IOT Gateway System SPG-M041
SPG-M041
IoT Gateway System
User’s Manual 1st Ed

Preface II
IOT Gateway System SPG-M041
Copyright Notice
This document is copyrighted, 2022. All rights are reserved. The original manufacturer
reserves the right to make improvements to the products described in this manual at
any time without notice.
No part of this manual may be reproduced, copied, translated, or transmitted in any
form or by any means without the prior written permission of the original
manufacturer. Information provided in this manual is intended to be accurate and
reliable. However, the original manufacturer assumes no responsibility for its use, or for
any infringements upon the rights of third parties that may result from its use.
The material in this document is for product information only and is subject to change
without notice. While reasonable efforts have been made in the preparation of this
document to assure its accuracy, AAEON assumes no liabilities resulting from errors or
omissions in this document, or from the use of the information contained herein.
AAEON reserves the right to make changes in the product design without notice to its
users.

Preface III
IOT Gateway System SPG-M041
Acknowledgements
All other products’ name or trademarks are properties of their respective owners.
⚫Microsoft Windows is a registered trademark of Microsoft Corp.
⚫Intel® is a registered trademark of Intel Corporation
⚫ARM, Cortex, and Cortex-A8 are registered trademarks of Arm Limited (or its
subsidiaries).
⚫ITE is a trademark of Integrated Technology Express, Inc.
⚫IBM and VGA are trademarks of International Business Machines Corporation.
⚫Ubuntu is a registered trademark of Canonical
All other product names or trademarks are properties of their respective owners. No
ownership is implied or assumed for products, names or trademarks not herein listed
by the publisher of this document.

Preface IV
IOT Gateway System SPG-M041
Packing List
Before setting up your product, please make sure the following items have been
shipped:
Item
Quantity
⚫SPG-M041
1
If any of these items are missing or damaged, please contact your distributor or sales
representative immediately.

Preface V
IOT Gateway System SPG-M041
About this Document
This User’s Manual contains all the essential information, such as detailed descriptions
and explanations on the product’s hardware and software features (if any), its
specifications, dimensions, jumper/connector settings/definitions, and driver installation
instructions (if any), to facilitate users in setting up their product.
Users may refer to the product page at AAEON.com for the latest version of this
document.

Preface VI
IOT Gateway System SPG-M041
Safety Precautions
Please read the following safety instructions carefully. It is advised that you keep this
manual for future references
1. All cautions and warnings on the device should be noted.
2. All cables and adapters supplied by AAEON are certified and in accordance with
the material safety laws and regulations of the country of sale. Do not use any
cables or adapters not supplied by AAEON to prevent system malfunction or
fires.
3. Make sure the power source matches the power rating of the device.
4. Position the power cord so that people cannot step on it. Do not place anything
over the power cord.
5. Always completely disconnect the power before working on the system’s
hardware.
6. No connections should be made when the system is powered as a sudden rush
of power may damage sensitive electronic components.
7. If the device is not to be used for a long time, disconnect it from the power
supply to avoid damage by transient over-voltage.
8. Always disconnect this device from any AC supply before cleaning.
9. While cleaning, use a damp cloth instead of liquid or spray detergents.
10. Make sure the device is installed near a power outlet and is easily accessible.
11. Keep this device away from humidity.
12. Place the device on a solid surface during installation to prevent falls
13. Do not cover the openings on the device to ensure optimal heat dissipation.
14. Watch out for high temperatures when the system is running.
15. Do not touch the heat sink or heat spreader when the system is running
16. Never pour any liquid into the openings. This could cause fire or electric shock.

Preface VII
IOT Gateway System SPG-M041
17. As most electronic components are sensitive to static electrical charge, be sure to
ground yourself to prevent static charge when installing the internal components.
Use a grounding wrist strap and contain all electronic components in any
static-shielded containers.
18. If any of the following situations arises, please the contact our service personnel:
i. Damaged power cord or plug
ii. Liquid intrusion to the device
iii. Exposure to moisture
iv. Device is not working as expected or in a manner as described in
this manual
v. The device is dropped or damaged
vi. Any obvious signs of damage displayed on the device
19. DO NOT LEAVE THIS DEVICE IN AN UNCONTROLLED ENVIRONMENT WITH
TEMPERATURES BEYOND THE DEVICE’S PERMITTED STORAGE TEMPERATURES
(SEE CHAPTER 1) TO PREVENT DAMAGE.

