AsReader ASR-R202G Series User manual

Updated:4/9/2019
ASR-R202G
Series
Quick Start
Guide
Manual

ASR-R202G Parts –Page 1/2
Font-view Back-view

How to Assemble –Page 1/7 (Preparation)
This section is for assembling the ASR-R202G
parts for use.
Please prepare the following parts to assemble:
a) Gun (ASR-R202G)
b) AsRing+ (ASA-102R)
c) AsLock Header (ASA-R250G-HDL)
d) AsLock Spacer (ASA-102R-SPL)
e) A compatible iOS Device
f) Case* (ASC-xxx-x)
a. b. c.
*Silicone ASC-P6-W case shown. Hybrid cases also available. d. e. f.
a.
f.
e.d.
c.b.

How to Assemble –Page 2/7 (Connect Header to Gun)
Slide Header firmly onto the ASR-R202G as shown (Steps 1-2).
Step 1 Step 2
Connector
PUSH FIRMLY
Face-Down Face-Up
Connection Point
Top View of Gun
Slide Header onto Gun Make sure Header is firmly
attached to the Gun.
Face-Down Face-Up
Top View of Gun
Step1 Step2
Push Firmly
Connector
Connector Point

How to Assemble –Page 3/7 (Combine AsRing+ and Spacer)
Set up the AsRing+ and Spacer as shown (Steps 1-4).
Step 1 Step 2 Step 3 Step 4
Place AsRing+ on top of Spacer. Slide top of AsRing+ into Spacer. Hardly press the bottom to fit the
AsRing+ into place.
Make sure none of the AsRing+ sides
are sticking out.
Press it hardly
Step1 Step2 Step3 Step4

How to Assemble –Page 4/7
Attach the assembled AsRing+/Spacer to the iOS device as shown (Steps 1-2).
Step 0 Step 1 Step 2
Prepare the assembled
AsRing+/Spacer and the iOS
device.
Connect Lightning Connector
to iOS device.
Make sure the parts are
securely connected.

How to Assemble –Page 5/7 (Using Silicone-only Case)
Silicone Case:
If a Silicone-only case is being used, please follow the instructions below (Steps 1-3).
Silicone-only Case Silicone-only Case Silicone-only Case
Insert device into case
starting at the bottom.
Slide remaining sides
into the case.
Make sure device is correctly
inside the case.
Step1 Step2 Step3

How to Assemble –Page 6/7 (Using Hybrid Case)
Hybrid Case:
If a Hybrid case is being used, please follow the instructions below (Steps 1-5). If using an iPod Touch with an ASC-P5H,
ASC-P7H, or ASC-P7PH case, make sure Step 0 on ‘How to Assemble – Page 4/7’ was followed before proceeding.
Step 1 Hybrid Case Step 2 Hybrid Case Step 3 Hybrid Case Step 4 Hybrid Case Step 5 Hybrid Case
(2)
(1)
(3)
Separate the silicone part
from the plastic part.
Place unit into silicone
part starting at the base.
Make sure all sides of
the device are properly
inside the case.
Place the unit into the plastic
part by aligning (1) bottom, (2)
right-hand side, then (3) top.
Slide the left side in and
make sure all sides are
properly in place.

How to Assemble –Page 7/7 (The final step)
Finally, attach the magnetic part of the AsRing+ to the top of the Header as shown (Steps 1-4).
Magnetic connection of AsRing+.
Magnetic connection of Header. Attach the parts as shown.
Picture of completely
assembled Gun.
Rotate clockwise until you hear a
click to indicate that the buckle
has tightened.
Step1 Step2 Step3 Step4

ASR-R202G Apps –Page 1/1
The LongRange2D App allows
the user to scan barcodes. Also can
export the data to .csv files.
Essential apps for the ASR-R202G and AsRing+ are the
following:
1) LongRange2D (Gun Demo App)
2) AsRing+ (for AsRing+ Firmware Updates)
3) AsTagFinder*
The AsRing+ Firmware Update App can be downloaded
from APPStore.
The AsRing + App is necessary to
update the AsRing+ to the latest
firmware version.
The LongRange2D App can be downloaded from:
AppStore.

How to Charge –Page 1/1
1) Please prepare the
following parts:
lASR-R202G (to be
charged)
lmicroUSB-to-USB
cable
2) Connect the
microUSB-to-USB
cable to a
powered charging
port via the USB
connection.
(Apple chargers are
recommended.)
C
A
B
B
C
C
B
B
Step 1 Step 2 Step 3 Step 4

Basic Use Guide –Page 1/3
Before using the ASR-R202G, please complete the
previous steps:
1. Assemble the ASR-R202G
2. Download the apps
3. Charge the ASR-R202G
Next, turn the ASR-R202G power on by pressing and
holding the ‘POWER’ button. The Gun should vibrate and
make a beep sound.
Open the LongRange2D App and check that you have the
latest versions* of:
‘Firmware Version’
‘AsRing+ Version’
*Use the latest Firmware for the best performance. For information on how to update the firmware on the Gun and AsRing+, please see our Firmware Update Manuals.

Basic Use Guide –Page 2/3
This section only applies to the
ASR-R202Gfor barcode use.
Select ‘Barcode Scan’ on the main page and
pull the Gun trigger (or tap ‘Start Scan’) to
begin scanning barcodes.
List of Scanned Barcodes
Rescan Time:
This setting is used to set a time between each
scan. ‘Not Used’ will set the Gun to only read
one barcode per trigger pull (‘Start Scan’ press).
Alternate
“soft-trigger” button
Total Number of Scans
Clear Scanned Tags
Export barcode data to .csv file
Select Encoding mode

Basic Use Guide –Page 3/3
More settings can be changed by selecting ‘Settings’ or ‘Barcode Option’.
Main Menu Settings Barcode Options Main Menu

Troubleshooting Guide –Page 1/1
If the Gun has issues such as a beep sound or vibration
that does not stop, even when the ‘POWER’ button is
pressed, please use the ’RESET’ button.
*Use a ballpoint pen or something similar to press it.
‘RESET’ button*
If the Gun isn’t connecting, the first thing you should
check is that your Header is firmly attached to the top of
the Gun.
Check that Header
is firmly in place.
Please contact us if you experience any other issues with
the ASR-R202G.
Push Firmly
