Atlas Copco BCP BL-12-I06 Instruction sheet

BCP BL-12-I06
Printed Matter No. 9836 9624 01 Battery-Powered Screwdriver
Publication Date 2020-09-29
Valid from Serial No. A1420001
Valid to Serial No. A2729999 Product Instructions
BCP BL-12-I06
(5.0-12.0 Nm)
8431127330
WARNING
Read all safety warnings and instructions
Failure to follow the safety warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference

2© Atlas Copco Industrial Technique AB - 9836 9624 01
Table of Contents
Product information................................................................................................4
General information ..........................................................................................4
Safety signal words ...............................................................................4
Warranty ................................................................................................4
ServAid ..................................................................................................4
Website..................................................................................................5
Safety Data Sheets MSDS/SDS............................................................5
Country of origin ....................................................................................5
Dimensional drawings ...........................................................................5
Overview...........................................................................................................5
Technical data .......................................................................................5
Service overview...............................................................................................5
Service recommendations .....................................................................5
Service instructions ...............................................................................6
Operation .................................................................................................................7
Ergonomic guidelines .......................................................................................7
Operating instructions.......................................................................................7
Setting the tightening torque..................................................................7
Controlling the torque ............................................................................8
Adjusting the torque.............................................................................10
Setting tool speed................................................................................11
Speed setting unit during charging ......................................................11
Attaching and removing the battery pack ............................................12
Operating the tool ................................................................................12
Rehit protection ...................................................................................14
Changing screwdriver bits ...................................................................14
Buzzer .................................................................................................14
LED indications....................................................................................15
Battery power status............................................................................15
Low battery status ...............................................................................15
Charging the battery pack ...................................................................16
Standby behaviour (to serial no.A3482444) ........................................16
Standby behaviour (from serial no.A3482445) ....................................16
Service ...................................................................................................................17
Preventing ESD problems ..............................................................................17
Maintenance instructions ................................................................................17
Service recommendations ...................................................................17
Service instructions .............................................................................17
Preventive maintenance ......................................................................17
Electric circuit diagram ........................................................................18
Troubleshooting....................................................................................................19
Error codes .....................................................................................................19

3
© Atlas Copco Industrial Technique AB - 9836 9624 01
Recycling ...............................................................................................................20
Recycling instruction.......................................................................................20
Recycling information BCP .............................................................................20

Product information EN BCP BL-12-I06
4© Atlas Copco Industrial Technique AB - 9836 9624 01
Product information
General information
WARNING Risk of Property Damage or Severe Injury
Ensure that you read, understand and follow all instructions before operating the tool. Failure to follow
all the instructions may result in electric shock, fire, property damage and/or severe bodily injury.
►Read all Safety Information delivered together with the different parts of the system.
►Read all Product Instructions for installation, operation and maintenance of the different parts of
the system.
►Read all locally legislated safety regulations regarding the system and parts thereof.
►Save all Safety Information and instructions for future reference.
Safety signal words
The safety signal words Danger, Warning, Caution, and Notice have the following meanings:
DANGER DANGER indicates a hazardous situation which, if not avoided, will result in death or se-
rious injury.
WARNING WARNING indicates a hazardous situation which, if not avoided, could result in death or
serious injury.
CAUTION CAUTION, used with the safety alert symbol, indicates a hazardous situation which, if
not avoided, could result in minor or moderate injury.
NOTICE NOTICE is used to address practices not related to personal injury.
Warranty
■Product warranty will expire 12 months after the product is first taken into use, but will in any case ex-
pire at the latest 13 months after delivery.
■Normal wear and tear on parts is not included within the warranty.
■Normal wear and tear is that which requires a part change or other adjustment/overhaul during
standard tools maintenance typical for that period (expressed in time, operation hours or other-
wise).
■The product warranty relies on the correct use, maintenance, and repair of the tool and its component
parts.
■Damage to parts that occurs as a result of inadequate maintenance or performed by parties other
than Atlas Copco or their Certified Service Partners during the warranty period is not covered by the
warranty.
■To avoid damage or destruction of tool parts, service the tool according to the recommended mainte-
nance schedules and follow the correct instructions.
■Warranty repairs are only performed in Atlas Copco workshops or by Certified Service Partners.
Atlas Copco offers extended warranty and state of the art preventive maintenance through its ToolCover
contracts. For further information contact your local Service representative.
For electrical motors:
■Warranty will only apply when the electric motor has not been opened.
ServAid
ServAid is a portal that contains technical information for all hardware and software products such as:
- Safety Information including declarations, standards and directives
- Technical data

