Atmel WINC1500 User manual

Platform Getting Started Guide
Getting Started Guide for WINC1500 Wi-Fi
using SAM D21 Xplained Pro
XX-XXX
Prerequisites
Hardware Prerequisites
Atmel SAM D21 Xplained Pro Evaluation Kit
Atmel WINC1500 extension
Atmel IO1 extension
USB micro cable (TypeA / MicroB)
Software Prerequisites
Atmel Studio
Weather client example project source code
Introduction
This getting started guide describes the Atmel WINC1500 Wi-Fi Network Controller to
build state-of-the-art Internet of Things (IoT) applications. This guide explains
hardware information and how to install Atmel Studio(IDE), compile examples and
download WINC1500 Firmware.
The following topics will be covered:
How to get Atmel Studio(IDE) and install it.
Update new ASF package.
Target board information.
How to get weather client example project.
How to get log message.
How to download firmware and certificate.
XXXXA10/14

Getting Started Guide for WINC1500 Wi-Fi
using SAM D21 Xplained Pro: XXXXA10/145
Page 2 of 28
Table of Contents
Prerequisites.....................................................................................1
Introduction.......................................................................................1
Icon Key Identifiers...........................................................................3
1. Getting Started with Atmel Studio ..............................................4
1.1 Download and Install Atmel Studio6.2.................................................4
1.2 Download and Install the latest ASF....................................................4
1.3 Download and Install the latest WINC1500 Extension Package.........6
2. Getting Started with Atmel Hardware.........................................8
2.1 Atmel SMART SAMD21-XPRO Evaluation Kit....................................8
2.2 Atmel SmartConnect WINC1500-XPRO Wi-Fi Extension Board.........9
2.3 Atmel IO1-XPRO Sensor Extension Board........................................10
2.4 Atmel OLED1-XPRO Display Extension Board.................................10
3. Getting Started with WINC1500 IoT Examples ........................12
3.1 Organization of WINC1500 IoT Examples.........................................12
3.2 Connect the Board.............................................................................13
3.3 How to Get Weather Client Example Project.....................................14
3.4 How to Build & Execute .....................................................................16
3.5 Provisioning .......................................................................................18
4. How to Debug WINC1500 Wi-Fi Firmware...............................21
5. How to Download New WINC1500 Firmware ..........................22
5.1 Download Firmware...........................................................................22
5.2 Download Certificate File...................................................................25
6. Conclusion...............................................................................26
7. Revision History.......................................................................27

Getting Started Guide for WINC1500 Wi-Fi
using SAM D21 Xplained Pro: XXXXA10/145
Page 3 of 28
Icon Key Identifiers
Delivers Contextual Information About a Specific Topic
Highlights Useful Tips and Techniques
Highlights Objectives to be Completed
Highlights the Expected Result of an Assignment Step
Indicates Important Information
Highlights Actions to be Executed Out of the Target

Getting Started Guide for WINC1500 Wi-Fi
using SAM D21 Xplained Pro: XXXXA10/145
Page 4 of 28
1. Getting Started with Atmel Studio
1.1 Download and Install Atmel Studio6.2
Atmel® Studio 6 is the integrated development platform (IDP) for developing and debugging Atmel ARM®
Cortex® -M and Atmel AVR® microcontroller (MCU) based applications. The Atmel Studio 6 IDP gives you a
seamless and easy-to-use environment to write, build and debug your applications written in C/C++ or
assembly code.
Atmel Studio 6.2 is now available, adding advanced debugging features such as Data and Interrupt Trace,
improved RTOS integration, and better ability to debug code that has been optimized.
With the introduction of Atmel Gallery and Atmel Spaces, Atmel Studio 6 further simplifies embedded MCU
designs to reduce development time and cost. Atmel Gallery is an online apps store for development tools
and embedded software. Atmel Spaces is a cloud-based collaborative development workspace allowing you
to host software and hardware projects targeting Atmel MCUs.
Download and install Atmel Studio 6.2 from http://www.atmel.com/microsite/atmel_studio6/
You can find the installed directory: C:\Program Files\Atmel\Atmel Studio 6.2
1.2 Download and Install the latest ASF
Atmel Studio 6 is free of charge and is integrated with the Atmel Software Framework (ASF)—a large library
of free source code with 1,600 ARM and AVR project examples. ASF strengthens the IDP by providing, in the
same environment, access to ready-to-use code that minimizes much of the low-level design required for
projects. Use the IDP for our wide variety of AVR and ARM Cortex-M processor-based MCUs, including our
broadened portfolio of Atmel SAM3 ARM Cortex-M3 and M4 Flash devices.
If the ASF version in your Atmel Studio is not the latest one you will be notified when Atmel Studio starts. The
following procedure demonstrates how to update the ASF to the latest version. You can install other
extensions in the list as well.

