D6061/D6071 Unitrol Double Unit Series
(Push Side) Power Operator
Installation Instructions
Tools Needed
1/4-20
#7
#2 and #3
10" or 12"
3/8
Punch
Set (Inch)
Supplied Fasteners per Operator
6061/6071
Union Assembly
(D6001U)
Union Spacer
(6001US)
End Cap - RH
(6001ENRH)
Closer Assembly
(7500LAP)
Operator LAP
(6021LAP)
Conduit Assembly
(D6001CON)
Power Module Sub-assembly
(6001PM)
Power Supply
(6000SUP)
Inverter
(6000IN)
End Cap - LH
(6001ENLH)
Union Spacer
(6001US)
Operator LAP
(6021LAP)
Inverter
(6000IN)
Power Supply
(6000SUP)
Power Module Sub-assembly
(6001PM)
Closer Assembly
(7500LAP)
Unitrol Arm
Standard Reveal
(6660-1) x2
Deep Reveal
(6670-1) x2
Pour la version francaise voir www.nortondoorcontrols.com.
READ AND FOLLOW ALL INSTRUCTIONS. SAVE THESE INSTRUCTIONS.
This product can expose you to lead which is known to the state of
California to cause cancer and birth defects or other reproductive harm.
For more information go to www.P65warnings.ca.gov.
WARNING
(D6001COV-36
D6001COV-38
D6001COV-40
D6001COV-42
D6001COV-44
D6001COV-46
D6001COV-48)
Backplate - LH
(D6001BP-36-RH
D6001BP-38-RH
D6001BP-40-RH
D6001BP-42-RH
D6001BP-44-RH
D6001BP-46-RH
D6001BP-48-RH)
Backplate - RH
Cover
(D6001BP-36-LH
D6001BP-38-LH
D6001BP-40-LH
D6001BP-42-LH
D6001BP-44-LH
D6001BP-46-LH
D6001BP-48-LH)
(D6001COV-36
D6001COV-38
D6001COV-40
D6001COV-42
D6001COV-44
D6001COV-46
D6001COV-48)

Copyright © 2019-2020, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
80-9360-1031-020 Rev 6 11/20
2
D6061/D6071 Unitrol Double Unit Series (Push Side) Power Operator
Certications and Standards
• ETL Certied: Operator conforms to ANSI/UL standard 325 for automatic closing doors and UL10C Positive Pressure
Fire Test for Door Assemblies.
• ANSI A156.19: These products are designed to conform to this specication “for power assist and low energy power
operated doors.” These products are designed to exceed all the requirements for “Low Energy Power Operated Door”.
• Americans with Disabilities Act (A.D.A.): These door operators can be installed and adjusted to conform with A.D.A.
regulations.
• ANSI A117.1: These door controls permit door assemblies to conform to the requirements of this specication “for
buildings and facilities - providing accessibility and usability for physically handicap people”.
Contents
Certications and Standards...............................................................................2
Product Safety Warnings ..................................................................................2
General Information.......................................................................................3
Before You Begin ..........................................................................................4
Mounting Hardware Chart.................................................................................4
Technical Data ............................................................................................4
Prepare Frame and Doors..................................................................................5
Install Operators ..........................................................................................8
Install Track and Arm .....................................................................................11
Adjustments .............................................................................................12
Power Operators .........................................................................................13
Sync Operators...........................................................................................14
Finalize Installation.......................................................................................15
General Electrical Information ............................................................................15
Wiring Options...........................................................................................16
Troubleshooting .........................................................................................27
D6061/D6071 Template..................................................................................28
WARNING: To reduce risk of injury to person, use this operator only with Pedestrian Swing doors. FOR INDOOR USE ONLY
Product Safety Warnings
1. READ AND FOLLOW ALL INSTRUCTIONS.
2. Install only on a properly operating and balanced door.
A door that is operating improperly could cause severe
injury. Have qualied service personnel make repairs to any
hardware before installing the operator.
3. Remove, or make inoperative, all locks (unless mechanically
and/or electrically interlocked to the power unit) that are
connected to the door before installing the operator.
4. Do not connect the door operator to the source power
until instructed to do so.
5. Never let children operate or play with door controls. Keep
remote control (when provided) away from children.
6. Personnel should keep away from a moving door in
motion.
7. Test door’s features at least once a month. After
adjusting either force or limit of travel, retest door
operator’s features. Failure to adjust operator
properly may cause severe injury or death.
8. KEEP DOOR PROPERLY OPERATING. An improperly
operating door could cause severe injury or death.
9. SAVE THESE INSTRUCTIONS.

