AUDIO TELEX ACM250P User manual

Description
The ACM250P is a 250 watt power amplifier with outputs for 4 ohms, 70 and 100 v olt line. It may be desk or rack
mounted but is packaged as self standing with rubber feet. The ACM250P features a flat screwdriver accessible
gain control on the rear panel.
Inputs
The ACM 250P feat ures two signal inputs. The unit has industry standard 3 pin XLR microphone sockets. Two line lev el
sockets are provided for bridged in/out connection.
Outputs
The ACM250P features 100 volt , 70 v olt and 4 ohm isolated t ransformer out puts.
Protection
Internal current limit ing protects the amplifier from both ov erload and overdrive conditions. The ACM 250P also
features protection in the form of excess temperature auto cut out. An in built auto temperature sensing fan will
turn on at a factory default level but in most situations, will nev er be required.
Manufacture
The ACM 250P is proudly designed and manufactured in Australia.
ACM250P
250w PowerAmplifier

Architectural and Engineering Specifications
The 250 watt power amplifier shall be designed to run 100 v olt line audio syst ems. The unit shall also features a four
ohm output. The amplifier may be desk mounted as standard or rack mounted with the addition of an optional
rack mount kit.
The unit shall feature high temperature prot ection wit h front panel indication. An in built auto temperature sensing
fan shall cool the unit when required and automatically turn off again once the amplifier is running at the correct
temperature. The amplifier must be capable of deliv ering 250 watts into a fourty ohm inductiv e load with less than
0.5% dist ortion measured at 1kHz and with system hum and noise less than 74dB.
The amplifier shall be an Audio Telex model ACM 250P, manufactured in Australia.
Power Output
250 watt s RMS
Max imum Load
40 Ohms @ 100 Volts
Power Bandwidth
60Hz-15kHz< O.5% THD
Frequency Response
60Hz-15kHz (+/- 3dB)
Total Harmonic Distortion
0.5% @ 1 KHz rated power
Signal To Nois e Ratio
-80dB
Input Sensitivity
700mv
Outputs
100v
70v
4 ohm
ACM250P Specifications
Controls
One gain control on rear of the unit v ia flat head
screwdriver control.
Indicators
Power "on" and Protect LED
Power Source
AC 240v-60Hz, 110v-50Hz (special) 3 pin IEC connector
Power consumption
400 watt s.
Protection
Current Limiter protection, plus AC and DC fuses
Dimensions / Weight
88mm H x 480mm W x 330mm D (Chassis Dimensions
only), 15kg
Rack Mounting
Optional ACMRK Rack mount kit