Getting Started Guide for WINC1500 Wi-Fi
using SAM D21 Xplained Pro: XXXXA10/145
Page 5 of 28
1) Run Atmel Studio 6.2.
2) You can see the start page of Atmel Studio 6.
3) Update ASF to the latest version.
Menu Tools Extension Manager

Getting Started Guide for WINC1500 Wi-Fi
using SAM D21 Xplained Pro: XXXXA10/145
Page 6 of 28
Available Downloads Updates Atmel Software Framework
Select an extension and proceed with download and installation.
Restart Atmel Studio to take effect of newly installed extension.
1.3 Download and Install the latest WINC1500 Extension Package
WINC1500 Extension package contains the WINC1500 software (latest firmware, Firmware update Tools and
Example projects).
As an Atmel Studio Extension (.vsix file), which can be found on the Atmel Gallery
web site (http://gallery.atmel.com/) or using the Atmel Studio Extension manager.
1) Atmel Studio Menu Tools Extension Manager.
2) Input “winc”in the search window then you can find the WINC1500 extension.
3) Select the extension and proceed with download and installation.

Getting Started Guide for WINC1500 Wi-Fi
using SAM D21 Xplained Pro: XXXXA10/145
Page 7 of 28
Restart Atmel Studio to take effect of newly installed extension.
4) Restart Atmel Studio.
5) Open the Tools and Document via File New Example Project (Ctrl + Shift + E).
6) Input “FIRMWARE”in the search window then you can find an example named like
“WINC1500_FIRMWARE_UPDATE_AND_DOCUMENTATION”.
This project contains documentation and tools to upgrade WINC1500 firmware to the specific version which is
matched up with the Wi-Fi driver in example projects. It also contains documentation on how to run example
projects in this extension.

Getting Started Guide for WINC1500 Wi-Fi
using SAM D21 Xplained Pro: XXXXA10/145
Page 8 of 28
2. Getting Started with Atmel Hardware
This chapter introduces Atmel Evaluation Kits for testing IoT applications. The SAMD21 and the WINC1500
are essential but the IO1 and the OLED1 extension boards are optional.
2.1 Atmel SMART SAMD21-XPRO Evaluation Kit
The Atmel® SAM D21 Xplained Pro evaluation kit is ideal for evaluating and prototyping with the Atmel SAM
D21 ARM® Cortex® -M0+ based microcontrollers. Extension boards to the SAM D21 Xplained Pro can be
purchased individually.
SAMD21J18A microcontroller
One mechanical reset button
One mechanical user pushbutton (wake-up, bootloader entry or general purpose)
One yellow user LED
32.768kHz crystal
USB interface, device and reduced host mode
8 Mbit Serial Flash
3 Xplained Pro extension headers
Embedded Debugger
Auto-ID for board identification in Atmel Studio 6.1
One yellow status LED
One green board power LED

Getting Started Guide for WINC1500 Wi-Fi
using SAM D21 Xplained Pro: XXXXA10/145
Page 9 of 28
Symbolic debug of complex data types including scope information
Programming and debugging
Data Gateway Interface: SPI, I²C, 4 GPIOs
Virtual COM port (CDC)
USB powered
Supported with application examples in Atmel Software Framework
Here is the link for more detailed information about SAM D21.
http://www.atmel.com/tools/atsamd21-xpro.aspx
2.2 Atmel SmartConnect WINC1500-XPRO Wi-Fi Extension Board
Atmel® SmartConnect-WINC1500 is an IEEE 802.11 b/g/n IOT network controller SoC. It is the ideal add-On
to existing MCU solutions bringing WiFi and Network capabilities through SPI-to-WiFi interface. The
WINC1500 connects to any Atmel AVR or SMART MCU with minimal resource requirements. The WINC1500
most advanced mode is a single stream 1x1 802.11n mode providing up to 72 Mbps PHY throughput.
WINC1500 features fully integrated Power Amplifier, LNA, Switch and Power Management. The WINC1500
provides internal Flash memory as well as multiple peripheral interfaces including UART, SPI, and I2C. The
only external clock source needed for the WINC1500 is a high-speed crystal or oscillator with a wide variety of
reference clock frequencies supported (between 12 –32 MHz). The WINC1500 is available in a QFN
package.
IEEE 802.11 b/g/n (1x1) for up to 72 Mbps
Integrated PA and T/R Switch
Superior Sensitivity and Range via advanced PHY signal processing
Wi-Fi Direct, station mode and Soft-AP support
Supports IEEE 802.11 WEP, WPA2 Security Enterprise
On-chip memory management engine to reduce host load
4 Mbit internal Flash memory with OTA firmware upgrade
SPI as host interfaces
TCP/IP protocol stack (client/server) sockets applications
Network protocols (DHCP/DNS)
Secure TLS stack
WSC (wireless simple configuration WPS)
On-Chip Network Stack to offload MCU

