SLESA-UE7
Sunlite Easy Stand Alone USB-DMX controller
http://www.nicolaudie.com/slesa-ue7.htm
Key Features
• 3 DMX512 universes in live mode (computer)
• 2 DMX512 universes in stand alone
• Network synchronisation for hundreds of universes
• Multi-zone microSD memory
• 250 scenes across 5 areas
• USB & Ethernet connectivity for programming/control
• 8 dry contact trigger ports via HE10 connector
• Clock and calendar with Sunrise/Sunset triggering
• Network communication. Control lighting remotely
• OEM customization
• Windows/Mac software to set dynamic colors/eects
• iPhone/iPad/Android remote and programming apps
Overview
The Stand Alone DMX controller can be used
to control a wide variety of dierent DMX
systems- from RGB/RGBW to more advanced
moving and color mixing luminaires, DMX
audio players and fountains. The controller
comes with a variety of features including 1024
DMX channels, clock/calendar, iPhone/iPad/
Android remote control, Ethernet facilities, dry
contact port triggering and multi-zone SD card
memory.
The lighting levels, colors and eects can be
programmed from a PC, Mac, Android, iPad or
iPhone using the included software.
Technical Data
Input Power 5-5.5V DC 0.6A
Output Protocol DMX512 (x2)
Programmability PC, Mac, Tablet, Smart-
phone
Available Colors Blue, Orange, Gray, Green,
Marine, White, Red
Connections Mini USB, XLR3, XLR5,
Ethernet, 2x HE10, battery
Memory microSD card
Environment IP20. 0°C - 50°C
Buttons 2 buttons to change scene
+ 1 button to change area
Dimentions
Complete Package
79x92x43mm 120g
140x135x50mm 340g
OS Requirements Mac OS X 10.7-10.10.
Windows XP/VISTA/7/8
Standards EC, EMC, ROHS, ETL, UL
(some are in progress)
Optional Accessories
POWER1_EU/UK/US 5V ACDC power supply with EU/UK/US plug
OnDMX Pro I0835
DMX live control and stand alone controller

www.nicolaudie.com
Sunlite Easy Stand Alone USB-DMX Interface SLESA-UE7
© Nicolaudie-Sunlite 1989-2015. All rights reserved. We reserve the right without notice to amend the technical information and specications.
Page 2
V 1.1
OR
ETHERNET
DMX (3 Universes)
USB
DMX (2 Universes)
POWER
IR
REMOTE
36 Khz
AC/DC ADAPTOR
5V-5.5V
POWER1_EU
Mini
USB
P1 PORT 1
P2 PORT 2
P3 PORT 3
P4 PORT 4
P5 PORT 5
P6 PORT 6
P7 PORT 7
P8 PORT 8
GND Ground
P8 P7 P5 P3 P1
GND P6 P4 P2
External HE10
1Ground
2Dimmer
3DMX1+
4PREVIOUS
5DMX1-
6NEXT
7Zone
8LED DMX
9VUSB
10 LED USB
2 4 6 8 10
13579
Internal HE10
FRONT REAR
micro USB 8 dry contact
ports
micro SDEthernet
External HE10
Universe 1
DMX Chip
SP485ECP-L
Battery CR2032
Rechargeable
(LIR)
Internal HE10
Universe #1
1 DMX1 ground
2 DMX1 data-
3 DMX1 data+
Universe #2 #3
1 DMX2 ground
2 DMX2 data-
3 DMX2 data+
4 DMX3 data-
5 DMX3 data+
1
3
21
2
3
4
5
ETHERNET
Technical datasheet Revision date 26 May. 2015
CONNECTIVITY
Live use with a computer
Stand Alone use
Network synchronization for multiple universes
PC or Mac running the software
iPhone, iPad, Android

