Aspire STAR User manual

USER MANUAL

IMPORTANT:
Do not use the Aspire Star Patient Mover without having first read
this manual.
TABLE OF CONTENTS
1. Symbols Used In This Manual 3
2. Symbols Used On This Product 3
3. Overview 4
4. Safety Precautions 4
5. Parts Glossary 6
6. Assembly 7
7. Preliminary Checks 11
8. General Operation 11
9. Transfer Guide 15
10. Sling Compatibility 17
11. Care & Maintenance 18
12. Warranty & Service 19
13. Troubleshooting 20
14. Specifications 21
15. Manufacturer, UK Representative & Importer Information 22

3
1. SYMBOLS USED IN THIS MANUAL
2. SYMBOLS USED ON THIS PRODUCT
WARNING! Indicates a potentially hazardous condition/
situation. Failure to follow designated procedures can cause
either personal injury, component damage or malfunction. On
the product, this icon is represented as a black symbol on a
white triangle with a black border.
ALWAYS! These actions should be performed as specified.
Failure to perform mandatory actions can cause personal
injury and/or equipment damage. On the product, this icon is
represented as a white infinity symbol on a black dot with a
white border.
DO NOT! These actions are prohibited. These actions should not
be performed at any time or in any circumstances. Performing
a prohibited action can cause personal injury and/or equipment
damage. On the product, this icon is represented as a white
symbol with a black circle and black slash.
Product Code SWL
xxxKG Safe Working Load
Serial Number Read User Manual
Manufacturer Caution
Importer Medical Device
CN Country of Manufacture UK REP Authorised Representative
in UK
UKCA Mark
WARNING
STAR MOVER
AUSTRALIA | Aidacare Pty Ltd | ABN 40 134 833
Buliding 3A, 1 Moorebank Avenue, Moorebank NSW 2170
1300 133 120 | [email protected]
UNITED KINGDOM | Aidacare Ltd | Registration 13785408
Arcadia House, Maritime Walk, Ocean Village, Southampton SO14 3TL
01622 541235 | [email protected]o.uk
MADE IN PRC
It is recommended that you have this product serviced every 12 months.
LSS390580
15 Coanwood Drive, Whitley Bay
Tyne and Wear NE25 9GB
[e-mail]
UK REP
European Device
Solutions Ltd
SWL
185KG
CN

4
3. OVERVIEW
The Aspire Star Patient Mover (the Star Mover), provides a simple solution
for transferring a user from a bed or chair in comfort and safety.
Offering a compact and versatile design, the Star Mover is suitable
for Homecare, Acute Care and Aged Care environments.
4. SAFETY PRECAUTIONS
INTENDED USE OF THE PRODUCT
The Star Mover has been designed to transfer human patients with the
assistance of one carer or attendant.
This Patient mover is designed for patients who can weight bear through
their legs. Patients should be able to stand independently or with minimal
amounts of assistance from an attendant or carer.
The Star Mover should only be used with Aspire approved standing slings, which
have been chosen and assessed by a competent trained health professional.
For a complete list of all compliant slings please contact Aidacare.
IMPORTANT – only approved slings and accessories are compatible with this
product. If you are unsure please contact Aidacare.
The correct and appropriate use of the Star Mover reduces the risks
associated with manual patient handling. The lifting and transferring
of patients should always be assessed and planned by a trained
health professional.

5
SAFETY CONSIDERATIONS
A clinical assessment should be carried out on the patient by a qualified
health professional to determine if the Star mover is suitable for the transfer
ALWAYS ensure that attendants have read this guide before
operating the patient mover.
ALWAYS use slings that are assessed and considered suitable
by a trained healthcare professional.
ALWAYS ensure the area around the patient mover and patient
is clear of obstructions.
ALWAYS minimise the distance over which the patient is being
transferred by positioning support surfaces as close as possible.
ALWAYS ensure braking castors are locked when performing
transfers in and out of the Star Mover.
DO NOT operate the patient mover without correct manual
handling training. IF IN DOUBT, DO NOT USE.
DO NOT use the patient mover where any doubt exists
regarding the safety of the patient mover, including but not
limited to wear or damage with particular importance to be
placed on the standing sling attachment points.
DO NOT use the patient mover with slings showing any signs
of wear or damage, including fraying.
DO NOT exceed the 185kg/29st safe working load of the
Star Mover.
DO NOT leave user unattended at any time.
Inspect all safety labels on the Star mover and replace all labels that are
damaged or not readable

6
5. PARTS GLOSSARY
1
3
9
5
4
7
6
3
2
8
1Push Handle 4Seat Pad 7Swivel Castor
2Grab Bar 5Knee Pad 8Foot Pedal
3Sling Attachment 6Footplate 9Locking Castor

