Asus RT-AC66U B1 User manual

Quick Start Guide
RT-AC66U B1
Wireless-AC1750 Dual Band Gigabit
Router
WEU15297 / Revised Edition V6 / March 2019
WEU15065_RT-AC66U_B1_QSG_V5.indb 1 2019/3/5 14:59:32

Table of contents
English.............................................................................................3
Dansk...............................................................................................16
Nederlands ....................................................................................29
Français ...........................................................................................42
Suomi...............................................................................................55
Deutsch...........................................................................................68
Ελληνικά..........................................................................................81
Italiano ............................................................................................94
Norsk................................................................................................107
Português.......................................................................................120
Español............................................................................................133
Svenska ...........................................................................................146
WEU15065_RT-AC66U_B1_QSG_V5.indb 2 2019/3/5 14:59:32

3
English
Package contents
RT-AC66U B1 AC adapter
RJ-45 cable Quick Start Guide
Warranty card
A quick look
1) USB 3.0 port 5) Power LED 9) Reset button
2) LAN LED 6) Power (DC-IN) port 10) WAN port
3) WAN LED 7) Power switch 11) LAN ports
4) 2.4GHz/5GHZ LED 8) USB 2.0 port 12) WPS button
NOTE: If any of the items is damaged or missing, contact your retailer.
WEU15065_RT-AC66U_B1_QSG_V5.indb 3 2019/3/5 14:59:33

4
English
NOTES:
• USB External HDD/Flash disk:
 •ThewirelessrouterworkswithmostUSBHDDs/Flashdisksupto
2TBandsupportsread-writeaccessforFAT16,FAT32,EXT2,EXT3,
andNTFS.
 •TosafelyremovetheUSBdisk,launchthewebGUI
(http://router. asus.com), then in the Network Map page's upper
right corner, click the USB icon and click Eject USB 1.
 •IncorrectremovaloftheUSBdiskmaycausedatacorruption.
 •Forthelistoflesystemandharddiskpartitionsthatthe
wirelessroutersupports,visithttp://event.asus.com/networks/
disksupport
• Forthelistofprintersthatthewirelessroutersupports,visit
http://event.asus.com/networks/printersupport
WEU15065_RT-AC66U_B1_QSG_V5.indb 4 2019/3/5 14:59:33

5
English
Positioning your wireless router
Forthebestwirelesssignaltransmissionbetweenthewirelessrouterandthe
networkdevicesconnectedtoit,ensurethatyou:
• Placethewirelessrouterinacentralizedareaforamaximumwirelesscoverage
forthenetworkdevices.
• Keepthedeviceawayfrommetalobstructionsandawayfromdirectsunlight.
• Keepthedeviceawayfrom802.11gor20MHzonlyWi-Fidevices,2.4GHz
computerperipherals,Bluetoothdevices,cordlessphones,transformers,
heavy-dutymotors,uorescentlights,microwaveovens,refrigerators,andother
industrialequipmenttopreventsignalinterferenceorloss.
• Toensurethebestwirelesssignal,orientthethreedetachableantennasas
shown in the drawing below.
• Foroptimumperformance,adjusttheinternalcoolingsystem.Refertotheuser
manual for details.
• Alwaysupdatetothelatestrmware.VisittheASUSwebsiteat
http://www.asus.comtogetthelatestrmwareupdates.
90° 90°
WEU15065_RT-AC66U_B1_QSG_V5.indb 5 2019/3/5 14:59:33

6
English
Before you proceed
1. Unpluganddisconnectthewires/cablesfromyourexistingmodemsetup
and release your computer’s outmoded IP address.
a: Unplug the AC adapter from the power outlet and disconnect it from your
cable/ADSL modem.
b: Disconnect the network cable from your cable/ADSL modem.
c: Reboot your computer (recommended).
Modem
OFF!
a
b
c
d
a
b
c
d
a
b
c
d
WARNING! Before disconnecting the wires/cables, ensure that your
cable/ADSL modem has been turned o for at least two minutes. If your
modemhasabackupbattery,removeitaswell.
WEU15065_RT-AC66U_B1_QSG_V5.indb 6 2019/3/5 14:59:33

