ATOMSTACK R3 Rotary Roller User manual

Shenzhen AtomStack Technologies Co., Ltd. [e-mail]
ATOMSTACK
R3 Rotary Roller User Manual

Shenzhen AtomStack Technologies Co., Ltd. [e-mail]
Table of Contents
1. Security Statement 3
1. Security of Laser 3
2. Security of Fire Fighting 3
3. Security of Material 3
4. Security of Operation 3
2. Disclaimer and warning.4
3. AtomStack R3 Rotary Roller Introduction 5
4. AtomStack R3 rotary roller software installation and use 6
4.1. LaserGRBL software installation and operation 6
1 Software download 6
2 Install LaerGRBL 6
3 LaserGRBL pulse adjustment 6
*A. Laser engraver connect with LaserGBRL 6
*B. Grbl Selection 7
*C. X/Y axis pulse value setting 7
4.2 LightBurn installation and pulse value setting 7
1 Software download 7
2 Install LightBurn 8
3 LightBurn pulse adjustment 8
*A. Laser engraver connect with LightBurn 8
*B. Edit selection 8
*C. Outputs Setup data sheet 9
*D. X/Y axis pulse value setting 9
5. R3 Rotary Roller setting 10
1. Definition for raiser of R3 Rotary Roller and Laser engraver 10
2. Cable explanation of of R3 Rotary Roller and Laser engraver 10
3. Definition of working scope for the synchronized belt 11
4. Definition for X axis of R3 Rotary Roller and Laser engraver 12
5. Gear Definition of R3 Rotary Roller 14
6. Precautions 15

Shenzhen AtomStack Technologies Co., Ltd. [e-mail]
1.Security statement
Before operating our R3 Rotary Roller，please read our instruction carefully，it will show
all the special situation，including some warning of the unsafe behavior which may cause
some property losing even harmful for your personal safety.
1. Security of Laser
AtomStack R3 Rotary Roller part with Laser engraver is Level 4 Laser product. The power of
laser head is high, it may cause injury of the eye and skin burning.
1. Please wear on the eye protection when you are operating the laser engraver and R3
Rotary Roller
2. Refrain to expose the skin on Level 4 laser beam, especially close distance.
3. It must be supervised by p arents or other adult person when the teenager operating
our device
4. DO NOT touch the laser module when it is activated.
2. Security of Fire Fighting
1. When Laser engraver operating with R3 Rotary Roller to cutting or engraving will burned
up the basic material, the high intensity laser will create extreme high temperature and massive
heat.
2. Some material will be burned during the cutting or engraving, and will cause some gas
or smog.
3. The lighting spot will create some flame when the laser beam shot at the material. The
flame will move with the laser and will not keep flaming when the laser moving. The operation
must be supervised during cutting or engraving. Please clear the sundry, scrap and flammable
material after the cutting or engraving. Ensure there is fire extinguisher at the workplace of the
operation. There is some smog, steam or particulate which could be poisonous ( plastic or
some flammable material ) caused by material when the laser engraver operating, this smog,
steam or particulate may be harmful for your healthy.

Shenzhen AtomStack Technologies Co., Ltd. [e-mail]
3. Security of Material
1. DO NOT cutting or engraving any unknown material.
2. Recommended material: wood, bamboo, leather, plastic, fabric, paper, non-
transparent acrylic, glass etc.
3. Not recommended material：Metal，gem，transparent material，reflected material.
4. Security of Operation
1. R3 Rotary Roller only operating on the horizontal flat, and make sure the Rotary Roller
must be fixed firmly, preclude fire when dropping or moving during the operation.
2. It is forbidden to aim at people, animal or any flammable material, no matter under
operation or not.

Shenzhen AtomStack Technologies Co., Ltd. [e-mail]
1.Disclaimer and warning
Atomstack product is not toy, not suitable for the people who is younger than 15.
Make sure DO NOT allow the children to tough any Atomstack product, be careful of children
when you operate our product accompany with children. Be careful when adjusting the product
gear, Atomstack will not take the responsibility due to the any harm cause by any incompatible
our instruction behavior.
R3 Rotary Roller is a multi-function Rotary Roller, it will provide you engraving and cutting
viewing experience under the normal condition. Visit our website:
http://www.atomstack3d.com/laserengrave to get the experience and user manual. Shenzhen
AtomStack Technologies Co., Ltd （Atomstack）will own the right to update the Disclaimer and
the user manual.
Before using our product, please be sure to read this document carefully to understand
your legal rights, responsibilities and safety instructions; otherwise it may cause property
damage, safety accidents and personal safety hazards. Once you use this product, you
should be deemed to have understood, accepted and accepted all the terms and contents of
this document. The user is responsible for his or her actions and all consequences arising
therefrom. The user agrees to use the product only for lawful purposes, and agrees to all the
terms and contents of this document and any related policies or guidelines that AtomStack
may establish. You understand and agree, unless you provide the original engraving or cutting
files, the configuration parameters of the engraving software used, operating system
information, videos of the engraving or cutting process, and the operating steps before
problems or failures occur.
Atomstack will not take the responsibility to any lost which caused by the failure using of
our product. AtomStack has the final right to interpret the documents and comply with legal
regulations. Atomstack reserves the right to update, modify or terminate the terms without
notice.

