Atag KS25178A User manual

Instructions for use
Refrigerator
KS25178A
KD25178A
KS24178A
KD24178A

EN 2
CONTENTS
Your refrigerator
Introduction 4
Safety instructions 5
Installation and connection
Selecting the location 11
Connecting the appliance 12
Changing the side on which the door opens / building
the appliance into a cupboard 13
Before using the appliance for the first time
Before you use the appliance for the first time 14
Energy-saving advice 14
Description of the appliance
Appliance 15
Operating the appliance 16
Appliance interior equipment 20
Storing food
Recommended distribution 25
Avoid contamination of food 26
Storing fresh food in the refrigerator 26
Maintenance
Defrosting the appliance 27
Cleaning the appliance 27

EN 3
Other
Faults table 29
Environmental aspects
Disposal of packaging and appliance 31
Pictograms used
Important information
Tip
Warning; risk of fire / flammable materials
CONTENTS

EN 4
YOUR REFRIGERATOR
Introduction
Congratulations on choosing this Atag refrigerator. This product is designed with simple
operation and optimum comfort in mind.
These instructions for use explain how you can make best use of this appliance. These
instructions contain information about the operation of the appliance and background
information that may be of help to you during its use.
Read these instructions thoroughly before you first use the appliance, and keep the
instructions for future use.
A section of the installation instructions is supplied separately.
Read the safety instructions before using the appliance!

EN 5
SAFETY INSTRUCTIONS
Before the installation and use of the appliance, carefully read
the supplied instructions. The manufacturer is not responsible if
an incorrect installation and use causes injuries and damages.
Always keep the instructions with the appliance for future
reference.
Safety of children and vulnerable people
• The appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use of
the appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play
with the appliance.
• Cleaning and user maintenance shall not be made by children
without supervision.
• Keep all packaging away from children.
For European markets only
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved.
• Children shall not play with the appliance.
• Cleaning and user maintenance shall not be made by children
without supervision.
• Children aged from 3 to 8 years are allowed to load and
unload refrigerating appliances.
Original instruction

EN 6
SAFETY INSTRUCTIONS
General safety
• The lamp in this household appliance is only suitable for
illumination of this appliance. The lamp is not suitable for
household room illumination.
• WARNING! This appliance is intended to be used in
household and similar applications such as:
– staff kitchen areas in shops, offices and other working
environments;
– farm houses and by clients in hotels, motels and other
residential type environments;
– bed and breakfast type environments;
– catering and similar non-retail applications.
• WARNING! Keep ventilation openings, in the appliance
enclosure or in the built-in structure, clear of obstruction.
• WARNING! Do not use mechanical devices or other means
to accelerate the defrosting process, other than those
recommended by the manufacturer.
• WARNING! Do not damage the refrigerant circuit.
• WARNING! Do not use electrical appliances inside the food
storage compartments of the appliance, unless they are of the
type recommended by the manufacturer.
• WARNING! Do not use water spray and steam to clean the
appliance.
• WARNING! Clean the appliance with a moist soft cloth.
Only use neutral detergents. Do not use abrasive products,
abrasive cleaning pads, solvents or metal objects.
• WARNING! Do not store explosive substances such as
aerosol cans with a flammable propellant in this appliance.
• WARNING! If the supply cord is damaged, it must be
replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.

EN 7
SAFETY INSTRUCTIONS
Installation
• WARNING! This appliance should only be connected by a
registered installer.
• Remove all the packaging.
• Do not install or use a damaged appliance.
• Obey the installation instruction supplied with the appliance.
• Always be careful when you move the appliance because it is
heavy. Always wear safety gloves.
• Make sure the air can circulate around the appliance.
• Wait at least 4 hours before connecting the appliance to
the power supply. This is to allow the oil to flow back in the
compressor.
• Do not install the appliance close to radiators or cookers,
oven or hobs.
• Do not install the appliance where there is direct sunlight.
• Do not install this appliance in areas that are too humid or too
colds, such as the construction appendices, garages or wine
cellars.
• When you move the appliance, lift it by the front edge to
avoid scratching the floor.
• WARNING! When positioning the appliance, ensure the
supply cord is not trapped or damaged.