Getting Started Guide for WINC1500 Wi-Fi
using SAM D21 Xplained Pro: XXXXA10/145
Page 10 of 28
Integrated Network IP stack to minimize host MCU requirements
Network features: TCP, UDP, DHCP, ARP, HTTP, SSL, and DNS
Here is the link for more detailed information about ATWINC1500.
http://www.atmel.com/devices/ATWINC1500.aspx
2.3 Atmel IO1-XPRO Sensor Extension Board
Atmel IO1 Xplained Pro extension board is a generic extension board for the Xplained Pro platform. It
connects to any Xplained Pro standard extension header on any Xplained Pro MCU board. The extension
board utilizes all functions on the standard Xplained Pro extension header to further enhance the feature set
of Xplained Pro MCU boards.
microSD card connector
2GB microSD card included
Accessed with SPI interface
PWM
LED control
PWM → Low pass filter → ADC
ADC
PWM → Low pass filter → ADC
Light sensor
UART
Loopback interface via pin header
TWI
AT30TSE758 Temperature sensor with EEPROM
Xplained Pro hardware identification system
Here is the link for more detailed information about AT IO1.
http://www.atmel.com/images/atmel-42078-io1-xplained-pro_user-guide.pdf
2.4 Atmel OLED1-XPRO Display Extension Board
Atmel® OLED1 Xplained Pro is an extension board to the Atmel Xplained Pro evaluation platform. The board
enables the user to experiment with user interface applications with buttons, LEDs and a display.

Getting Started Guide for WINC1500 Wi-Fi
using SAM D21 Xplained Pro: XXXXA10/145
Page 11 of 28
UG-2832HSWEG04 monochrome OLED display
128 x 32 Pixels
Controlled by 4-wire SPI interface, up to 100MHz
Three LEDs
Three Mechanical push buttons
Xplained Pro hardware identification system
Here is the link for more detailed information about AT OLED1.
http://www.atmel.com/images/atmel-42077-oled1-xplained-pro_user-guide.pdf

Getting Started Guide for WINC1500 Wi-Fi
using SAM D21 Xplained Pro: XXXXA10/145
Page 12 of 28
3. Getting Started with WINC1500 IoT Examples
This chapter introduces WINC1500 IoT examples and describes how to run an example on the SAM D21
board.
3.1 Organization of WINC1500 IoT Examples
All of these examples are included in ASF Package and there are various IoT examples using Wi-Fi module.
Basic Examples
These examples describe basic Wi-Fi operation in ‘how-to’manner:
How to read chip ID(to identify WINC1500 H/W revision)
How to set debug message level
How to get MAC address of the Wi-Fi module
How to start Wi-Fi in specific operation mode, such as:
STA Mode (Station mode), AP mode (Access Point mode), P2P mode (client mode)
How to switch mode among STA, AP and P2P modes during the runtime
How to scan APs nearby
How to set deep sleep mode
How to connect to secure Wi-Fi with using WEP/WPA/WPA2 security
How to connect to enterprise security network
How to connect to security WPS
How to set packet monitoring
How to get RF signal status by reading RSSI value
How to set AP provision
How to set HTTP provision
Protocol Examples
After basic code examples, user may be interested in how to send and receive network packets. Here are
protocol examples that can be extended for IoT application.
UDP protocol example
TCP protocol example
NTP Time client –retrieve network time for IoT application
MQTT protocol client example
Send email –send an email from SMTP server
Location client –get the current location of the network provider using HTTP
Advanced Examples
These examples demonstrate more complex function like:
Growl client –demonstrates using RESTful API over SSL (essential for IoT application)
MQTT Chat client –demonstrate how to send and receive IoT information using MQTT protocol
Weather client –get the current weather information of the network provider and utilize the IO1
sensor device
Wi-Fi serial - useful for chatting or controlling a remote device
OTA Firmware Upgrade –WINC1500 Firmware upgrade via OTA server

Getting Started Guide for WINC1500 Wi-Fi
using SAM D21 Xplained Pro: XXXXA10/145
Page 13 of 28
SSL connection - Set up an SSL connection
3.2 Connect the Board
Connect the WINC1500 Wi-Fi module to the SAM D21 as shown in the figure.
The WINC1500 Wi-Fi module comes with a Wi-Fi software API. The purpose of this API is to provide an
abstraction of the binary protocol used between the host processor and the WINC1500 Wi-Fi module while
keeping an easy and reliable solution to add wireless capabilities to any user application. This software is
based on the Atmel Software Framework (ASF) and is configured to use a WINC1500 Wi-Fi module on EXT1
by default. Note that switching to another extension port (EXT2 or EXT3) is possible by modifying a
configuration file.
Connecting several WINC1500 Wi-Fi modules is possible but not supported by the
provided Wi-Fi Software API.
For this getting start guide the WINC1500 Wi-Fi module will remain connected on
EXT1.
Connect the DEBUG USB port on the SAM D21 to your PC using a micro-USB cable. The SAM D21 will be
visible in the Windows Device Manager with its COM port.
DEBUG USB

