Astonica 50103220 User manual

OUTDOORLIVING
Made in China
© 2002 Distruibuted by:
World Factory, Inc.®
Southlake,TX
1-888-422-7800
Limited Warranty
World Factory, Inc.® Products for Home Use
World Factory, Inc.® (Seller) warrants to the original Buyer only, that each Astonica™ Product will be free
from defects in material and workmanship for a period of one (1) year from date of purchase. SELLER’S
SOLE OBLIGATION AND BUYER’S EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL
BE THE REPAIR OR REPLACEMENT OF PARTS, WITHOUT CHARGE, WHICH ARE DEFECTIVE IN
MATERIAL OR WORKMANSHIP. ANY PARTS AS DETERMINED BY THE SELLER WHICH HAVE BEEN
MISUSED; ABUSED OR DAMAGED EITHER DIRECTLY OR INDIRECTLY FROM REPAIRS OR
ALTERATIONS ATTEMPTED BY UNAUTHORIZED PERSONS; IMPROPER MAINTENANCE, NEGLECT
OR ACCIDENT ARE NOT COVERED BY THIS LIMITED WARRANTY. This warranty does not apply to
damage, heat-induced coloration changes, scratching or alteration due to normal use or weathering.
To make a claim under this Limited Warranty, you must return the complete product, transportation prepaid,
to any World Factory, Inc.® authorized service center. Call 1-888-422-7800 for the location of the nearest
authorized service center.
Additional Limitations
THIS LIMITED WARRANTY DOES NOT APPLY TO ACCESSORY OR CONSUMABLE ITEMS RELATED
TO THIS PRODUCT. ALL IMPLIED WARRANTIES SHALL BE LIMITED IN DURATION TO ONE (1) YEAR
FROM DATE OF PURCHASE. IN NO EVENT SHALL SELLER BE LIABLE FOR ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES, INCLUDING BUT NOT LIMITED TO LIABILITY FOR LOSS OF PROFITS,
ARISING FROM THE SALE OR USE OF THIS PRODUCT.
If any provision of this Limited Warranty is for any reason held to be invalid or unenforceable, such
provision shall not affect any other provision herein, this Limited Warranty shall be construed as if such
invalid and/or unenforceable provision had never been contained herein.
This Warranty contains the entire agreement between Seller and Buyer and supersedes any and all prior
agreements, arrangements, or understandings between the parties relating to product warranty.
Cast Aluminum Grapevine
Garden Bench
Instruction Manual
Please keep this instruction manual for future reference
IF YOU HAVEANY PROBLEMS OR QUESTIONS CONCERNING THIS PRODUCT,
DO NOT RETURN IT TO YOUR RETAILER, CONTACT CONSUMER SUPPORTAT
1-888-424-3354
IF YOUARE A STORE MANAGER OR EMPLOYEE IN NEED OF ASSISTANCE CALL
1-888-851-5569
PLEASE HAVE YOUR STORE NUMBER READY
OR
Read the instructions and precautions before use of this product
MODEL NO: 50103220 - 50103221

IF YOU HAVE ANY PROBLEMS OR QUESTIONS CONCERNING THIS PRODUCT,
DO NOT RETURN ITTOYOUR RETAILER. CONTACT CUSTOMER SERVICE AT
1-888-424-3354.
Carefully remove the contents from the package.
If any parts are missing do not attempt to use the product until
they have been obtained and correctly installed.
ASSEMBLY INSTRUCTIONS
Caution: Do not over tighten fasteners.
1. Insert the studs (F) into the bottom of
 the backrest (A) and tighten until snug.
 Position backrest (A) studs through
 holes in seat base (B) and attach
 washers (I) and nuts (K) (leave loose).
PARTS & HARDWARE LIST
PART # DESCRIPTION QUANTITY
A 1Back Rest
B 1Seat Base
C 4Legs
D 2
7mm x 30mm Stud
Arm Rest
E 8
7mm x 40mm Stud
F 4
8mm x 17mm Screw
G 2
6mm x 30mm Screw
H 4
8mmWasher
I 12
6mmWasher
J 4
8mm Nut
K 12
6mm Nut
L 4
FIGURE 1
FIGURE 2
FIGURE 3
2. Insert studs (E) into bottom of
 seat base (B) and tighten until snug.
 Position two front legs (C) over
 studs (E) and attach with washers (I)
 and nuts (K) (leave loose).
 Repeat for the the two rear legs.
3. Attach armrest (D) to backrest (A)
 with screws (G). Attach Armrest (D)
 to seat base (B) with screws (H),
 washers (J) and nuts (L)
4. Place upright on a level surface.tighten
 armrest (D) first, seat back (A) second
 and legs (C) last.
CAUTION: Do not over tighten fasteners.
Minor rocking will settle with use.
A
B
F
I
K
E
A
C
I
K
B
D
A
B
C
H
HI
G
AB
C D E F
J K L G
J
L
