Audiovox MMD10 - DVD Player With LCD Monitor Service manual

MMD10
10" LCD MONITOR&DVD PLAYER
Owner/ Installation Manual

2
Note:
This Productincorporates copyrightprotection technologythat is pro-
tectedbymethod claims ofcertain patents and other intellectual prop-
erty rights owned byMacrovision Corporation and other rights owners.
Useofthis copyrightprotectiontechnologymust beauthorizedby
Macrovision Corporation,and isintendedforhomeand otherlimitedview-
inguses only unless authorizedby MacrovisionCorporation. Reverse
engineeringor disassemblyis prohibited.
Warnings
Do not use anysolvents or cleaningmaterials when cleaningthe video
monitor.
Do not use anyabrasive cleaners, theymayscratch the screen.
Useonly alightly dampenedlintfree cloth to wipethescreenifitisdirty.
LocktheLCD screen in the fullyclosed position when not in use.
Before putting onheadphonesalwaysadjust the volume setting to the
lowest position.
Remember to leavethe dome light switch inthe off or auto positions
when thevehicle is unattended, as the dome lights, ifleft on, can drain
thevehicle sbattery.
Do not put pressure on the screen.
Licensedunder one ormoreofthefollowingpatents,
PatentNOS.5,775,762and5,927,784

3
AnLCDpanel and/or videomonitormaybeinstalled in amotor vehicle
and visible to the driver ifthe LCD panelor videomonitor is used for
vehicle information, system control, rear or side observationor
navigation.If the LCDpanelor video monitor is usedfortelevision
reception, video or DVD play, the LCDpanel or video monitor must be
installedsothat these featureswill onlyfunction when the vehicle is in
“park”orwhenthevehicle s parkingbrake isapplied.
AnLCD panelor video monitor used for television reception, videoor
DVDplay thatoperateswhenthevehicleis ingear or whentheparking
brakeis not appliedmust be installedtothe rearofthe driversseat
where itwill notbevisible, directly or indirectly, to theoperator of the
motor vehicle.
Important Notice

4
A.Introduction
Thank youfor selecting the MMD10. The main featuresinclude a
10"Wide Screen(16:9AspectRatio)Liquid Crystal Display (LCD)
monitor and abuilt-in DVD player. Theunit appliesthe latest state of
theart electronics.The unitisconstructed to provide years ofreliable,
trouble-free service. Please read theentire instruction manual sup-
plied with this product prior to operation. The documentation will as-
sistyouininstallingthesystemproperly to obtainthebest equipment
performance. Pleasestore this manual forlater use.
B. Cautions and Warnings
1. Installation
Ensure thatthe MMD10 isinstalled in accordance with theinstruc-
tions and illustrations provided in this manual.
2. Objects and Liquids
Do not push objects ofany kind into the unit through openings; do
notspill or sprayliquid ofany kind on orin the system (this may
result in a fire or electric shock). Toensure proper ventilation and
proper operation, nevercoverorblocktheventilation slots andopen-
ings
3.Disassembly
Do not attempt to disassemble the cabinet. There is ariskofelec-
tricshock and/orexposure to LaserRadiation. Contact qualified
service personnel ifyour system is in need of repair.
4.Cleaning Unit
When cleaning, makesurethe systemis unplugged fromthepower
source.Do not useliquid cleanersor aerosol cleaners.Use a
clothlightlydampenedwith water forcleaning the exteriorof the
systemonly.