Copyright © 2019-2020, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
80-9360-1031-020 Rev 6 11/20 3
D6061/D6071 Unitrol Double Unit Series (Push Side) Power Operator
Operation:
Your Low Energy Operator can be congured in three variations to meet the standards:
1. Push plates, Wave-to-open switches, etc. are available to activate the operator.
2. Push & Go can be enabled. In this mode, your door is pushed (or pulled) slowly 15° manually, and then
automatically opens to full open position.
3. Door can be used as a manual door. The door will work and act like a standard door closer, with or without power,
when pushed or pulled open manually. If Push & Go is enabled and door is opened quickly, door will function as a
manual door (energy save feature). Push plates are still active.
If desired, overhead presence devices can be provided for an extra level of protection. Consult local authority having
jurisdiction. These are not required by current ANSI/BHMA A156.19 standards.
Opening:
When an opening signal is received by the control unit, the door opens to the fully open position. The open position is
held by the motor and is adjustable from 0 to 30 seconds. If the door is obstructed while opening, the door will stop; the
operator will sense obstruction (obstruction time is adjustable from 0 to 5 seconds) and the door will close.
NOTE: Door must be visible by person operating activation switch(s). Switch(s) to comply with ANSI/BHMA
requirements. Auxiliary door stop (by others) required.
Closing:
When the hold open time has elapsed, the door closer will close the door automatically. The door will slow to low speed
at latch before it reaches the fully closed position. The door is kept closed by spring force of the closer. If the door is
obstructed while closing, the door will stop against the obstruction; the operator will sense obstruction and reopen to
fully open position after obstruction time has been reached. Once the hold open time has elapsed a second time, the door
closer will close the door automatically. If the door is obstructed during this second closing cycle, the door will stop and
rest against the obstruction using only the force of the closer spring. To reset, allow door to fully close and re-activate push
plates to test operation.
Innite Hold Open:
An optional feature to be used if door is desired to be held open for more than 30 seconds.
Set selector mode switch on underside of union assembly to hold open. Door will immediately begin to open to the
fully open position. Once door is fully open, brake on end of motor energizes holding door in open position. To release
from hold open, if door is set up for executive operation (see page 20 or 22 for executive wiring instructions), door can
be closed with activation device. A pull on the door will also allow the unit to be taken out of hold open. Once door has
closed, the door will reopen to fully open position unless activation device is pressed or selector mode switch is changed
from hold open position.
NOTE: Door must be visible by person operating activation switch(s). Switch(s) to comply with ANSI/BHMA
requirements. Auxiliary door stop (by others) required.
General Information
WARNING: Make sure (120V, 60Hz) input
power is turned OFF at facility’s main circuit
breaker before proceeding with installation

Copyright © 2019-2020, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
80-9360-1031-020 Rev 6 11/20
4
D6061/D6071 Unitrol Double Unit Series (Push Side) Power Operator
Technical Data
Input power: 120VAC, 60Hz
Power consumption: .9 amps
Circuit breaker: 3 amps
Power supply: 24 V DC, max. 2.2 amp.
Door width: 36" - 48" (91-122 cm)
Door weight: 100-250 lb. (43-113 kg)
Door opening angle: up to 110° with reveal of 3" (7.6 cm) max
Hold open time: 0-30 seconds (A.D.A. 5 seconds min.)
Indenite for optional Innite Hold Open
Notes:
• Permanent wiring is to be implemented as
required by local codes.
• Activation devices: push plates, access control,
mats, touchless wall switches, etc.
• Maximum wire size is:
12AWG at terminals LINE and NEUTRAL
(120VAC; 60Hz) on Power Input Terminal
mounted on inside of end cap.
14AWG at all other terminals
• Rate of operation shall not exceed 300 cycles of
opening and closing per hour.
Before You Begin
1/8"
(3)
Door
Frame
Fasteners for Frame:
• 1/4-20 Machine screws for
hollow metal and aluminum.
• No. 14 x 2-3/4" (70mm) long
sheet metal screws for wood. Templating based on 1/8" gap
between door and frame.
• All dimensions are given in inches.
DO NOT scale drawings.
• Thickness recommended for reinforcements
in hollow metal doors and frames is charted.
• This template information based upon use of
5" maximum width butt hinges.
• Maximum frame reveal is 6-7/8" for both
6061 and 6071 units.
• Before beginning the installation, verify that
the door frame is properly reinforced and is
well anchored in the wall. Frame header must
be straight - without warp or bow.
• Unreinforced hollow metal frames and
aluminum frames should be prepared and
tted with 1/4-20 blind rivet nuts, furnished
by others.
• Concealed electrical conduit and concealed
switch or sensor wires should be pulled to
the frame before proceeding.
Hollow Metal Door Frame Reinforcing
Frame Material Reinforcing
Recommended Min. Required
12 Ga.
.105
(2.66)
12 Ga.
.105
(2.66)
18 Ga.
.048
(1.21)
14 Ga.
.075
(1.90)
10 Ga.
.134
(3.41)
12 Ga.
.105
(2.66)
16 Ga.
.060
(1.52)
10 Ga.
.134
(3.41)
12 Ga.
.105
(2.66)
18 Ga.
.048
(1.21)
8 Ga.
.164
(4.18)
10 Ga.
.134
(3.41)
Mounting Hardware Door or Frame Drill
Backplate:
14 x 1-1/2 Flat Head Self Drilling Screw Wood 3/16" (4.76mm)
Backplate:
1/4-20 x 1 Flat Head Machine Screw Metal Drill #7 (.201 dia. or 5.10mm)
Tap 1/4-20
Backplate:
1/4-20 x 5/8 Flat Head Machine Screw
Adjusting Tube and Shoe:
Sex Nut and Bolt (SNB)
(optional)
Hollow Metal 9/32" (7.00mm) thru
3/8" (9.50mm) door face opposite to closer
Aluminum or Wood 3/8" (9.50mm) thru