Shenzhen AtomStack Technologies Co., Ltd. [e-mail]
3. AtomStack R3 Rotary Roller brief introduction
AtomStack R3 collocates with laser engraver to process the engraving and cutting.
AtomStack R3 rotary roller adopts the base of aluminum profile, which is firm and stable.
The height of the roller protrudes from the height of the base, which can engrave longer
objects, expands the engraving area, and has no restriction on the shape of the engraved
object; the rotary roller is adjustable wide and narrow, for objects of different sizes, engraving
can be achieved by adjusting the width of the roller, which makes the engraving machine more
widely used.
AtomStack R3 rotary roller adjustment is very convenient, you just need to adjust four
plum blossom handle from both side to match different size object to make the engraving and
cutting. Rotary roller is the concentric circles designing, Synchronous belt will keep the same
status no matter how to adjust, and it is an advanced design that some others similar product
dose not have. There are positioning holes on the side cover for setting to make sure the rollers
will keep the same horizontal level under the adjustment. The motor of our R3 rotary roller is
build-in, will not scald people even the motor is getting hot after some processing. Integrated
rubber roller, the hardness is 70A. The process will be more stable with the strong friction.
AtomStack R3 with the speed which adapts 95% brands of the engraves that we know,
including Atomstack Neje and Ortur etc, just plug and play.

Shenzhen AtomStack Technologies Co., Ltd. [e-mail]
3. AtomStack R3 Rotary roller installation and using
AtomStack R3 roller coordinate with either X axis or Y axis of the engraver to make the
processing, and compatible with engraver of Neje, Atomstack and Ortur. No need to adjust the
pulse, directly process after link. If coordinate with other brands, may need to adjust the pulse.
The main supplied OS is LaserGRBL and LightBurn.
Below there are software installation manual and the procedure of the pulse adjustment.
4.1 LaserGRBL installation and procedure of the pulse adjutment
1. Download the software
LaserGRBL is one of the popular software for engraving, we could visit and download from
http://lasergrbl.com/download.
2. Install LaerGRBL
Click to start the installation file, and keep clicking next step until the installation is finished.
4.1 LaserGRBL installation
3. LaserGRBL procedure of the pulse adjustment
*A. Start up LaserGRBL，connect the engraver and the computer which already installs
the LaserGRBL. Click the lightning mark, the connection is successful when the lightning
mark turns into red X.
4.2 LaserGRBL connecting with the laser engraver
Lightning mark
Connection/disconnect
Com port
Baud rate 115200
Next

Shenzhen AtomStack Technologies Co., Ltd. [e-mail]
*B.Click the Grbl, and select the Grbl Configuration
4.3 Grbl Configuration
*C. Find the$100(X-axis travel resolution), $101(Y-axis travel resolution)，and set the
Value according to your device，（ you can first engrave a small square with 30*30mm to
confirm the pulse value. The processing is to check if error is within 1mm after testing
engraving is finished. If confirmed, that is the suitable pulse value）click write and close to
finish the configuration.
4.4 X and Y Axis pulse setting
4.2 LightBurn installation and procedure of the pulse adjustment
1 Download
You could visit and download the software from the link:
https://lightburnsoftware.com/pages/trial-version-try-before-you-buy
2 Install LightBurn
Click to install the software ( LightBurn need to charge, you may pay for the genuine to get
the better experience, here we will show by the trial for installation ), and click the next for next
step.
4.5 Select the installation
Grbl Configuration
Grbll
Next
Write
Close

Shenzhen AtomStack Technologies Co., Ltd. [e-mail]
3. LightBurn procedure of the pulse adjustment
*A. Start up LightBurn，connect the engraver and the computer which already installs the
LightBurn. When there is portal information show up from the devices means
connection is successful.
4.6 LightBurn connectivity with engraver
*B. Click Edit, and select Machine Settings
4.7 Machine setting position
Devices
GRBL
Cu.usbserial-1420
Machine settings
Edit

Shenzhen AtomStack Technologies Co., Ltd. [e-mail]
*C.Click to Outputs Setup to find the hidden parameter
4.8 Outputs Setup parameter
*D. Find the$100(X-axis travel resolution), $101(Y-axis travel resolution)，and set the Value
according to your device，（ you can first engrave a small square with 30*30mm to confirm the
pulse value. The processing is to check if error is within 1mm after testing engraving is finished.
If confirmed, that is the suitable pulse value）click write and close to finish the configuration.
4.9 X and Y Axis pulse setting
Outputs setup
Write
OK
X Steps per mm($100)
Y steps per mm($101)