7
6. ASSEMBLY
TOOLS REQUIRED:
Allen key
5mm
Allen key
6mm
Socket
14mm
Open ended spanner
14mm
Ratchet
CARTON CONTAINS:
1. Base Unit
2. Right Upright Frame, M10 bolt and washer
3. Left Upright Frame, M10 bolt and washer
4. Knee pad with 2 x spacers, 2 x steel washers, 2 x nylon washers
and 2 x M8 bolts
5. Right Seat Pad
6. Left Seat Pad
7. 1 x Grab bar with 2 x Sling anchor bolts
8. 1 x Grab bar with 2 x Bolts and 2 x Plastic caps
9. 2 x Seat Pad mounting hardware
• 2 x Narrow retaining ring
• 2 x Deep retaining ring
(already mounted in each
Upright Frame)
• 2 x Mounting Plate
• 6 x Mounting Bolts
• 2 x Cover Caps
5 6
9 1
3
2
9
7
8
4

8
1
3
4
1. Insert each Side Frame into
the base, these are notched on
the end to ensure they locate
correctly.
2. Using the washers and spacers
provided, loosely fit the
Knee Pad to the Side Frame
ensuring that the Knee Pad is
positioned correctly.
3. Fasten Knee Pad in place by
securing both bolts, allowing no
movement of the Knee Pad.
4. Locate the Grab Bar and 2x sling
anchor bolts; and Grab Bar with 2
x Bolts and Plastic caps
2

9
RHLH
7
8
5
6
5. Place the Grab Bars in between
the arms of the Upright Frame.
Secure the top Grab Bar with
the sling anchors bolts and the
bottom Grab Bar with the two
bolts as shown. Tighten and
secure bolts to lock in place. Use
the two plastic caps to cover the
holes in the Upright Frames.
6. Fasten the Upright Frame to the
Base Unit using a large washer
and bolt. Tighten the bolt firmly.
The bolts are provided with
threadlocker on the thread, if this
is missing or more is required,
medium strength 243 Loctite can
be applied before tightening.
7. Select the desired seat pad
(left or right) and insert into the
appropriate side frame.
8. Slide the Narrow retaining ring
over the seat pad mounting
and nest the mounting into the
frame. Check to ensure it can
freely rotate through range.

10
11
9 10
14
9. Check the Deep retaining ring
is already positioned in the
Mounting plate.
10. Fasten the three Bolts evenly and
check the pad is free to rotate
through range. Tighten each
bolt firmly.
11. Press the Cover cap in place.
12. The fitting process is the same
for both Seat Pads.
13. Complete a final check after all
bolts are tightened to ensure the
Seat Pads are rotating smoothly.
14. Assembly is now complete and
the Star Mover should look like
this image on the right.

11
8. GENERAL OPERATION
TRANSFERRING TO THE STAR MOVER
7. PRELIMINARY CHECKS
After assembling the Star Mover, complete the following checks prior
to first use.
1. Check the seat pads are secure and rotate back and forth smoothly
throughout the full range of movement.
2. Check that locking castors engage and disengage.
3. Check that the leg opening and closing mechanism works correctly
using the Foot Pedal.
4. If using a sling, ensure the clip attachment is securely mounted to the
sling anchor bolts on the frame.
1. Position the Star Mover close to the user
requiring transport.
2. To open or close the legs, push down
on the Foot Pedal. Legs can be opened
around chair legs OR closed to slide
in between.
3. Apply the rear castor brakes by pressing
down on the locking tabs.
2
3

12
4
5
6
4. Raise the Seat Pads using the
integrated handle.
5. With feet positioned on the footplate, the
user should grasp the Grab bar and stand
up with lower legs against the Knee Pad
for support.
6. Once the user is fully standing, lower
the Seat Pads so the user can be seated.
Once the user is secure, release the
Castor Brakes by lifting the locking tabs.
The carer can then move the Star Mover
using the Push Handles as shown below.

13
TRANSFERRING FROM THE STAR MOVER
2
3
4
5
1. Position the Star Mover close to the seat
or bed.
2. Open the legs of the Star Mover for
greater stability. Do this by pushing down
on the Foot Pedal.
3. Apply the Castor Brakes by pressing
down on the locking tabs.
4. Have the user stand up using the Grab
bar for assistance. Lift up the Seat Pads.
5. The user can now slowly lower
themselves onto the seat using the Grab
bar for support. The carer should hold
the Star Mover by the Push Handles
throughout this operation.
6. Ensuring that the user has removed their
feet from the footplate, the carer can now
unlock the Castor Brakes and wheel away
the Star Mover.

14
SLING ATTACHMENT
KNEE PAD ADJUSTMENT
Sling and Transfer Belt attachments are
provided for users who require extra support.
See page 17 for approved Aspire Slings.
1
2
1. The Knee Pad can be height adjusted
using an Allen key. Loosen the bolt on
either side until the Knee Pad is free
to move.
2. Slide the Knee Pad to the correct position
and fasten both bolts securely.

15
9. TRANSFER GUIDE
USING THE STAR MOVER WITH A BED
The Star Mover can be used to aid a user getting out of bed.
1
2
3
4
1. Position the user facing the Star Mover
with their feet on the floor.
2. Apply the Castor Brakes, open the legs
of the Star Mover if required and flip up
the Seat Pads. Ensure the user’s feet are
squarely on the footplate.
3. The user should grasp the Grab bar with
both hands for assistance standing up.
4. Once the user is fully standing, flip down
the Seat Pads for the user to sit on.
5. The carer can then remove the brakes
and propel the Star Mover to the
required destination.