EN 8
SAFETY INSTRUCTIONS
Electrical connection
• WARNING! Risk of fire and electrical shock.
• The appliance must be earthed.
• All electrical connections should be made by a qualified
electrician.
• Make sure that the electrical information on the rating plate
agrees with the power supply. If not, contact an electrician.
• Always use a correctly installed shockproof socket.
• Do not use multi-plug adapters and extension cables.
• Make sure not to cause damage to the electrical components
(e.g. mains plug, mains cable, compressor). Contact the
Service or an electrician to change the electrical components.
• The mains cable must stay below the level of the mains plug.
• Connect the mains plug to the mains socket only at the end
of the installation. Make sure that there is access to the mains
plug after the installation.
• Do not pull the mains cable to disconnect the appliance.
Always pull the mains plug.
• WARNING! Do not locate multiple portable socket-outlets or
portable power supplies at the rear of the appliance.
• If a stationary appliance is not fitted with a supply cord and a
plug, or with other means for disconnection from the supply
mains having a contact separation in all poles that provide full
disconnection under overvoltage category III conditions, the
means for disconnection must be incorporated in the fixed
wiring in accordance with the wiring rules. Using an omnipolar
switch with a contact separation of at least 3 mm fitted in the
supply cable will fulfil this requirement.

EN 9
SAFETY INSTRUCTIONS
Use
• WARNING! Risk of injury, burns, electrical shock or fire.
• Do not change the specification of this appliance.
• Do not put electrical appliances (e.g. ice cream makers)
in the appliance unless they are stated applicable by the
manufacturer.
• Be careful not to cause damage to the refrigerant circuit. It
contains isobutene (R600a), a natural gas with a high level of
environmental compatibility. This gas is flammable.
• If damage occurs to the refrigerant circuit, make sure that
there are no flames and sources of ignition in the room.
Ventilate the room.
• Do not let hot items to touch the plastic parts of the
appliance.
• Do not store flammable gas and liquid in the appliance.
• Do not put flammable products or items that are wet with
flammable products in, near or on the appliance.
• Do not touch the compressor or the condenser. They are hot.
Care and cleaning
• WARNING! Risk of injury or damage to the appliance.
• Before maintenance, deactivate the appliance and disconnect
the mains plug from the mains socket.
• This appliance contains hydrocarbons in the cooling unit.
Only a qualified person must do the maintenance and the
recharging of the unit.
• Regularly examine the drain of the appliance and if necessary,
clean it. If the drain is blocked, defrosted water collects in the
bottom of the appliance.

EN 10
SAFETY INSTRUCTIONS
Disposal
• WARNING! Risk of injury or suffocation
• Disconnect the appliance from the mains supply.
• Cut off the mains cable and discard it.
• Remove the door to prevent children and pets to be closed
inside of the appliance.
• The refrigerant circuit and the insulation materials of this
appliance are ozone friendly.
• The insulation foam contains flammable gas. Contact your
municipal authority for information on how to discard the
appliance correctly.
• Do not cause damage to the part of the cooling unit that is
near the heat exchanger.

EN 11
INSTALLATION AND CONNECTION
Selecting the location
• Place the appliance in a dry and well aired room. The permitted ambient temperature range
for the appliance depends on the appliance’s climate class, which is shown on the type
plate.
/
//
//
• Do not place the appliance near a source of heat, such as a gas cooker, radiator or boiler,
etc., and do not expose it to direct sunlight.
Climate class Ambient temperature range Relative humidity
SN (subnormal) +10 °C to +32 °C
75%
N (normal) +16 °C to +32 °C
ST (subtropical) +16 °C to +38 °C
T (tropical) +16 °C to +43 °C
Do not place the appliance in a room where the temperature can fall below 5 °C: the
appliance may not work properly or become defective!
The appliance is not suitable for outdoor use and may not be exposed to rain.
• The appliance must be placed at a distance of at least 5 cm from an electrical or gas cooker
and at least 30 cm from a radiator or heater. An insulation panel must be fitted when these
distances cannot be kept.

