Audiovox HR7011PKG User manual

AUX
AUX
HR7011PKG
Two Custom Vehicle Headrests
with 7” LCD Monitors Touch Screen Control
and Built-in
DVD Player for Rear Entertainment
Installation Guide
128-8939

Installation of headrest products require careful planning and preparation. Be
extremely careful of seats that have airbags built into them. Keep wiring away from
any air bag wiring (usually identified by yellow connectors and yellow wire jackets).
Damage to air bag wiring can result in personal injury to vehicle occupants. If you
have any questions regarding wire routing or installation in a vehicle, please contact
Audiovox Technical Support at 1-800-225-6074.
When connecting power and ground in a mobile video installation, insure that the
ACC wire is fused at the point where it is connected to the vehicle ACC wiring.
Failure to do so can result in damage to the vehicle if a short circuit develops
between the vehicle connection point and the mobile video product.
IMPORTANT NOTICE
An LCD panel and/or video monitor may be installed in a motor vehicle and visible to
the driver if the LCD panel or video monitor is used for vehicle information, system
control, rear or side observation or navigation. If the LCD panel or video monitor is
used for television reception, video or DVD play, the LCD panel or video monitor
must be installed so that these features will only function when the vehicle is in
“park” or when the vehicle’s parking brake is applied.
An LCD panel or video monitor used for television reception, video or DVD play that
operates when the vehicle is in gear or when the parking is not applied must be
installed to the rear of the driver’s seat where it will not be visible, directly or
indirectly, to be operator of the motor vehicle.
Licensed under one or more of the following patents:
Patent NOS. 7,245,274, 6,899,365, and 6,678,892
2

3
MATERIAL TO USE IN THIS PACKAGE:
M1/M2
Note:
M1/M2 Monitor include master
monitor headrest cable
& hardware screws
Front view =
Remote Control
Back view =
Wireless Game Controller
1) HR7011PKG System Monitor (P/N HR7011M) (2 pcs)
Monitor with touch screen control and DVD Player
a) Remote Control with
Wireless Game Controller
(P/N 136-5008) - (2pcs)
d) Wireless FMM Interface Box
(P/N 136-5009) - (1pc)
b) 2 Pin DC Power Cable
(P/N 112-3667) - (1pc)
e) AV Adapter Cable
(P/N 112B3227) - (1pc)
g) Eject Card
(P/N 126-1359) - (1pc)
c) 12 Pin AV Adapter Cable
(P/N 112-4094) - (1pc)
POWER
MUTE
RETURN
123
456
789
0
EJECT
VOLUME
DAY
NIGHT PIX
OK
AUDIO
M1 M2
DISPLAY
MODE
ZOOM
MENU SETUP
SYSTEM
MENU
SOURCE
IRT
ON/OFF
FMM
ON/OFF
FMM
SELECT
SUBTITLE
A-BREPEAT
FLO
DVD
SOURCE
DVD
i
Note: The HR7011M touch screen monitor has been designed to be
interchangeable from one headrest to the other.
The wireless FMM Interface Box automatically determines which headrest
is M1 and which headrest is M2 and sets each headrest to its own function
(IR transmitter channel and IR receiver remote control codes).
The headrests will still have the Red/Green and Blue/Yellow DIN cables on
them and should be connected to their respective connectors. In the event
a touch screen monitor needs to be replaced, simply order P/N HR7011M.
2) HR7011PKG Accessories Package (P/N HR7011K) (1 pc)
The Accessories Package contains the following items:
Note: The Eject Card is packaged with the Owner’s
Manual (P/N 128-8938) - (1pc), Installation Guide
(P/N 128-8939) - (1pc), and Product Registration Card
(132-6751) - (1pc).
f) 3 Pack/Shrink Wrapped 1.5V AAA Batteries
(P/N 156-2268) - (2pcs)