7
English
2. Setupyourwirelessenvironment.
a: Insert your wireless router’s AC adapter to the DC-IN port and plug it to a
power outlet.
b: Using the bundled network cable, connect your computer to your wireless
router’s LAN port.
IMPORTANT! Ensure that the WAN and LAN LEDs are blinking.
c: Using another network cable, connect your modem to your wireless router’s
WAN port.
d: Insert your modem’s AC adapter to the DC-IN port and plug it to a power
outlet.
3. Disable some settings on your computer.
A. Disable the proxy server, if enabled.
B. Set the TCP/IP settings to automatically obtain an IP address.
C. Disable the dial-up connection, if enabled.
NOTE:Formoredetailsondisablingyourcomputersettings,referto
Frequently Asked Questions (FAQs).
RT-AC66U B1
c
WAN
a
db
LAN
Internet
Modem
WEU15065_RT-AC66U_B1_QSG_V5.indb 7 2019/3/5 14:59:33

8
English
1. Congureyourwirelesssettingsviathewirelessrouter’swebgraphics
user interface (web GUI).
a: LaunchyourwebbrowsersuchasInternetExplorer,Firefox,GoogleChrome,
or Safari.
Getting started
a
b
c
d
a
b
c
d
NOTE: If QIS does not launch automatically, follow these steps to
manuallylaunchQIS:
•Onyourwebbrowser,keyinhttp://router.asus.com and run the
Quick Internet Setup (QIS) Wizard again.
•Disabletheproxysettings,dial-upconnection,andsetyourTCP/IP
settingstoautomaticallyobtainanIPaddress.Formoredetails,refer
to the FAQs section for auto-diagnosis.
WEU15065_RT-AC66U_B1_QSG_V5.indb 8 2019/3/5 14:59:34

9
English
b: The wireless router’s Quick Internet Setup (QIS) feature automatically detects
if your ISP connection type is Dynamic IP, PPPoE, PPTP, L2TP, and Static IP.
Keyinthenecessaryinformationforyourconnectiontype.
IMPORTANT!ObtainthenecessaryinformationaboutyourInternet
connectiontypefromyourInternetServiceProvider(ISP).
NOTE: The auto-detection of your ISP connection type takes place
whenyoucongurethewirelessrouterforthersttimeorwhenyour
wireless router is reset to its default settings.
NOTE: You can assign a network name with up to 32 characters.
c: Assign the network name (SSID)
and security key for your 2.4GHz
and 5GHz wireless connection. Click
Apply when done.
d: Your Internet and wireless settings
are displayed. Click Next to
continue.
e: Read the wireless network
connection tutorial. When done,
click Finish.
WEU15065_RT-AC66U_B1_QSG_V5.indb 9 2019/3/5 14:59:34

10
English
English
Frequently Asked Questions (FAQs)
After following the steps, I still cannot access the wireless router’s web
graphics user interface (web GUI) to congure the wireless router settings.
A. Disable the proxy server, if enabled.
Windows® 7
1. Click Start > Internet Explorer to launch the web
browser.
2. Click Tools > Internet options > Connections tab
> LAN settings.
3. FromtheLocalAreaNetwork(LAN)Settings
screen, untick Use a proxy server for your
LAN.
4. Click OK when done.
English
WEU15065_RT-AC66U_B1_QSG_V5.indb 10 2019/3/5 14:59:34

11
English
English
MAC OS
1. FromyourSafaribrowser,clickSafari >
Preferences > Advanced > Change Settings...
2. FromtheNetworkscreen,deselectFTP Proxy
and Web Proxy (HTTP).
3. Cllick Apply Now when done.
NOTE: Refer to your browser's help feature for details on disabling the
proxyserver.
B. Set the TCP/IP settings to automatically obtain an IP address.
Windows® 7
1. Click Start > Control Panel > Network and
Internet > Network and Sharing Center >
Manage network connections.
2. Select Internet Protocol Version 4 (TCP/IPv4),
then click Properties.
English
WEU15065_RT-AC66U_B1_QSG_V5.indb 11 2019/3/5 14:59:34