BCP BL-12-I06 EN Product information
© Atlas Copco Industrial Technique AB - 9836 9624 01 5
- Installation, Operation and Service Instructions
- Spare parts lists
- Accessories
ServAid is continuously updated and is available at:
https://servaid.atlascopco.com
For further information contact your local Atlas Copco representative.
Website
Log in to Atlas Copco: www.atlascopco.com.
You can find information concerning our products, accessories, spare parts and published matters on our
website.
Safety Data Sheets MSDS/SDS
The safety data sheets describes chemical products sold by Atlas Copco.
For more information, consult the website:
www.atlascopco.com
Choose Products - Safety Data Sheets, and follow the instructions on the page.
Country of origin
Please refer to the information on the product label.
Dimensional drawings
For information about the dimensions of a product, see the Dimensional drawings archive:
http://webbox.atlascopco.com/webbox/dimdrw
Overview
Technical data
Ordering No 8431127330
Model BCP BL-12-I06
Distance center to side mm
Speed range r/min
Lenght 200 mm (without battery)
Height 188
Torque range 5.0–12.0 Nm
Torque range 3.7–8.8 ft lb
Square drive 1/4 in
Weight 0.86 kg (without battery)
Weight 1.89 lb (without battery)
Service overview
Service recommendations
Preventive maintenance is recommended at regular intervals. See the detailed information on preventive
maintenance. If the product is not working properly, take it out of service and inspect it.
If no detailed information about preventive maintenance is included, follow these general guidelines:

Product information EN BCP BL-12-I06
6© Atlas Copco Industrial Technique AB - 9836 9624 01
■Clean appropriate parts accurately
■Replace any defective or worn parts
Service instructions
Overhaul and preventive maintenance is recommended at regular intervals once per year or after a maxi-
mum of 250.000 tightenings. More frequent overhaul may be needed if the tool is used at high torque or
with long tightening times. Take out the tool for inspection if it is not working correctly.
At overhaul, clean all parts accurately and replace defective or worn parts.
Lubricate gears and clutch with grease containing molybdenum disulphide, for example Molykote BR2
Plus, refer to the exploded views.
Lubricate o-rings and threaded connections with grease before assembling.
Make sure that all threaded connections on the tool are tightened correctly according to the specifications
on the exploded views.

