ATC Z-2281 M User manual

Installation Method
First Fix
A Recessed Junction box
should be installed to allow
hand dryer to sit flush with the
wall. Height should be
determined from table
overleaf
Cover Removal
Remove the Allen Screws on
either side of the hand dryer,
lift off cove. Make sure to put
the cover in a location where it
will not be damaged.
Mounting
Drill mounting holes according
to the area that the Hand
Dryer is to be installed in (see
Overleaf) & mount the hand
dryer.
Connect the electrical cables
and ensure correct Polarity.
NOTE: The Sensitivity of the
Cheetah is fixed. Do not install
with anything below the dryer
that can start the dryer. E.g.
Shelves, Radiators, above sinks
etc.
Replace Cover
Replace the cover
NOTE: The cover is earthed
through the mounting screws.
Please ensure they are firmly
attached prior to re-energising
the power supply.
Install the two Allen Screws
and test the hand dryer
Daily Use & Maintenance
External Maintenance:
•Regularly clean cover with a
soft cloth, do not use harsh
detergents, Abrasive, Acid or
Alkali Based Cleaning products
or cleaning brushes as they
may damage the cover finish.
If using a chemically
impregnated cloth please test
on an inconspicuous area prior
to use to check suitability.
Internal Maintenance
After turning off the power supply, remove cover and
check all connections,
Clean away any dirt that has deposited inside the hand
dryer.
Remove the motor housing and check the brushes on the
motor for wear. Replace worn Brushes.
Please note: Brushes are a consumable item and are not
covered under warranty
Method Of Operation:
Insert the back
of your hands
Turn your hands
over
Rub your hands
together until dry
Packing List
ATC Cheetah Hand Dryer User Manual
5mm Plastic wall plug x4 Allen Key
30mm Self Tapping Screws x4
ATC CHEETAH
Hand Dryer
Z-2281 M/W/B
Infra-Red Sensor

Specification
Voltage
230v ~ 50Hz
Sound Level
Phase
1Φ
Sensor Range
15-20cm (fixed)
Load
1475w
IP Class
IPX1
Air Speed
65m/s
Size (mm)
295x320x170
Heat level
900w
Nett Weight
4.5kg
Features
Infra-Red operated Hygienic High Speed hand dryer
Solid Stainless Steel or Painted Steel
Auto stop Function after
4
s to prevent overrun
Product Description
Circuit Diagram
Environmental Protection
♻
Waste electrical products should not be disposed
of with household waste, please recycle this
product where the facilities exist.
Please check with your local authority
Warranty
ATC Electrical &Mechanical provides a 2-year limited parts
warranty for the
Z-2281 M/W/B
as long as the following conditions
are followed: Installation and use of the hand dryer is in
accordance with the instruction manual, which is packed
with hand dryer.
In order to arrange parts for the hand dryer the following
information is required.
Receipt number: ____________________________________________
Date of Manufacture: __________________________________________
Date of Purchase: __________________________________________
Precautions before installation
Do not install in the following locations; Installation in these
areas can cause the unit to malfunction
Areas with Temperatures below 0oC or above 40oC
In direct Sunlight or areas above reflective surfaces
Areas where the unit can come into direct contact with
water
Above counters or sinks
Areas of High moisture and Humidity levels
Locations containing Corrosive or Oxidizing gasses
Areas at Altitude above 2000m
Installation Location
The Chart below shows the recommended mounting
height for the Hand Dryer.
Make sure the dryer is mounted more than 150mm away
from walls on either side of the dryer.
Ensure the wall the hand dryer is mounted on is flat and
smooth.
Do not mount the unit behind doors where the opening of
the door may damage the dryer
Do not install the dryer with the power connected; the
dryer must be connected by a qualified electrician when
being installed.
The power cord Supplying the hand dryer should be at least
1.5m² 2 Core & Earth
Motor Cable
Entry Hole
P.C.B
Heating Element
Infra-Red Sensor
Allen Key
Countersunk
Cover Screw
Cover
Check indicator
power indicator
Air outlet
sensor plug
75 dB@1m
5