Shenzhen AtomStack Technologies Co., Ltd. [e-mail]
5. R3 Rotary Installation
1. When you want to engrave or cutting wide surface object or coordinate with the rotary
roller to engrave on cylinder, you need the set the heighten accessory. The supported
bracket of laser engraver is thin-shaping, could be fasten by the Plum blossom handle of the
heighten accessory so that heighten the laser engraver to engrave or cutting higher object.
4.10 R3 Rotary Roller and Heighten Accessory 4.12 Heighten Accessory
2. Atomstack set up two connection wire for the R3 rotary roller and engraver( black plug and
white plug ), pay attention that the wire order of them is different，need to be careful for the
connectivity.
2.1 The 4PIN white plug wire is for the connection with Atomstack, AtomStack engraver.
2.2 The 4PIN black plug wire is for the connection with Neje, Ortur engraver.
2.3 These 4PIN wire (white and black plug) is the our main connection wire，for the other
brand engraver, you may try one of them to connect. If it fails to connect, please change
the order of wire, and the change processing is in chart 4.16-4.17
4.16 Connection order of white plug wire 4.17 Connection order of black plug wire
Heightening Column
R3 Rotary Roller
Engraver
Plum blossom handle
Heighten Accessory

Shenzhen AtomStack Technologies Co., Ltd. [e-mail]
4.13 Connection plug on rotary roller 4.14 White plug wire
4.15 black plug wire
3. The synchronized belt must be set out of the processing area, make sure will not be
destroyed by the laser during the operation.
4.18 Rotary roller and synchronized belt
Connection
socket
Plug for roller
Plug for motor
4PIN white plug wire
Plug for roller
Plug for motor
4PIN black plug wire
Laser Head
R3 Rotary Roller
Roller
Synchronized belt
Out of processing area

Shenzhen AtomStack Technologies Co., Ltd. [e-mail]
4. The roller of R3 Rotary need to keep parallel with the X axis of engraver，and the rotary
roller must be at the same horizontal surface with the desk, can not have any object under the
roller.
4.19 Right side of roller 4.20 Left side of the roller
4.21 Make sure no object under the roller
Focus plank
Adjust roller position to keep parallel
with connecting plate( right )
Focus plank
Adjust roller position to keep parallel
with connecting plate ( left )
Roller
Roller
R3 Rotary Roller must be at
the same horizontal
surface

Shenzhen AtomStack Technologies Co., Ltd. [e-mail]
5. There is 8 Steps for our R3 Rotary Roller, it can adjust to match different size object for
engraving via different gear.
4.22 Steps setting of roller
4.23 Steps for adjustable
4.24 plum blossom handle
1
7
3
2
5
6
4
8
R3 Rotary roller can adjust
for different size object
Roller
Roller
The Steps can
adjust to match
different size
object
plum blossom handle
plum blossom handle
plum blossom handle

Shenzhen AtomStack Technologies Co., Ltd. [e-mail]
6.Precautions
1. R3 Rotary Roller must be keep away from the high temperature environment such as fire.
The high temperature environment may cause heat distortion to destroy the device.
2. Non-technical people cannot disassemble your product to prevent the damage.
3. The roller should not be stride intensely, R3 Rotary Roller is the full-metal device but the
motor may be damage when the device is stride over the secured level. Meanwhile, it may
also distroy the profile.
4. Our R3 should keep away from the chemicals, must be cleaned in time if contact with any
chemicals.
5. It is not allowed for splash water get into the roller, otherwise will damage the motor to
cause failure.
6. R3 rotary roller is electromagnetic, should keep away from the strong magnetic field. It may
cause the failure of motor or the roller is not rolling stably.

Shenzhen AtomStack Technologies Co., Ltd. [e-mail]
Customer Service:
For detailed warranty policy,please visit our
official website at: www.atomstack3d.com
For Laser Engraver technical support and
service,
please email: [email protected]
Manufacturer: Shenzhen AtomStack Technologies Co., Ltd.
Address: AB301,New Chabridge Industrial Park,No.3,Baolong 6th
Rd.,Longgang Dist,Shenzhen,Guangdong,CHINA 518116
Search us:

Shenzhen AtomStack Technologies Co., Ltd. [e-mail]
ATOMSTACK
R3 Bedienungsanleitung für Drehwalzen