BCP BL-12-I06 EN Operation
© Atlas Copco Industrial Technique AB - 9836 9624 01 7
Operation
Ergonomic guidelines
Consider your workstation as you read through this list of general ergonomic guidelines and see if you can
identify areas for improvement in posture, component placement, or work environment.
■Take frequent breaks and change work positions frequently.
■Adapt the workstation area to your needs and the work task.
■Adjust for convenient reach range by determining where parts or tools should be located to avoid
static load.
■Use workstation equipment such as tables and chairs appropriate for the work task.
■Avoid work positions above shoulder level or with static holding during assembly operations.
■When working above shoulder level, reduce the load on the static muscles by reducing the weight
of the tool, using for example torque arms, hose reels or weight balancers. You can also reduce
the load on the static muscles by holding the tool close to the body.
■Make sure to take frequent breaks.
■Avoid extreme arm or wrist postures, particularly for operations requiring a degree of force.
■Adjust for convenient field of vision by minimizing movement of the eyes and head during the work
task.
■Use the appropriate lighting for the work task.
■Select the appropriate tool for the work task.
■Use ear protection equipment in noisy environments.
■Use high-quality inserted tools or consumables to minimize exposure to excessive levels of vibration.
■Minimize exposure to reaction forces.
■When cutting:
A cut-off wheel can get stuck if the wheel is either bent or if it is not guided properly. Make sure to
use the correct flanges for cut-off wheels and avoid bending the wheel during cut-off operation.
■When drilling:
The drill might stall when the drill bit breaks through. Makes sure you use support handles if the
stall torque is too high. The safety standard ISO11148 part 3 recommends using something to ab-
sorb the reaction torque above 10 Nm for pistol grip tools and 4 Nm for straight tools.
■When using direct-driven screw or nutrunners:
Reaction forces depend on tool setting and joint characteristics. The ability to bear reaction forces
depends on the operator’s strength and posture. Adapt the torque setting to the operator's strength
and posture and use a torque arm or reaction bar if the torque is too high.
■Use dust extraction system or mouth protection mask in dusty environments.
Operating instructions
Setting the tightening torque
For a safe and accurate operation, set the tightening torque of the screwdriver in relation to the screw
joint.
Ref. No. Ordering No. Torque rate Nm / rev. Torque range Nm
3 4145 0958 80 10 0.5 – 0.5
3 4145 0958 81 25 1.5 – 3.0
3 4145 0958 82 45 3.0 – 6.0
3 4145 0958 83 80 6.0 – 9.0

Operation EN BCP BL-12-I06
8© Atlas Copco Industrial Technique AB - 9836 9624 01
Ref. No. Ordering No. Torque rate Nm / rev. Torque range Nm
3 4145 0958 84 130 9.0 – 25.0
Test joint - Hard joints
Ref. No. Ordering No. Torque rate Nm / rev. Torque range Nm
3 4145 0959 80 0.7 0.6 – 2.0
3 4145 0959 81 1.5 1.5 – 4.0
3 4145 0959 82 3.0 3.0 – 7.0
3 4145 0959 83 5.5 5.5 – 10.0
3 4145 0959 84 10.0 10.0 – 25.0
Test joints - Soft joints
Controlling the torque
Atlas Copco’s Torque Analyser, ACTA 4000, plus an correctly-sized in-line rotary transducer, such as
IRTT, are suitable instruments for controlling the torque.

BCP BL-12-I06 EN Operation
© Atlas Copco Industrial Technique AB - 9836 9624 01 9
Ref. No. Ordering No. Qty Description
Remark / Included
in Service kit
1 1 Torque testing read-
out instrument
(Type: ACTA 3000 /
FOCUS 2000) See
our main catalogue
or separate leaflet

Operation EN BCP BL-12-I06
10 © Atlas Copco Industrial Technique AB - 9836 9624 01
Ref. No. Ordering No. Qty Description
Remark / Included
in Service kit
2 8092112905 1 Torque transducer (Type: IRTT 5-I06)
See our main cata-
logue or separate
leaflet
2 8092112910 1 Torque transducer (Type: IRTT20-I06)
See our main cata-
logue or separate
leaflet
8092113320 1 ACTA 3000 B
8092113330 1 ACTA 3000 QC
8092113340 1 ACTA 3000 AA
Adjusting the torque
The tightening torque is adjusted by changing the tension of the clutch spring with the key and the adjust-
ment disc (clutch adjusting kit).
Start at a low torque setting to prevent screw joint damage. If the torque is set too high, there will be no
click-sound from the clutch, the green LED will not lit and the motor will be turned off.
Do not adjust the torque over the recommended maximum value as it will result in incorrect function
and faster wear.
1. Put the key in the hole at the front part of the tool.
2. Turn the key clockwise to increase the tightening torque.
3. Finish the adjustment at a holding position, located each 1.5 turns of the key.

