ASTRO HDIP 1 User manual

Version 10-2019A

Before starting operation of the device
Operating Manual HDIP 1 - Version 10-2019APage 2
Before starting operation of the device
NOTE: Read this operating manual through carefully!It
contains important information about installation, ambient
conditions and maintenance of the device. Keep this operating
manual for future use and for handover in the event of a
change of owner or operator. A PDF version of this manual is
available to download on the ASTRO website (there may be a
more recent version).
The ASTRO company confirms that the information in this
manual was correct at the time of printing, but it reserves the
right to makechanges, without prior notice, to the
specifications, the operation of the device and the operating
manual.

Page 3
Contents
Operating Manual HDIP1 - Version 10-2019A
Contents
Symbols and conventions used...........................................page 04
Intended use........................................................................page 05
Target group for this manual...............................................page 05
Device description...............................................................page 06
Important safety instructions................................................page 07
Warranty conditions.............................................................page 11
Performance description......................................................page 11
Disposal...............................................................................page 11
Connecting..........................................................................page 12
Starting operation................................................................page 14
Programming – the web interface........................................page 15
Connecting to the network...................................................page 26
Appendix..............................................................................page 29
Troubleshooting...................................................................page 30
Maintenance and repair.......................................................page 30
Technical data.....................................................................page 31

Symbols and conventions used
Operating Manual HDIP 1 - Version 10-2019APage 4
Symbols and conventions used
Symbols used in these instructions
Pictograms are visual symbols with specific meanings. You will
encounter the following pictograms in this installation and operating
manual:
Warning about situations in which electrical voltage and non-obser-
vance of the instructions in this manual pose a risk of fatal injuries.
Warning about various dangers to health, the environment and
material.
Recycling symbol: indicates components or packaging materials
which can be recycled (cardboard, inserts, plastic film and bags).
Used batteries must be disposed of at approved recycling points.
Batteries must be completely discharged before being disposed of.
This symbol indicates components which must not be disposed of
with household rubbish.

Page 5
Proper use
Operating Manual HDIP1 - Version 10-2019A
Proper use
The HDIP 1 is an HDMI to IP converter. It is intended exclusively for
signal conversion.
Modification of the devices or use for any other purpose is not
permitted, and will immediately void any guarantee provided by the
manufacturer.
Target group of this manual
Installation and starting operation
The target group for installation and starting operation of the
ASTRO headend technology are qualified experts who have
training enabling them to perform the work required in accordance
with EN 60728-11 and EN 60065. Unqualified persons are not
allowed to install and start operation of the device.
Device configuration
Target group for the configuration of the ASTRO headend are
persons who have received instructions and have training enabling
them to perform a configuration. Knowledge of EN 60728-11 and
EN 60065 is not necessary for configuration.

Device description
Operating Manual HDIP 1 - Version 10-2019APage 6
Device description
The delivery is comprised of the following parts:
HDIP 1 HDMI to IP converter
Power supply unit
Operating manual
[1] HDMI input socket
[2] Ethernet input socket
[3] USB port
[4] Mini USB port
[5] Reset button
[6] Power supply socket
Figure 1: HDIP 1 signal converter
The HDIP 1 signal converter encoder has a CE marking. This
confirms that the products comply with the relevant EC directives
and adhere to the requirements specified therein.
1234
5
6

Page 7
Important safety information
Operating Manual HDIP1 - Version 10-2019A
Important safety information
To avoid any potential risks to the greatest extent possible, you
must adhere to the following safety information:
ATTENTION: Failure to observe this safety
information may result in personal injury due to electrical
and thermal dangers!
Proper use
Only use the device at the approved operating sites and in the
ambientconditionsallowed(asdescribedinthefollowing),and
only for the purpose described in the section “Proper use”.
Before starting operation of the device
NOTE: Read this operating manual attentively! It contains
important information about installation, ambient conditions
and maintenance of the device. Keep this operating manual
for future use and for handover in the event of a change of
owner or operator. A PDF version of this manual is available
to download on the ASTRO website (there may be a more
recent version).
Check the packaging and the device for transport damage
immediately. Do not start operation of a device that has been
damaged.
Transporting the device by the power cable may damage the
mains cable or the strain relief, and is therefore not permitted.
Installation and operation
The device may only be installed and operated by qualified
persons (in accordance with EN 60065) or by persons who
have been instructed by qualified persons. Maintenance work
may only be carried out by qualified service personnel.
An installation site must be provided that prevents children
from playing with the device and its connections.
The electrical connection conditions must correspond to the
specifications on the device type plate.

