Aspire VOGUE LIGHTWEIGHT WALKER User manual

USER MANUAL
WALK ERS
VOGUE FOREARM WALKER
VOGUE LIGHTWEIGHT WALKER
VOGUE CARBON FIBRE WALKER
vogue
aspire for...
style
support
independence

2 3
Congratulations and thank you for choosing this
Aspire Vogue Walker.
Aspire Vogue Walkers are manufactured with
the utmost attention to quality. Enjoy your
independence with peace of mind, in style.
This user manual contains a description of the
product and important guidelines to ensure
correct and safe use. It is important to read this
manual carefully prior to use. It is especially
important to read the safety requirements and
follow these.
Aidacare continuously improves products and
reserves the right to change the specifications
and functions of products without notice.
If you have any queries please contact your
dealer or Aidacare directly. Contact information
is located on the last page of this manual.
TABLE OF CONTENTS
1. Intended Use
2. Product Description
3. Warnings
4. Product Specifications
5. Accessories
6. List of Components
7. Instructions for Use
8. Care & Maintenance
9. Compliance
10. Warranty
4
4
5
6
6
7
8
10
11
11

4 5
Aspire Vogue Walkers are specifically designed for individuals who, due to a wide variety of reasons,
require additional support while walking. It should be used as a tool to assist people who have mobility
diculties with standing, walking or sitting independently.
The Aspire Vogue Forearm Walker is specially designed for individuals who cannot support weight on
their wrists but can still use their forearms for support.
With an Aspire Vogue Walker a user can stand, walk and rest more easily, allowing them to fulfil most
daily tasks and routines without assistance from others. Any other usage is not advised.
1. INTENDED USE
The Aspire Vogue Walker is a four wheel, lightweight walker with a cross folding frame. The product is
made of aluminium, so it is light and easy to store or transport. The walker oers great manoeuverability
and stability and its handles / forearm supports are height adjustable for a customised fit. It is equipped
with a fabric seat, soft backrest and a weatherproof shopping bag which allows the user to rest and to
carry small items.
2. PRODUCT DESCRIPTION
WARNING! This User Manual must be read before using the walker. The manufacturer
does not take any responsibility for damage and/or injuries caused by the fact that
the User Manual has not been followed.
WARNING! The walker must not be used by users with serious diculty balancing or
whose muscle strength is too low to stand and walk, even with the extra support of
a walker.
WARNING! The decision to use a walker should always be guided by a qualified
Health Care Professional, who can also advise and assist with the correct height
adjustment and usage instruction.
LIMITATIONS FOR USE
• Safe Working Load is 150kg.
• The shopping bag has a Load Limit of 5kg.
• The walker is to be used indoor and/or outdoor on flat surfaces.
• The walker is not intended to be self-propelled while seated.
• Ensure the walker is opened fully before use.
• The brakes MUST be in the locked position BEFORE sitting on the seat.
• Use the walker only for the purpose it is intended for.
• Use the walker only in good technical condition.
• Avoid modifying the walker without the manufacturer’s written acceptance for such modifications.
• DO NOT stand on the walker.
• DO NOT use in place of a wheelchair or patient transport device.
• All wheels MUST be in contact with the ground at ALL TIMES during use.
NOTE: Fingers or other body parts can be trapped between the walker’s parts during
folding, unfolding or adjusting of the walker. Be extremely careful when adjusting
the walker. Observe the dimensions of gaps between the walker’s elements to avoid
trapping your fingers or other body parts.
3. WARNINGS

