Asus ROG Spatha User manual

English
2
Quick Start Guide
Package contents
• 1xROGSpathaGamingMouse
• 1x2-meterUSBcable
• 1x1-meterUSBcable
• 2xJapan-madeOmronmouseswitches
• 1xWirelessreceiver/chargingdock
• 1xTravelcase
• 1xUserdocumentation
• 2xROGlogostickers
System requirements
• Windows®10/Windows®8.1/Windows®8/Windows®7
• 100MBofharddiskspace(foroptionalsoftwareinstallation)
• Internetconnection(fordownloadingoptionalsoftware)
• USBport
Customizing with ROG Armoury
Formoreprogrammablebuttons,performancesettings,lightingeects,surfacecalibration,
andprolesettings,downloadandinstalltheROGArmouryfromwww.asus.com.
English

English
3
ROG Spatha Gaming Mouse
Device features

English
4
Quick Start Guide
Rightbutton Laser sensor
Scrollwheel Mouse charging connectors
DPIbutton Powerswitch
MicroUSB2.0connector Pairbutton
Leftbutton Wirelessreceiver/chargingdock
Forwardbutton Dock charging connectors
Backwardbutton Pairbutton(Dock)
Programmablethumbbuttons MicroUSBcable
Screwhole Dock LED indicator
+Changeproles(downloadROGArmourytocustomizeproles)

English
5
ROG Spatha Gaming Mouse
Getting started
To set up your ROG Spatha Gaming Mouse as a wired mouse:
1. ConnectthemicroUSBcabletoyourROGSpathaGamingMouse.
2. ConnecttheUSBcabletoyourcomputer’sUSBport.
To set up your ROG Spatha Gaming Mouse as a wireless mouse:
1. ConnectthemicroUSBcabletoyourwireless
receiver/chargingdock.
2. ConnecttheUSBcabletoyourcomputer’sUSB
port.
NOTE: Downloadthedriverfromhttp://www.
asus.com then install it in your computer.
3. PressthePairbuttonontherearofyour
wirelessreceiver/chargingdock.
4. SlidethePowerSwitchtoturnonyourROG
SpathaGamingMouse.
5. PressthePairbuttononyourROGSpatha
GamingMouse.
6. TheDockLEDindicatorwilllightgreen
whenyourROGSpathaGamingMousehas
successfullypaired.
NOTE:ClickontheleftbuttontowakeyourROG
SpathaGamingMousefromsleepmode.
To update your ROG Spatha Gaming Mouse rmware:
1. Launch ROG Armoury.
2. ConnectROGSpathaGamingMousetoyourcomputerasawiredmouse.
3. Click Nextonthepopupwindowtostartthermwareupdate.
NOTE:Thepopupwindowwillonlyappearifthereisanewrmwareupdateavailable.
IMPORTANT!Whenyouencounteraproblemwhileupdatingthermware,unplugthemicroUSB
cable,thenpressandholddowntheleft,rightandscrollbuttononyourmouseandreplugthe
microUSBcabletorestarttheupdate.

English
6
Quick Start Guide
Replacing the switches
NOTE:Refertowww.asus.comforthelistofcompatibleswitches.
Ifyouwanttoreplacetheswitches,followthestepsbelow:
1. Removethefour(4)screwsandsetitaside.
2. Remove the top cover.
3. Replacetheswitches.
IMPORTANT!
• Ensuretoinstalltheswitchintotheswitchsocketwithitsbuttonfacingthefrontofthemouse.
• Ensurethattheswitchesareseatedproperlyintheswitchsockets.
4. Placethetopcoverandsecureitwiththefour(4)screws.
Switch
socket
Switch
socket
Mouseswitches
To update your wireless receiver/charging dock rmware:
1. Launch ROG Armoury.
2. ConnectthemicroUSBcabletoyourwirelessreceiver/chargingdock.
3. Click Nextonthepopupwindowtostartthermwareupdate.
NOTE:Thepopupwindowwillonlyappearifthereisanewrmwareupdateavailable.
IMPORTANT!Whenyouencounteraproblemwhileupdatingthermware,unplugthemicroUSB
cable,thenpressandholddownthePairbuttononthewirelessreceiver/chargingdockandreplug
themicroUSBcabletorestarttheupdate.
