Asus RP-AC55 User manual

Quick Start Guide
RP-AC55
Wireless AC1200 Repeater
U14322/ Third Edition / May 2018
U14322_RP-AC55_QSG_V3.indb 1 2018/5/22 18:09:58

English..................................................................................................................................................................................................................................................................................... 3
Български.............................................................................................................................................................................................................................................................................. 9
Hrvatski.................................................................................................................................................................................................................................................................................15
Čeština...................................................................................................................................................................................................................................................................................21
Dansk.....................................................................................................................................................................................................................................................................................27
Nederlands ..........................................................................................................................................................................................................................................................................33
Eesti........................................................................................................................................................................................................................................................................................39
Français .................................................................................................................................................................................................................................................................................45
Suomi.....................................................................................................................................................................................................................................................................................51
Deutsch.................................................................................................................................................................................................................................................................................57
Ελληνικά................................................................................................................................................................................................................................................................................63
Magyar ..................................................................................................................................................................................................................................................................................69
Italiano ..................................................................................................................................................................................................................................................................................75
Lietuvių .................................................................................................................................................................................................................................................................................81
Latviski ..................................................................................................................................................................................................................................................................................87
Norsk......................................................................................................................................................................................................................................................................................93
Português.............................................................................................................................................................................................................................................................................99
Polski................................................................................................................................................................................................................................................................................... 105
Русский.............................................................................................................................................................................................................................................................................. 111
Română.............................................................................................................................................................................................................................................................................. 117
Español............................................................................................................................................................................................................................................................................... 123
Srpski .................................................................................................................................................................................................................................................................................. 129
Slovensky........................................................................................................................................................................................................................................................................... 135
Slovenščina....................................................................................................................................................................................................................................................................... 141
Svenska .............................................................................................................................................................................................................................................................................. 147
Türkçe ................................................................................................................................................................................................................................................................................. 153
Українська........................................................................................................................................................................................................................................................................ 159
Table of contents
U14322_RP-AC55_QSG_V3.indb 2 2018/5/22 18:09:59

ENGLISH
3
Package contents
NOTE: If any of the items is damaged or missing, please contact your retailer.
A quick look
RP-AC55 Wireless AC1200 Repeater Quick Start Guide
Warranty Card
1) Reset button
2) Power switch
3) WPS button
4) Power LED
On: RP-AC55 is power on.
O: RP-AC55 is power o.
5) Existing network LED
On: Connected to the router/AP.
O: Not connected to the router/AP.
6) Move closer
Need to move RP-AC55 closer to the router/AP.
Move away slightly
Need to move RP-AC55 slightly away from the router/AP.
U14322_RP-AC55_QSG_V3.indb 3 2018/5/22 18:09:59

4
ENGLISH
Turning the Repeater on
1. Place your RP-AC55 near your Router/AP and plug it to a
power outlet. Press the power switch to ON.
2. Wait until the power LED changes from red to solid blue,
indicating that RP-AC55 is ready to connect to the existing
network.
Setting up the Repeater
Connecting to a network
Select one of the following ways to connect the Repeater to a
network.
Method One: Using WPS (Wi-Fi Protected Setup)
1. Press the WPS button on the router/AP.
2. Press the WPS button of RP-AC55 for more than ve (5) sec-
onds until the Power LED starts to blink.
NOTE: Refer to the section A quick look for the location of the
WPS button.
3. Check if RP-AC55’s Wi-Fi indicator turns solid light, which
indicates that the Repeater has connected to the wireless
network successfully. The Repeater’s wireless network name
(SSID) changes to your existing Wi-Fi network name, ending
with _RPT or _RPT5G. For example:
Existing Wi-Fi network name: existing NetworkName
New Extender 2.4GHz network name: existing NetworkName_
RPT
New Extender 5GHz network name: existing NetworkName_
RPT5G
To connect an additional Wi-Fi device to your extended net-
work, use the same network password as that of your existing
wireless router.
Method Two: Connecting through GUI
1. Use a Wi-Fi enabled device, such as your desktop PC/note-
book/tablet, to nd and connect to ASUS_RPAC55/ASUS_
RPAC55_5G wireless network.
2. Launch a web browser and enter http://repeater.asus.com in
the address bar to access the Repeater.
U14322_RP-AC55_QSG_V3.indb 4 2018/5/22 18:09:59

ENGLISH
5
3. Follow the Quick Extender Setup steps to set up the Repeat-
er:
• ConnecttoaWi-Finetworkandwhenprompted,enterthe
security key. If your Wi-Fi network is hidden, click Manual
setting.
• TickSame with Parent AP SSID/Password to copy the rout-
er/AP’s SSID and password for your extended network. You
could also set a unique SSID and password for your extended
network by typing in the text box. When done, click Apply.
NOTE: The Repeater’s default SSID and password is the same
as that of your router/AP, with the SSID ending with _RPT or
_RPT5G. You can change these default settings to a unique SSID
and password.
• Connectyourwirelessdevicestothenewextendednetwork.
Moving the Repeater
• Whentheconnectioniscomplete,placeyourRP-AC55
between the router/AP and the wireless device to get the best
performance.
• AfterplacingyourRP-AC55inanideallocation,RP-AC55
connects to your router/AP in about one (1) minute.
U14322_RP-AC55_QSG_V3.indb 5 2018/5/22 18:10:00