12
English
English
3. ToobtaintheiPv4IPsettingsautomatically,tick
Obtain an IP address automatically.
4. Click OK when done.
MAC OS
1. Click the Apple icon located on the top left of
your screen.
2. Click System Preferences > Network >
Congure...
3. FromtheTCP/IP tab, select Using DHCP in the
Congure IPv4 dropdown list.
4. Cllick Apply Now when done.
NOTE: Refer to your operating system’s help and support feature for
detailsonconguringyourcomputer’sTCP/IPsettings.
English
WEU15065_RT-AC66U_B1_QSG_V5.indb 12 2019/3/5 14:59:34

13
English
English
C. Disable the dial-up connection, if enabled.
D. Close all running web browsers.
NOTE: Refer to your browser's help feature for details on disabling
the dial-up connection settings.
Windows® 7
1. Click Start > Internet Explorer to launch the
browser.
2. Click Tools > Internet options > Connections tab.
3. Tick Never dial a connection.
4. Click OK when done.
The client cannot establish a wireless connection with the router.
Out of Range:
 • Puttherouterclosertothewirelessclient.
 • Trytochangethechannelsettings.
Authentication:
 • Usewiredconnectiontoconnecttotherouter.
 • Checkthewirelesssecuritysettings.
 • PresstheResetbuttonattherearpanelformorethanveseconds.
English
WEU15065_RT-AC66U_B1_QSG_V5.indb 13 2019/3/5 14:59:34

14
English
Cannot nd the router:
 • PresstheResetbuttonattherearpanelformorethanveseconds.
 • CheckthesettinginthewirelessadaptersuchasSSIDandencryption
settings.
Cannot access the Internet via wireless LAN adapter.
• Movetherouterclosertothewirelessclient.
• Checkwhetherthewirelessadapterisconnectedtothecorrectwireless
router.
• Checkwhetherthewirelesschannelinuseconformstothechannels
availableinyourcountry/area.
• Checktheencryptionsettings.
• CheckiftheADSLorCableconnectioniscorrect.
• RetryusinganotherEthernetcable.
If the ADSL“LINK”light blinks continuously or stays o, Internet access is
not possible - the Router is unable to establish a connection with the ADSL
network.
• Ensurethatallyourcablesareallproperlyconnected.
• DisconnectthepowercordfromtheADSLorcablemodem,waitafew
minutes, then reconnect the cord.
• IftheADSLlightcontinuestoblinkorstaysOFF,contactyourADSLservice
provider.
Network name or encryption keys are forgotten.
• Trysettingupthewiredconnectionandconguringthewirelessencryption
again.
• PresstheResetbuttonofthewirelessrouterformorethanveseconds.
• Factorydefaultsettings:
User name / Password:
admin / admin IP address: http://router.asus.com SSID: Check the rating label
on the back side of your
router
WEU15065_RT-AC66U_B1_QSG_V5.indb 14 2019/3/5 14:59:34

15
English
Where can I nd more information about the wireless router?
• OnlineFAQsite: http://support.asus.com/faq
• TechnicalSupportsite:https://www.asus.com/support/
• CustomerHotline:RefertotheSupportHotlineinthisQuickStartGuide
WEU15065_RT-AC66U_B1_QSG_V5.indb 15 2019/3/5 14:59:34

16
Dansk
Pakkens indhold
RT-AC66U B1 AC adapter
RJ-45 kabel Kvikstartguide
Garantibevis
En hurtig oversigt
BEMÆRK: Du bedes venligst kontakte din forhandler, hvis nogen af delene
mangler eller er beskadiget.
1) USB 3.0 porte 5) Strøm LED 9) Nulstillingsknap
2) LAN LED 6) Strøm (DC-IN) port 10) WAN porte
3) WAN LED 7) Afbryder 11) LAN-porte
4) 2.4GHz/5GHZ LED 8) USB 2.0 porte 12) WPS knap
WEU15065_RT-AC66U_B1_QSG_V5.indb 16 2019/3/5 14:59:35