Preface VIII
IOT Gateway System SPG-M041
FCC Statement
This device complies with Part 15 FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any
interference received including interference that may cause
undesired operation.
Caution:
There is a danger of explosion if the battery is incorrectly replaced. Replace only with the
same or equivalent type recommended by the manufacturer. Dispose of used batteries
according to the manufacturer’s instructions and your local government’s recycling or
disposal directives.
Attention:
Il y a un risque d’explosion si la batterie est remplacée de façon incorrecte.
Ne la remplacer qu’avec le même modèle ou équivalent recommandé par le constructeur.
Recycler les batteries usées en accord avec les instructions du fabricant et les directives
gouvernementales de recyclage.

Preface IX
IOT Gateway System SPG-M041
China RoHS Requirements (CN)
产品中有毒有害物质或元素名称及含量
AAEON System QO4-381 Rev.A0
部件名称
有毒有害物质或元素
铅
(Pb)
汞
(Hg)
镉
(Cd)
六价铬
(Cr(VI))
多溴联苯
(PBB)
多溴二苯
醚(PBDE)
印刷电路板
及其电子组件
×
○
○
○
○
○
外部信号
连接器及线材
×
○
○
○
○
○
外壳
○
○
○
○
○
○
中央处理器
与内存
×
○
○
○
○
○
硬盘
×
○
○
○
○
○
液晶模块
×
×
○
○
○
○
光驱
×
○
○
○
○
○
触控模块
×
○
○
○
○
○
电源
×
○
○
○
○
○
电池
×
○
○
○
○
○
本表格依据 SJ/T 11364 的规定编制。
○ ：表示该有毒有害物质在该部件所有均质材料中的含量均在
GB/T 26572标准规定的限量要求以下。
×：表示该有害物质的某一均质材料超出了GB/T 26572的限量要求，然而该
部件
仍符合欧盟指令2011/65/EU 的规范。
备注：
一、此产品所标示之环保使用期限，系指在一般正常使用状况下。
二、上述部件物质中央处理器、内存、硬盘、光驱、电源为选购品。
三、上述部件物质液晶模块、触控模块仅一体机产品适用。

Preface X
IOT Gateway System SPG-M041
China RoHS Requirement (EN)
Hazardous and Toxic Materials List
AAEON System QO4-381 Rev.A0
Component
Name
Hazardous or Toxic Materials or Elements
Lead (Pb)
Mercury (Hg)
Cadmium (Cd)
Hexavalent Chromium (Cr(VI))
Polybrominat ed biphenyls (PBBs)
Polybrominat ed diphenyl ethers (PBDEs)
PCB and
Components
X
O
O
O
O
O
Wires &
Connectors for
Ext.Connections
X
O
O
O
O
O
Chassis
O
O
O
O
O
O
CPU & RAM
X
O
O
O
O
O
HDD Drive
X
O
O
O
O
O
LCD Module
X
X
O
O
O
O
Optical Drive
X
O
O
O
O
O
Touch Control
Module
X
O
O
O
O
O
PSU
X
O
O
O
O
O
Battery
X
O
O
O
O
O
This form is prepared in compliance with the provisions of SJ/T 11364.
O: The level of toxic or hazardous materials present in this component and its parts is
below the limit specified by GB/T 26572.
X: The level of toxic of hazardous materials present in the component exceed the
limits specified by GB/T 26572, but is still in compliance with EU Directive 2011/65/EU
(RoHS 2).
Notes:
1. The Environment Friendly Use Period indicated by labelling on this product is
applicable only to use under normal conditions.
2. Individual components including the CPU, RAM/memory, HDD, optical drive, and
PSU are optional.
3. LCD Module and Touch Control Module only applies to certain products which
feature these components.

