User’s Manual
SPB3200
Battery Case Charger for Samsung Galaxy S®4

Page 2
Welcome |Thank you for purchasing SPB3200
Introduction
Features
- Micro USB port to charge the Battery Case
- Rechargeable 2500 mAh Lithium-polymer battery
- Power Indicator – 4 LEDs power display
- Lightweight, thin design

Page 3
What’s Included
Unpack the battery case and make sure all accessories are put
aside so they will not be lost.
USB to Micro USB Cable
Battery Case

Page 4
Content
Introduction
Features 2
What’s Included 3
Safety Information
Important Safety Instructions 5
Getting Started
Location of Main Unit Controls 6
Operational Instructions
Charging Your SPB3200 Battery Case 7
Checking the Battery Case Power Level 7
Inserting Your Galaxy S4 into the Battery Case 8
Charging Your Galaxy S4 Using the SPB3200 Battery Case 8
Charging the Galaxy S4 Battery When Inserted in the SPB3200 8
Switching Your SPB3200 Battery Case to Standby Mode 9
Troubleshooting 10
Compliance with FCC Regulations 11
Warranty Information 12
Specications 14

Page 5
Safety Information
Important Safety Instructions
Please read all safety and operating instructions carefully before
installation and use, and keep these instructions handy for future
reference. Take special note of all warnings listed in this user’s
manual and on the SPB3200.
1. Attachments - Do not use attachments that are not recommended by
the manufacturer.
2. Water and Moisture - The unit should not be used near water. For
example: near a bathtub, washbowl, kitchen sink, laundry tub, swimming
pool or in a wet basement.
3. Ventilation - The unit should be situated so that its location or position
does not interfere with its proper ventilation. For example, it should
not be situated on a bed, sofa, rug or similar surface that may block
ventilation openings. Also, it should not be placed in a built-in installation,
such as a bookcase or cabinet, which may impede the ow of air through
the ventilation openings.
4. Objects and Liquid Entry - Care should be taken so that external objects
do not fall into and liquids are not spilled onto any openings or vents
located on the product.
5. Power Source - The unit should be connected to a power supply only of
the type described in the operating instructions or as marked on the unit.
If you are not sure please consult the dealer or local power company.
6. Heat - The unit should be situated away from heat sources such as
radiators, heat registers, stoves or other appliances (including ampliers)
that produce heat.
7. Servicing - The user should not attempt to service the unit beyond
those methods described in the user’s manual. Opening or removing
covers will expose you to dangerous voltage and other hazards. Service
methods not covered in the user’s manual should be referred to qualied
service personnel.

Page 6
Getting Started
Location of Main Unit Controls
6
1
4 2 5
3
1. USB connector
2. Power ON/OFF button
3. Micro USB input
4. LED Power indicators
5. Galaxy S4 speaker port
6. Battery case slide/lock

Page 7
Operational Instructions
Charging Your SPB3200 Battery Case
- Using the included USB to micro-USB cable, plug the micro-USB
connector into the micro-USB input jack on the bottom of your
SPB3200.
- Plug the USB cable into any USB powered device, such as a
personal computer, USB wall adapter or USB enabled battery pack.
- Upon initial use, or aer a prolonged storage period, the SPB3200
should be fully charged in approximately 4 hours.
Note: The case will charge when connected to the USB power source even when there is no phone
inserted into the SPB3200 Battery Case.
Checking the Battery Case Power Level
- Press the Power ON/OFF button and the blue LED lights will
illuminate. The battery case is fully charged when all four LED is
light up.
LED Power Indicator Chart
Status Power indicator
0-25% •
25-50% • •
50-75% • • •
75-100% • • • •

Page 8
Operational Instructions
Inserting Your Galaxy S4 into the Battery Case
1. Pull the Slide/Lock top of the battery case up to open it.
2. Align the micro USB connector on the bottom of your Galaxy S4
with the micro USB connector on the SPB3200 battery case and
gently slide it onto the battery case’s micro USB connector.
3. Complete the assembly by pushing the slide/lock of the battery
pack down onto the Galaxy S4, securing it into the battery case.
4. Press the power button to use the battery case battery power
for your Galaxy S4.
Charging Your Galaxy S4 Using the SPB3200 Battery Case
- With the Galaxy S4 inserted into the SPB3200 press the battery
case power button to turn the SPB3200 “On”. The blue lights will be
illuminated when powered on.
- With the battery case turned on, your Galaxy S4 will recognize that
it is being charged and the Galaxy S4 battery level indicator will
show that the Galaxy S4 is charging.
Charging the Galaxy S4 Battery When Inserted in the SPB3200
- To charge the Galaxy S4 battery while inserted in the SPB3200
battery case, plug the micro USB charging cable into the micro-
USB input jack on the bottom of your SPB3200.
- Plug the USB cable into any USB powered device, such as a
personal computer, USB wall adapter or USB enabled battery pack.
- Press the SPB3200 power button to turn it “On” and the Galaxy S4
battery indicator will show that the Galaxy S4 is charging.
- The SPB3200 will also begin charging once the Galaxy S4 battery is
charged.