Copyright © 2019-2020, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
80-9360-1031-020 Rev 6 11/20 5
D6061/D6071 Unitrol Double Unit Series (Push Side) Power Operator
Door Size Dim A Dim B
Pair of 36" doors: 5-9/16" (141mm) 30-9/16" (776mm)
Pair of 38" doors: 7-9/16" (192mm) 32-9/16" (827mm)
Pair of 40" doors: 9-9/16" (243mm) 34-9/16" (878mm)
Pair of 42" doors: 11-9/16" (294mm) 36-9/16" (929mm)
Pair of 44" doors: 13-9/16" (344mm) 38-9/16" (979mm)
Pair of 46" doors: 15-9/16" (395mm) 40-9/16" (1030mm)
Pair of 48" doors: 17-9/16" (446mm) 42-9/16" (1081mm)
Prepare Frame and Door
Figure 1
Become familiar with operator components and fasteners. It is recommended that components remain in boxes
until installed. Verify there is minimum ceiling clearance for operator installation before proceeding. (Figure 1)
A. Prepare frame.
1. Determine if push or pull installation. (Figure 2)
NOTE: These instructions are for Pair of Doors,
PUSH only. See 80-9360-1029-020 instructions
for D6011/D6051 or 80-9360-1030-020
instructions for D6021/D6031 Push installation.
2. Frame header MUST be at / without twists.
Backplates can be used as reference.
NOTE: If frame is not at or is twisted,
additional steel back plates or shimming is
required. Failure to mount units properly can
result in improper function of operator or
inability to snap on covers.
3. Mark center of opening on frame header
between jambs.
4. Using chart, mark from center of opening to left.
(Figure 3)
NOTE: Template provided on page 28.
5. Measure 5/16" up from bottom of frame header
and mark at Dim A and Dim B locations.
6. Drill holes.
7. Using supplied backplate screw pack in Box 1,
insert screws into prepared mounting holes.
For Metal Frame: Use two (2) 1/4-20 x 1" at
head machine screws.
For Wood Frame: Use two (2) #14 x 1-1/2" at
head self-drilling screws.
NOTE: Do not tighten mounting screws at
this time. Leave 5/16" minimum (thickness of
backplate) between frame face and back of
screw head.
OR
Figure 2
Figure 3
Center of Opening
Pull Side
Push Side Right Hand
PUSH
Left Hand
PUSH

Copyright © 2019-2020, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
80-9360-1031-020 Rev 6 11/20
6
D6061/D6071 Unitrol Double Unit Series (Push Side) Power Operator
Prepare Frame and Door
Figure 4
Figure 5
Figure 6
B. Mount Backplates.
1. Select backplate with 2 “ngers” for interlocking
plates and marked “Mount This Plate First” from
Box 1. (This is LEFT backplate.)
2. Slide left backplate over mounting screws.
(Figure 4)
NOTE: Left backplate conduit slot is ALWAYS at
bottom of plate and toward center of opening.
3. Use level in backplate to align then tighten
mounting screws. (Figure 4)
4. Interlock right backplate (3 “ngers”) from Box 2
with left backplate. (Figure 5)
NOTE: Right backplate conduit slot is ALWAYS
at bottom of plate and center of opening.
5. Use level on right backplate to ensure proper
alignment. (Figure 5)
6. Using backplate as template, mark conduit slot
and Dim D mounting hole. (Figure 5)
NOTE: Dim D should be 5/16" up from bottom
of frame header if backplate is properly
aligned.
7. Drill hole for mounting screw at Dim D.
8. Using supplied backplate screw pack in Box 2,
insert screw into prepared mounting hole.
(Figure 6)
For Metal Frame: Use one (1)
1/4-20 x 1" at head machine screw.
For Wood Frame: Use one (1)
#14 x 1-1/2" at head self-drilling screw.
NOTE: Do not tighten mounting screw at
this time. Leave 5/16" minimum
(thickness of backplate) between frame
face and back of screw head.
9. Using countersunk holes in backplates as
a template, drill/tap remaining eleven (11)
mounting holes: 1/4-20 for steel frame or #14
for wood frame. (Figure 6)
Remaining Mounting Holes
Conduit Slot
Built-in Level 2 Fingers
Built-in Level
Dim D
OR
First Mounting
Screw
Door Size Dim D
Pair of 36" doors: 30-9/16" (776mm)
Pair of 38" doors: 32-9/16" (827mm)
Pair of 40" doors: 34-9/16" (878mm)
Pair of 42" doors: 36-9/16" (929mm)
Pair of 44" doors: 38-9/16" (979mm)
Pair of 46" doors: 40-9/16" (1030mm)
Pair of 48" doors: 42-9/16" (1081mm)