BCP BL-12-I06 EN Operation
© Atlas Copco Industrial Technique AB - 9836 9624 01 11
Setting tool speed
1. Set the tool speed with + or - button.
2. Confirm the speed with the enter button.
3. The LED flashes yellow once when the new speed is confirmed.
RANGE Min rpm Max rpm
BCP BL2-I06 (0.8 - 2.5) 500 1550
BCP BL6-I06 (2 - 6) 300 1000
BCP BL8-I06 (3 - 8) 300 800
BCP BL12-I06 (5 - 12) 250 600
BCP BL2-L-I06 (0.8 - 2.5) 150 440
BCP BL6-L-I06 (1.5 - 6) 150 440
BCP BL12-L-I06 (3 - 12) 150 440
Speed setting unit during charging
The display light on the speed setting unit flashes when it is put in the charger.
1 Green LED:
■The green LED flashes: The battery pack charges.
■The green LED is steady lit: The battery is fully charged.
2 Red LED:

Operation EN BCP BL-12-I06
12 © Atlas Copco Industrial Technique AB - 9836 9624 01
■The red LED flashes: Contact problems; the battery pack is defective.
■The red LED is steady lit: The temperature is too high/low.
Attaching and removing the battery pack
Attach the battery pack to the tool and make sure that it is fastened correctly. The battery pack can be at-
tached pointing forward or backward to get the best accessibility and balance. To remove the battery
pack, push the button on the battery and push it out.
Since a battery pack slowly discharge itself, keep the battery pack in the charging unit that provides a
trickle charge.
Operating the tool
1. Make sure that the switch (CW/CCW) is in the clockwise position.
Release the trigger to change the switch.

BCP BL-12-I06 EN Operation
© Atlas Copco Industrial Technique AB - 9836 9624 01 13
2. Push the trigger to start the tool.
3. Run the tool until the preset torque is reached and the clutch is released.
4. A click sound is heard, the LED is green and the motor is turned off.
The LED on the tool notify the tightening status after each tightening. There is no notification if the tool is
run in counterclockwise mode.

Operation EN BCP BL-12-I06
14 © Atlas Copco Industrial Technique AB - 9836 9624 01
Rehit protection
Changing screwdriver bits
Buzzer
1. To enable the buzzer function, push and keep the trigger half way.
2. After 10 seconds the LED flashes orange and the buzzer function is activated.
3. To disable the buzzer function, repeat the same procedure.

BCP BL-12-I06 EN Operation
© Atlas Copco Industrial Technique AB - 9836 9624 01 15
LED indications
Indication Status
No colour, not lit Screwdriver direction is clockwise.
Green/Red flashing Screwdriver direction is counterclockwise.
Green Tightening OK, tool is turned off by the clutch.
Yellow Battery energy is not sufficient, motor turned off.
Battery power status
A temperature above 50°C reduces the battery perfomance. Do not expose the battery to heat or
sunshine.
Low battery status

Operation EN BCP BL-12-I06
16 © Atlas Copco Industrial Technique AB - 9836 9624 01
Charging the battery pack
Use only an Atlas Copco battery charger (see optional accessories). Refer to the separate instruc-
tions delivered with the charger.
Fully charge a new or a long time unused battery pack before using your battery tool. Full loading capacity
of a battery pack is reached after 4-5 charges.
Keep battery and charger contacts clean.
It the tool will not be used for 100 hours or longer, remove the battery pack from the tool. Otherwise the
electronics will discharge the battery.
Standby behaviour (to serial no.A3482444)
To save battery power the tool will switch automatically to a standby mode when it is not used. All LEDs
are off in standby mode.
Push the trigger to wake up the tool. The tool starts immediately and runs in a clockwise direction even if it
is set to counterclockwise.
Push the trigger a second time to run the tool in the set direction.
Standby behaviour (from serial no.A3482445)
To save battery power the tool will switch automatically to a standby mode when it is not used. All LEDs
are off in standby mode.
Push the trigger to wake up the tool. Push the trigger a second time to run the tool.
Make sure that the tool is set to the wanted direction.

