Atlas Copco RRH 10P-TS Instruction sheet

RRH 10P-TS
Printed Matter No. 9836 9756 01 Riveting Hammer
Publication Date 2021-09-09
Valid from Serial No. A5400001 Product Instructions
RRH10P TS 8426111070
WARNING
Read all safety warnings and instructions
Failure to follow the safety warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference

2© Atlas Copco Industrial Technique AB - 9836 9756 01
Table of Contents
Product information................................................................................................3
General information ..........................................................................................3
Safety signal words ...............................................................................3
Warranty ................................................................................................3
ServAid ..................................................................................................3
Website..................................................................................................4
Safety Data Sheets MSDS/SDS............................................................4
Country of origin ....................................................................................4
Dimensional drawings ...........................................................................4
Service overview...............................................................................................4
Service recommendations .....................................................................4
Overhaul ................................................................................................4
Installation ...............................................................................................................5
Installation requirements...................................................................................5
Air quality...............................................................................................5
Air lubrication guide ...............................................................................5
Compressed air connection...................................................................5
Installation instructions .....................................................................................5
Installation of vibrating tools ..................................................................5
Operation .................................................................................................................6
Ergonomic guidelines .......................................................................................6
Operating instructions.......................................................................................6
Operating the tool ..................................................................................6
Trigger control .......................................................................................6
Service .....................................................................................................................7
Maintenance instructions ..................................................................................7
Service recommendations .....................................................................7
Preventive maintenance ........................................................................7
Lubrication instructions .....................................................................................7
Lubrication guide ...................................................................................7
Lubrication .............................................................................................7
Recycling .................................................................................................................8
Recycling instruction.........................................................................................8

RRH 10P-TS EN Product information
© Atlas Copco Industrial Technique AB - 9836 9756 01 3
Product information
General information
WARNING Risk of Property Damage or Severe Injury
Ensure that you read, understand and follow all instructions before operating the tool. Failure to follow
all the instructions may result in electric shock, fire, property damage and/or severe bodily injury.
►Read all Safety Information delivered together with the different parts of the system.
►Read all Product Instructions for installation, operation and maintenance of the different parts of
the system.
►Read all locally legislated safety regulations regarding the system and parts thereof.
►Save all Safety Information and instructions for future reference.
Safety signal words
The safety signal words Danger, Warning, Caution, and Notice have the following meanings:
DANGER DANGER indicates a hazardous situation which, if not avoided, will result in death or se-
rious injury.
WARNING WARNING indicates a hazardous situation which, if not avoided, could result in death or
serious injury.
CAUTION CAUTION, used with the safety alert symbol, indicates a hazardous situation which, if
not avoided, could result in minor or moderate injury.
NOTICE NOTICE is used to address practices not related to personal injury.
Warranty
■Product warranty will expire 12 months after the product is first taken into use, but will in any case ex-
pire at the latest 13 months after delivery.
■Normal wear and tear on parts is not included within the warranty.
■Normal wear and tear is that which requires a part change or other adjustment/overhaul during
standard tools maintenance typical for that period (expressed in time, operation hours or other-
wise).
■The product warranty relies on the correct use, maintenance, and repair of the tool and its component
parts.
■Damage to parts that occurs as a result of inadequate maintenance or performed by parties other
than Atlas Copco or their Certified Service Partners during the warranty period is not covered by the
warranty.
■To avoid damage or destruction of tool parts, service the tool according to the recommended mainte-
nance schedules and follow the correct instructions.
■Warranty repairs are only performed in Atlas Copco workshops or by Certified Service Partners.
Atlas Copco offers extended warranty and state of the art preventive maintenance through its ToolCover
contracts. For further information contact your local Service representative.
For electrical motors:
■Warranty will only apply when the electric motor has not been opened.
ServAid
ServAid is a portal that contains the most up-to-date product information such as:
- Safety Information
- Installation, Operation and Service Instructions

