motor housing should be
checked visually for oil level and contamination. To check
oil, set unit upright. Remove pipe plug from housing.
Withaashlight,visuallyinspecttheoilinthehousingto
make sure it is clean and clear, light amber in color and
free from suspended particles. Milky white oil indicates
the presence of water. Oil level should be just above the
motor when pump is in vertical position.
Oil Testing
• Drain oil into a clean, dry container by placing pump on
it’s side. Remove pipe plug, from housing.
• Check oil for contamination using an oil tester with a
range to 30 Kilovolts breakdown.
• If oil is found to be clean and uncontaminated
 (measuringabove15KV.breakdown),rellthehousing.
• If oil is found to be dirty or contaminated (or measures
• If oil is found to be dirty or contaminated (or measures
 below15KV.breakdown),thepumpmustbecarefully
inspected for leaks at the shaft seal, cable assembly,
 o-ringandpipeplug,beforerellingwithoil.Tolocate
the leak, perform the following pressure tests.
After leak is repaired, dispose of old oil properly, and
rellwithnewoil.
Pressure builds up extremely fast, increase
pressure by “TAPPING” air nozzle. Too much
pressure will damage seal.
DO NOT exceed 10 P.S.I.
Motor Housing Pressure Test:
Ifoilhasbeendrained,lltonormallevelbeforeperform-
ing pressure test. Remove pipe plug from motor housing.
Apply pipe sealant to pressure gauge assembly and tight-
en into hole. Pressurize motor housing to 10 P.S.I. Use
soap solution around the sealed areas above the oil level
and inspect joints for “air bubbles”. For sealed areas
belowoillevel,leekswillseepoil.If,afterveminutes,
the pressure is still holding constant, and no “bubbles” /
oil seepage is observed, slowly bleed the pressure and
remove the gauge assembly. Replace oil. Leak must be
located and repaired if pressure does not hold.
Oil Replacement Motor Housing
Remove pipe plug from motor housing.
Drain all oil (if not already done so) from motor housing
and dispose of properly per Local Code. Set pump
uprightandrellwithnewcoolingoil,see“CoolingOil”
chart. Fill to just above motor (0.34L) as an air space
must remain in the top of the motor housing to compen-
sate for oil expansion. Apply pipe thread compound to
threads of pipe plug then assemble to motor housing.
Check that o-ring is in place and does not need to be
replaced. Reassemble cord cap to motor housing.
DO NOT overll oil. Overlling of housing
with oil can create excessive and dangerous
hydraulic pressure which can destroy the
pump and create a hazard. Overlling
oil voids warranty.
Cooling Oil Recommended Supplier/Grade
BP Enerpar SE100
 Conoco  PaleParafn22
Mobile D.T.E. Oil Light
Shell Canada Transformer-10
 Texaco  Diala-Oil-AX
Before any service work is
done, disconnect and lock
out electrical power to pump.
WARNING

7
Efuent Pumps
Model: EPH30
Installation and Service
Volute - Remove socket head cap screws from volute.
Impeller - Remove impeller by turning counter-clockwise
careful application of heat may be necessary. Do Not
store pump without impeller in place.
Seal- Handle seal parts with care. Remove rotating mem-
ber from shaft. Remove pressed-in spring component
from seal plate. Examine all seal parts. Inspect contact
faces for signs of uneven wear tracks on stationary face,
chips and scratches on either seal face. DO NOT inter-
change seal components, replace the entire shaft seal if
necessary.
Seal Plate - Remove cap screws from seal plate. Remove
seal plate and o-ring.
Bearings - Using a bearing puller or arbor press remove
bearing from shaft. Remove upper motor bearing from
shaft with a bearing puller.
IMPORTANT! - All parts must be clean before
reassembly. Handle seal parts with extreme
care. DO NOT damage lapped surfaces.
REASSEMBLY
Bearing - Be careful not to damage the rotor shaft when
replacing bearing. Using an arbor press, hold the rotor
and press the upper bearing on the rotor shaft,
applying force to the inner race of the bearing only.
In the same manner replace lower bearing (49) onto rotor
shaft.
Seal Plate - Lubricate and set o-ring in bottom of seal
plate. Place seal plate over shaft, being sure o-ring is not
twisted and in the groove. Place four capscrews through
holes in motor housing and into seal plate and torque to
6.5 ft/lbs.
Outer Seal - Clean and oil stationary seal cavity in seal
plate. Slide seal guide tool over motor shaft. Lightly oil
(Do not use grease) outer surface of seal’s stationary
member.
Pressstationaryrmlyintosealplateusing a seal pusher
tool. Be sure the stationary member is in straight. Noth-
ing but the seal tool is to come in contact with seal face.
IMPORTANT ! Do not hammer on the seal
pusher. It will damage the seal face.
With lapped surface of rotating member facing inward
toward stationary, slide rotating member and onto shaft,
until lapped faces of stationary and rotating seal are
together.
Impeller - Place impeller on motor shaft by turning clock-
wise. Blue thread locking compound is recommended.
Volute - Place volute on seal plate. Place socket head cap
screws through volute and into seal plate Then torque
evenly to 11 ft/lbs.

