Audioroot eSMART Li-49Wh User manual
eSMART DUAL CHARGER
2 bay desktop smart battery simultaneous c arger
Version 1.2
Modified : 15/04/2019
The eSMART DUAL CHARG R is a portable and rugged smart battery charger specially designed for
location sound recordists. The unit is powered via a 24Vdc/3.34A universal AC/DC adapter and features a
96×64 pixels OL D color screen.
This charger is compatible with our eSMART Li-98Wh and Li-49Wh li-ion batteries. Similar batteries
from third party vendors are also compatible with this unit.
•
Maximum charging current per bay : 2.0A
•
96x64 pixels full color OL D screen
•
Fanless design
•
All anodized aluminum CNC machined and extruded enclosure with laser engraving
•
24V/3.4A dc input on Switchraft 712 barrel connector
•
110/240V AC/DC PSU supplied
•
Charger dimensions : 170 x 109 x 36mm
•
AC/DC adapter dimensions : 140 x 60 x 35mm
•
Total weight (charger + AC/DC PSU) : 0.8Kg
Ce document est la propriété d'AUDIOROOT, et ne peut-être reproduit ou communiqué sans autorisation
UNPACKING AND INSPECTION
T e eSMART QUAD CHARGERS are carefully c ecked for good condition before being
s ipped from t e factory. Despite t e protective carton and rugged design, s ipping
may damage t e unit. C eck for possible carton damage w en unpacking t e unit.
Please save t e carton for return s ipment if necessary. AUDIOROOT does not
warrant against damage caused by returning products in ot er cartons t an t e
original ones or improperly packing t e products. If s ipping damage is evident,
notify t e transportation company immediately. Only t e consignee can file a claim
wit t e carrier for s ipping damage. AUDIOROOT will fully co-operate in suc an
event. Be sure to save t e carton for t e s ipper to inspect.
Warning
Do not try to repair t is product or replace any of its elements if t is user manual does
not give specific instructions on ow to do so. T is equipement was built wit surface
mount components and needs special tooling for repair. T e removal of t e electronic
PCB needs special tec nical skills.
UNIT CONNECTIONS AND CONTROLS:
1. Battery charging bay #1
2. Battery charging bay #2
3. OL D display
◦
This display shows all the needed information regarding the SoC (state of charge) of each
batteries. See the “OL D DISPLAY” section of this manual for more information.
4. Front panel status L Ds. ach battery bay has a L D which shows the charging status :
- green flasing : the battery is charging
- green solid : the battery is fully charged
- led off : no battery present in the charging bay
5. 24V Switchcraft 712 DC input jack
OLED DISPLAY :
The 96x64 pixels OL D display located on the charger's front panel shows valuable information
about each battery connected to the charger as shown below. Battery voltage, charging current, cycle
count and battery temperature are displayed sequentially every 3 seconds.
The OL D display will show SoC information for a battery only if it is inserted in a charging bay or if
it is actually charging. If no battery is present inside a charging bay, the corresponding SoC portion of the
display will stay blank. If all batteries are fully charged or if all of the charging bays are empty the OL D
display will stay off.
Ce document est la propriété d'AUDIOROOT, et ne peut-être reproduit ou communiqué sans autorisation
During battery charging, a color changing line will be drawn every 2-3 seconds at the bottom of the
display. This animation is purely esthetic and has no technical function.
BOX CONTENTS :
1. 1 x eSMART DUAL CHARG R
2. 1 x AC cord ( U, US, UK or AU depending of your region)
3. 1 x 100/240V 24Vdc/3.34A universal AC/DC adapter
4. 1 x user manual
SAFETY PRECAUTIONS :
–
Do not expose the charger to liquids. The aluminum enclosure is not water resistant.
–
Do not open the charger – no parts are user accessible/replaceable.
–
Do not cover aluminum extruded housing. Do not obstruct the airflow around the unit.
–
Place the charger in a cool spot, away from direct sunlight or any external heat sources.
CHARGER OPERATION :
To operate the battery charger proceed as follows :
–
Place the charger on a flat level surface away from sources of heat and moisture.
–
Plug the supplied AC/DC's adapter DC jack to the eSMART DUAL charger's rear connector.
–
Plug the supplied AC cord to the I C C13 socket located on the AC/DC adapter.
–
Plug the other end of the AC cord to a compatible wall socket.
–
Insert one or two batteries in the charging bays, ensuring that the 5-way connector is fully seated.
–
The status L Ds and OL D display will provide status information and the charger will
automatically begin charging.
–
Once the batteries are full, the charging will automatically stop and the OL D display will shut off.
CHARGING TIMES :
The following values are givent for a full charge from 0% to 100% state of charge.
–
eSMART Li-49Wh : 2.5 hours (@1500mA charging current)
–
eSMART Li-98Wh : 3.5 hours (@2000mA charging current)
SUPPORT :
Please contact us directly via email at audioroot@audioroot.fr for more support.
Ce document est la propriété d'AUDIOROOT, et ne peut-être reproduit ou communiqué sans autorisation
FCC COMPLIANCE:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Warning: Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user authority to operate the equipment.
Notes: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can radiate
radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-- Consult the dealer or an experienced radio/TV technician for help.
----------------------------------------------------------------------------------------------------------------------
CE DECLARATION OF CONFORMITY:
We, S.A.S.U SULACO, declare under our sole responsibility that the product :
Product name : eSMART DUAL CHARG R
Description : 2 bay lithium-ion smart battery charger
Model number : DUAL C
Brand name : AUDIOROOT
Manufacturer : SASU SULACO
is in conformity with the following standards or other normative documents :
Electromagnetic Compatibility:
N 55032: 2015/AC: 2016; N 55035: 2017; N61000-3-2: 2014; N61000-3-3:2013
Following t e provisions of EU-Directives:
MC lectromagnetic Compatibility (2014/30/U )
Place of issue : Sélestat, FRANC Date of issue : 15 April 2019
Antoine MALNATI
President
Ce document est la propriété d'AUDIOROOT, et ne peut-être reproduit ou communiqué sans autorisation