Preface XI
IOT Gateway System SPG-M041
Table of Contents
Chapter 1 - Product Specifications ......................................................................................... 1
1.1 Specifications............................................................................................................ 2
Chapter 2 –Hardware Information ........................................................................................7
2.1 Dimensions ............................................................................................................... 8
2.2 I/O Location.............................................................................................................. 9
2.3 LED Indicators .........................................................................................................10
Chapter 3 –Gateway Setup and Configuration..................................................................12
3.1 System Test and Initialization ...............................................................................13
3.1.1 Serial Connection ...................................................................................14
3.1.2 RJ-45 Ethernet Cable Wiring................................................................14
3.1.3 Digital Input (DI) Connection...............................................................16
3.1.4 Relay Output Connection.....................................................................17
3.1.5 WWAN Module Installation..................................................................18
3.1.6 SIM Installation........................................................................................19
3.1.7 MicroSD Card Installation (Without Cover)......................................20
3.2 Connecting Power Supply ....................................................................................21
3.3 Reset Button ...........................................................................................................23
3.4 Installation and Mounting....................................................................................24
3.4.1 DIN Rail Mounting.................................................................................25

IOT Gateway System SPG-M041
Chapter 1
Chapter 1 - Product Specifications

Chapter 1 –Product Specifications 2
IOT Gateway System SPG-M041
1.1 Specifications
System
Processor
ARM® Cortex®-M4F
External flash
128 Mbit Flash
Storage
External MicroSD slot x 1 (Max 32GB)
Operating System
Zephyr v.3.0.99
Support Protocol
Dependent on real-time OS support
Indicator
LED indicator x 10 (for functional power/serial
port/DI/RF activity/signal strength indicators)
Real time clock
Yes
Expansion
Mini-PCIe slot x 1 (UART signal, for wireless
module)
Nano SIM card slot x 2
Micro SD card slot x 1
Radio Frequency
LTE 4G (CAT 1)
(by model)
3GPP Rel.9 compliant protocol
Frequency bands:
FDD LTE: B1 /B2 /B3 /B4 /B5 /B7 /B8 /B12 /B13
/B18 /B19 /B20 /B25 /B26 /B28
TDD LTE: B38/B39/B40/B41
WCDMA: B1/B2/B4/B5/B6/B8/B19
GSM: B2/B3/B5/B8
Data rate:
FDD LTE DL: Max. 150 Mbps, UL: Max. 50 Mbps
TDD LTE DL: Max. 130 Mbps, UL: Max. 30 Mbps
HSDPA: Max. 42 Mbps, HSUPA: Max. 5.76 Mbps

Chapter 1 –Product Specifications 3
IOT Gateway System SPG-M041
WCDMA DL: Max. 384 kbps, UL: Max. 384 kbps
EDGE DL: Max. 296 kbps, UL: Max. 236.8 kbps
GPRS DL: Max. 107 kbps, UL: Max. 85.6 kbps
SIM Card Size: Micro-SIM slot
Antenna Type: External type
Antenna Connector: SMA-Male
CAT NB / CAT M1
(by model)
3GPP Rel.14 compliant protocol
Frequency bands:
FDD LTE: B1/ B2/ B3/ B4/ B5/ B8/ B12/ B13/ B18/
B19/ B20/ B25/ B26/ B27/ B28/ B66/ B71/ B85
GSM: 850MhZ/900Mhz/1800Mhz/1900Mhz
Data rate:
LTE Cat.NB1 DL: max. 27 kbps, UL: max. 63 kbps
LTE Cat.NB2 DL: max.124 kbps, UL: max. 158
kbps
LTE Cat.M1 DL: max. 300 kbps, UL: max. 1.1 Mbps
SIM-Card type: Micro-SIM slot
Antenna Type: External type
Antenna Connector: SMA-Male
GPS
GPS/GLONASS/Galileo/BeiDou (Compass)
Antenna Type: External Type
Antenna Connector: SMA-Female