Copyright © 2019-2020, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
80-9360-1031-020 Rev 6 11/20 7
D6061/D6071 Unitrol Double Unit Series (Push Side) Power Operator
Figure 7
Figure 8
Door Opening
Angle 85° 90° 95° 100° 105° 110°
Dimension E 13-1/4"
(336.5)
12-5/8"
(320)
12"
(305)
11-1/2"
(292)
11-1/8"
(282.5)
10-3/4"
(273)
C. Secure Backplates.
1. Secure backplates to frame using eleven (11):
1/4-20 x 5/8" machine screws or
1/4 x 1-1/2" self-drilling screws from screw
packs in Boxes 1 and 2. (Figure 7)
NOTE: It is important to properly secure
top edge of backplate. Use of blocking
(supplied by others) or shims (provided) to
ll gap between backplate and wall above
header is HIGHLY recommended. Material
must comply with local codes. Failure to
properly secure top of backplate could result
in operator being allowed to ‘rock’ during
operation. This could result in damage to
operator and diminish operator function.
(Figure 7)
OR
Prepare Frame and Door
Blocking
D. Prepare doors for Adjusting Tubes and Shoes.
1. Locate and prepare adjusting tube and shoe holes in doors.
(Figure 8)
NOTE: Template provided on page 28.
2. Drill 3/8" (9.5mm) through (4 places) for sex bolts.

Copyright © 2019-2020, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
80-9360-1031-020 Rev 6 11/20
8
D6061/D6071 Unitrol Double Unit Series (Push Side) Power Operator
B. Install Operator LAP.
NOTE: Backplates are printed with text to assist
installation.
1. With backplates mounted to frame, use text to
locate holes along bottom of backplates that
correspond to your specic closer installation.
(Figure 10)
2. Insert two (2) 1/4-20 x 1/2" Phillips pan head
screws on each backplate into appropriate
engraved locations. Leave a 5/16" minimum
gap between backplate and underside of
screw head.
3. On each backplate, orient LAP so spring tube
of closer is pointed toward closest hinge edge
of frame. Slide each LAP over two (2) screws
and tighten. (Figure 11)
NOTE: When properly oriented, spring tube
is at bottom on left hand backplate (Figure
12) and at top on right hand backplate.
4. For each LAP, use six (6) 1/4-20 x 1/2" Phillips
head screws to secure. (Figure 12)
NOTE:
• Holes in LAP align with threaded holes in
backplate.
• Screws to be torqued to 80 in-lb minimum.
Install Operator
Figure 9
Remaining LAP Mounting Screws - Left Hand View
Figure 10
Figure 11 Left Hand LAP shown
Spring Tube
(at top
of backplate)
6060/6070 @ 85DEG
6060/6070 @90DEG
6060/6070 @ 95DEG
6060/6070 @ 100DEG
6020 & 6060/6070 @ 105DEG
6060/6070 @ 110DEG
6010/6050 & 6030
Operator LAP
Mounting Screws
A. Install End Caps.
1. Secure end caps to each end of
connected backplates using four (4)
(two each) #8-32 x 5/16" Phillips pan
head screws. (Figure 9)
NOTE: Orient end caps so that text
on labels is legible when observed
from ground.
Figure 12