17
Dansk
BEMÆRKINGER:
• USB ekstern HDD/Flashdrev:
 • DentrådløseroutervirkermeddeesteUSBHDD/Flashdrev(optil
2TBistørrelse),ogunderstøtterlæs-skrivadgangpåFAT16,FAT32,
EXT2,EXT3ogNTFS.
 • ForsikkerernelseafUSB-disken,skaldustarteinternetgrænseade
(http://router. asus.com),øversttilhøjrepåsidenNetwork Map
(Netværkskort),klikpåUSB-ikonetogklikherefterpåEject USB 1
(Fjern USB 1).
 • FjernesUSBdrevetpåenforkertmåde,kandetmedfølge
ødelæggelse af data.
 • Foratseenlisteoverhvilkelsystemeroghardiskpartitioner,som
dentrådløserouterunderstøtter,bedesduvenligstbesøgehttp://
event.asus.com/ networks/disksupport
• Foratseenlisteoverhvilkeprintere,somdentrådløserouter
understøtter, bedes du venligst besøge
http://event.asus.com/networks/printersupport
WEU15065_RT-AC66U_B1_QSG_V5.indb 17 2019/3/5 14:59:35

18
Dansk
Placering af din router
Foratopnådenbedstetrådløsesignaloverførselmellemdentrådløserouterog
netværksenhederne, som er forbundet til den, skal du søre for at:
• Stildentrådløserouterpåetcentraltstedfor,atfåstørsttrådløsdækningtil
netværksenhederne.
• Holdenhedenvækframetalforhindringer,ogvækfradirektesollys.
• HoldenhedenvækfraWi-Fienheder,derkunkørerpå802.11geller
20MHz,2,4GHzcomputerudstyr,Bluetoothenheder,trådløsetelefoner,
transformatorer,kraftigemotorer,uorescerendelys,mikrobølgeovne,
køleskab og andet industriudstyr for, at forhindre forstyrrelser eller signaltab.
• Foratsikredetbedstmuligetrådløsesignal,skaldurettedetreaftagelige
antenner,somvistpåtegningennedenfor.
• Foratopnåenoptimalydelse,skaldujusteredetindbyggedekølesystem.Se
brugermanualen for yderligere oplysninger.
• Sørgaltidfor,atopdateretildennyestermware.BesøgASUS'hjemmeside
påhttp://www.asus.comfor,athentedesenestermwareopdateringer.
90° 90°
WEU15065_RT-AC66U_B1_QSG_V5.indb 18 2019/3/5 14:59:35

19
Dansk
ADVARSEL! Førdutrækkerledningerne/kablerneud,bedesdusørge
for at dit kabel/ADSL modem har været slukket i mindst to minutter.
Hvisditmodemharetbackup-batteri,bedesduogsåernedette.
Før du fortsætter
1. Træk ledningerne/kablerne ud af dit eksisterende
modemsopsætning,ogfrigivdemforældedeIP-adressepådincomputer.
a: Træk stikket ud af stikkontakten, og træk stikket ud af dit kabel/ADSL
modem.
b: Træk netværkskablet ud af dit kabel/ADSL modem.
c: Genstartdincomputer(anbefales).
Modem
OFF!
a
b
c
d
a
b
c
d
a
b
c
d
WEU15065_RT-AC66U_B1_QSG_V5.indb 19 2019/3/5 14:59:36

20
Dansk
2.Opsætningafdittrådløstmiljø.
a: Slut den ene ende af el-ledningen til DC-IN stikket, og den anden til en
stikkontakt.
b: Hvisdubrugerennetværkskabel,skalduforbindedincomputertilLAN
portenpådintrådløserouter.
VIGTIGT! Sørg for, at WAN og LAN LED lamperne blinker.
c: Hvis du bruger en anden netværkskabel, skal du forbinde dit modem til WAN
portenpådintrådløserouter.
d: Slutdeneneendeafel-ledningentilDC-INstikketpåmodemmet,ogden
anden til en stikkontakt.
3. Deaktivernogleindstillingerpådincomputer.
A. Deaktiver proxyserveren, hvis den er aktiveret.
B. Indstil TCP/IP indstillingerne til at hente en IP-adresse automatisk.
C. Deaktiver opkaldsforbindelsen, hvis den er aktiveret.
BEMÆRK: Foryderligereoplysningeromdeaktiveringafdine
computerindstillinger,bedesduvenligstseOfte stillede spørgsmål
(FAQ).
RT-AC66U B1
c
WAN
a
db
LAN
Internet
Modem
WEU15065_RT-AC66U_B1_QSG_V5.indb 20 2019/3/5 14:59:36
