ATEN CS-62 User manual

CS62 / CS62S
2-Port PS/2 KVM Switch
Diagram
Features
© Copyright 2009ATEN® International Co., Ltd. All brand names and trademarks are the registered property of their respective owners. 2009. Version 1.0
Headquarters
ATEN International CO., Ltd.
3F, No.125, Sec. 2, Datung Rd. Sijhih City, Taipei 221, Taiwan
Tel: [phone] Fax: [phone] E-mail : [email protected]
Specications
* The specications and pictures are subject to change without notice.
Console
Computer 1
Computer 2
PS/2
PS/2
OS Support
Win, Linux, FreeBSD
Console
PS/2
Computers
PS/2
Non-Powered
• One PS/2 console controls two PS/2 computers
• Compact design, built in 1.2m cables(CS62),0.9m
Cables(CS62S)
• All-in-one design
• Superior video quality- up to 2048 x 1536; DDC2B
• Auto Scan function to monitor computer operation
• Non-powered
Function CS62 / CS62S
Computer Connections 2
Port Selection Hotkey
Connectors
Console
Ports
Keyboard 1 x 6-pin Mini-DIN Female (Purple)
Video 1 x HDB-15 Female (Blue)
Mouse 1 x 6-pin Mini-DIN Female (Green)
KVM
Ports
Keyboard 2 x 6-pin Mini-DIN Male (Purple)
Video 2 x HDB-15 Male (Blue)
Mouse 2 x 6-pin Mini-DIN Male (Green)
LEDs Selected 2 (Green)
Cable
Length Computers 1.2m / 0.9m
Emulation Keyboard/Mouse PS/2
Video 2048 x 1536; DDC2B
Scan Interval 3, 5, 10, 20 Seconds(default 5 sec)
Environment
Operating Temp. 0-50°C
Storage Temp. -20-60°C
Humidity 0-80% RH, Non-condensing
Physical
Properties
Housing Plastic
Weight 0.33 kg
Dimensions
(L x W x H) 7.30 x 5.85 x 2.25 cm
The CS62/CS62S Switch is a control unit that allows access to two computer systems from a single
console (keyboard, monitor, and mouse). The CS62/CS62S improves on previous models with a 50%
smaller desktop footprint plus attached custom KVM cables for hassle-free installation and a neat and
tidy workspace.
Setup is fast and easy; plugging cables into their appropriate ports is all that is entailed. There is no
software to congure, no installation routines, and no incompatibility problems.