Copyright © 2019-2020, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
80-9360-1031-020 Rev 6 11/20 9
D6061/D6071 Unitrol Double Unit Series (Push Side) Power Operator
Install Operator
D. Install Power Module Sub-assemblies.
1. Using three (3) #8-32 x 5/16" Phillips screws per
assembly, secure power module sub-assemblies
to backplate at location marked on backplates.
(Figure 15)
NOTE: Orient assemblies so LCD screens on
inverters are toward corresponding closer
assemblies. (Figure 15)
C. Install Conduit Assembly and wire to building.
1. Orient conduit assembly so two (2) conduit
holes are at bottom and text on wire input label
is legible. (Figure 13)
2. Secure assembly to backplate using four (4)
#8-32 x 5/16" Phillips head screws. (Figure 13)
WARNING: BUILDING POWER MUST BE OFF
BEFORE PROCEEDING!
3. Secure conduits to conduit assembly (surface or
concealed conduit). (Figure 14)
4. Wire building 120VAC to conduit assembly –
LINE, NEUTRAL, and GROUND. (See page 15 for
General Electrical Information.)
5. Wire 24VDC for accessories to conduit assembly
24VDC + / - as required. (See page 15 for General
Electrical Information.)
WARNING: DO NOT TURN ON BUILDING POWER
UNTIL DIRECTED TO DO SO! RISK OF INJURY OR
DEATH!
Figure 13
Conduit Assembly
Mounting Screws
Conduit Holes
Wire Input
Labels
Left hand LAP Right hand LAP
Figure 15 Wiring Removed From View
Power Module Sub-assembly
Mounting Screws
LCD Screen Closer
LCD Screen
Closer
Power Module Sub-assembly
Mounting Screws
Figure 14

Copyright © 2019-2020, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
80-9360-1031-020 Rev 6 11/20
10
D6061/D6071 Unitrol Double Unit Series (Push Side) Power Operator
Install Operator
Figure 16
Figure 17
Access Door
Union Assembly - View From Floor
Spacer
Spacer
Union Assembly
Mounting Screw
(typical)
Power Module
Sub-assembly
4 Pin Black
Connector
Power Module
Sub-assembly
4 Pin Black
Connector
Union Assembly
4 Pin Black Connector
Figure 18
Operator LAP
3 Pin White
Connector
Power Module
Sub-assembly
3 Pin White
Connector
Power Module
Sub-assembly
10 Pin Black
Connector
Operator LAP
10 Pin Black
Connector
Operator LAP
3 Pin White
Connector
Power Module
Sub-assembly
3 Pin White
Connector
Power Module
Sub-assembly
10 Pin Black
Connector
Operator LAP
10 Pin Black
Connector
E. Connect Power Module Sub-assemblies to LAPS.
1. Attach 10-pin black connectors between each power
module sub-assembly and its operator LAP.
(Figure 16)
NOTE: Connectors are keyed and only attach one way.
2. Attach 3-pin white connectors between each power
module sub-assembly and its operator LAP.
(Figure 16)
F. Install Union Assembly.
1. Orient union assembly so access door
covering selector mode switches faces oor.
(Figure 17)
2. Secure union assembly to backplate using
four (4) #8-32 x 5/16" Phillips pan head
screws. (Figure 17)
3. Connect 4-pin black square connector from
power module sub-assembly to 4-pin black
connector from union assembly for each
operator. (Figure 18)
NOTE: Connectors are keyed and only
assembly one way.

Copyright © 2019-2020, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
80-9360-1031-020 Rev 6 11/20 11
D6061/D6071 Unitrol Double Unit Series (Push Side) Power Operator
B. Install Main Arms.
A. Mount Adjusting Tubes and Shoes to doors.
Install Adjusting Tubes and Shoes and Main Arms
Figure 19
Figure 20
Figure 21
Figure 22
Figure 23
Figure 24
1. Using previously prepared holes in
doors, install two (2) 1/4-20 x 1-5/8"
screws through each shoe and into
sex bolts. (Figure 19)
NOTE: Orient shoe with short side
of shoe toward hinge. (Figure 20)
View from ceiling looking downward
1. Open door of your choosing.
2. Slide main arm rod into adjusting
tube. (Figure 21)
3. Place square of main arm onto closer
pinion. (Figure 21)
NOTE: Pinion at should be aligned
as shown. (Figure 22)
4. Attach main arm to pinion with
screw then tighten with 7/16"
wrench. (Figure 21)
5. With door closed, rotate main arm
away from hinge until adjusting tube
is perpendicular (90 degrees) with
door. (Figure 23)
6. While holding arm in position,
secure rod to adjusting tube with
forearm screw. (Figure 24)
7. Repeat on second door.
View from ceiling looking downward
Long Side
of Shoe
Hinge