6 7
4. PRODUCT SPECIFICATIONS
OVERALL
HEIGHT
OVERALL
LENGTH
OVERALL
WIDTH
FOLDED
WIDTH
SE AT
DEPTH
SE AT
WIDTH
SE AT
HEIGHT
WHEEL
SIZE
TOTAL
WEIGHT
BAG
S.W.L S.W.L
1020 -
1270mm 660mm 620mm 225mm 190mm 460mm 620mm 8” 9kg 5kg 150kg
VOGUE FOREARM WALKER - WAF705400
VOGUE CARBON FIBRE WALKER - WAF705350
OVERALL
HEIGHT
OVERALL
LENGTH
OVERALL
WIDTH
FOLDED
WIDTH
SE AT
DEPTH
SE AT
WIDTH
SE AT
HEIGHT
WHEEL
SIZE
TOTAL
WEIGHT
BAG
S.W.L S.W.L
695 –
920mm 680mm 600mm 225mm 190mm 460mm 550mm 8” 6.7kg 5kg 150kg
VOGUE LIGHTWEIGHT WALKER - WAF705300WH (WHITE), WAF705300RE (RED)
6. LIST OF COMPONENTS
1Lock release pulling cord (pull to fold)
2Push handle length adjustment locking
knob
3Height adjustable profile
4Seat tube (push here to open and lock seat)
5Height adjustment locking knob
6Folding cross bar
7Padded forearm supports
8Push handle & brake lever
9Fold-up lock button
10 Soft seat
11 Weatherproof shopping bag
12 Ultra soft-ride wheels for all terrain
1Lock release pulling cord (pull to fold)
2Push handle and soft touch brake lever
3Height adjustable profile
4Seat tube (push here to open and lock seat)
5Height adjustment locking knob
6Folding cross bar
7Fold-up lock button
8Soft seat
9Weatherproof shopping bag
10 Ultra soft-ride wheels for all terrain
11 Padded and stable backrest
VOGUE FOREARM WALKERVOGUE LIGHTWEIGHT/CARBON
FIBRE WALKER
Aspire Vogue Walkers are supplied in boxes and come folded, for easier transportation. The contents
include one complete folded Aspire Vogue Walker and one User Manual.
1
2
3
4
5
6
7
8
10
11
12
1
8
3
6
4
9
5
10
11
79
• Oxygen Bottle Holder Bag
• IV Pole
• Crutch and Cane Holder
• Meal Tray
• Night Light - LED Lamp
• Single Hand Brake System
5. ACCESSORIES
2
OVERALL
HEIGHT
OVERALL
LENGTH
OVERALL
WIDTH
FOLDED
WIDTH
SE AT
DEPTH
SE AT
WIDTH
SE AT
HEIGHT
WHEEL
SIZE
TOTAL
WEIGHT
BAG
S.W.L S.W.L
695 –
920mm 680mm 600mm 225mm 190mm 460mm 550mm 8” 5kg 5kg 150kg

8 9
6. INSTRUCTIONS FOR USE
INITIAL CHECK
• In the first instance remove the walker from the box and check the contents (using the picture above)
to ensure nothing is missing. If you discover any component is missing or damaged do not continue to
assemble the product. Contact your supplier immediately.
OPENING THE WALKER
• Press the fold-up lock button on the seat tubes to release walker from folded position.
• Simultaneously push both seat tubes down until you hear an audible “click” of the seat locking
mechanism locking in place on the frame. If the frame is open and secured correctly, you should not
be able to fold the frame back up by pulling on the seat tubes
FOLDING THE WALKER
• Pull upwards on the lock release pulling cord (as shown in the list of components).
• Push seat tubes together until the fold-up lock button clicks together
WARNING! After unfolding or assembling the walker always ensure that the seat is
securely locked and the frame does not move anymore.
WARNING! Always ensure that handles/forearm supports are securely locked
in place by tightening the locking knobs to prevent the accidental sliding of the
handles/forearm supports when forced.
WARNING! Always test to see that accessories are properly and safely locked in
place (without play) BEFORE using.
WARNING! Failure to follow these warnings can result in personal injury.
ADJUSTING THE HEIGHT OF THE HANDLES/FOREARM SUPPORTS
• Release the handle height adjustment locking knob;
• Make adjustments to your desired height;
• Tighten the knob
ADJUSTING THE DEPTH OF THE FOREARM SUPPORTS
• Release the push handle length adjustment locking knob;
• Make adjustments to your desired length;
• Tighten the knob
WARNING! Both handles / forearm supports should be adjusted to the same
height/length.
WARNING! Seek advice from a qualified health professional for the appropriate
height/length level to suit your needs.
USING THE HAND BRAKES
• To stop the walker, activate the brakes by pulling the brake handles towards the hand grips.
• To start moving again, release the brake handles. They will drop down automatically and the brakes
will be released.
WARNING! You should always engage the brakes when you don’t want the walker
to move.
WARNING! NEVER leave the walker without the brakes engaged when there is
someone sitting in it.
WARNING! NEVER leave the walker on a slope without the brakes engaged.
LOCKING/UNLOCKING THE HAND BRAKES
• To lock the brakes push the brake handles down until you hear an audible “click”.
• To unlock the brakes pull the brake handles up until you feel them loosen
WARNING! When using the walker in a stationary position, the hand brakes MUST
always be locked.
SITTING ON THE WALKER
• Ensure the hand brakes have been activated.
• While holding onto the handles turn with your back facing the seat and pull the walker towards you
until it can be felt against the backs of your legs.
• Slowly and carefully lower yourself onto the seat.
WARNING! ALWAYS sit centrally on the walker, avoid leaning heavily in any direction
as this may cause the walker to become unstable.
WARNING! You should NOT sit (partly) above the shopping bag.
WARNING! ALWAYS sit up right on the walker while resting your forearms or hands
on the push handles.
WARNING! NEVER propel yourself with your feet using the walker as a
transportation device – it is NOT designed for this purpose.
WARNING! NEVER allow another person to push you along while seated on the
walker – it is NOT designed as a transportation device and is NOT a substitute for a
wheelchair.