5
5. Disc
Do not use irregularlyshaped discs such asheart orstar-shaped
discs as theymay cause the unittomalfunction.Donotstickpaper,
tapeor glue on the disc. Do not expose thedisc to direct sunlight
or heat sources such as hot air ducts. Do not touch the surface of
disc.Handlethe discbyits edge. Cleanthediscby wiping thedisc
from thecenter outwith acleaning cloth. Removethe disc from
theunit andstoreitinitscaseafterplaying.Someplaybackopera-
tions of discs may be intentionallyfixedbysoftwareproducers.
Since this unit plays discs accordingto the disc contents the soft-
wareproducersdesigned,some playbackfeaturesmay notbe
available. Also refer to the instructions supplied with the discs.
C. CONTENTS
1. 10"LCD Monitor & DVD Player Combo
2.A/V Adapter Cable
3.Power Domelight
4. Hardware Package
4pcs M4 x 16mm Machine Screws
4 pcs M4 x25mm Screws
4 pcs 2.6x10mm Screws
4pcsSmall RubberRings
4pcs ConnectingAxises
5. Remote Control
6.Mounting Plate
7. Owner/InstallationManual
8. Trim Ring

6
TOOLS REQUIRED:
#2Philips Screwdriver
#1Philips Screwdriver
Utilityor Razor Knife or Shears
WireStrippers
Upholstery hooktool (for removal ofpanels as necessary)
ElectricalTape
Masking Tape
Multimeter (toverify 12 voltDC andcontinuity:Donotuse atestlight
or logic probe)
Marker pen #to markheadliner
Scribe(to marktrim ringifused)
Misc.electrical connectors(toconnect tovehicle power source).
Requirements will varyfrom vehicle to vehicle.
D. Installation and Powering

7
GENERAL INSTALLATIONAPPROACH:
1)Decide upon system configuration and options that will be installed
(i.e.: what components, VCP,Tuner,RF Modulator/externalamp,
remoteheadphones, DVD, etc.).
2)Reviewall manuals to become familiar withelectrical requirements
and hookups.
3)Decideupon mounting locations of all componentsandmethodof
mounting.
4)Prep the vehicle by removing anyinteriortrim necessary to gain ac-
cess to vehicle'swiring as well asall areas whereinterconnecting
wire harnesseswillneed to belocated.Ifany access holes need to
be cut intothevehicle(headliner,other trim components etc.), this
should be done nowas well.
5)Route the wiring harnesses throughout the vehicleas necessary.
(Refer to theWiringDiagrams on page10 of this manual as wellas
the wiringinstructions for the individual components and accessory
options being installed).Besure thatall wiring isprotected from
sharpedges and is routed in such amannerthatitwill notbe pinched
whenall components andinterior trim arefully installed. Be sure to
leaveenoughslack inthewiringateachcomponenttoallowworking
room.
6)Remove allA/V system components fromtheirpackaging and place
them looselyin the vehicle at their respective locations.
7)Connectallcomponents together(electrically)and verifyproper op-
erationof all system functions.Note:This is bestdoneBEFORE
components have been permanentlymounted.
8)Afterverifyingproper operation ofthe system,proceed tomounteach
ofthecomponents.
9)When all componentsaremounted,recheck theentire systemagain
to ensure that no wiring was pinched orconnected improperlydur-
ingfinalinstallation.

8
Notes :The MMD10 video system is onlyintended for an overhead,
drop downinstallation.Itisnotintended forseat back or any other
type of mounting. Thehinging mechanismis designedfor horizontal,
drop down use only.
VEHICLE PREPARATION:
1)Locateanaccessorypowersource (+12v whenkeyisin theACC.
and run positions, and 0v when key is off). Generally, thiswire can
be found at the ignition switch or fuse-box.
2)The mountingmethod and location will vary from vehicle to vehicle,
so this manual will only focuson the installation ofthevideo monitor
and related consoleaccessories.
3)Generally,the bestlocationforthevideomonitor iswherethevehicle's
factory domelight isinstalled. The monitorshouldbelocated in
suchamannerthatitcan be comfortablyviewed byrearseatpassen-
gers. NEVER INSTALL THE MONITOR IN A PLACE WITHIN THE
DRIVER'SVIEW.THISISNOTONLYDANGEROUS,BUT ITIS
ALSO ILLEGAL.
4)Once the mounting locationof the monitor has been determined,
there maybe additional preparation worknecessary, dependingon
the vehiclestructure and installation method.Someof the steps
thatmaybe required are:
A)Removal ofthe vehicle's dome light.
B)The headliner may need to be trimmed.