Copyright © 2019-2020, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
80-9360-1031-020 Rev 6 11/20
12
D6061/D6071 Unitrol Double Unit Series (Push Side) Power Operator
B. Adjust spring force on each operator.
NOTE:
• The amount of effort to manually open or
close a door is called force and is controlled by
the operator’s closer spring.
• Make necessary mechanical adjustments
described in “A” above.
• A closer set to ADA required 5 lbs opening
force may not be strong enough to close door
due to latching hardware, air pressure, or
frame issues.
1. Using 11/16" wrench, turn nut in end of each
closer body tube to desired force.
(Figure 26)
NOTE: If spring adjustment nut is too close
to end cap and wrench will not reach nut,
remove Torx screw in end cap access door and
slide door open. When nished, slide access
door closed and reinsert #6 Torx at head
screw to secure door. (Figure 26)
Adjustments
A. Adjust mechanical closer features on each operator.
NOTE:
• Make necessary mechanical adjustments
so unit functions as a standard surface
mounted door closer before adjusting
spring force, applying power, adding
accessories or making electrical/
programming adjustments.
• Valve location S/D is not adjustable.
Do not remove valves from closer.
Hydraulic oil will escape.
1. Closing Speed Controls (Figure 25)
• Valve “S” controls Sweep Range from
full open to 10°.
• Valve “L” controls Latch Range from
10° to closed.
2. Opening Cycle (Figure 25)
• Valve “B” controls strength of cushioning
in Backcheck Range.
NOTE: NEVER close Backcheck valve
completely – it is not to provide a
positive stop.
• Valve “P” adjusts angle that backcheck
is felt in open cycle. Factory preset is
typically acceptable.
Figure 25 View of Left Hand operator from ceiling looking down
Figure 26 View of Left Hand operator

Copyright © 2019-2020, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
80-9360-1031-020 Rev 6 11/20 13
D6061/D6071 Unitrol Double Unit Series (Push Side) Power Operator
Power Operators
1. Open door on union assembly and place each selector
mode switch in ‘OFF’ position. (Figure 27)
2. Turn On/Off switch to ‘OFF’ position on conduit assembly.
(Figure 27)
3. Turn on building power.
4. Turn On/Off switch to ‘ON’ position on conduit assembly.
See page 17 for controller adjustment options.
• To scroll through menu items, push up or down on
joystick. (Figure 27)
• To change setting of a menu item, when cursor is on that
item, push joystick left/right to increase/decrease value.
NOTE: Values will auto-save 3 seconds after
adjustments.
5. Set ‘HOME’ procedure for both doors.
• With door closed and union assembly selector mode
switch in “OFF” position, use joystick to scroll down
menu on LCD screen to “Home”.
• Push in on joystick to activate menu feature. Display
changes to “Set Close Limit”.
• Push in on joystick again, while door is still closed, to set
Home or closed position (Figure 28). Display changes to
“Set Open Limit”.
• Open door to desired open position (Figure 28) and
push in on joystick again. Display changes to
“Closing to Home”.
• Allow door to fully close again (Figure 28). Display
changes to “Home”.
NOTE: Values will auto-save.
Figure 27
Figure 28
View From Floor
Union Assembly
Selector Mode Switches

Copyright © 2019-2020, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
80-9360-1031-020 Rev 6 11/20
14
D6061/D6071 Unitrol Double Unit Series (Push Side) Power Operator
You’ve now installed the D6061 or D6071 Unitrol PUSH SIDE Low Energy Operator.
Continue with Electrical Instructions to customize the installation.
Sync Operators
1. Determine which door will be Master.
2. Run Sync Cable between operators. (Figure 29)
• Attach end of Sync Cable marked “M” to 4-pin connector
on top of inverter board on unit selected as Master Door.
• Attach other end of Sync Cable marked “F” to 4-pin
connector on top of inverter board selected as Follower
Door.
NOTE: Connectors are keyed and only attach one way.
3. To set up inverter for Master - Follower functionality:
Master Unit:
• go to Page 2 on inverter screen
• scroll down to Single
• increase to Dbl:Master or
*Dbl:MasterCoord
Follower Unit:
• go to Page 2 on inverter screen
• scroll down to Single
• increase to Dbl:Follower
*NOTE: Dbl:MasterCoord to be used when astragal or
similar is attached to Master door or as a replacement
for a mechanical door coordinator. Once set, Master
Figure 29
Union Assembly Switches
door will open slightly before Follower door during
opening cycle. Upon closing, if Master door reaches
a set door opening position (MasterStopOffset) and
Follower door has not reached full closed position,
Master door will stop and wait for Follower door to
reach fully closed and then close. The point at which
Master door stops (MasterStopOffset) is adjustable.
*NOTE: If Dbl:MasterCoord is used and Follower door
is opened manually, Master door will automatically
open to MasterStopOffset position until Follower
door has reached fully closed position and then close.
4. Make necessary adjustments to Master Door inverter
only, add activation to Master Door inverter only, and
add required accessories to each door.
NOTE: Settings will automatically transfer over to
Follower Door inverter.
5. Place both selector mode switches of union assembly
in ‘ON’ position for activation by push plate, RF button,
or other activation devices. Place switches in ‘H/O’ for
continuous hold open. (Figure 29)
6. Secure union assembly door with #4 Phillips screw.