16
USING THE STAR MOVER WITH A CHAIR
The Star Mover can be used to aid a user get out of a chair or wheelchair,
or off a commode or toilet. If used with a wheelchair, the wheelchair brakes
must be applied and leg rests removed prior to operation.
1
2
3
4
1. Position the user so they are facing the
Star Patient Mover with their feet on
the floor.
2. Open the legs of the Star Mover if
required, flip up the Seat Pads and apply
the Castor Brakes. Ensure the user’s feet
are squarely on the footplate.
3. The user should grasp the Grab bar with
both hands for assistance standing up.
4. Once the user is fully standing, flip down
the Seat Pads for the user to sit on.
5. The carer can then disengage the Castor
Brakes and commence transport of
the patient.

17
10. SLING COMPATIBILITY
The Aspire Standing Sling range is designed specifically for safe user with
the Star Patient Mover. Always consult with Aidacare if wanting to use a
different brand of clip sling to ensure compatibility.
DELUXE STANDING SLING
Code Description Edging SWL
LSS390920 Deluxe Padded Standing Sling – Polyester – Clip – Small 200kg
LSS390925 Deluxe Padded Standing Sling – Polyester – Clip – Medium 200kg
LSS390930 Deluxe Padded Standing Sling – Polyester – Clip – Large 300kg
LSS390935 Deluxe Padded Standing Sling – Polyester – Clip – Extra Large 300kg

18
11. CARE & MAINTENANCE
For trouble-free operation and prolonged working life of the Star Mover,
we recommended periodic inspection by a person suitably qualified and
acquainted with the design, use and care of patient movers.
If inspection reveals that the safety of the Star Mover has been jeopardized
in any way, the unit should be IMMEDIATELY WITHDRAWN FROM SERVICE,
tagged as such, and reported to the owner.
MAINTENANCE GUIDE & CHECK LIST
• Check Castors are fastened securely to the frame
• Castors should run and swivel smoothly – periodically remove any hair
or other fibres that have built up within the Castor.
• Check that the brakes on the rear Castors function normally.
• Clean surfaces with a pH-neutral detergent – chlorine, alcohol and phenol
based detergents should not be used as these may damage patient
mover components and surfaces.
• All moving parts and pivot points should be routinely checked for fatigue
and lubricated if necessary.
• Sling attachment points should be checked for general wear and tear
and replaced if necessary.

19
12. WARRANTY & SERVICE
AIDACARE warrants its products to be free from material – and
workmanship-related defects under normal use and service. From the
date of purchase, within the period stated below, we shall repair or replace
without cost to the original customer, any part assembly or portion thereof
which shall be returned to Aidacare and deemed to be defective by our
own inspection.
2YEARS
WARRANTY
Above warranty only applies to manufacturer defect only, and does not
cover wear and tear through use.
WARRANTY IS CONTINGENT UPON ANNUAL SERVICING BEING
COMPLETED FOR THE LENGTH OF THE WARRANTY PERIOD.
Aidacare cannot be held responsible for any personal injury, damage to the
Star Mover or damage to property resulting from improper or unsafe use of
the product. No warranty claim shall apply where the product or any part
thereof has been modified, varied, altered or damaged either accidentally
or through improper or negligent use.
No warranty claim shall apply where the patient mover has been repaired
or serviced by parties other than those accredited and/or approved
by Aidacare.
ALL WARRANTIES MADE ARE BACK TO BASE WARRANTIES MEANING
THAT ANY PARTS OR WHOLE STAR MOVERS REQUIRING REPAIR NEED
TO BE RETURNED TO THE NEAREST AIDACARE SERVICE CENTRE AT THE
CUSTOMER’S EXPENSE – PLEASE CONTACT AIDACARE FOR A CURRENT
LIST OF SERVICE CENTRE LOCATIONS.
SPARE PARTS
Spare parts list available upon request from Aidacare.

20
13. TROUBLESHOOTING
WARNING: TROUBLESHOOTING SHOULD ONLY BE CARRIED OUT BY
AIDACARE AUTHORISED SERVICE TECHNICIANS.
The following is a guideline only to general troubleshooting.
PROBLEM POTENTIAL FAULT ACTION
Castors are not
moving smoothly
over carpet or
other surfaces.
Build up of material
in castor housing.
Clean castors thoroughly.
Castors not sitting flat
on the floor.
Castor may be
lodged incorrectly
in mount point.
Remove unit from
service and contact
Aidacare immediately for
inspection and possible
castor replacement.
Seat and Knee Pads
are not swivelling.
Connection points
could have become
loose or unsecured.
Remove unit from
service and contact
Aidacare immediately for
inspection and possible
castor replacement.
Leg operation is not
functioning when
engaging foot pedals.
Build up of material
in leg opening
mechanism.
Clean thoroughly.
If problem persists,
contact Aidacare
for inspection.