EN 12
INSTALLATION AND CONNECTION
• The appliance must be placed at a distance of about 5 cm from the wall, back and sides
of a cupboard. A kitchen cupboard above the refrigerator must have a gap of at least 5 cm
between the back of the cupboard and the wall. This is needed to make sure that there is
sufficient cooling air for the condenser.
• The plug of the installed appliance must remain accessible!
Place the appliance in a room with a sufficient volume of air. The room must have a
volume of at least 1 m3of air for every 8 grams of refrigerant. The quantity of
refrigerant is shown on the type plate on the inside of the appliance.
• The kitchen unit in which the appliance is to be built in must have an opening of at least
200 cm2in its base to allow sufficient air to circulate.
• The appliance’s air outlet is at the top. Make sure that the outlet is not blocked. Blocking the
outlet can result in damage to the appliance.
Warning:
An anti-condensation accessory must be installed before built-in appliances are
installed next to each other in a cupboard or surround. For safety reasons, this must
be installed by a recognized installer!
Connecting the appliance
• Connect the appliance to the power supply with a plug. The socket must be earthed. The
nominal voltage and frequency required for the appliance are shown on the appliance’s type
plate/label with basic information.
• The appliance must be connected to the mains and earthed in accordance with the
prevailing standards and regulations. The appliance can withstand small variations in the
mains voltage to a maximum of plus or minus 6%.
When you are not going to use the appliance for a longer period then switch it off with
the appropriate key and disconnect it from the mains. Empty, defrost and clean the
appliance, and leave the door ajar.

EN 13
INSTALLATION AND CONNECTION
Freeze burn hazard
To avoid freeze burn, never put frozen food in your mouth and do not touch frozen
food.
In the event of a defect or power cut, do not open the freezer compartment unless
the appliance has been out of operation for more than the hours indicated on the
appliance’s type plate (temperature rise time). After this time, you must either use the
frozen food or make sure that it is properly cooled (for example, by transferring it to
another appliance).
Changing the side on which the door opens / building the appliance into a
cupboard
Information about changing the side on which the door opens and building the appliance into a
cupboard is enclosed in separate installation instructions.

EN 14
BEFORE USING THE APPLIANCE FOR THE FIRST TIME
Before you use the appliance for the first time
Do not connect the appliance to the mains until you have carefully read the instructions for the
correct and safe use of the appliance. As these instructions are for various types and models,
it is possible that the instructions for use refer to settings or parts that are not available on
your appliance. We recommend that you keep these instructions for future use. If you sell the
appliance, enclose them with the appliance.
Inspect the appliance for damage and/or irregularities. If the appliance is damaged, contact the
store that sold you the appliance.
Allow the appliance to stand upright for at least 4 hours before you connect the appliance to the
mains. This reduces the risk of malfunctions resulting from transport effects on the refrigerant unit.
Before using the appliance for the first time, the interior and all internal accessories should be
cleaned with lukewarm water and a neutral cleaning agent. Wipe the cleaned parts with a cloth with
clean water and then dry them thoroughly.
If you use the appliance for the first time, do not put food into the appliance until the temperature
has decreased to the set temperature.
Energy-saving advice
• Install the appliance as stated in the instructions for use.
• Do not open the door more than necessary.
• Never cover or obstruct the ventilation openings.
• Replace a door seal that is damaged or no longer seals properly as quickly as possible.
• Store food in well-sealed containers or suitable packaging.
• Allow food to cool to room temperature before you put it in the appliance.
• Defrost food in the refrigerator compartment.
• Space the shelves evenly in the refrigerator compartment. Place the food so that the air
can circulate freely in the appliance (follow the recommendations for the location of foods
enclosed in the instructions).
• When the appliance is equipped with a fan then make sure that the ventilation openings are
kept clear.
• The lower the set temperature, the higher the power consumption.

EN 15
DESCRIPTION OF THE APPLIANCE
Appliance
1. Control panel
2. LED lighting
3. CoolFlow
4. Bottle rack
5. Glass shelves
6. Upper drawer
7. Vegetable drawer with humidity control
8. Vegetable drawer
9. Door compartments
1
3
5
7
2
6
8
9
4

EN 16
DESCRIPTION OF THE APPLIANCE
Operating the appliance
A
B
CD
A Appliance on/off, temperature settings, and extra function key
B Refrigerator compartment temperature display
The indicator for the selected temperature will be lit.
C Intensive cooling (boost) function indicator
Symbol Cwill be lit when the intensive cooling function is activated.
D High temperature indicator
To set the appliance temperature or activate extra functions, press the Akey successively. When
the key is first pressed, the currently set value or function will start to flash. With each successive
press of the key, the indicator moves to the next setting. The indicator cycles through the settings
in a circular manner, from right to left. While the settings are being adjusted, the display will flash.
Three seconds after the key is released, the setting will be stored automatically and the relevant
symbol will be lit.
Switching the appliance on/off
Switching the appliance on: Press the Akey and hold it for 3 seconds.
Switching off the appliance: Again press the Akey and hold it for 3
seconds. The appliance will be off, but there is still voltage in it as it is
still connected to the power mains.