Copyright © 2019-2020, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
80-9360-1031-020 Rev 6 11/20 15
D6061/D6071 Unitrol Double Unit Series (Push Side) Power Operator
Attach Covers to nalize installation
1. Align cut-outs in each cover to corresponding
pinion shafts. (Figure 30)
2. Slide covers onto units using end caps and
union spacers as guides.
NOTE: Verify all wiring and sheet metal
guards are inside cover.
3. Snap covers securely to backplates. Pull on
covers to verify they are secure.
NOTE: If cover will not securely snap onto
backplate, verify backplate is not warped or
twisted. Additional support or shimming may
be required. See Sections A & B under Prepare
Frame and Door.
WARNING: Make sure no wiring is loose or can be
caught by cover when it is snapped into place.
Figure 30
General Electrical Information
• Power inputs at power input connection and
power output contacts must be made with
copper wire only.
• Maximum wire size:
12 AWG at power input connection
14 AWG at all other terminals.
• Power input at terminals LINE and NEUTRAL
must be 120VAC at 60 Hz (+10%, -15%).
Pinion Shaft Cut-out
Pinion Shaft Cut-out
• Maximum current draw from auxiliary devices is
1.3 amps.
• All wiring and connections use standard wiring
practice conforming with local wiring codes.
• Labeled re or smoke barrier door assemblies
require 120VAC 60Hz power input be supplied
through normally closed alarm contacts of the
alarm system / alarm panel.

Copyright © 2019-2020, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
80-9360-1031-020 Rev 6 11/20
16
D6061/D6071 Unitrol Double Unit Series (Push Side) Power Operator
Factory Pre-Wiring of Connections and Incoming Wiring
Controller Error Codes
Error Code Description
Short Circuit A short was sensed on the motor outputs
Temperature Trip Power module reached 200°F or greater (too much load in too hot ambient
condition)
Over Voltage Line Voltage has reached 145VAC or greater
Under Voltage Line Voltage has dropped below 80VAC
Aux 1 Stuck Activation device connected to Aux 1 is sending constant signal
Aux 2 Stuck Activation device connected to Aux 2 is sending constant signal
Aux 3 Stuck Activation device connected to Aux 3 is sending constant signal
Comm Error No communication between top and bottom controller boards. Boards not
functioning properly
Presence Detect Device connected to Presence Detect and was activated
Drive Disabled Selector mode switch on end cap closest to latch is in “OFF” position
To connect wiring:
For Incoming 120VAC and 24VDC for accessories
1. For 20 - 10 AWG wire
2. Strip end of wire 1/4 inch
3. Insert wire into appropriate position as shown
and use at head screw driver to secure
For Low Voltage / Dry Contacts on Inverter
1. For 24 - 16AWG wire
2. Strip end of wire 3/8 inch
3. Use at blade screw driver to push down on
white button above desired location, insert
wire, release button. Pull on wire to conrm
installed properly.

Copyright © 2019-2020, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
80-9360-1031-020 Rev 6 11/20 17
D6061/D6071 Unitrol Double Unit Series (Push Side) Power Operator
Controller Interface Description
Screen 1 Adjustments Default Description
Mount: Push or Pull Push Side of opening operator is mounted on
Hold Open: 0 - 30 sec in 1 sec increments 4s Amount of time door will stay in full open position after an activation
Open Delay
(previously
Start Delay):
0 - 10 sec in 1 sec increments 0s Time before operator begins to open door. This is to allow accessories time to
function and not hinder the opening of the door.
Latch Rtrct: OFF, 3 - 45 sec in 5 sec
increments OFF Amount of time power is supplied to a latch retraction device.
Home: see Setting Open Position -Used to set the Home position and the Fully Open position of the door.
Vestibule: OFF, 5 - 30 sec in 5 sec
increments OFF Amount of delay for opening 2nd vestibule door
Push: OFF or PushNGo OFF Turn on or off Push N Go feature. If On, a slight push or pull of the door starts it
automatically opening.
Open Speed: 0 - 100% in 1% increments 120 How fast the door opens to the full open position.
Close Speed: 0 - 100% in 1% increments 80
How fast the motor returns to the home position. As Latch and Sweep on the
closer are adjusted, adjustments may be needed for Close Speed to assure
closer is not trying to backdrive the motor.
Errors: not adjustable -Error code seen by controller. See Page 16 for Controller Error Codes.
Screen 2 Adjustments Default Description
Door Feedback: not adjustable -General feedback. Includes Door State, Door Position, Motor Position, Open
Limit, Close Limit.
Drive Feedback: not adjustable -General feedback. Includes Bus Voltage, Bus Current, Frequency.
Usage: not adjustable -General feedback. Includes Open Time, Close Time, Days, Cycles, Firmware Rev.
Single: Single Door, Dble:Follow,
Dble:Master, Dble:Mast Coord Single
Set on Single for a single, stand alone door. Dble:Follow for Follower door on
pair of doors. Dble:Master for Master door on a pair of doors. Dble:Mast Coor
for Master door on a pair of doors when door coordination is needed.
MastStopOffset: 0-500 180
Adjustable point where Master Coord door will stop and wait for Follower
door to fully close so Follower does not contact astragal attached to Master
Coord door.
PDET Option: On, Off Off On or Off for 585 Presence Detector
DT:
Standard, SS1:Stall,
SS1:Return Open, SS1:Stall /
Open
Stnd Standard is Door Toggle. SS1 is not functional.
A2:
Standard, SS2:Stall,
SS2:Return Home, SS2:Stall /
Nome
Stnd Standard is Activation mode - just like A1 activation. SS2 is not functional.
Rly2: Alarm, Activation, On Opened,
On Closed Alarm
How Relay 2 is used: Alarm - used with above Alarm Delay; Activation - acts as
an additional NO/NC contact; On Opened - relay trips (closed contacts) when
door is in opened position; On Closed - relay trips (closed contacts) when
door reaches the fully closed position.
Alarm Delay: OFF, 30 sec, 60 sec OFF Used only for alarm accessories
Slow Speed: 0 - 100% in 1% increments 55 Speed up or slow down door during last few degrees of opening.
Hold Speed: 0 - 100% in 1% increments 55 Increase or decrease hold open force (when in “ON” position only, not “H/O”)
to compensate for spring force, wind conditions, etc.
Obst Delay: 0 - 5 sec in 1 sec increments 3s
Obstruction Delay: the amount of time the operator will push against an
obstruction before closing if during an opening cycle or reopening and trying
to close again if during a clocking cycle.

