Code Cr1500-k10 series User manual

D030210_06_CR1500_User_Manual

USER MANUAL

MANUAL VERSION 06

UPDATED: OCTOBER 2022

CR1500

D030210_06_CR1500_User_Manual

Statement of Agency Compliance

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC

Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment

generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If

this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and

on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Industry Canada (IC)

This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this

device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation

of the device.

Industrie Canada (IC)

Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée

aux deux conditions suivantes : (1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage

radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.

The software described in this manual may only be used in accordance with the terms of its license agreement.

No part of this publication may be reproduced in any form or by any means without written permission from Code Corporation. This includes

electronic or mechanical means such as photocopying or recording in information storage and retrieval systems.

NO WARRANTY. This technical documentation is provided AS-IS. Further, the documentation does not represent a commitment on the part of

Code Corporation. Code Corporation does not warrant that it is accurate, complete or error free. Any use of the technical documentation is at

the risk of the user. Code Corporation reserves the right to make changes in specications and other information contained in this document

without prior notice, and the reader should in all cases consult Code Corporation to determine whether any such changes have been made.

Code Corporation shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages

resulting from the furnishing, performance, or use of this material. Code Corporation does not assume any product liability arising out of or in

connection with the application or use of any product or application described herein.

NO LICENSE. No license is granted, either by implication, estoppel, or otherwise under any intellectual property rights of Code Corporation. Any

use of hardware, software and/or technology of Code Corporation is governed by its own agreement.

The following are trademarks or registered trademarks of Code Corporation:

CodeShield®, CodeXML®, MakerTM, QuickMakerTM, CodeXML®MakerTM, CodeXML®Maker ProTM, CodeXML®RouterTM, CodeXML®Client

SDKTM, CodeXML®FilterTM, HyperPageTM, CodeTrackTM, GoCardTM, GoWebTM, ShortCodeTM, GoCode®, Code RouterTM, QuickConnect CodesTM,

Rule RunnerTM, CortexTM, CortexRM®, CortexMobile®, Code®, Code ReaderTM, CortexAGTM, CortexStudio®, CortexTools®, AfnityTM, and

CortexDecoder®.

All other product names mentioned in this manual may be trademarks of their respective companies and are hereby acknowledged.

The software and/or products of Code Corporation include inventions that are patented or that are the subject of patents pending. Relevant

patent information is available on Code’s Patent Marking page at codecorp.com.

The Code Reader software uses the Mozilla SpiderMonkey JavaScript engine, which is distributed under the terms of the Mozilla Public License

Version 1.1.

The Code Reader software is based in part on the work of the Independent JPEG Group.

Code Corporation, 434 W. Ascension Way, Ste. 300, Murray, Utah 84123

codecorp.com

Code Reader™ 1500 User Manual Legal Disclaimer

D030210_06_CR1500_User_Manual

Table of Contents

1. CR1500 Readers & Accessories .............................................................................. 4

1.1 Readers..................................................................................................................... 4

1.2 Accessories.............................................................................................................. 4

1.3 Power Supplies ........................................................................................................ 4

1.4 Cables....................................................................................................................... 4

2. Unpacking & Installation.......................................................................................... 5

2.1 CR1500 & Cables ..................................................................................................... 5

2.2 Universal Stand ........................................................................................................ 5

3. Attaching & Detaching a Cable ................................................................................ 6

4. Setup...................................................................................................................... 6

5. Using a CR1500 Outside of a Universal Stand .......................................................... 7

6. Using a CR1500 in a Universal Stand ...................................................................... 7

7. Typical Reading Ranges .......................................................................................... 7

8. Reader Feedback .................................................................................................... 8

9. Symbologies Turned On by Default .......................................................................... 8

10. Symbologies Turned Off by Default........................................................................ 8

11. Reader ID, Firmware Version & License.................................................................. 9

12. CR1500 Overall Dimensions .................................................................................. 9

13. USB Cable Example with Pinouts ......................................................................... 10

14. RS232 Cable Examples with Pinouts.................................................................... 10

15. Reader Pinouts ................................................................................................... 10

16. CR1500 Maintenance .......................................................................................... 11

17. Online Resources for the CR1500 ........................................................................ 11

18. Contact Code for Support.................................................................................... 12

18. Warranty ............................................................................................................. 12

D030210_06_CR1500_User_Manual

Part Number Description

CR1500-K10x Cabled, Light Gray, CodeShield® Level 3

CR1500-K20x Cabled, Dark Gray, CodeShield Level 2

CR1500-L20x CPM Reader, Cabled, Dark Gray, CodeShield Level 2

CR1500-M20x XHD Reader, Cabled, Dark Gray

1.1 Readers

Part Number Description

CRA-US2 CR1xxx - Stand, Light Gray

CRA-US3 CR1xxx - Stand, Dark Gray

CRA-MB9 CR1xxx - Vice Clamp Mount

CRA-WMB3 CR1xxx - Wall Mount Bracket (Light Gray)

1.2 Accessories

Part Number Description

CRA-P4 USB Power Adapter for all Cabled Readers

CRA-P5 International Power Supply, USB, with US/EU/UK/AU Adapter Clips

CRA-P6 International Power Supply, Barrel Plug 5V/1A, with US/EU/UK/AU Adapter Clips

CR2AG-P1 US Power Supply for RS232

CR2AG-P2 EU Power Supply for RS232

1.3 Power Supplies

Refer to codecorp.com for a complete list of available cables.