10 11
7. CARE & MAINTENANCE
Weekly Periodically Yearly Serviceable Components
• Check brake
function
• Check all
wheels are
secure
• Check handgrips for wear
• Check frame bolts are
secure
• Check folding hinge bolts
are secure
• Check front and rear axle
bolts are secure
• Check for wear or cracks
• Check wheels for splitting or
damage
• Check seat upholstery for
wear and seat base for
cracks and that it is secured
to frame
• Take your walker
to an authorised
repairer for a full
check, clean, service
and lubrication of all
moving parts.
• Wheels
• Bag
• Hand grips
• Forearm Supports
• Brake Cables
• Seat
• Brake Handles
• Bearings
• Nuts & Bolts
MAINTENANCE SCHEDULE
GENERAL:
• Clean the walker regularly with a damp cloth.
• Use a mild washing agent and warm water for excess dirt build up.
• DO NOT use harsh abrasives or bleach based agents which may cause damage or discolouration.
• Dry with a soft cloth.
WHEELS:
• Clean wheels with a mild washing agent and warm water. Remove hair and other dirt from axles.
• Lubricate with multi-purpose oil periodically or if wheels begin to squeak.
MAINTENANCE:
• Ensure that every part of the walker is secure at ALL times.
• Check all screws for tightness. If not, tighten if necessary.
• Replace any broken, damaged or worn items immediately.
9. WARRANTY
Aidacare provides a 12 month warranty subject to reasonable wear and tear. Aidacare is bound by
Australian Consumer Law in respect to “Warranty Against Defects” on this product. A copy of the
Aidacare “Warranty Against Defects” Statement is available on our homepage (www.aidacare.com.au).
Any contact pertaining to warranty matters should be directed to Aidacare Customer Serivce on 1300
133 120 where support will be provided.
Should any part of the walker brake, fatigue or show defects that may be due to manufacturing issues
or error, Aidacare will replace the aected components free of charge and reserves the right to replace
the entire walker should this be more economical for Aidacare. All warranties are back to base, which
requires the user to return the walker or the aected part to an Aidacare Service Centre. For the location
of your nearest service centre call 1300 133 120.
For all warranty claims, proof of purchase must be provided by the customer. Aidacare warranty does
not cover any product or component damaged or broken due to neglect or misuse. Aidacare does not
honour this warranty for any product that has been modified from its original state. Aidacare will bear no
freight costs for the return of any items under warranty.
The suggested service period for all walkers is every 12 months.
8. COMPLIANCE
Aspire Vogue Walkers are manufactured to strict quality control standards.
As part of Australian Standards compliance, safety stickers are located on the frame of this walker.
Please ensure that you familiarise yourself with these prior to use.
This product complies with Australian Standards ISO11199-2:2005.
As the importer of this product Aidacare maintains records of all testing reports and compliance
certificates.

AIDACARE PTY LTD
4 Noonan Road, Ingleburn NSW 2565
1300 133 120
www.aidacare.com.au
MADE IN CHINA
ASUM12.16 060417
vogue