Important safety information
Operating Manual HDIP 1 - Version 10-2019APage 8
To avoid damage due to overheating, the device may only be
installed on vertical surfaces. The connection for the power
supply unit must point to the right. The installation basis should
be level and non-flammable. Operating position: Device
vertical, with HF sockets at the bottom and external DC power
supply connection on the right.
The permitted ambient temperatures specified in the technical
data must be complied with. If the device overheats, the insu-
lation used to isolate the mains voltage may be damaged.
The device and its cable may only be operated away from
radiant heat and other sources of heat.
To avoid trapped heat, ensure there is good ventilation on all
sides (minimum interval of 20 cm to other objects). Installing
thedevicein recesses or covering the installationlocation, e.g.
with curtains, is not permitted. Ventilation openings may not be
covered.
If the device is installed in a cabinet, ensure adequate air
convection is possible to avoid exceeding the maximum
permitted ambient temperature.
Do not place any objects on the device or on the external
power supply unit.
The subscriber network must be earthed in accordance with
EN 60728-11, and must remain earthed even when the device
is removed.
Thedevice and the power supplyunit do not provide protection
against water and may therefore only be operated and
connected in dry rooms. The device and the external power
supplyunitmustnot beexposedtosplashingordrippingwater,
condensation or similar effects of water, as this may impair the
isolation from the mains voltage.
The mains plug of the external power supply unit is used as a
mains voltage disconnection unit in the event of servicing and
danger, and must therefore be accessible and usable at any
time. The external power supply unit is operational when
connected to the mains power. If the power supply unit is also
connected to the DC socket of the device, the device is also in
operation.
The device may only be powered by the supplied external
power supply unit. The supplied external power supply unit
may only be used to power the device supplied with the
external power supply unit.

Page 9
Important safety information
Operating Manual HDIP1 - Version 10-2019A
All adhere to all applicable national safety regulations and
standards.
Excess mechanical loads (e.g. falling, impacts, vibrations)
may damage the insulation used to provide protection from
mains voltage.
High excess currents (lightning strike, surges in the power
utility grid) may damage the insulation used to provide protec-
tion from mains voltage.
If there is no information about intended use (e.g. operating
site, ambient conditions), or the operating manual does not
include the corresponding information, then you must consult
the manufacturer of this device to ensure that the device may
be installed. If you do not receive any information on this from
the manufacturer, do not start operating the device.
The device may only be operated in rooms in which the
permissible ambient temperature can be maintained should
climatic conditions vary (e.g. due to sunlight).
Do not install the device and external power supply unit in loca-
tions with excessive dust formation, as this may impair the
isolation from the mains voltage.
Electromagnetic compatibility (EMC)
In order to avoid malfunctions from occurring when operating radio
and telecommunications equipment, as well as other operating
units or broadcasting services, the following points must be
observed:
Beforeinstallation, the devicemustbecheckedfor mechanical
damage. Damaged or bent covers or housings may not be
used.
During operation, the device must always be covered by the
components provided for this purpose. Operation with an
opened cover is not permitted.
The braided line or the contact springs may not be damaged
or removed.

