78344
MODEL: PRODUCT TYPE:
Page 1
WARNING
WARNING
MADE IN TAIWAN
Study, understand and follow all instructions provided with this
product. Read these instructions carefully before installing,
operating, servicing or repairing this tool. Keep these instructions
in a safe accessible place.
INTENDED USE OF THE TOOL
DO NOT DISCARD – GIVE TO USER
10PC 3/8" DRIVE NANO
PINLESS UNIVERSAL IMPACT SOCKETS
- METRIC
PRODUCT INFORMATION:
Before Use
When unpacking, check the parts diagram and part
number listing on page 2 to make sure all parts are
included. If any parts are missing or damaged, please
call your distributor.
The 78344 Nano Pinless Universal impact Socket Set is
designed to be used with a 3/8" drive impact wrench to drive
hex fasteners. Do not use this tool outside of the designed
intent. Never modify the tool for any other purpose or use.
•Use of this product can expose you to chemicals
including ethylene glycol, gasoline vapors and
engine exhaust, which are known to the State of
California to cause cancer, birth defects, or
reproductive harm. For more information, visit
www.P65Warnings.ca.gov. Always wear ANSI
approved safety equipment, safety glasses and
clothing when using this product. Study,
understand, and follow all instructions provided
with this product. Failure to read and follow all
warnings and operating instructions may result in
damages and serious injury or death.
•Always wear ANSI approved goggles when using
this product. (Users and Bystanders).
•Never use this tool for any application other than
for
which it was designed.
• Only use accessories designed for this tool.
• Never alter or modify this tool in any way.
•Improper operation and/or maintenance of the tool,
modification of the tool, or use of the tool with
accessories not designed for it could result in
serious injury or death.
•Always select the correct accessories of the
correct size and design for the job that you are
attempting to perform.
• Always work in a clean, safe, well-lit, organized and
adequately equipped area.
•Do not begin repairs without assurance that
vehicle is in secure position, and will not move
during repair.
3/8" DRIVE NANO
PINLESS UNIVERSAL IMPACT SOCKETS - METRIC •Pinless design allows a full 360° of freedom for the
universal head to angle and rotate
•Astro’s Nano form factor, up to 11% shorter than
standard low-profile universal impact sockets
•Forged CRO-MO with lifetime warranty

78344
MODEL: PRODUCT TYPE:
PARTS BREAKDOWN
Parts List
1 2 3 4 5 6 7 8 9 10
1112 12
10PC 3/8" DRIVE NANO
PINLESS UNIVERSAL IMPACT SOCKETS
- METRIC
1
2
3
4
5
6
7
8
9
10
11
12
Index Part No. Description Qty
1
1
1
1
1
1
1
1
1
1
1
2
7834401
7834402
7834403
7834404
7834405
7834406
7834407
7834408
7834409
7834410
7831415
7831012
10mm Nano Impact Socket
11mm Nano Impact Socket
12mm Nano Impact Socket
13mm Nano Impact Socket
14mm Nano Impact Socket
15mm Nano Impact Socket
16mm Nano Impact Socket
17mm Nano Impact Socket
18mm Nano Impact Socket
19mm Nano Impact Socket
Aluminum Socket Holder
Black Rubber Sheath
11 12
10 19
13 14 15 16 17 18
11
10 12 13 14 15 16 17 18 19
