ATEN Petite CS682 User manual

CS682
USER MANUAL
USB 2.0 DVI KVM Switch
cs682.fm Page 1 Friday, October 31, 2014 11:52 AM

EMC Information
FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE
STATEMENT: This equipment has been tested and found to comply with
the limits for a Class B digital service, pursuant to Part 15 of the FCC rules.
Theselimitsaredesignedtoprovide reasonableprotectionagainstharmful
interference in a residential installation. Any changes or modifications
made to this equipment may void the user’s authority to operate this
equipment. This equipment generates, uses, and can radiate radio
frequency energy. If not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FCCCaution:Any changes ormodificationsnotexpresslyapprovedby the
party responsible for compliance could void the user's authority to operate
this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:(1) this device mat not cause harmful
interference, and(2) this device must accept any interference received,
including interference that may causeundesired operation.
RoHS
This product is RoHS compliant.
SJ/T 11364-2006
The following contains information that relates to China.
cs682.fm Page 2 Friday, October 31, 2014 11:52 AM

- 3 -
CS682 User Manual
Online Registration
Telephone Support
Technical Support
For international online technical support – including
troubleshooting, documentation, and software updates:
http://eservice.aten.com
For North American technical support:
International http://eservice.aten.com
International 886-2-8692-6959
China 86-10-5255-0110
Japan 81-3-5615-5811
Korea 82-2-467-6789
North America 1-888-999-ATEN ext 4988
United Kingdom 44-8-4481-58923
Email Support [email protected]
Online
Technical
Support
Troubleshooting
Documentation
Software Updates
http://www.aten-usa.com/support
Telephone Support 1-888-999-ATEN ext 4998
cs682.fm Page 3 Friday, October 31, 2014 11:52 AM

- 4 -
Package Contents
The CS682 USB 2.0 DVI KVM Switch package contains the
following items:
1 CS682 2-Port USB 2.0 DVI KVM Switch
1 Remote Port Selector
1 User Manual*
1 Quick Start Guide
Check to make sure that all the components are present and that
nothing got damaged in shipping. If you encounter a problem,
contact your dealer.
Read this manual thoroughly and follow the installation and
operation procedures carefully to preventanydamageto theunit,
and/or any of the devices connected to it.
*Features may have been added to the CS682 since this
manual was printed. Please visit our website to download the
most up-to-date version of the manual.
Copyright © 2014 ATEN® International Co., Ltd.
Manual Date: 2014-10-31 - Manual Part No. PAPE-1337-AT4G
ATEN and the ATEN logo are trademarks of ATEN International Co., Ltd. All rights
reserved. All other trademarks are the property of their respective owners.
cs682.fm Page 4 Friday, October 31, 2014 11:52 AM

- 5 -
Overview
The CS682 takes a giant step forward from prior cable KVM
models in the Petite series, by offering DVI functionality, USB 2.0
peripheral sharing (via a USB hub attached to the USB mouse
port), a rich bass experience for 2.1 surround systems, and a
firmware upgrade function that allows you to keep up with latest
available versions.
Another new feature of the CS682 is the implementation of a
remote port selector. This means that you can now control port
switching from the desktop while the switch itself can be placed
in a convenient, out-of-the-way, location. Also, in addition to new
hotkeys, the CS682 offers the latest mouse port-switching
function–simplydouble-clickon thescroll wheelof aUSBmouse
to change ports.
Furthermore, the CS682 features enhanced Video DynaSync
technology, which eliminates boot-up display problems and
optimizes resolution when switching between ports.
Finally, the CS682's new Power on detection feature means that
if one of the computers is powered off, switch will automatically
switch to the other powered-on computer.
Featuring an unbeatable combination of DVI functionality, USB
2.0 peripheral sharing convenience, and enhanced user-friendly
operations, the CS682 allows users to keep up with the latest
innovations in desktop multimedia applications.
cs682.fm Page 5 Friday, October 31, 2014 11:52 AM

- 6 -
Features
One DVI video console controls two USB computers
Fully DVI-Digital specification compliant
Computer selection via remote port selector, hotkeys, and
USB mouse
Audio-enabled – full bass response provides a rich
experience for 2.1 channel surround sound systems
Multiplatform support – Windows 2000 / XP / Vista / 7, Mac,
Sun, Linux
Compact design, built-in all-in-one cables (2 x 1.2 m)
Superior video quality – up to 1920 x 1200
Compatible with widescreen LCD monitors
Video DynaSync – exclusive ATEN technology which
eliminates boot-up display problems and optimizes resolution
when switching between ports
Power on detection – if either of the computers is powered
off, the CS682 will automatically switch to the other computer
Supports multimedia keyboards
Supports wireless keyboards and mice
Console mouse port emulation/bypass feature supports most
mouse drivers and multifunction mice
Mac/Sun keyboard support and emulation*
USB 2.0 mouse port can be used for USB hub and USB
peripheral sharing
HDCP Compliant
Non-Powered
Firmware upgradable
Note: 1. PC keyboard combinations emulate Mac/Sun
keyboards.
2. Mac/Sun keyboards work only with their own
computers.
cs682.fm Page 6 Friday, October 31, 2014 11:52 AM

- 7 -
3. To use the USB 2.0 mouse port as a USB hub, you
must first disable mouse emulation mode.
See Hotkey Summary Table, page 15 for
information.
System Requirements
Console
A DVI monitor capable of the highest resolution that you will
be using on any computer in the installation
A USB Keyboard and a USB Mouse
Speakers and microphone (optional)
Computers
Thefollowingequipmentmust beinstalledon each computer that
is to be connected to the system:
A DVI video port
USB Type A port
Speaker and microphone ports (optional)
Cables
The CS682’s innovative design features built-in KVM and audio
cables for extra convenience. No further cables are necessary.
cs682.fm Page 7 Friday, October 31, 2014 11:52 AM

- 8 -
Operating Systems
Supported operating systems are shown in the table, below:
OS Version
Windows 2000 / XP / Vista / 7
Linux RedHat 6.0 and higher
SuSE 8.2 and higher
Mandriva (Mandrake) 9.0 and higher
UNIX AIX 4.3 and higher
FreeBSD 3.51 and higher
Sun Solaris 9 and higher
Novell Netware 5.0 and higher
Mac OS 9 and higher
DOS 6.2 and higher
cs682.fm Page 8 Friday, October 31, 2014 11:52 AM

- 9 -
Components
CS682
Remote Port Selector
3
3
1
2
5
46
7
8
3
cs682.fm Page 9 Friday, October 31, 2014 11:52 AM

- 10 -
No. Component Description
1 Console Audio Ports Your console speakers and microphone
plug in here.
2 Console Monitor Port Your console DVI monitor plugs in here.
3 Port LEDs The Port LEDs indicate status.
The LED lights on to indicate that the
computer attached to the corresponding
port is selected and has the KVM focus.
The LED flashes to indicate that the
computer attached to its corresponding
port is being scanned by the Auto Scan
function.
The LED is off to indicate the port is not
selected.
4 KVM Cable The connectors on the built-in KVM
cables attach to the two computers in
your CS682 installation. See the diagram
on page 12 for further details.
5 Console Keyboard
Port Your console USB keyboard plugs in here.
6 Console Mouse Port Your console USB mouse plugs in here.
7 Remote Port Selector
Jack The Remote Port Selector plugs in here.
8PortSelection
Pushbutton Press the Port Selection Pushbutton to toggle the KVM and Audio focus
between the two computers.
cs682.fm Page 10 Friday, October 31, 2014 11:52 AM