Getting Started Guide for WINC1500 Wi-Fi
using SAM D21 Xplained Pro: XXXXA10/145
Page 14 of 28
Atmel Studio may detect your device automatically and show a proper page.
3.3 How to Get Weather Client Example Project
This example demonstrates the use of the WINC1500 with the SAM D21 Xplained Pro board to receive
weather information from a weather server. It uses the following hardware:
The SAM D21 Xplained Pro
The WINC1500 on EXT1 header
The IO1 on EXT2 header
A wireless access point
A mobile device (for provisioning)
Weather Server

Getting Started Guide for WINC1500 Wi-Fi
using SAM D21 Xplained Pro: XXXXA10/145
Page 15 of 28
1) Open the Weather client example via File New Example Project (Ctrl + Shift + E).
2) Input “WEATHER”in the search window then you can find an example named like
“SAMD21_XPLAINED_PRO_WINC1500_WEATHER_CLIENT_EXAMPLE”.

Getting Started Guide for WINC1500 Wi-Fi
using SAM D21 Xplained Pro: XXXXA10/145
Page 16 of 28
3) Press OK button then Atmel Studio will bring over the project source code of the example.
3.4 How to Build & Execute
This guide demonstrates how to build an example and execute it on the SAM D21 Xplained Pro.
1) Build the solution (F7) and ensure you get no errors.
2) Connect the WINC1500 Wi-Fi extension and the IO1 extension to the SAM D21 Xplained Pro as
displayed below:
3) Connect the SAM D21 Xplained Pro board to your PC using DEBUG USB connector.
4) Program the application by clicking on the Start Debugging and Break icon.
DEBUG USB

Getting Started Guide for WINC1500 Wi-Fi
using SAM D21 Xplained Pro: XXXXA10/145
Page 17 of 28
5) You will be asked to select your debug tool:
6) Select EDBG and SWD (Serial Wire Debug) as Interface
7) Click again on the Start Debugging and Break icon:
8) The application will be programmed in the SAM D21 embedded flash and breaks at main function. Click
on Continue to execute the application:
You may be asked to upgrade your EDBG firmware. If so, click on Upgrade button:
Upgrade operation may take a few minutes, please wait for the operation to complete.
The example is now programmed and running.

Getting Started Guide for WINC1500 Wi-Fi
using SAM D21 Xplained Pro: XXXXA10/145
Page 18 of 28
Open the SAM D21 EDBG DEBUG USB serial COM port, with the following settings:
115200 bauds,
8 bit data,
no parity,
one stop bit,
and no flow control
Open a serial terminal tool to see the result. You can use your preferred serial terminal, such as PuTTY, Tera
Term, etc. You can also use terminal window plug-in in Atmel studio. You can install it through below menu.
(Menu > Tools > Extension Manager)
Connect to the device.
Following information will be displayed on the terminal window.
-- WINC1500 weather client example --
-- SAMD21_XPLAINED_PRO --
-- Compiled: xxx xx xxxx xx:xx:xx –
Provision Mode started.
Connect to [atmelconfig.com] via AP[WINC1500_08:CA] and fill up the page.
3.5 Provisioning
As seen in the log message, the device is waiting for provisioning. In this stage, The WINC1500 device will
running as AP mode, waiting for user setup a credential for desired Access Point to use.
Some examples have this kind of provision function while some are not. It depends on the scenario of demo
purpose. To setup a desired AP:

Getting Started Guide for WINC1500 Wi-Fi
using SAM D21 Xplained Pro: XXXXA10/145
Page 19 of 28
1) Connect your mobile device to WINC1500 in Wi-Fi Setting.
2) Browse the webpage (atmelconfig.com) for setting AP, fill up the page then press Connect button.
3) Then WINC1500 will running as a client and will connect to the AP which you selected (the mobile device
will be disconnected from your WINC1500).

Getting Started Guide for WINC1500 Wi-Fi
using SAM D21 Xplained Pro: XXXXA10/145
Page 20 of 28
4) After the network is online, device will communicate with weather server. The weather info will be printed
on the terminal window.
Wi-Fi IP is xxx.xxx.xxx.xxx
wifi_cb: M2M_WIFI_RESP_PROVISION_INFO.
Wi-Fi connected
Wi-Fi IP is xxx.xxx.xxx.xxx
Host IP is 144.76.102.166
Host Name is openweathermap.org
City: Seoul
Temperature: 20.63
Weather Condition: sky is clear
It may not be operated normally if the server connection is unstable.