Important safety information
Operating Manual HDIP 1 - Version 10-2019APage 10
Maintenance
The operating display only shows whether the DC current,
which supplies the device components, has been discon-
nected. However, operating displays (on the power supply unit
or the device) that are not lit up in no way indicate that the
device is completely disconnected from the mains voltage.
There may still be voltages in the external power supply unit
that are dangerous to touch. Even after disconnection from the
mains, there may still be voltages in the external power supply
unitthat remain dangeroustotouchforseveralminutes.Donot
open the case of the device or the external power supply unit.
Read carefully: EN 60728-11 – Part 1, Safety requirements /
No service tasks during electrical storms!
Disconnect the mains plug before cleaning the device!
Repair
Repairs may only be performed by the manufacturer. Improp-
erly performed repairs may result in considerable dangers for
the user.
If malfunctions occur, the device must be disconnected from
the mains and authorised experts must be consulted. The
device may need to be sent to the manufacturer.
General information
Store or use the device in a safe location, well out of reach of
small children. It may contain small parts that can be swal-
lowed or inhaled. Dispose of any small parts that are not
needed.
Plastic bags may have been used for packaging the device.
Keep these plastic bags away from babies and children in
order to avoid any danger of suffocation. Plastic bags are not
toys.
Do not store the device near chemicals or in places in which
anyleakageofchemicals mayoccur.Organicsolventsorfluids
in particular may cause the housing and/or cables to melt or
disintegrate, presenting a danger of fire or electric shock. They
may also cause device malfunctions.
Do not connect the mains adapter provided to any other prod-
ucts.

Page 11
Warranty conditions
Operating Manual HDIP1 - Version 10-2019A
Warranty conditions
The general terms and conditions of ASTRO Strobel GmbH apply.
You will find these in the current catalogue or on the Internet under
“www.astro-kom.de”.
Performance description
The HDIP 1 is used to convert local HDMI sources (e.g. camera,
set-top box, PC) into an IP data stream. The source signal can be
fed in from a set-top box, a PC or TV set, etc. This can be trans-
mitted via Internet/LAN and played back, for example, from a PC,
smartphone or other mobile device. The device offers the following
performance features:
Multiple output streams with a different protocol / resolution /
bit rate
Downscale resolution conversion
Supports HLS protocol (simultaneous playback at different
resolutions and bit rates)
USB port for TS recording and playback
HDMI input
IP output via UDP (Unicast / Multicast), RTMP, RTP / RTSP,
HTTP and HLS
Power supply via 12-V plug-in power supply unit
To use the device properly, carefully read the following safety and
operating instructions.

Disposal
Operating Manual HDIP 1 - Version 10-2019APage 12
Disposal
All of our packaging material (cardboard boxes, inserts, plastic film
and bags) is completely recyclable.
After use, this device must be disposed of in an orderly manner as
electronic scrap in accordance with the current disposal regulations
of your district / country / state.
ASTRO Strobel is a member of the Elektro system solution for the
disposal of packaging materials. Our contract number is 80395.
Connecting
PREPARATION:
To connect the HDIP 1 connectors proceed as follows:
TASK
1. Insert the plug of an HDMI cable into the HDMI socket of the
device whose transport stream is to be processed by the HDIP
1 (e.g. camera signal, DVD player).
2. Plug the second plug of the HDMI cable into the HDMI socket
[1] of the HDIP 1.
3. If you want to connect a source via LAN, connect it to the
Ethernet socket [2] of the HDIP 1 using an appropriate cable.
RESULT:
The device is now connected.
NOTE: You must connect the device before starting
operation. It is not possible to connect or change the cabling
(Hot Plug) during operation!
2
1
2
3
4

Operating Manual HDIP 1 - Version 10-2019APage 13
Connecting
Figure 3 shows a connection example for the HDIP 1:
Figure 3: Connection example
The IP output signal can be transmitted via RTMP, RTSP, HLS, HTTP (Internet and LAN) or via UDP
(Multicast / Unicast via LAN).
Signal
Blue Ray Player
IRD
Camera
PC
PC
TV
Tablet
IP Settop Box
Smartphone
HDMI
USB Router Internet
Client Router
Client Router
Client Router
Client Router
Client Router
TV