BCP BL-12-I06 EN Service
© Atlas Copco Industrial Technique AB - 9836 9624 01 17
Service
Preventing ESD problems
The components inside the tool and controller are sensitive to electrostatic discharge. To avoid future mal-
function, make sure that service and maintenance is carried out in an ESD approved work environment.
The figure below shows an example of an appropriate service work station.
Maintenance instructions
Service recommendations
Preventive maintenance is recommended at regular intervals. See the detailed information on preventive
maintenance. If the product is not working properly, take it out of service and inspect it.
If no detailed information about preventive maintenance is included, follow these general guidelines:
■Clean appropriate parts accurately
■Replace any defective or worn parts
Service instructions
Overhaul and preventive maintenance is recommended at regular intervals once per year or after a maxi-
mum of 250.000 tightenings. More frequent overhaul may be needed if the tool is used at high torque or
with long tightening times. Take out the tool for inspection if it is not working correctly.
At overhaul, clean all parts accurately and replace defective or worn parts.
Lubricate gears and clutch with grease containing molybdenum disulphide, for example Molykote BR2
Plus, refer to the exploded views.
Lubricate o-rings and threaded connections with grease before assembling.
Make sure that all threaded connections on the tool are tightened correctly according to the specifications
on the exploded views.
Preventive maintenance
Maximize battery life
In order to maximize battery life, do not leave the battery connected to the tool you do not use it for sev-
eral days. The battery can discharge and go into “sleep mode” which will require a special wake-up charge
procedure. For further information, see instructions for multicharger, 4211542485.

Service EN BCP BL-12-I06
18 © Atlas Copco Industrial Technique AB - 9836 9624 01
Electric circuit diagram

BCP BL-12-I06 EN Troubleshooting
© Atlas Copco Industrial Technique AB - 9836 9624 01 19
Troubleshooting
Error codes
LED
Indications
3 red flashes followed by 2 yellow flashes
Clutch sensor error. The tool does not start or stops correctly.
The signal given by the clutch sensor is out of tolerances. Do a check of the sensor and the
magnets for the sensor. Make sure that the flex is connected correctly to the electronic board.
If the fault still appears, contact customer service.
3 red flashes followed by 3 yellow flashes
The temperature is over the maximum limit of 70°C. The tool does not start or stops correctly.
The temperature measured with the electronic board is higher than 70°C. Wait for the tool to
cool down. When the temperature is lower than 70°C it is possible to operate the tool again.
Decrease the tool rate. If the temperature is lower than 70°C and the fault still appears, con-
tact customer service
3 red flashes followed by 4 yellow flashes
Overheated tool. Too high current over too long time. The tool does not start or stops cor-
rectly.
The power requested is too big. If the fault still appears, contact customer service.
3 red flashes followed by 5 yellow flashes
Battery voltage fault. The tool does not start or stops correctly.
The battery voltage is not correct for the tool. Make sure that the correct battery is used. If the
battery used is correct and the fault still appears, contact customer service.
3 red flashes followed by 6 yellow flashes
Overcurrent on the power circuit. The hardware limit is reached. The tool does not start or
stops correctly.
If the fault still appears, the power stage is faulty, contact customer service

Recycling EN BCP BL-12-I06
20 © Atlas Copco Industrial Technique AB - 9836 9624 01
Recycling
Recycling instruction
When a product has served its purpose it has to be recycled properly. Dismantle the product and recycle
the components in accordance with local legislation.
Batteries shall be taken care of by your national battery recovery organization.
Recycling information BCP
Pos. Part Remarks Recycle as
1 Clutch housing Metal, aluminum
2 Clutch Metal, steel
3 Gear Metal, steel
4 Plastic housing Plastics, other, PA
5 Motor Electronic
6 Window kit Electronic
7 Plastic housing Plastics, other, PA
8 Li-Ion battery Electronic
9 Trigger Plastics, other, PA
10 Circuit board Electronic
11 Battery connector Plastics, other, PA