www.nicolaudie.com
Sunlite Easy Stand Alone USB-DMX Interface SLESA-UE7
© Nicolaudie-Sunlite 1989-2015. All rights reserved. We reserve the right without notice to amend the technical information and specications.
ESA Pro Software (Windows) - Timeline + Multi-Zone
http://www.nicolaudie.com/en/esapro.htm
ESA2 Software (Windows/Mac) - Single Zone
http://www.nicolaudie.com/esa2.htm
Hardware Manager (Windows/Mac) - Firmware, clock..
http://www.dmxsoft.com/global/ftp/hardwaremanager.zip
http://www.dmxsoft.com/global/ftp/HardwareManager.dmg
http://www.nicolaudie.com/smartphone-tablet-apps.htm
Page 3
V 1.1
... ...
P1P2
P8 P7 P5 P3 P1
GND P6 P4 P2
Technical datasheet Revision date 26 May. 2015
The controller can be connected to a local network, allowing it to be
controlled from a smartphone or tablet over WiFi.
• Connect the controller to a router or switch with an RJ45 cable
• The controller is set by default to get an IP address from the
router via DHCP. If the network is not working with DHCP, a
manual IP address and subnet mask can be set using the
Hardware Manager
• If the network has a lewall enabled, allow port 2430
The controller can be connected to an existing automation system
over a network and triggered via UDP packet on port 2430. Refer to
the remote protocol document for more information.
Dry Contact Port Triggering
Network Control
UDP Triggering
The controller works with the ocial IR remote control. A 36khz infra
red receiver can also be connected as an extension, such as the
TSOP34836 by Vishay Semiconductors. Farnell ref: 4913127. It’s a
good idea to add a resistor and capacitor to surpress power supply
disturbance.
Infra Red
It is possible to start scenes using the
input ports (contact closure). To activate
a port, a brief contact of at least 1/25
second must be established between the
ports (1...8) and the ground (GND). Note:
the scene will not be switched o when
the switch is released.
The controller can be programmed from a PC, Mac, Tablet or Smartphone using the software available on our website. Refer to
the corresponding software manual for more information. The rmware can be updated using the Hardware Manager which is
included with the programming software.
Programming the Controller
Setting up the Controller
The controller can be used with one of 2 dierent apps. Each
available at Google Play and the App store.
Easy Remote
Create an entirely customized remote controller for your tablet
or smartphone. Easy Remote is a powerful and intuitive app
allowing you to easily add buttons, faders, color wheels and
more. Connect to a WiFi network and the app will nd all
compatible devices.
Arcolis
The Arcolis application is a comprehensive tool allowing you
to directly control and re-program the controller from your
smartphone or tablet. This is a simple application which can
be used by just about everyone in any situation. Mobile, easy
to use and powerful, Arcolis is the ideal controller for dimming
or switching traditional, LED and RGB color mixing DMX
lighting xtures. Program static and dynamic lighting scenes
and eects.
iPhone/iPad/Android Control
Service *To replace the Li-Ion rechargeable battery :
1. You need a rechargeable 3.6v LIR 2032 replacement battery
2. Remove the underside of the plastic casing with the 2 screws
3. Pull the battery out of its holder, being careful not to pull the holder
itsself
4. Slide the replacement battery in from the top, making sure the posi-
tive side is as marked
5. Re-attach the casing
Servicable parts include:
• Memory card - used to store the scenes
• Battery - used to store the clock/calendar
• DMX Chip for universe 1 - used to drive the DMX (see p2.)

www.nicolaudie.com
Sunlite Easy Stand Alone USB-DMX Interface SLESA-UE7
© Nicolaudie-Sunlite 1989-2015. All rights reserved. We reserve the right without notice to amend the technical information and specications.
Page 4
V 1.1
Technical datasheet Revision date 26 May. 2015
Troubleshooting
The controller is in bootloader mode. This is a special ‘startup mode’
which is run before the main rmware loads.
-Try re-writing the rmware with the latest hardware manager
-Try formatting or replacing the SD card
There is no showle detected on the SD memory card.
-Try formatting the SD card in the computer
-Try re-writing the show le
-Try replacing the SD memory card
There is no SD card detected.
-Check the SD card is properly connected
-Try formatting the SD card in the computer
-Try re-writing the show le
-Try replacing the SD memory card
-Be sure that the latest software version is installed
-Connect by USB and open the Hardware Manager (found in the software
directory). If it’s detected here, try to update the rmware
-Check the DMX + - and GND are connected correctly
-Check that the driver or lighting xture is in DMX mode
-Be sure that the DMX address has been set correctly
-Check there are no more than 32 devices in the chain
-Check that the red DMX LED is ickering. There’s one by each XLR
-Connect with the computer and open Hardware Manager (found in the
software directory). Open the DMX Input/Output tab and move the faders.
If your xtures respond here, it is possibly a problem with the show le
‘888’ is showing on the display ‘OFF’ is showing on the display
‘OFF’ is ashing on the display
The controller is not detected by the
computer
The lights are not responding