Product information EN RRH 10P-TS
4© Atlas Copco Industrial Technique AB - 9836 9756 01
- Exploded views
It is also possible to order spare parts, service tools and accessories for the product of your choice directly
from ServAid. It is continuously updated with information about new and redesigned products.
If translations exist, you can view content in the language of your choice. ServAid offers advanced search
functionality of our entire product range and can also be used to display information about obsolete prod-
ucts.
ServAid is available on DVD and on the website:
https://servaid.atlascopco.com
For further information contact your Atlas Copco sales representative or e-mail us at:
[email protected]
Website
Log in to Atlas Copco: www.atlascopco.com.
You can find information concerning our products, accessories, spare parts and published matters on our
website.
Safety Data Sheets MSDS/SDS
The safety data sheets describes chemical products sold by Atlas Copco.
For more information, consult the website:
www.atlascopco.com
Choose Products - Safety Data Sheets, and follow the instructions on the page.
Country of origin
Please refer to the information on the product label.
Dimensional drawings
For information about the dimensions of a product, see the Dimensional drawings archive:
http://webbox.atlascopco.com/webbox/dimdrw
Service overview
Service recommendations
Preventive maintenance is recommended at regular intervals. See the detailed information on preventive
maintenance. If the product is not working properly, take it out of service and inspect it.
If no detailed information about preventive maintenance is included, follow these general guidelines:
■Clean appropriate parts accurately
■Replace any defective or worn parts
Overhaul
If the riveting hammer is used every day, it should be overhauled and cleaned once every six months.
The filter behind the adapter should be cleaned frequently to prevent choking with resultant decrease in
capacity.

RRH 10P-TS EN Installation
© Atlas Copco Industrial Technique AB - 9836 9756 01 5
Installation
Installation requirements
Air quality
■For optimum performance and maximum product life we recommend the use of compressed air with
a maximum dew point of +10°C (50°F). We also recommend to install an Atlas Copco refrigeration
type air dryer.
■Use a separate air filter which removes solid particles larger than 30 microns and more than 90% of
liquid water. Install the filter as close as possible to the product and prior to any other air preparation
units to avoid pressure drop.
For impulse/impact tools make sure to use lubricators adjusted for these tools. Regular lubricators
will add too much oil and therefore decrease the tool performance due to too much oil in the mo-
tor.
Make sure that the hose and couplings are clean and free from dust before connecting to the tool.
Both lubricated and lubrication free products will benefit from a small quantity of oil supplied from a lu-
bricator.
Air lubrication guide
Brand Air lubrication
Atlas Copco Optimizer (1 liter) 9090 0000 04
Q8 Chopin 46
Shell Shell Air Tool Oil S2 A 320
Compressed air connection
WARNING Compressed air can cause serious injury
►Always shut off the air supply, drain hose of air pressure and disconnect the tool from air supply;
when not in use, before making any adjustments to the product - for example changing acces-
sories, or when making repairs.
WARNING Whipping hoses can cause serious injury
►Always make sure that there are no damaged or loose hoses or fittings.
WARNING Compressed Air
High air pressure can cause severe damage and bodily injury.
►Do not exceed maximum air pressure.
►Make sure that there are no damaged or loose hoses or fittings.
For correct air pressure and hose size, see section Technical data.
Make sure that the hose and couplings are clean and free from dust before connecting to the tool.
Installation instructions
Installation of vibrating tools
We recommend using a minimum length of 300 mm (12") of flexible hose for compressed air between a vi-
brating tool and the quick-action coupling.