HR7011PKG SYSTEM OVERVIEW
4
1) The HR7011PKG SYSTEM is a versatile audio / video system with built-in DVD player
HR7011PKG which includes two touch screen monitors, that can accept an Audio / Video
input and independent AUX input. A separate audio output is provided for connecting an
optional FM Modulator to the vehicle’s radio.
2) The M1 Monitor is comprised of a 7" Touch Screen TFT LCD monitor with built-in DVD
player that allows the user to select from the DVD, USB, M2, AUX, AV, MEDIA and, GAME
source. The M1 monitor has a built-in infrared audio transmitter (CH A) for use with the
optional two-channel wireless headphones (CH A).
3) The M2 monitor is comprised of a 7" Touch Screen TFT LCD monitor with built-in DVD
player that allows the user to select from the DVD, USB, M1, AUX, AV, and MEDIA source.
The M2 monitor has a built-in infrared audio transmitter (CH B) for use with the optional
two-channel wireless headphones (CH B).
4) The monitors will show all of the functions on screen with the Graphical User Interface
(GUI) and allow system control with the touch screen GUI.
5) The two-channel wireless headphone sets have an A-B switch that allow the users to
select the audio from either the M1 (CH A) or the M2 (CH B).
6) Using different IR codes, the M1 monitor will only respond to the remote control unit when
the Select M1 button on remote control is pressed. The M2 Monitor only responds to the
Remote Control unit when the Select M2 button on remote control is pressed.
7) The optional wired headphones allow the user to listen to audio from the system.
8) The M1 and M2 Monitor will accept an audio / video input through the 1/8” jack located on
the front of the unit. The audio / video device could be a video game system, video camera
or other input device.
AUX
WIRED HEADPHONE
USB
AUX
TOUCH SCREEN GRAPHICAL USER INTERFACE (GUI)

PULL UP
AUX
USB JACK
WIRED HEADPHONE
PUSH UP
5
9) Pivot the screen until a comfortable viewing angle reached. The internal lock limits the
screen to a maximum adjustment of 19 degrees from closed position. The headrest itself
can be tilted forward to help achieve a comfortable viewing position.
10) Insert/Eject disc.
Internal Lock
Open Position
Shaft Angle
Closed Position
Insert/Eject Disc
19 Degrees

6
VEHICLE PREPARATION
1) Read the manuals and get familiar with the electrical requirements and
connections.
2) Prepare the vehicle by removing any interior trim necessary to gain access to the
vehicle's wiring as well as all areas where interconnecting wire harnesses will be
located. The mounting method and the location will vary from vehicle to vehicle, so
this manual will only focus on the installation of the Master and Satellite Monitors in
the supplied configuration. The best location for the HR7011PKG System
components are:
a. Monitors: Vehicle-specific Headrest
The Master Monitor should be installed in the passenger position most
used.
b. Wireless FM Interface Box: Under either seat where monitors are located.
Note:
3) Locate an accessory power source (+12 VDC present when the
ignition key is in the accessory and run positions. 0 VDC should be present
when the ignition key is in the OFF position) and a good ground. Generally,
these wires can be located at the ignition switch or fusebox.
Ensure that the switched power is fused at the source. Failure to do so
may result in vehicle wiring damage.
4) Run the wiring harnesses throughout the vehicle as necessary. (Refer to the
Wiring Diagrams on page 10, as well as the wiring instructions for the individual
components and accessory options being installed). Be sure that all the wiring
is protected from sharp edges and is routed in such a manner that it will not be
pinched when it is fully installed. Be sure to leave enough slack in the wiring at
each component to allow sufficient working room. Be sure to leave enough
slack in the monitor cables to allow the headrest to move up or down, and the
seat to move backward and forward.
5) Remove all the components from their packaging and then place them in the
vehicle at their respective locations.
6) Install the Headrests:
a. Remove the vehicle's original Headrests.
b. Hold the Headrest above the seat and insert the two cables into the headrest
support tube holes. Make sure that the headrest is in the correct position
(Display facing the rear).
c. Route the cables through the seat back and out the bottom of the seat.
d. Place the Headrest support tubes into the support tube holes while pulling
the cables to remove the slack. Be sure to leave enough slack in the monitor
cables to allow the headrest to move up or down.
should be
Note:

7
7) Connect all the components together (electrically) and verify proper operation of
all the system functions.
a. The headrest DIN cables and the FMM Interface Box DIN cables are color
coded. Connect each headrest cable to the correct color cable on the FMM
Interface Box.
b. Extend the wireless FM antenna to its full length and orientate for best
reception. Do not place it on the FMM Interface Box or near metal.
c. Connect the DC power jack.
.
8) After verifying the proper operation of the system, mount each component.
9) When all the components are mounted, recheck the entire system to be sure it is
functioning correctly. Make sure that no wiring was pinched or connected
improperly during the final installation.
Wireless FM Modulator
The HR7011PKG is equipped with a built-in wireless FM Modulator*, that allows
you to listen to the DVD audio signal by tuning your vehicle’s radio to the selected
frequency, ( 88.1MHz, 88.3MHz, 88.5MHz, 88.7MHz,
88.9MHz, 89.1MHz, 89.3MHz, 89.5MHz, 89.7MHz,
89.9MHZ, 90.1MHz, 90.3MHz, 90.5MHz, 90.7MHz,
90.9MHz, 91.1MHz). This feature is accessed by using the FM
transmitter buttons on the remote (FMM ON/OFF, Channel Select).
Whenever the FM Modulator is on, broadcast reception on the vehicle’s radio will
be poor. Switching off the FM Modulator will allow normal radio reception.
CH1 CH2 CH3 CH4
CH5 Ch6 Ch7 Ch8 Ch9 CH10
Ch11 CH12 Ch13 CH14
CH15 CH16
*Note:
Audiovox P/N
SIRSWB
In certain areas where there are a large number of FM radio stations (e.g. large
cities, urban areas), the reception of the FM signal may not be satisfactory, resulting in
static, distorted sound or signal bleed thru from strong local radio stations. This is not a
defect in the product, but the result of a stronger local radio station overpowering the
wireless FM transmitter in your overhead pod.
If wireless reception is unsatisfactory, an optional wired relay box (
) can be installed which will improve audio quality. Please contact the installer
if this is the case with your product.

8
ELECTRONICS INSTALLATION GUIDE
Monitor Unit Install Monitor Unit to Headrest
(Master Monitor) (Satellite Monitor)
(Master Monitor / M1) (Satellite Monitor / M2)
Monitor must be in closed
position. Insert Eject Card
at top slot to the end.
Hold the Eject Card then
press monitor and pull it
out.
1 2 3
45
Cable 1 :
Monitor Pigtail Cable
Cable 2 :
Headrest Cable
Match M1 monitor pigtail cable to M1 headrest cable
Match M2 monitor pigtail cable to M2 headrest cable
Press the release tab to release
the monitor completely.
Note: The HR7011M touch screen monitor has been designed to be interchangeable from one
headrest to the other.
The wireless FMM Interface Box automatically determines which headrest is M1 and which headrest
is M2 and sets each headrest to its own function (IR transmitter channel and IR receiver remote
control codes).
The headrests will still have the Red/Green and Blue/Yellow DIN cables on them and should be
connected to their respective connectors. In the event a touch screen monitor needs to be replaced,
simply order P/N HR7011M.

9
6 7 8
9
With Screw (x4)
10 Move the locking tab to right position
to fully insert the monitor into the
headrest
11

10
M1 Monitor
Master Monitor
M2 Monitor
Satellite Monitor
OPTIONAL
FM ANTENNA
INTERFACE BOX
Relay Box for wireless FM MOD
See antenna note below
SIRSWB
DC
IN
2 PIN DC POWER CABLE
AV Input AV Output
BLUE YELLOW
GREEN RED
HR7011PKG WIRING DIAGRAM
Relay Box
See the instructions supplied with the SIRSWB for installation.
12 Pin AV Adapter Cable

11
This page intentionally left blank.

128-8939
© 2011 Audiovox Electronics Corp., Hauppauge, NY 11788