Copyright © 2019-2020, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
80-9360-1031-020 Rev 6 11/20
18
D6061/D6071 Unitrol Double Unit Series (Push Side) Power Operator
Basic Double Door Wiring Diagrams Using Factory Pre-Wired Connection
Standard Function with Switches
• For Master/Follow or Master-Coord/Follow
only (Sync Cable must be used to connect
inverters.)
• Doors are normally closed.
Fail Secure Electric Strike 24VDC Wiring
• For Master/Follow or Master-Coord/Follow
only (Sync Cable must be used to connect
inverters.)
• Doors are normally closed and latched.
• Activating either switch will open both
doors. Door will close after hold open time
delay has expired.
• Activating switch will unlock electric strike and
door will automatically open. Door will close
after hold open time delay has expired.
• Door will remain locked during power failure.

Copyright © 2019-2020, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
80-9360-1031-020 Rev 6 11/20 19
D6061/D6071 Unitrol Double Unit Series (Push Side) Power Operator
Double Door Fail Safe Electric Strike or Electromagnetic Lock 24VDC Wiring
Double Door 24VDC Electric Exit Device Wiring
Factory Pre-Wiring in Illustration is for this functionality
Change Factory Pre-Wiring to Illustration Below (move NO to NC)
• For Master/Follow or
Master-Coord/Follow only
(Sync Cable must be used
to connect inverters.)
• Doors are normally closed
and latched.
• Activating switch will
energize exit device and
door will automatically
open. Exit device will
stay energized based on
Latch Rtrct setting. Door
will close after hold open
time delay has expired.
• Current draw at Power
Outputs not to exceed
1.3 amps.
• For Master/Follow or
Master-Coord/Follow only
(Sync Cable must be used
to connect inverters.)
• Doors are normally closed
and latched.
• Activating switch will
unlock electric strike or
mag lock and door will
automatically open. Door
will close after hold open
time delay has expired.
• Door will remain
unlocked during power
failure.
• Current draw at Power
Outputs not to exceed
1.3 amps.

Copyright © 2019-2020, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
80-9360-1031-020 Rev 6 11/20
20
D6061/D6071 Unitrol Double Unit Series (Push Side) Power Operator
Double Door Electric Dogging Exit Device Wiring
Double Door Hard Wired Executive Function Wiring
Factory Pre-Wiring Not Required to Change
• For Master/Follow or Master-
Coord/Follow only (Sync
Cable must be used to
connect inverters.)
• Doors are normally closed.
• Activating switch will open
door.
• Door will remain in indenite
hold open until activating
switch is activated a second
time causing door to close.
Change Factory Pre-Wiring to Illustration Below (move NO to +24)
• For Master/Follow or Master-
Coord/Follow only (Sync Cable
must be used to connect
inverters.)
• Doors are normally closed and
latched.
• Turning key switch ON will
apply power to exit device.
• First depression on device
touchpad will electrically dog
device for push/pull operation.
• Door will now open
automatically when wall switch
is depressed.
• Device will re-latch during
a power failure or when key
switch is turned off.
• Exit device allows egress at all
times. Exit device allows egress
during power failures.
• Current draw at Power Outputs
not to exceed 1.3 amps.
