Askey TCG310-d User manual

!
Page!1!/!26!
!
!
!
TCG310)d+
USER+MANUAL
+
+

!
Page!2!/!26!
!
!
Chapter 1: Connections and Setup ............................................................................................................... 4!
Introduction............................................................................................................................ 4!
Features ............................................................................................................................. 4!
Computer Requirements......................................................................................................... 5!
Cable Modem Overview ............................................................................................................ 6!
Front Panel.......................................................................................................................... 6!
Rear Panel .......................................................................................................................... 8!
Relationship among the Devices .................................................................................................. 9!
What the Modem Does........................................................................................................... 9!
What the Modem Needs to Do Its Job ........................................................................................ 9!
Contact Your Local Cable Company.......................................................................................... 9!
Connecting the Cable Modem to a Single Computer........................................................................ 10!
Attaching the Cable TV Wire to the Cable Modem ...................................................................... 11!
Installation procedure for connecting to the Ethernet interface ........................................................ 12!
Chapter 2: WEB Configuration.................................................................................................................. 13!
Accessing the Web Configuration............................................................................................... 13!
Overview Web Page Group....................................................................................................... 14!
Overview.......................................................................................................................... 14!
Settings Web Page Group ......................................................................................................... 15!
Language.......................................................................................................................... 15!
Password .......................................................................................................................... 16!
Configuration .................................................................................................................... 17!
Status Web Page Group ........................................................................................................... 18!
Status .............................................................................................................................. 18!
Upstream .......................................................................................................................... 19!
Downstream ...................................................................................................................... 20!
Event log .......................................................................................................................... 21!
Chapter 3: Additional Information............................................................................................................. 22!
Frequently Asked Questions...................................................................................................... 22!
General Troubleshooting.......................................................................................................... 23!
Service Information ................................................................................................................ 24!
Glossary .............................................................................................................................. 25!
CAUTION for UL(Check caution label on gift box)........................................................................ 26!

!
Page!3!/!26!
!
!

!
Page!4!/!26!
!
!
CHAPTER(1:(CONNECTIONS(AND(SETUP(
Introduction
Features
!!Broadcom BCM3390 based Docsis 3.1 Capable Cable Modem with Advanced multiprocessor
architecture, providing ultra high speed internet connectivity.
!!1.2GHz Full Band Capture Front End.
!!Supports 2 OFDM and 32 single-carrier QAM Downstream channels, 2 OFDMA and 8 single-
carrier QAM Upstream channels.
!!Latest CableLabs DOCSIS 3.1 Technology support, backward compatible to CableLabs DOCSIS
1.0/1.1/2.0/3.0 Standard Compliant.
!!Switchable diplexer better adapts current MSO Coax HFC environment.
!!Upstream Diagnostic Analyzer and Downstream Spectrum Analyzer function makes installation
process easy, further reduce the operation cost.
!!Quad Gigabit Ethernet Switch with auto-negotiation and MDIX functions; Support maximum
Ethernet cable length up to 100m (Category 5e).
!!Supports Fast Scan.
!!Local and Remote Management Support.
!(

!
Page!5!/!26!
!
!
Computer Requirements
For the best possible performance from your Cable Modem, your personal computer must meet the
following minimum system requirements (note that the minimum requirements may vary by cable
companies):
IBM PC COMPATIBLE
MACINTOSH**
CPU
Pentium preferred
PowerPC or higher
System RAM
16MB or Higher
24MB or Higher
Operating System
Windows* NT / 2000 / Me / XP /
Vista / Windows 7, Linux
Mac OS** 7.6.1 or higher
Video
VGA or better (SVGA preferred)
VGA or better (SVGA built-in preferred)
Ethernet
100BaseT or 1000BaseT
100BaseT or 1000BaseT
An Ethernet card makes it possible for your computer to pass data to and from
the internet. You must have an Ethernet card and software drivers installed in
your computer. You will also need a standard Ethernet cable to connect the
Ethernet card to your Cable Modem.
Software
•!A TCP/IP network protocol for each machine
•!Internet Browser (Microsoft Internet Explorer, Google Chrome, Mozilla
Firefox or equivalent)
* Windows is a trademark of Microsoft Corporation.
** Macintosh and the Mac OS are trademarks of Apple Computer, Inc.
!
!
!

