Atmel FingerChip FCDEMO4 Installation and operating instructions

1
FingerChip™Demonstrator FCDEMO4 USB/EPP
Description
Congratulations for choosing FingerChip™technology!
FingerChip™is the best choice for fingerprint capture. No other technology offers such
a small device with superior capture capabilities at such a low cost.
With the USB or parallel reader FCDEMO4, the user will be able to:
• Capture a fingerprint image.
• Evaluate the characteristics of FingerChip™technology using the AT77C101B
device (500 dpi sensor, 8-bit digital output).
This document describes how to install the device, and provides all electrical and
mechanical schematics. If you have the electronic version of the present document,
you will need the associated CAD files in order to get all the details.
Requirements
• USB Version FCSWEEP05: one PC running Windows 98®/Windows 2000®with
one USB v1.1 compliant port. Note that Windows 2000®is supported from release
V12.00 or later of the accompanying software.
• EPP Version FCSWEEP04: one PC running Windows 95®or later with one EPP
(Enhanced Parallel Port) + PS2 port (used only for power supply). Windows 2000®
is not supported.
Biometrics
FingerChip™
ApplicationNote
Rev. 2176A–BIOM–10/02

2FCDEMO4
2176A–BIOM–10/02
Main Features • Plug and Play
• FingerChip™Thermal CMOS Sensor AT77C101B
• Image Zone: 0.4 x 14 mm = 0.02” x 0.55”
• Image Array: 8 x 280 = 2240 Pixels
• Pixel Pitch: 50 µm x 50 µm (~500 dpi)
• Low Power Consumption
• Operating Temperature Range: 0°C to +70°C
• ESD Resistant
• No Latent Prints
Applications • Fingerprint Acquisition and Authentication
• OS Login, Screen Saver
• Password Replacement
• File/disk/e-mail Encryption
• E-commerce
• Pointing Device
Contents • Installation
• Software Description
• Hardware Description

3
FCDEMO4
2176A–BIOM–10/02
Software
Installation The user will either need the accompanying CDROM, which contains all the programs and
documentation, or the zip file downloaded from our web site or received by email. In the latter
case, not all the files are included in order to reduce the size of the zip file for easier
downloading.
Windows 98 USB Important remark: the USB version of the FCDEMO4 device uses the same schematics and
USB interface chip as the Sweepee Genesys device. It also uses the same software.
• Insert the Sweepee Installation CDROM first: this will install the driver (if the user plugs
the device in first, Windows will ask for the driver: in this case, you can find the driver in the
“driver” directory of the CDROM).
• Run the setup program and follow the accompanying instructions (see the installation
document on the CDROM). If asked, choose Sweepee Genesys in the list.
• Plug the FCdemo into a USB socket of the computer.
• The activity LED will light up and the USB P&P String is displayed: Windows loads the
driver.
Windows 98 EPP • Plug the FCdemo into the parallel and PS2 sockets of your computer.
• Insert the Sweepee Installation CDROM.
• Choose EPP.
Once the installation program is finished, the user can run one of the imaging programs to
check out the device.
Uninstalling Please follow the instructions described in the installation document on the CDROM.
Software
Description
Only the acquisition and reconstruction software is provided. Atmel does not directly provide
authentication software. Please contact Atmel to get authentication software from one of our
FingerChip™Partners.
Imaging software has been installed during the installation procedure. Please read the accom-
panying document that describes the software included on the CDROM.
Hardware Parameters: there is no specific need to adjust the hardware parameters since the
default parameters are usually OK. Refer to the documentation to adjust the parameters if
needed.