Page 9
Operational Instructions
Switching Your SPB3200 Battery Case to Standby Mode
- The power button on the front of the SPB3200 allows you to
choose between standby mode and charging mode.
- To use your phone’s internal battery, press the SPB3200 power
button to turn it “O” and you will be in standby mode. When your
internal battery is low, press the SPB3200 power button to turn it
“On,” and your Galaxy S4 will begin charging immediately.

Page 10
Troubleshooting
Symptom Solution
No power - Verify that there is power le in the
battery case.
- Recharge the battery case, as
needed.

Page 11
Compliance with FCC Regulations
Caution!
The user is cautioned that changes or modications not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
The equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses,
and can radiate Radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to Radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to Radio or television reception, which can be
determined by turning the equipment o and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit dierent from that to which the receiver
is connected.
-Consult the dealer or an experienced Radio/television technician for assistance.
This equipment complies with FCC’s RF radiation exposure limits set forth for an uncontrolled
environment. The antenna(s) used for this transmitter must be installed and operated to
provide a separation distance of at least 20 cm from all persons and must not be collocated
or operating in conjunction with any other antenna or transmitter. Installers must ensure that
20 cm separation distance will be maintained between the device (excluding its handset) and
users.
THE SPECIFICATION AND EXTERNAL APPEARANCE OF THE UNIT ARE SUBJECT TO CHANGE
WITHOUT PRIOR NOTICE.
If at any time in the future you should need to dispose of this
product, please note that waste electrical products should not be
disposed of with household waste. Please recycle where facilities
exist. Check with your local authority or retailer for recycling advice.

Page 12
Warranty Information
Limited Warranty
The AT&T brands are used under license. Any repair, replacement, or warranty
service, and all questions about this product should be directed to Concept
101 LLC at www.att.com/electronics or call 1 [phone] from the USA or
Canada.
Concept 101 LLC warrants to the original purchaser that the product will be free from defects
in material, parts and workmanship for the period designated for this product. The warranty
commences the day the product is purchased and covers up to a period of one (1) year. Concept
101 LLC agrees that it will, at its option, replace the defective product with either a new or
remanufactured headset equivalent to your original purchase during the warranty period.
Should the Parts warranty period exceed the Labor warranty period, Concept 101 LLC will supply
at no charge for the remainder of the Parts warranty, any new or remanufactured replacement
parts as required by the product. During this period all labor and service charges will become the
responsibility of the customer.
Exclusions: This warranty does not apply to the appearance or exterior of the product
which may have been damaged or defaced, altered or modied in design or
construction. This warranty does not apply if the serial number is altered or
removed, or if there is any damage due to power line surge, user damage to
the AC power cord, connection to improper voltage source, general misuse,
accidents, or repair attempts by unauthorized service agents. Other exclusions
include ear pads, rechargeable and non-rechargeable batteries.
REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE
EXCLUSIVE REMEDY OF THE CUSTOMER; Concept 101 LLC SHALL NOT BE
LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR BREACH
OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT, EXCEPT TO
THE EXTENT PROHIBITED BY APPLICABLE LAW. ANY IMPLIED WARRANTY
OF MERCHANTABILITY OF FITNESS FOR A PARTICULAR PURPOSE ON THIS
PRODUCT IS LIMITED TO THE DURATION OF THE WARRANTY.
Some states do not allow the exclusion or limitations of incidental or
consequential damages, or limitations on how long the warranty lasts. In
these cases the above exclusions or limitations may not apply to you. This
warranty gives you specic legal rights and you may also have other rights
which vary from state to state.

Page 13
Obtaining Service: To obtain service, product literature, supplies or accessories please
call 1 888-920-8680, or visit our website, www.att.com/electronics,
to create a ticket for exchange/repair. Please make sure to provide
the date of purchase, model number and a brief description of the
problem. Our customer service representative will contact you or
send detailed return instructions.
Concept 101 LLC does not warrant that the unit will work properly in all environmental
conditions, and makes no warranty and representation, either implied or expressed, with
respect to the quality, performance, merchantability, or tness for a particular purpose
other than the purpose identied within this user’s manual. Concept 101 LLC has made
every eort to ensure that this user’s manual is accurate and disclaims liability for any
inaccuracies or omissions that may have occurred. Information in this user’s manual is
subject to change without notice and does not represent a commitment on the part of
Concept 101 LLC. Concept 101 LLC reserves the right to make improvements to this user’s
manual and/or to the products described in this user’s manual at any time without notice.
If you nd information in this manual that is incorrect, misleading, or incomplete, please
contact us through our website.

Page 14
Specications
- Input: DC5.0V-500mA
- Output: DC5.0V-500mA(max)
- Capacity: 2500 mAh lithium polymer battery
- Dimensions: 146 x 75 x 18mm
- Weight: 98g

www.att.com/electronics
© 2017 Concept 101 LLC. All Rights Reserved. AT&T and the AT&T logo are trademarks
of AT&T Intellectual Property licensed to Concept 101 LLC, New York, New York 10018.
D Issue 2.0 AT&T 9/2017.
Galaxy S® is a trademark of Samsung Electronics Co. Other trademarks and trade names
are those of their respective owners.