Starting operation
Operating Manual HDIP 1 - Version 10-2019APage 14
Starting operation
To start operation of the HDIP 1, you must connect the device to the
mains using the supplied power supply unit. You do so like this:
Insert the plug of the power supply unit into the power supply
socket of the device [6] (see left).
Connect the mains plug of the powersupply unit to the mains.
If the operating status lamp [5] (see left, below) is glows continu-
ously the unit is ready for operation.
ATTENTION: If the operating status light flashes or does
not light up, it may be that
- The power supply unit is defective
- The device is defective, or
- An inadmissible operation is present (e.g. operating error,
wrong power supply unit).
(See “Maintenance and repair” section)
NOTE: The use of another power supply unit with a
different output voltage or polarity can lead to the destruction
of the device as well as to malfunctions and voids the warranty!
2
6
2
5

Operating Manual HDIP 1 - Version 10-2019APage 15
Programming – the web interface
Programming – the web interface
You can configure the Network Encoder HDIP 1 via a web browser interface.
NOTE: Make sure that the IP address of the device is not the same as that of your PC or
laptop. This would otherwise result in an IP conflict.
Log in
The IP address of the device is: 192.168.200.64
Change the IP address of the PC / laptop as follows:
192.168.200.xxx (where xxx can be between 1 and 254, except 64 to avoid IP conflicts).
Connect the device to your PC or laptop via an Ethernet cable and use the ping diagnostic tool (ping
command) to determine whether the HDIP 1and your PC / laptop are on the same network.
If this is the case, enter the IP address of the HDIP 1 in the address line of the browser and press
the Enter key.
You should now see the login screen (see figure 6 below).
Figure 6: login screen
Enter your user name and password here. The user name and password are “admin” by default.
Then click on the “Login” button to access the configuration interface.

Programming – the web interface
Operating Manual HDIP 1 - Version 10-2019APage 16
Status overview
After logging in, the interface displays astatus overview (see figure 7).
Figure 7: Status overview
The following parameter values are displayed for each of the three output channels:
Work Status: Green if function OK, Grey indicates a malfunction
Alarms: error messages
Work Time: operating time
Input Resolution: resolution of the input signal
Output Resolution: resolution of the output signal
Output Bitrate: bit rate of the output signal
Output URL: URL of the output signal

Operating Manual HDIP 1 - Version 10-2019APage 17
Programming – the web interface
Editing and saving parameters
To edit the parameters of an output channel, click on the “Parameters” item in the main menu at the
top (see fig. 7). The following input mask will now appear:
Figure 7: Parameters of the output channels
Click here on one of the entries “CH1”, “CH2” or “CH3” to configure the parameters of the respective
channel.

Programming – the web interface
Operating Manual HDIP 1 - Version 10-2019APage 18
When you have set all parameters as desired, click on the “Apply” button.
Afterwards, you must save the changed values so that they are loaded when the device is restarted.
To do so, click on the “Save” item in the main menu. The following view appears:
Figure 8: Saving the configuration
Here you can save your new settings by clicking on the “Save” button.
If you click on the “Restore” button, the last saved configuration is loaded.
If you click on the “Factory” button, the factory settings are loaded.

Operating Manual HDIP 1 - Version 10-2019APage 19
Programming – the web interface
Creating or loading a configuration backup
You can save the parameter values you haveset in a backup file or load a previouslycreated backup
file. To do so, click on the “Backup” item in the main menu. The following view appears:
Figure 9: Loading or saving a backup
Use the selection button at the bottom left to load a previously saved backup file.
By clicking the “Backup” button you can save the current values in a backup file.

Operating Manual HDIP 1 - Version 10-2019APage 20
Programming – the web interface
System update
To install an update, click on the “System” item at the top of the main menu and then select
“Upgrade” from the pop-up menu. The following view appears:
Figure 10: Installing an update
In the drop-down list at the bottom left, you can select whether the update file to be used is from a
USB storage device or from the network.
Then click on the corresponding button to install either an update for web, app or CPU.