4FCDEMO4
2176A–BIOM–10/02
Hardware Note that both the USB and EPP versions use the same printed circuit board and packaging.
Only the connector and the bill of materials differ.
CAD Files If the user gets the electronic version of this document accompanied by CAD files, he will be
able to get detailed information on the mechanical and board specifications.
The user needs Cadstar or Cadstar Design Viewer to see the electrical schematic and printed
circuit board files. This viewer is free and can be downloaded from Cadstar’s web site:
http://www.cadstarworld.com.
The user either needs Autocad, Solidworks or Solidworks viewer to see the mechanical files.
This viewer is free and can be downloaded from Solidworks’ web site:
http://www.solidworks.com.
Printed Circuit
Board
Click here to see electronic version.
Figure 1. Printed Circuit Board
5.50
3.25 20.50
27.00
5.50 23.00
34.00
17.00 2.50
LED
J2
J3
J4
J5
J6
J7
J8
J9
J10
J11
J12
J13
J14
J15
Blanc/Orange
Blanc
Noir/Rouge
Blanc/Rouge
Noir
Gris clair
Rouge
Vert foncØ
Orange
Vert clair
Rose
Bleu
Jaune
Gris foncØ
+ 5V
Tresse masse GND
DB 25 - 17
DB 25 - 16
DB 25 - 14
DB 25 - 11
DB 25 - 2
DB 25 - 6
DB 25 - 3
DB 25 - 7
DB 25 - 4
DB 25 - 8
DB 25 - 5
DB 25 - 9
C1
J1
RR1
RR2
RR3
C3
C8
C7
R6
C9
C6
U2
D2
R3
T1
R1
C4
L1
J16
J17
J18
J19
J20
USB - 1
USB - 2
USB - 3
USB - 4
USB - 5
R4
R5
C10
C2 R7
C5
Q1
C11

5
FCDEMO4
2176A–BIOM–10/02
Electrical
Schematics
Click here to see the electronic version.
Figure 2. Electrical Schematics

6FCDEMO4
2176A–BIOM–10/02
Mechanical
Schematics
Note that the most difficult point for the plastic design is located near the FingerChip™. The
user must ensure that the finger will touch the FingerChip™: avoid having the silicon part in a
“hole;” it is better to have the FingerChip™a little bit ABOVE the plastic than the reverse. If not,
the skin will not touch the sensor, and the image acquisition will be degraded or impossible.
The thickness of the silicon is 800 microns. The thickness of the plastic piece that comes close
to the silicon is 500 microns, and its shape is not “square”.
Figure 3. Mechanical Schematic

7
FCDEMO4
2176A–BIOM–10/02
Click here to see the cover part of the case with Autocad.
Click here to see the cover part of the case with Solidworks.
Figure 4. Mechanical Schematic
Click here to see the bottom part of the case with Autocad.
Click here to see the bottom part of the case with Solidworks.
Click here to see the brace with Autocad.
Click here to see the brace with Solidworks.
Click here to see the wire with Autocad.
Click here to see the wire with Solidworks.
20.50
5.50
30
18.95
6.70 9.40
3.92
3.60
1.70
1.20
0.50
4.40
1
CC
C-C
34
14
A-A B-B
F
F (4:1)
R39
10.76
15.80
16
5.30 6.30
AB
38
23
14 0.401.40
0.40 1.40
1.10
2.85
AB
50°

8FCDEMO4
2176A–BIOM–10/02
Part List
Note: 1. Not required for EPP version.
Elastomer Connector
Specification
Silver zebra L = 20 mm, H = 1 mm, W = 1 mm
Compression rate = 20%
PN 05-10225
Table 1. Part List
Reference Designation Package Manufacturer Note 1
C1, C5 Ceramic capacitor 10 µF 10V X7R 1206 MURATA
C10, C11 Ceramic capacitor 47 pF 50V NPO 0603 – C10, C11
C2, C6, C7, C8 Ceramic capacitor 47 nF 16V X7R 0603 – C6, C7, C8
C3 Ceramic capacitor 1 nF 50V X7R 0603 –
C4, C9 Ceramic capacitor 1 µF 16V Y5V 0805 MURATA C9
D2 Red reverse led LST770 PLCC 2 SIEMENS
L1, L2 Inductor BLM11A 121S 0603 – L1
Q1 Ceramic resonator 12 MHz CSTCS – MURATA Q1
R1 Resistor 10R 1206 –
R3 Resistor 680R 0603 –
R4, R5 Resistor 22R 0603 – R4, R5
R6 Resistor 1K5R 0603 – R6
R7 Resistor 300K 0805 – R7
RR1, RR2, RR3 BCN16 4A 4 x 220R resistors network 1206 –
T1 2N7002 MOS transistor SOT23 –
U2 GL640USB-A parallel/USB interface LQFP 48 GENESYS U2
1 Fingerchip COB ATMEL
1 Elastomer connector – FUJIPOLY®
1 Bottom of the case – –
1 Cover of the case – –
1 Wire clip – –
6Screw ––
4Brace ––
1Holder ––
1 USB or DB25 + PS2 wire – –
