Atlantic Portland series User manual

ASSEMBLY INSTRUCTIONS
Before assembling your Headboard, please read through these
instructions carefully and familiarize yourself with the different parts.
PORTLAND HEADBOARD
Page 1 of 5
Portland Headboard & Bed
BACK VIEW
Adult Assembly
Step 1
Step 2
1
2
3
B
B
B
B
B
C
C
C
C
Instructions apply for all bed sizes
TWIN > FULL > QUEEN > KING
PARTS LIST HARDWARE
Split Washer - 4 pcs
Flat Washer - 4 pcs
JCB M6 X 25mm (1”) - 4 pcs
Spare - 1 pc
Spare - 1 pc
Spare - 1 pc
JCB M6 X 70mm (2 3/4”) - 4 pcs
Spare - 1 pc
B
A
C
D
G
F
E
H
HEADBOARD PANEL 1 PC
1
2
3
4
1 PC
1 PC
2 PCS
LEFT LEG
RIGHT LEG
SPACER BLOCK
Allen Wrench - 1pc
Spare - 1pc
ATTENTION! If you receive a damaged or defective item,
please contact Atlantic Furniture at [email protected] 1-800-955-3726 / M-F 9:00-5:00 EST
Barrel Nut - 4 pcs
Wooden Dowel - 6 pcs Wood Screw - 4 pcs
Spare - 1 pc
Spare - 2 pcs Spare - 1 pc
NOTE: WE INCLUDE SPARE HARDWARE IN CASE THE ALLEN WRENCH, JCB, BARREL NUT, WOODEN DOWEL, WOOD SCREW, SPLIT OR FLAT WASHER ARE DAMAGED DURING ASSEMBLY.
READY
ASSEMBLE
TO
Congratulations!
Your Portland Headboard is now ready to assembe.
To ensure lasting safety, we recommend that you periodically check
that all screws are tight and all parts are secure.
Insert wooden dowels (A) to the locator holes on (1) and (4). Attach the spacer
blocks (4) to the legs (2) and (3), using wood screws (D), as shown below.
Tighten with Phillips head screwdriver. (Customer Supplied)
Attach the legs (2) and (3) to the headboard panel (1),
using JCB (B) and barrel nut (C). Tighten with the
Allen wrench (H).
1
44
4
2
3
A
D
D
A
A

ASSEMBLY INSTRUCTIONS
Before assembling your Headboard, please read through these
instructions carefully and familiarize yourself with the different parts.
PORTLAND BED
READY
ASSEMBLE
TO
Instructions apply for all bed sizes
TWIN > FULL > QUEEN > KING
BED SHOWN WITH OPEN FOOTRAIL
BED SHOWN WITH FLAT PANEL FOOTBOARD BED SHOWN WITH MATCHING FOOTBOARD
Adult Assembly
Page 2 of 5
Portland Headboard & Bed

01
01
01
02
03
04
05
PARTS LIST
HARDWARE
HARDWARE
HARDWARE
HEADBOARD
FOOTBOARD
LONG RAILS
SLAT KIT
BOX 1
BOX 2
BOX 3
BOX 4
01
04
04
04
05
02
02
03
04
BED SHOWN WITH OPEN FOOTRAIL
Attach the long rails (04) to the headboard (02) using the bed hook as shown below.
Use the upper set of pins when
using only mattress, use the lower
set of pins if using both box spring
and mattress.
Step 1
Adult Assembly
Page 3 of 5
Portland Headboard & Bed

Step 2
Step 3
Attach the long rail assemblies (04) to the footboard (03) using bed hook as shown below.
04
04
03
Adult Assembly
BED SHOWN WITH OPEN FOOTRAIL
Lastly, lay slat kit (05) onto the bed. For slat kit assembly, follow the assembly instructions included
with slat kit.
Congratulations!
Your Portland bed is now ready for use.
Adult Assembly
Phillips head
screwdriver
Customer supplied
BED SHOWN WITH OPEN FOOTRAIL
PLATFORM BED - TALL HEIGHT TRADITIONAL BED - LOW HEIGHT
Page 4 of 5
05
To ensure lasting safety, we recommend that you periodically check
that all screws are tight and all parts are secure.
Portland Headboard & Bed
05

ASSEMBLY INSTRUCTIONS
Before assembling your Bed, please read through these
instructions carefully and familiarize yourself with the different parts.
PORTLAND HEADBOARD
Adult Assembly
PARTS LIST
01
02
HARDWARE
HEADBOARD
Step 1
Attach the headboard assembly (02) to the metal frame using JCB (E), flat washer (F),
and split washer (G) then tighten with Allen wrench, as shown below.
Congratulations!
JCB M6 X 1”
E
Allen Wrench M4
H
FLAT WASHER
SPLIT WASHER
F
G
02
01
E
E
G
G
F
F
Instructions apply for all bed sizes
Twin > Full > Queen > King
Page 5 of 5
attach to metal frame sold separately
Your Portland Bed is now ready for use.
To ensure lasting safety, we recommend that you periodically check
that all screws are tight and all parts are secure.
Portland Headboard & Bed
