AudioCodes MediaPack 1xx Analog Media Gateways
MP-124 AC-Powered Quick Guide
1Before Installing
Congratulations on purchasing your AudioCodes MP-124 AC-Powered Analog Media Gateway! Before you
begin using the device, ensure that the following items are included in the shipped box:
Two brackets and screws for 19-inch rack mounting
AC power cord
You’ll also need the following (not supplied):
RJ-45 Ethernet cables
PC running a Web browser
Warning: MP-124 devices are indoor units and therefore, must be installed only indoors.
Routing of FXS telephony cables outdoors can be done only in conjunction with AudioCodes’
approved surge protector (Circa model 4B3S-75) and proper installation and grounding. When
done correctly, the installation will meet ITU-T K.21 (basic) standards. The Ethernet port
interface cabling must be routed only indoors and must not exit the building.
2MP-124 LEDs
MP-124 provides LEDs on its front panel, as shown below and described in the subsequent table.
LED Description
Channels Green On: Off-hook Red On: Line malfunction or unavailable due to
SRTP enabled
Off: On-hook
Data Green Flash:Transmitting RTP Red Flash:Receiving RTP Off: No traffic
Control Green On: Sending/receiving SIP messages Off: No traffic
Lan Green On: 10/100BaseTX link Red On: Malfunction
Ready Green On: Power on Amber Flash: Initializing Red On: Malfunction Off: No power

3MP-124 Ports
MP-124 provides ports on its rear-panel, as shown below and described in the subsequent table.
1 Grounding lug
2 AC power socket
3 50-pin female Telco connector, supporting up to 24 FXS interfaces
4 DB-9 pin female connector for RS-232 serial interface
5 RJ-45 Ethernet port (10/100BaseTX)
4Cabling and Installing MP-124
Warnings:
•Prior to installing MP-124, proper grounding (earthing) and power-surge protection must
be done; refer to the Hardware Installation Manual for detailed instructions. AudioCodes'
will not bear responsibility to damage that may be caused to the device as a result of not
complying with the instructions detailed in the Hardware Installation Manual.
•Prior to connecting MP-124 to power, refer to the Compliancy and Regulatory Information
document at https://www.audiocodes.com/library/technical-documents.
•Connect MP-124 to an electrical socket outlet providing protective earthing. Use only the
AC power cord supplied with the device.
•For FXS cabling, you can use your own third-party MDF connector cable or you can use
AudioCodes' MP-124 FXS Patch Panel (ordered separately from AudioCodes). When using a
third-party MDF for FXS cabling, to reduce noise interference, use a twisted-pair Octopus
cable terminated on a metal-hooded 50-pin Telco connector.

To cable and install MP-124:
1. Connect the Ethernet port to your LAN switch, using the RJ-45 Ethernet cable connector.
2. Connect MP-124 to FXS-based analog equipment (for example, telephone, fax, and modem):
•Third-party MDF: Using a twisted 25-pair Octopus cable, connect each wire pair to its corresponding
MDF adaptor block socket, and then connect the wire-pairs at the other end to a 50-pin male Telco
connector. Connect this to the MP-124 50-pin female Telco connector. Connect your analog
equipment to the MDF using RJ-11 cables.
1
2
3
4
5

•AudioCodes MP-124 FXS Patch Panel: Mount the Patch Panel in a 19-inch rack. Insert and fasten the
Patch Panel's 50-pin male connector to the MP-124 50-pin female Telco connector. Connect your
analog equipment to the Patch Panel using RJ-11 cables.
3. Connect MP-124 to a standard AC electrical wall outlet using the supplied AC power cord. The Ready
LED first flashes amber and then turns green after initialization completes. The Lan LED turns green
indicating an Ethernet link.
4. For desktop mounting, simply place MP-124 on a horizontal desk. For 19-inch rack mounting, refer to
the Hardware Installation Manual.
5Assigning an IP Address
Your MP-124 is shipped with a default IP address:

IP Address:10.1.10.10

Subnet: 255.255.0.0

Default Gateway: 0.0.0.0

To change the IP address:
1. Unplug MP-124 from the network and reconnect the Ethernet port directly to a PC’s LAN port, using
an Ethernet crossover cable.
2. Change your PC’s IP address and subnet mask to correspond with the MP-124 default IP address and
subnet mask (see above).
3. In your Web browser, enter the default IP address of MP-124 (e.g., http://10.1.10.10); the MP-124
Web-based management tool opens, requesting your login credentials.
4. Log in using the default (case-sensitive) username ("Admin") and password ("Admin"), and then click
Login.
5. Access the Interface table (Configuration tab > VoIP menu > Network > IP Interfaces Table).
6. Modify the IP address to correspond with your network IP addressing scheme, and then click Submit.
7. Save your settings to flash ("burn") in the Maintenance Actions page (Maintenance tab >
Maintenance menu > Maintenance Actions); your Web browser disconnects from the MP-124 Web
interface.
8. Unplug MP-124 from your PC and reconnect it to the network.
9. Restore your PC’s IP address and subnet mask to their original settings, and then restart your PC and
re-access the MP-124 Web interface with its newly assigned IP address.
6Configuring Basic SIP Settings
Configure MP-124 with basic SIP parameters using the Web interface:

To configure basic SIP parameters:
1. In the Coders Table page (Configuration tab > VoIP menu > Coders and Profiles > Coders), configure
coders used by MP-124 that best suit your VoIP network and are supported by your VoIP provider.

2. In the Proxy & Registration page (Configuration tab > VoIP menu > SIP Definitions > Proxy &
Registration), set the 'Use Default Proxy' field to Yes and the 'Enable Registration' field to Enable.
3. Click the Proxy Set Table button, and then enter the IP address or domain name of the Proxy server
provided by your VoIP provider.
7Setting up your Voice Ports
The MP-124 FXS voice ports are enabled by assigning them a phone number.
To set up your MP-124 voice ports:
1. Open the Endpoint Phone Number Table page (Configuration tab > VoIP menu > GW and IP to IP >
Hunt Group > Endpoint Phone Number).
2. In the 'Channel(s)' column, enter the port number (labeled on the rear panel) of the port that you
want to enable.
3. In the 'Phone Number' column, enter the port’s phone number (e.g., 401). This number is typically
provided by your VoIP provider.
4. Click Submit.
Warning: Burn your configuration settings to flash before resetting or powering down the
device; otherwise, your settings will not be preserved.
Notice Information
This Quick Guide describes the quick setup for AudioCodes MediaPack MP-124 AC-Powered series Voice-over-IP
(VoIP) SIP media gateways.
Information contained in this document is believed to be accurate and reliable at the time of printing. However,
due to ongoing product improvements and revisions, AudioCodes cannot guarantee accuracy of printed material
after the Date Published nor can it accept responsibility for errors or omissions. Updates to this document and
other documents as well as software updates can be viewed on AudioCodes’ Web site at
https://www.audiocodes.com/library/technical-documents.
© Copyright 2018 AudioCodes Ltd. All rights reserved.
This document is subject to change without notice.
Date Published: February-18-2018
Document #: LTRT-53218