8
Efuent Pumps
Model: EPH30
Installation and Service
Starting Pump After Installing in Sump
Before lowering pump into basin, connect power lines
and start motor. Impeller should turn counterclockwise
when looking at impeller.
Service and Repair
Important: Pump should be thoroughly cleaned of trash
and deposits before starting disassembly operations
(pages 6-8).
Disconnect all power and control wires to motor at
control panel before starting disassembly operation.
Never rely on opening circuit breaker only.
Operating pump builds up heat and pressure; allow time
for pump to cool to room temperature
Installing Pump in BASIN
Install pump in properly vented basin according to
localcodesandregulations.PVCpipealongwithplastic
check valve and shut-off valve are recommended. Drill a
1/8” hole in the discharge pipe below the check valve.
Install check valve 12” above pump discharge. See
Figure 3
CAUTION
WARNING
FIGURE 3
Entry pipe
Discharge pipe
Vent
Shut off valve
Check check
Union
To control
panel
Air bleed
hole

9
ELECTRICAL PRECAUTIONS
Before servicing a pump, always shut off the main power breaker and
then unplug the pump. Make sure you are not standing in water and are wearing insulated protective sole
shoes, under ooded conditions. Contact your local electric company or a qualied licensed electrician for
disconnecting electrical service prior to pump removal
Efuent Pumps
Model: EPH30
Trouble Shooting
PROBLEMS
PUMP DOES NOT RUN
AND MAKES HUMMING
SOUND
PUMP RUNS BUT DOES
NOT DELIVER WATER
PUMP RUNS AND
PUMPS
OUT SUMP, BUT DOES
NOT STOP
PUMP RUNS BUT ONLY
DELIVERS A SMALL
AMOUNT OF WATER
FUSE BLOWS OR
CIRCUIT BREAKER TRIPS
WHEN
PUMP STARTS
MOTOR RUNS FOR A
SHORT TIME, THEN
STOPS
POSSIBLE CAUSES/SOLUTIONS
• Line circuit breaker is off, or fuse is blown or loose
• Water level in sump has not reached turn-on level as indicated in
installation drawing.
• Pump cord is not making contact in receptacle.
• Float is stuck. It should operate freely in basin.
• If all of the above are OK, then the motor could be malfunctioning.
• Check if valve is installed backwards.
Arrow on valve should point direction of ow
• Discharge shut-off valve (if used) may be closed.
• Impeller or volute openings are fully or partially clogged.
Remove pump and clean.
• Pump is air-locked. Start and stop several times by plugging and
unplugging cord. Check for clogged vent hole in pump case.
• Inlet holes in pump base are clogged. Remove pump and clean the
openings.
• Vertical pumping distance is too high. Reduce distance or change the
discharge ttings of the pump.
• Float is stuck in up position. Be sure oat operates freely in basin.
• Defective oat switch. Replace oat switch.
• Pump is air-locked. Start and stop several times by plugging in and
unplugging cord. Check for clogged vent hole in pump case.
• Vertical pumping distance is too high. Reduce distance or change the
discharge tting of the pump. Inlet holes in pump base are clogged.
Remove pump and clean the strainer and openings.
• Impeller or volute openings are fully or partially clogged.
Remove pump and clean.
• Pump impeller is partially clogged with tar or paint, causing motor to
run slow and overload. Remove pump and clean.
• Pump impeller is partially clogged causing motor to run slow and
overload. Remove pump and clean.
• Motor stator may be defective.
• Fuse size or circuit breaker may be too small. (must be 15 amps).
• Impeller or volute opening are fully or partially clogged.
Remove pump and clean .
• Inlet holes in pump base are clogged. Remove pump and clean the
openings.
• Pump impeller is partially clogged causing motor to run slow and
overload. Remove pump and clean.
• Motor stator may be defective.
• Impeller or volute openings are fully or partially clogged.
Remove pump and clean. Also clean the strainer if one is installed.

10
Efuent Pumps
Model: EPH30
Parts
NO. PART NO. DESCRIPTION Q’TY
1 091EPH301 IMPELLER 1
2 091EPH302 O-RING 1
3 091EPH303 SHAFT-SEAL 1
4 091EPH304 STATOR ASSY 1
5 091EPH305 SEALING RING 1
6 091EPH306 SCREW 1
7 091EPH307 POWERCORD ASSY 1
8 091EPH308 VOLUTE 1
9 091EPH309 SEAL PLATE 1
10 091EPH310 ROTOR ASSY 1
11 091EPH311 SCREW 1
12 091EPH312 RINGS 1
8
9
10
11
12 7
6
4
3
1
2
5
1
3
2
4
5
6
8
9
10
11
12 7