Operation EN RRH 10P-TS
6© Atlas Copco Industrial Technique AB - 9836 9756 01
Operation
Ergonomic guidelines
Consider your workstation as you read through this list of general ergonomic guidelines and see if you can
identify areas for improvement in posture, component placement, or work environment.
■Take frequent breaks and change work positions frequently.
■Adapt the workstation area to your needs and the work task.
■Adjust for convenient reach range by determining where parts or tools should be located to avoid
static load.
■Use workstation equipment such as tables and chairs appropriate for the work task.
■Avoid work positions above shoulder level or with static holding during assembly operations.
■When working above shoulder level, reduce the load on the static muscles by reducing the weight
of the tool, using for example torque arms, hose reels or weight balancers. You can also reduce
the load on the static muscles by holding the tool close to the body.
■Make sure to take frequent breaks.
■Avoid extreme arm or wrist postures, particularly for operations requiring a degree of force.
■Adjust for convenient field of vision by minimizing movement of the eyes and head during the work
task.
■Use the appropriate lighting for the work task.
■Select the appropriate tool for the work task.
■Use ear protection equipment in noisy environments.
■Use high-quality inserted tools or consumables to minimize exposure to excessive levels of vibration.
■Minimize exposure to reaction forces.
■When cutting:
A cut-off wheel can get stuck if the wheel is either bent or if it is not guided properly. Make sure to
use the correct flanges for cut-off wheels and avoid bending the wheel during cut-off operation.
■When drilling:
The drill might stall when the drill bit breaks through. Makes sure you use support handles if the
stall torque is too high. The safety standard ISO11148 part 3 recommends using something to ab-
sorb the reaction torque above 10 Nm for pistol grip tools and 4 Nm for straight tools.
■When using direct-driven screw or nutrunners:
Reaction forces depend on tool setting and joint characteristics. The ability to bear reaction forces
depends on the operator’s strength and posture. Adapt the torque setting to the operator's strength
and posture and use a torque arm or reaction bar if the torque is too high.
■Use dust extraction system or mouth protection mask in dusty environments.
Operating instructions
Operating the tool
A trigger start (TS) riveting hammer always starts when the trigger is pushed whether a forward feed force
is applied or not.
It is recommended to use a hand guard on the tool to prevent vibration injuries.
Trigger control
The trigger valve is designed to allow different impact energies and impact frequencies. The impact en-
ergy and frequency can be steplessly controlled by pushing the trigger to different positions.

RRH 10P-TS EN Service
© Atlas Copco Industrial Technique AB - 9836 9756 01 7
Service
Maintenance instructions
Service recommendations
Preventive maintenance is recommended at regular intervals. See the detailed information on preventive
maintenance. If the product is not working properly, take it out of service and inspect it.
If no detailed information about preventive maintenance is included, follow these general guidelines:
■Clean appropriate parts accurately
■Replace any defective or worn parts
Preventive maintenance
Overhaul
If the riveting hammer is used every day, it should be overhauled and cleaned once every six months.
The filter behind the adapter should be cleaned frequently to prevent choking with resultant decrease in
capacity.
Lubrication instructions
Lubrication guide
Brand General purpose, Bearings and Gears*
BP Energrease LS-EP2
Castrol OBEEn UF 1
Esso Beacon EP2
Q8 Rembrandt EP2
Mobil Mobilegrease XHP 222 NLG 2
Klüber Lub. Klübersynth UH 1 14-151
Texaco Multifak EP2
Molykote BR2 Plus
* Not for angle gears.
Brand Angle gears
Molykote Longterm 2 Plus
Lubrication
When the riveting hammer is in use, it should be oiled once per shift. The oil (fluid type), which should be
applied in an amount of 1 cm³, can be dropped into the air hose. When the machine is in continuous ser-
vice, installation of an Atlas Copco oil-fog lubricator is recommended.
An excessive amount of oil will prevent the main valve from functioning. It is therefore vitally important
to lubricate in strict accordance with the recommendations.
Use lubricants of good quality. The oils and grease delivered by the oil companies mentioned in the table
are examples of lubricants which are recommended.

Recycling EN RRH 10P-TS
8© Atlas Copco Industrial Technique AB - 9836 9756 01
Recycling
Recycling instruction
When a product has served its purpose it has to be recycled properly. Dismantle the product and recycle
the components in accordance with local legislation.
Batteries shall be taken care of by your national battery recovery organization.

Original instructions
Atlas Copco Industrial
Technique AB
SE-10523 STOCKHOLM
Sweden
Telephone: [phone]
www.atlascopco.com
© Copyright 2021, Atlas Copco Industrial Technique AB. All rights reserved.
Any unauthorized use or copying of the contents or part thereof is prohibited.
This applies in particular to trademarks, model denominations, part numbers
and drawings. Use only authorized parts. Any damage or malfunction caused
by the use of unauthorized parts is not covered by Warranty or Product
Liability.
Out of respect to wildlife and nature, our technical literature is printed on
environmentally friendly paper.