6
ENGLISH
Frequently Asked Questions
Q1: What should I do if my router does not support WPS?
 •YoucanuseMethodTwotosetupRP-AC55.
Q2: Why is it that the LED indicator for the current network does not light up after the Wi-Fi setup is
complete?
 •Youmayhaveenteredthewrongpasswordfortherouter/AP.PleaserestartyourRP-AC55,enterthecorrectpassword,andtryto
set up your RP-AC55 again.
Q3: Why is it that I cannot see the login page after entering http://repeater.asus.com in the browser?
 •EnsurethatyourcomputerisconnectedtoyourRP-AC55networkonly,andsetyourcomputertoObtain an IP address au-
tomatically. If you still cannot nd the login page, please download the ASUS Device Discovery utility. You can download the
utility for Windows and Mac from https://www.asus.com/Networking/RP-AC55/HelpDesk_Download/.
Q4: How do I reset RP-AC55?
 •PresstheRESETbuttononthesideofRP-AC55forabouttwo(2)seconds.Waitforaboutve(5)secondsuntiltheexistingnet-
work LED blinks slowly.
Q5: I cannot access the web GUI to congure the RP-AC55 settings.
• Closeallrunningwebbrowsersandlaunchagain.
• Followthestepsbelowtocongureyourcomputersettingsbasedonits
operating system.
Windows 7
A. Disable the proxy server, if enabled.
1. Click Start > Internet Explorer to launch the web browser.
2. Click Tools > Internet options > Connections tab > LAN settings.
3. From the Local Area Network (LAN) Settings screen, untick Use a proxy server for your LAN.
4. Click OK when done.
U14322_RP-AC55_QSG_V3.indb 6 2018/5/22 18:10:00

ENGLISH
7
B. Set the TCP/IP settings to automatically obtain an IP address.
1. Click Start > Control Panel > Network and Internet > Network and Sharing Center > Manage
network connections.
2. Select Internet Protocol Version 4 (TCP/IPv4), then click Properties.
3. Tick Obtain an IP address automatically.
4. Click OK when done.
Mac OS
A. Disable the proxy server, if enabled.
1. From the menu bar, click Safari > Preferences... > Advanced tab.
2. Click Change Settings... in the Proxies eld.
3. From the list of protocols, deselect FTP Proxy and Web Proxy (HTTP).
4. Click OK when done.
U14322_RP-AC55_QSG_V3.indb 7 2018/5/22 18:10:00

8
ENGLISH
B. Set the TCP/IP settings to automatically obtain an IP address.
1. Click the Apple icon > System Preferences > Network.
2. Select Ethernet and select Using DHCP in the Congure eld.
3. Click Apply when done.
U14322_RP-AC55_QSG_V3.indb 8 2018/5/22 18:10:00

9
БЪЛГАРСКИ
Съдържание на пакета
ЗАБЕЛЕЖКА: Ако някой от компонентите е повреден или липсва, свържете се с Вашия търговски представител.
Бърз преглед
RP-AC55 Безжичен ретранслатор AC1200 Гаранционна карта
Ръководство за бърз старт
1) Бутон за нулиране
2) Ключ Вкл/Изкл
3) WPS бутон
4) Мощен светодиод (Power LED)
On (Вкл.): RP-AC55 е включен.
O (Изкл.): RP-AC55 е изключен.
5) LED на съществуваща мрежа
On (Вкл.): Установена връзка с маршрутизатор/точка
за достъп.
O (Изкл.): Няма връзка с маршрутизатор/точка за
достъп.
6) Преместете по-близо
Трябва да преместите RP-AC55 по-близо до
маршрутизатора/точката за достъп.
Преместете малко по-далеч
Трябва да преместите RP-AC55 малко по-далеч от
маршрутизатора/точката за достъп.
U14322_RP-AC55_QSG_V3.indb 9 2018/5/22 18:10:01

10
БЪЛГАРСКИ
Включване на разширителя на обхват
1. Поставете RP-AC55 близо до Вашия рутер/точка и включете в
контакт. Натиснете ключа за включване в положение ON (ВКЛ.).
2. Изчакайте LED индикаторът да се промени от червено на
непрекъснато синьо, което показва, че RP-AC55 е готов за
свързване към съществуваща мрежа.
Настройка на разширителя на обхват
Свързване към мрежа
Изберете един от следните начини за свързване на
разширителя на обхват към мрежа.
Метод 1: Използване на WPS (защитена Wi-Fi настройка)
1. Натиснете WPS бутона на рутера/точката за достъп.
2. Натиснете бутона WPS на RP-AC55 за повече от пет (5)
секунди докато LED на захранването започне да мига.
ЗАБЕЛЕЖКА: Вижте раздела A quick look( Бърз преглед) за
местоположението на бутона WPS.
3. Проверете дали Wi-Fi индикаторът на RP-AC55 свети
постоянно, което показва, че разширителят на обхват
е свързан успешно към безжичната мрежа. Името на
безжичната мрежа на разширителя на обхват (SSID) става
името на съществуващата Wi-Fi мрежа, като в края се
добавя _RPT или _RPT5G. Например:
Съществуващо име на Wi-Fi мрежа: съществ. NetworkName
(Име на мрежа)
New Extender 2.4GHz име на мрежа: съществуващо име на
мрежа NetworkName_RPT
New Extender 5GHz име на мрежа: съществуващо име на
мрежа NetworkName_RPT5G
За да свържете допълнително Wi-Fi устройство към Вашата
разширена мрежа, използвайте същата мрежова парола,
като тази на съществуващия безжичен рутер.
Метод 2: Свързване чрез потребителския интерфейс
1. Използвайте устройство с Wi-Fi като компютър/ноутбук/
таблет, за да откриете и да се свържете към безжична
мрежа ASUS_RPAC55/ASUS_RPAC55_5G.
2. Стартирайте уеб браузър и отидете на http://repeater.
asus.com в адресната лента, за да получите достъп до
разширителя на обхват.
U14322_RP-AC55_QSG_V3.indb 10 2018/5/22 18:10:01