Chapter 1 –Product Specifications 4
IOT Gateway System SPG-M041
Communication Interface
Ethernet
10/100Mbps, Auto-sensing MDI/MDIX, RJ45 x 2
Magnetic Isolation Protection
1.5 KV
Serial Ports
Terminal Block x 2
Serial Standards
RS232, 3W-RS485, 2W-RS485 (software
selectable)
Serial Baud Rate (Data Rate)
300 ~ 921.6kbps
Data Bits
7, 8
Parity
Odd, Even, None
Stop bits
1, 2
RS-232 Pinout
TxD, RxD, RTC, CTS, GND
RS-485 Pinout
3 Wire: Data-, Data+, GND
2 Wire: Data-, Data+
Terminator for RS-485
120 ohms (software selectable)
Magnetic isolation protection
-
Digital Input
Digital
Terminal Block x 4
Serial Standards
RS232, 3W-RS485, 2W-RS485
Input Types
P-switching
Input Filter Time
Input delay adjustable from 0 to 40ms
(disabled, 0.3ms, 3ms, 10ms, 20ms, 40ms)
Input Mode
DI or Event Counter
Input Counter Frequency
20 Hz

Chapter 1 –Product Specifications 5
IOT Gateway System SPG-M041
Low Input Voltage
< + 5 V
High Input Voltage
+10 ~ +30 V
Sensor Type
Wet Contact, Dry Contact
Dry Contact
On: Short to GND
Off: Open
Wet Contact (DI To COM)
On: 10 ~ 30 VDC
Off: 0 ~ 3 VDC
Reverse Polarity Protection
Yes
Individual Channel Diagnostic
No
Magnetic Isolation Protection
1.5 kV
Relay Output
Relay Output
Terminal Block x 1
Output Types
Normally open (NO)
Output Delay
Output delay adjustable from 0 to 10s
(no delay, 500ms, 1s, 2s, 5s, 10s)
Max. Output Current Per Input
1A at 250VAC
1A at 30VDC
Actuator Connection
2-wire
Individual Channel Diagnostic
No

Chapter 1 –Product Specifications 6
IOT Gateway System SPG-M041
Physical & Environmental
Power Ports
Terminal Block x 1 (Dual DC Power Inputs for
Power Redundancy)
Power Supply Rated Voltage
12 / 24 VDC
Power Supply Voltage Range
9.6 ~ 31.2 VDC
Input Current
12V/2.29W, 24V/3.14W
Reverse Polarity Protection
Yes
Voltage Variation Protection
Yes
Mechanical
Enclosure
Metallic Casing
Dimensions (W x D x H)
6.2” x 6.2” x 1.0” (160mm x 106mm x 27 mm)
Weight
1.1 lb. (0.5 Kg)
Mounting
DIN Rail Mounting
Environmental
Operating Temperature
-4OF ~ 158OF (-20OC ~ 70OC)
Storage Temperature
-40OF ~ 185OF (-40OC ~ 85OC)
Operating Humidity
5% ~ 95%, non-condensing
Certification
CE / FCC

Chapter 2
Chapter 2 –Hardware Information

Chapter 2 –Hardware Information 8
IOT Gateway System SPG-M041
2.1 Dimensions

Chapter 2 –Hardware Information 9
IOT Gateway System SPG-M041
2.2 I/O Location
Please refer to the table below for the system’s I/O layout so that you can configure
your application
Label
Interface
Connection Type
Description
1
LAN 1
RJ-45
Connectivity for local network or
internet access
2
LAN 2
RJ-45
Connectivity for local network or
internet access
3
Serial 1
Terminal block
RS-232/RS-485, software selectable
4
Serial 2
Terminal block
5
Antenna
RP-SMA (male)
Antenna for wireless WAN (3G/4G)
access
6
Antenna
Reserved
-
7
Antenna
RP-SMA (female)
Antenna for GPS signal reception
8
External storage
Micro SD
Micro SD storage for system log,
event message data storage
9
Console
Micro-USB
Interface for device administration
10
Digital Input x 4
Relay x 1
Terminal block
Please refer to sections 3.1.3 and
3.1.4 for more information
