ATS Help Dialer 700 User manual

BATTERY PRECAUTION
 Necklace Panic Button Battery: (1)A23S Battery
 Wrist Panic Button Battery: (2) CR2016 Batteries
 When red LED is on (base unit), the backup batteries
are low.
 If the LED on Necklace Panic Button turns red when
Necklace Panic Button is pressed, it is time to change
the battery.
 If the LED on the Wrist Panic Button dims when the
Wrist Panic Button is pressed and held, it is time to
change the battery.
 To test your panic button battery, press and Hold the
panic button on the Necklace or the Wrist button for
10 seconds if the light DOES NOT stay lit for the
entire 10 seconds the battery is weak and should be
replaced.
Assistive Technology Services
“Our mission is to provide evaluation, consultation, spiritual
guidance and assistive devices to make the quality of life better
for those that need a little help.”
Visit our website: AtsCares.com
HELP DIALER 700
MANUAL
email: [e-mail]
Phone: [phone] v04302121

POWER AND TELEPHONE CONNECTION
 Open the cover at the top of Base unit
(will see DC jack and telephone plug
socket)
 Insert one end of adaptor (included) to DC
jack and other end to AC power supply
outlet
 Insert one end of telephone cable (included)
into telephone jack and the other end into
the Base unit
For backup power, insert 4 AAA batteries (not
included) into battery compartment located on
back of unit.
Turn ON unit with switch located at side of unit.
The green LED (power indicator) and red LED
will flash for 3 seconds to indicate unit is ready to
record and store numbers.
HOW TO PERSONALIZE THE
EMERGENCY MESSAGE
Press and hold the above buttons on the keypad – at
the same time.
The Red LED light will come on. You have (6)
seconds to record your personal message.
To playback your recorded message, press button:
NOTE: To change the recorded message, repeat
steps above
Example: “I need help, please press a button to
accept the call”
(If calling from a landline, 911 already has your
location)
#

EMERGENCY OPERATION
Press the button on either Panic Button or on Base
unit. The Base unit will dial the (3) preset numbers
automatically in the order they were programmed.
It will call each number for (45) seconds. The
system will repeatedly play the outgoing message
until the receiver presses a button on their phone. If
the receiver does not answer the phone, it will keep
dialing for (5) cycles and then go into standby
mode.
When the receiver answers the call from the
system, they will hear the pre-recorded message.
The receiver can then open up a two-way
communication and listen to the caller’s
surroundings by pressing any number on their
telephone keypad. After communicating for
approximately (45) seconds, the receiver will hear
(3) “beep” tones to advise receiver to extend the
talk and listen time. Receiver can extend the time
by pressing any number on their keypad to
extend for another (60) seconds. When the
conversation is over the receiver should press 9
before hanging up, the Base unit will go back to
standby mode after several minutes. If the call is
answered, (by the receiver of the call pressing any
number on their phone) the Base unit will stop
dialing the remaining contacts.
HOW TO STORE TELEPHONE NUMBERS
You will need to store your emergency contact
numbers the same way you would key them in if
dialing them from the home phone line manually.
This is an example of dialing a long distance
number. Which includes ‘1’ plus area code plus
number.
You will only need to store a second ‘1’ if dialing a
long distance number.
For Example: to store 1-615-562-0043 as the First
contact
Press the following keys
1 1 6 1 5 5 6 2 0 0 4 3
For Example: to store a local number as the First
contact
Press the following keys
1 562 0043

To store telephone numbers, follow these steps:
MAKE SURE to press the key Before and
After each phone number is entered.
Press 1 phone number to store 1st number
Press 2 phone number to store 2nd number
Press 3 phone number to store 3rd number
NOTE: If you make a mistake, simply repeat the
process above.
*If storing only one number you must program
that same number in all three memory locations
or unit will stop dialing after the first call.
* If you need to change a number just re-program
the number and the system will overwrite the old
number in the same position with the new number.
Pairing the Pendants to the Base: If the base does
not beep when the pendant is pressed, or you purchase
a replacement pendant it may need to be ‘re-paired’ to
the Base.
Follow the instructions below to pair both pendants to
the Base.
1. Turn power Off. (on Base Unit)
2. Turn power On
.
(on Base Unit)
3. Within 4 seconds, press and hold the Big Blue
Help Button on the Base Unit.
4. Then while still holding down the Big Blue Help
Button on the Base Unit, press the Panic Button on
the Necklace Pendant or the Wrist Pendant. (In one
second, you will hear a small beep) This means the
pairing was successful.
5. If you have more than one pendant you should
always re
-
p
air both pendants.
6. Turn Base Unit off.
7.Turn Base Unit On. Wait for Red LED on top right
of base
to stop flashing.
8. Press a Pendant to Activate Alarm. (This is to test
the pairing process)
The ‘1’ means the first contact to call
The ‘2’ means the second contact to call
The ‘3’ means the third contact to call