Shenzhen AtomStack Technologies Co., Ltd. [e-mail]
Table of Contents
1. Sicherheitserklärung 3
1. Lasersicherheit 3
2. Sicherheit bei der Brandbekämpfung 3
3. Materialsicherheit 3
4. Betriebssicherheit 3
2. Haftungsausschluss und Warnung..4
3. AtomStack R3 Einführung in die Rotationswalze 5
4. AtomStack R3 Installation und Verwendung der Rotationswalzen
Software 6
4.1. LaserGRBL Softwareinstallation und -betrieb 6
1 Software herunterladen 6
2 Installieren LaerGRBL 6
3 LaserGRBL Pulseinstellung 6
*A. Lasergravierer verbinden mit LaserGBRL 6
*B. Grbl Auswahl 7
*C. Impulswerteinstellung der X / Y-Achse 7
4.2 LightBurn Installation und Impulswerteinstellung 7
1 Software herunterladen 7
2 Installieren LightBurn 8
3 LightBurn Pulseinstellung 8
*A. Lasergravierer verbinden mit LightBurn 8
*B. Edit Auswahl 8
*C. Datenblatt zur Konfiguration der Ausgänge 9
*D. Impulswerteinstellung der X / Y-Achse 9
5. R3 Drehwalzeneinstellung 10
1. Definition für Raiser von R3 Rotary Roller und Lasergravierer 10
2. Kabel Erklärung von R3 Rotary Roller und Lasergravierer 10
3. Definition des Arbeitsumfangs für den Synchronriemen 11
4. Definition für die X-Achse von R3 Rotary Roller und Lasergravierer 12
5. Zahnraddefinition der R3-Rotationsrolle 14
6. Vorsichtsmaßnahmen 15

Shenzhen AtomStack Technologies Co., Ltd. [e-mail]
1.Sicherheitserklärung
Bevor Sie unseren R3 Rotary Roller in Betrieb nehmen, lesen Sie bitte unsere Anleitung
sorgfältig durch. Sie zeigt alle besonderen Situationen auf, einschließlich einiger Warnungen
vor dem unsicheren Verhalten, das zum Verlust von Eigentum führen kann, sogar schädlich für
Ihre persönliche Sicherheit.
1. Lasersicherheit
Atomstack R3 Rotationsrollenteil mit Lasergravierer ist ein Laserprodukt der Stufe 4. Die
Leistung des Laserkopfes ist hoch, dies kann zu Augenverletzungen und Hautverbrennungen
führen.
1. Bitte tragen Sie beim Betrieb des Lasergravierers und der Rotationswalze R3 einen
Augenschutz.
2. Vermeiden Sie es, die Haut dem Laserstrahl der Stufe 4 auszusetzen, insbesondere im
Nahbereich.
3. Es muss von den Eltern oder einer anderen erwachsenen Person beaufsichtigt werden,
wenn der Teenager unser Gerät bedient.
4. Berühren Sie das Lasermodul NICHT, wenn es aktiviert ist.
2. Sicherheit bei der Brandbekämpfung
1. Wenn ein Lasergravierer mit dem R3 Rotary Roller zum Schneiden oder Gravieren das
Grundmaterial brennt, erzeugt der Hochleistungslaser extrem hohe Temperaturen und massive
Hitze massive.
2. Einiges Material wird beim Schneiden oder Gravieren verbrannt, was zu Gas oder Smog
führt.
3. Der Beleuchtungsfleck erzeugt eine Flamme, wenn der Laserstrahl auf das Material
geschossen wird. Die Flamme bewegt sich mit dem Laser und brennt nicht weiter, wenn sich
der Laser bewegt. Beim Schneiden oder Gravieren muss der Prozess überwacht werden. Bitte
entfernen Sie alle anderen Materialien, Schrott und brennbare Materialien nach dem Schneiden
oder Gravieren. Stellen Sie sicher, dass am Arbeitsplatz des Unternehmens ein Feuerlöscher zur

Shenzhen AtomStack Technologies Co., Ltd. [e-mail]
Verfügung steht. Es gibt einige Smog, Dämpfe oder Partikel, die giftig sein können (Kunststoff
oder ein brennbares Material), die durch das Material verursacht werden, wenn der
Lasergravierer arbeitet. Dieser Smog, Dampf oder diese Partikel können gesundheitsschädlich
sein.
3. Materialsicherheit
1. KEINE unbekannten Materialien schneiden oder gravieren.
2. Empfohlenes Material: Holz, Bambus, Leder, Kunststoff, Stoff, Papier, opakes Acryl, Glas
usw..
3. Nicht empfohlenes Material: Metall, Edelstein, transparentes Material, reflektierendes
Material.
4. Betriebssicherheit
1. Der R3 Rotary Roller funktioniert nur in der horizontalen Ebene. Bitte stellen Sie sicher,
dass der Rotary Roller sicher befestigt ist, um Feuer zu vermeiden, wenn er fallen oder während
des Betriebs bewegt wird.
2. Es ist verboten auf Menschen, Tiere oder brennbares Material zu zielen, egal ob in
Betrieb oder nicht.