EN 17
Adjusting the temperature in the appliance
• The factory default setting is the recommended temperature of 4 °C.
• After the appliance is switched on, it may take several hours for
the set temperature to be reached. Do not place any food into the
refrigerator before the temperature drops to the selected setting.
• Adjust the temperature as desired using the Akey.
• Press the Akey (several times) until the desired temperature
indicator lights up.
• When the Akey is pressed for the first time, the currently set value
or function will start to flash. Every successive time you press the A
key, the settings indicator will move to the next setting (from right to
left, in a circular manner).
• After three seconds, the setting will stop flashing. Your setting will
be stored and the corresponding indicator will be continuously lit.
The numbers 2, 4, 6 and 8 indicate the degrees Celsius (°C) in the
appliance refrigerator compartment.
• The recommended temperature setting is +4 °C. At this
temperature, food quality and freshness are preserved longer.
• If the ambient temperature in the room where the appliance is
installed is below 16 °C, we recommend setting a temperature lower
than 4 °C.
DESCRIPTION OF THE APPLIANCE

EN 18
DESCRIPTION OF THE APPLIANCE
Intensive cooling (SuperCool)
• To activate the intensive cooling function, press the Akey several
times until symbol Clights up.
• To switch off the intensive cooling function, press the Akey to
select the desired temperature B.
This appliance has an intensive cooling function. This function decreases the temperatures in
the refrigeration compartment as quickly as possible. This is ideal for cooling products that have
just been put into the refrigerator. Use this function when you put a large quantity of food in the
appliance.
When the intensive cooling function is selected, the appliance works at maximum
capacity. It may then make more noise for a while.
When the intensive cooling function is not manually disabled then the function will
be automatically disabled after about six hours. The temperature then returns to the
latest set temperature.
Should a power failure occur while the function is activated then the function will be
activated again when the power is restored.
Adjusting the temperature of the refrigeration compartment while the intensive cooling
function is activated will immediately disable the intensive cooling function.

EN 19
DESCRIPTION OF THE APPLIANCE
High temperature alarm
Stopping the alarm
1. Touch the Akey to stop the alarm.
▷The alarm will stop sounding.
▷Symbol Dshown in the display continues to flash while the temperature is still too high.
A signal will sound when the temperature in the appliance is too high. Furthermore, symbol D
shown in the display will flash. A high temperature can be caused for several reasons:
• The door has been opened for too long or too frequently.
• The door does not seal properly.
• Too much fresh food has been put in at the same time.
Every time the appliance is switched on again, it takes a while until the correct
temperature is reached. For this reason, the alarm is disabled for the first 24 hours
after the appliance is switched on to prevent the unnecessary activation of the alarm.
When the alarm is not stopped manually and the temperature remains too high, the
signal will sound for the first minutes of every half hour and when the door is opened.
When you press the Akey for the first time, the alarm will be acknowledged and
turned off. When you press the Akey again, it will already work as a settings
adjustment key.
Open door alarm
An alarm signal sounds when a door is open for too long.
Stopping the alarm
1. Close the door.
▷The alarm will stop sounding.
If you only switch off the alarm by touching the Akey, the alarm will switch on again
after some time because the door is still open.

EN 20
DESCRIPTION OF THE APPLIANCE
Appliance interior equipment
Glass shelves
The shelves are made from safety glass. To change the height of a shelf,
lift the front of the shelf (1). Take hold of the back and pull the shelf
slightly forwards (2). Move the shelf to a higher or lower position (3).
To remove a shelf from the refrigerator, lift the front of the shelf (4). Take
hold of the back and pull the shelf out of the appliance (5).
The bottle rack can contain a maximum load of nine 0.75-litre bottles or
13 kilograms of total weight. Also cans can be put on the bottle rack
(lengthwise or crosswise). Make sure that the door can close correctly if
you have put bottles or cans on the rack.
The bottle rack cannot accidentally being pulled out. It can only be
pulled out when it is empty. To pull it out, lift it slightly at the front (1)
and pull it towards you (2).
Bottle rack