!
Page!6!/!26!
!
!
Cable Modem Overview
Front Panel
Fig. 1-1 Front Panel
The following illustration shows the front panel:
Power - Indicates the Power status.
DS - Indicates the status of Data reception by the cable modem from the Network (Downstream
Traffic).
US - Indicates the status of Data transmission by the cable modem to the Network (Upstream
Traffic).
Online - Displays the status of your cable connection. The light is off when no cable connection
is detected and fully lit when the modem has established a connection with the
network and data can be transferred.
LAN -Indicates the state of Ethernet ports.

!
Page!7!/!26!
!
!
The lights on the front panel LEDs are described in the table below (from left to right):
ON = the LED is light, OFF = the LED is gray, FLASH = the LED is blinking.
TCG310-d
Power
Internet
LAN
Description
DS
US
Online
Boot-up Operation
ON
ON
ON
ON
ON
Power on 0.25 sec
ON
0.25 second
ON
FLASH
FLASH
FLASH
X
From power ON to system initialization complete
ON
ON
ON
ON
X
Following system initialization complete to (before)
1 second
DS scanning
DOCSIS Start-up Operation
ON
FLASH
OFF
OFF
X
During DS scanning and acquiring SYNC
ON
ON
FLASH
OFF
X
From SYNC completed, receiving UCD to ranging
completed
ON
ON
ON
FLASH
X
During DHCP, configuration file download, registration,
and Baseline Privacy initialization
ON
ON
ON
ON
X
Operational (NACO=ON)
ON
FLASH
FLASH
OFF
X
Operational (NACO=OFF)
CPE Operation
ON
X
X
X
OFF
No Ethernet Link
ON
Ethernet Link
FLASH
TX/RX Ethernet Traffic
SW Download Operation
ON
FLASH
FLASH
ON
X
A software download and while updating the FLASH
memory
Table 1-1 LED behavior

!
Page!8!/!26!
!
!
Rear Panel
!
Fig. 1-2 Rear Panel
!
Connector
Description
Power Jack
Connector for DC12V.
USB Host
USB 3.0 connector (software upgrade only)
Ethernet
Ethernet ports, 10/100/1000BaseT RJ-45 connector.
Reset
To restart the modem or press over 5 seconds can
default the modem.
Cable
Connector for the cable network.
Table 1-2 Rear Panel description(

!
Page!9!/!26!
!
!
Relationship among the Devices
This illustration shows a cable company that offers DOCSIS compliant data services.
Fig. 1-3 Connection overview
What the Modem Does
The Cable Modem provides high-speed Internet access as well as cost-effective, commercial, and
education subscribers on public and private networks via an existing CATV infrastructure. The IP traffic
can transfer between the Cable Modem and DOCSIS compliant head-end equipment. The data security
secures upstream and downstream communications.
What the Modem Needs to Do Its Job
"!The Right Cable Company: Make sure your local cable company provides data services that use
cable TV industry-standard DOCSIS compliant technology.
Check with your cable company to make sure you have everything you need to begin; they’ll know if you
need to install special software or re-configure your computer to make your cable internet service work
for you.
Contact Your Local Cable Company
You will need to contact your cable company to establish an Internet account before you can use your
cable modem. You should have the following information ready (which you will find on the sticker on the
cable modem):
•!The serial number.
•!The model number.
•!The Cable Modem (CM) Media Access Control (MAC) address.

!
Page!10!/!26!
!
Please check the following with the cable company
"!The cable service to your home supports DOCSIS compliant two-way modem access.
"!Your internet account has been set up.
"!You have a cable outlet near your PC and it is ready for Cable Modem service.
Note: It is important to supply power to the modem at all times. Keeping your modem plugged in will
keep it connected to the Internet. This means that it will always be ready whenever you need.
Important Information
Your cable company should always be consulted before installing a new cable outlet. Do not attempt any
rewiring without contacting your cable company first.
Please verify the following on the Cable Modem
The Power LED should be lighted when plug-in the power adapter.
Connecting the Cable Modem to a Single Computer
This section of the manual explains how to connect your Cable Modem to the Ethernet port on your
computer and install the necessary software. Please refer to Figure 1-5 to help you connect your Cable
Modem for the best possible connection.
!(