1.4 Cables

1. CR1500 Readers & Accessories

D030210_06_CR1500_User_Manual

2.1 CR1500 & Cables

2.2 Universal Stand

2. Unpacking & Installation

CR1500 USB Cable RS232 Cable 5VDC

Power Supply

D030210_06_CR1500_User_Manual

3. Attaching & Detaching a Cable

4. Setup

Plug In

Wait 2 seconds

LED will Flash

Reader will beep

Reader will vibrate

2 Sec.

D030210_06_CR1500_User_Manual

5. Using a CR1500 Outside of a

Universal Stand

6. Using a CR1500 in a

Universal Stand

7. Typical Reading Ranges

Test Barcode CR1500-KXXX (standard)

Min/Max Distance

CR1500-LXX

Min/Max Distance

CR1500-M2XX

Min/Max Distance

3 mil Code 39 3.3” (85 mm)/4.2” (107mm) 0.6” (14 mm) / 1.5” (39 mm)

5.8 mil PDF417 0.4” (9 mm) / 1.7” (44 mm)

7.5 mil Code 39 0.7” (18 mm) / 6.6” (167 mm) 0.9” (24 mm) / 6.7” (170 mm) 1.4” (35 mm) / 2.3” (58 mm)

10.5 mil GS1 DataBar 0.2” (5 mm) / 8.1” (205 mm) 0.2” (5 mm) / 6.1” (155 mm) 0.6” (15 mm) / 2.8” (71 mm)

13 mil UPC 0.5” (13 mm) / 10.4” (265 mm) 0.7” (17 mm) / 9.6” (245 mm) 1.2” (31 mm) / 3.3” (83 mm)

3.3 mil Data Matrix 0.4” (11 mm) / 1.1” (29 mm)

4.2 mil Data Matrix 1.0” (25 mm) / 2.4” (60 mm) 0.4” (9 mm) / 1.2” (31 mm)

5 mil Data Matrix 1.1” (28 mm) / 3.9” (100 mm) 0.8” (20 mm) / 2.8” (70 mm) 0.4” (9 mm) / 1.5” (39 mm)

6.3 mil Data Matrix 0.7” (18 mm) / 5.3” (135 mm) 0.5” (12 mm) / 3.6” (92 mm) 0.3” (7 mm) / 1.6” (41 mm)

10 mil Data Matrix 0.2” (5 mm) / 6.5” (165 mm) 0.2” (5 mm) / 5.9” (150 mm) 0.3” (7 mm) / 2.1” (54 mm)

20.8 mil Data Matrix 0.5” (13 mm) / 12.9” (328 mm) 0.4” (10 mm) / 10.4” (265 mm) 0.3” (7 mm) / 3.6” (92 mm)

Note: Working ranges are a combination of both the wide and high density elds. All samples were high quality

codes and were read along a physical center line at a 10° angle. Default automatic gain control settings were

used with regular ofce lighting. Accuracy= +/- 10%. Testing conditions may affect working ranges. Measured

from the front of the device in metric units then converted to Imperial units.

10 cm 10 cm

D030210_06_CR1500_User_Manual

9. Symbologies Turned On

by Default

10. Symbologies Turned Off

by Default

8. Reader Feedback

Scenario Top LED Light Sound Vibration

CR1500 successfully powers up Green LED ashes 1 beep Handle vibrates

CR1500 successfully enumerates with host

(via cable) Once enumerated, the green LED turns

off 1 beep No vibration

Attempting to decode Green LED light is off None No vibration

Successful decode and data transfer Green LED ashes 1 beep Handle vibrates

Conguration code successfully decoded

and processed Green LED ashes 2 beeps Handle vibrates

Conguration code successfully decoded but wasn’t

successfully processed Green LED ashes 4 beeps Handle vibrates

Downloading le/rmware Amber LED ashes None No vibration

Installing le/rmware Red LED is on 3-4 beeps* Handle vibrates

*Depending on comm port conguration

The following are symbologies that are turned

on by default. To turn symbologies on or off,

scan the symbology barcodes in the CR1500

Conguration Guide—located on the CR1500

product page:

codecorp.com/products/code-reader-1500

• Aztec

• Codabar

• Code 39

• Code 93

• Code 128

• Data Matrix

Rectangle

• All GS1 DataBar

• Interleaved 2 of 5

• PDF417

• QR Code

• UPC/EAN/JAN

• Code 11

• Code 32

• Code 49

• Composite

• Grid Matrix

• Han Xin Code

• Hong Kong 2 of 5

• IATA 2 of 5

• Matrix 2 of 5

• Maxicode

• Micro PDF417

• MSI Plessey

• NEC 2 of 5

• Pharmacode

• Plessey

• Postal Codes

• Standard 2 of 5

• Telepen

• Trioptic

Code barcode readers can read a number of

barcode symbologies that are not enabled

by default. To turn symbologies on or off,

scan the symbology barcodes in the CR1500

Conguration Guide—located on the CR1500

product page:

codecorp.com/products/code-reader-1500

D030210_06_CR1500_User_Manual

11. Reader ID, Firmware Version & License

12. CR1500 Overall Dimensions

You will see a text string indicating your rmware version and CR1500 ID number.

Example:

For device management and obtaining support from Code,

reader information will be needed. To nd out the Reader

ID, rmware version and optional licenses,open a text editor

program (e.g., Notepad, Microsoft Word, etc.) and scan the

Reader ID and Firmware conguration barcode on the right.

Scan for Reader ID, Firmware,

and Licenses

Note: Code will periodically release new rmware for CR1500 readers. For information on latest rmware

please see codecorp.com/products/code-reader-1500.

Model Number Serial Number Firmware Version

Number

License Part

Number

(if there is any)

77 mm

(3.0”) D

52 mm

(2.0”) W

132 mm

(5.2”) H

D030210_06_CR1500_User_Manual

14. RS232 Cable Example with Pinouts

13. USB Cable Example with Pinouts

15. Reader Pinouts

The connector on the CR1500 is

an RJ-50 (10P-10C). Pinouts:

Notes:

1. Part to be ROHS and Reach compliant.

2. Maximum voltage tolerance = 5V +/- 10%

3. Caution: Exceeding the maximum voltage will void

manufacturer warranty.

Notes:

1. Part to be ROHS and Reach compliant.

2. Maximum voltage tolerance = 5V +/- 10%

3. Caution: Exceeding the maximum voltage will void

manufacturer warranty.

Pin 1 +VIN (5v)

Pin 2 USB_D-

Pin 3 USB_D+

Pin 4 RS232 TX (output from reader)

Pin 5 RS232 RTS (output from reader)

Pin 6 RS232 RX (input to reader)

Pin 7 RS232 CTS (input to reader)

Pin 8 External Trigger (active low input to reader)

Pin 9 N/C

Pin 10 Ground

CONN A NAME CONN B COLOR CONN C

1 VIN 1 RED TIP

4 TX 2

5RTS 8

6 RX 3

7CTS 7

10 GND 5 BLACK RING

NC - SHIELD

CONNECTOR A NAME CONNECTOR B

1 VIN 1

2 D- 2

3 D+ 3

4 GND 10

SHELL - NC

Connector B

Connector C

Connector A Connector B

Connector A

410

D030210_06_CR1500_User_Manual

16. CR1500 Maintenance

17. Online Resources for the CR1500

The CR1500 device needs only a minimum of maintenance to operate. A few tips are given below for

maintenance suggestions.

Cleaning the CR1500 Window

CR1500 window should be clean to allow the best performance of the device. The window is the clear plastic

piece inside the head of the reader. Do not touch the window. Your CR1500 uses CMOS technology that

is much like a digital camera. A dirty window may stop the CR1500 from reading barcodes. If the window

becomes dirty, clean it with a soft, non-abrasive cloth or a facial tissue (no lotions or additives) that has been

moistened with water. A mild detergent may be used to clean the window, but the window should be wiped

with a water moistened cloth or tissue after using the detergent.

Technical Support and Returns

For returns or technical support visit codecorp.com.

Please visit codecorp.com for resources to set up and manage the CR1500. On the CR1500 product page,

you will nd various information about the product.

The Firmware and Software tabs contain downloads for the device. They include:

• The latest device rmware

• CortexTools3, a Windows utility program to congure your code Reader, create conguration

barcodes, update reader rmware, set data parsing rules, load custom JavaScript applications, upload

images to your PC and much more

• Various Drivers (OPOS, JPOS, Virtual COM, etc.)

To congure the CR1500, go to “Support” and select “Device Conguration” to view the manual

conguration codes.

D030210_06_CR1500_User_Manual

If any problem is encountered when using a Code device, contact your facility’s technical support rst. If

they determine the problem lies with the Code device, they should contact the Code Support department at

codecorp.com. To obtain support, please provide the following information:

• Device model number

• Device serial number

• Firmware version

Code Support will respond by telephone or email.

If it is deemed necessary to return the device to Code for repair, Code Support will provide a Return

Authorization (RMA) Number and shipping instructions. Packaging or shipping improperly may result in

damage to the device and void the warranty.

For complete Warranty and RMA information, go to codecorp.com.

18. Contact Code for Support

19. Warranty

This manual suits for next models

Table of contents

Code CR1500-K10 Series User manual

Popular Barcode Reader manuals by other brands