9
Figure2
NOTE:
Two ofthe mountingholesare locatedunder thedomelight covers.
If using the TRIM RING to mount the MMD10, please use the M3.5 x25mm screws.
MOUNTING THE MMD10

10
Trim Ring Installation
The TrimRingInstallation isaccomplishedusingthe four(4)2.6X1 0mm
screws supplied. Please refer to theillustration below.
A
AA
A
1.Placethe MMD10 on a softsurface withthe rubbergasket facing
up. Usecare to avoid scratching the unitsexterior surface.
2. Takeoff therubberring.
3.Placethetrim ringon the unitandnotethe location ofthefourmounting
screws.
4.Attach the trim ringto the unit usingthe longer four (4) 2.6 X 10mm
screwssupplied.
5.Attachthe four (4) post extensions tothe bracket.
6.Attach the four (4) rubber spacers on the post extensions

11
7.Refertothe Owner/Install ManualfortheMMD10tocomplete the
installation.

12
MMD10
1)Make the connections to the vehicle with the 5 pin wiring harness.
2)Connect the 5pin harnessto the matingconnector onthe Video
Monitor.
3)Connect powerharnessto vehicle's electrical systembytapping
into an accessoryhot line.
4)Verifyallfunctions ofthesystem beforefinal mountingofthefinished
assembly.
NOTE: AVCPorother A/VComponent can be connected tothe
video monitorsystem using an RCAA/V cable.This secondhar-
nesswould plug intotheAV1inputs or AUXjack.
A/V Source Definitions :
1 =Built-in DVD
2 =AV1 input ( VCP, DVD, etc )
3 =AV2 Input ( VCP,Game, DVD, etc )
Figure3

13
CONNECTINGTHEDOME LIGHTS
Thedomelightsinthe video monitor requirethreeconnections tothe
vehicle'swiring. Therearetwocommon typesof domelight circuits
used, positiveor negativeswitched. Positivesystems supply voltageto
theinteriorlights toturnthemon, negative switched systems apply
ground toilluminate the bulbs. Todetermine which systemyou have
youmust locate the wires atthe domelight.On apositive switched
system,with all the doors closed and the lights out, both wiresat the
domelight will rest at ground. Whenthe light isactivated, oneofthese
wires will switch to +12V DC. This is the vehicle's switchingwire. On a
negativeswitched system, withall the doorsclosedandthe lightsout,
bothwires at thedomelight will rest at + 12VDC.When the lightis
activated,one of thesewires will switchto ground. This isthe switching
wire.
Forpositivesystems, connect the violet/ brown (Lamp auto) wire to the
vehicle'sswitched wire. Then connect the red / black(lamp on) wire to
afusedconstant12 voltsourceandtheblack /red(lamp common)wire
toagoodground.Positive systemsarecommonlyfoundonFord
vehicles.
For negative systems,connect the violet /brown(Lamp auto) wire to
the vehicle'sswitchedwire.Thenconnect thered /black (lampon) wire
to a good ground andthe black/red(lamp common) wire to fusedcon-
stant12voltsource. Negative systemsarecommonlyfoundonGen-
eral Motors and import vehicles.
Note:
Some vehicleswhichincorporate transistorized control of the dome
light circuit,such asthe1999DodgeCaravan, mayrequirethatthe
violet/brown(Lampauto)wirebeconnected tothedoor pin switch
wire, as the additionalcurrentdraw ofthe Monitor'slights may not be
supportedbytheoutput of thevehicles bodycontrol computer.

14
Red / black - Lamp on
Black / red - Lampcommon
Violet / brown-LampAuto
To3 pin
connector
onMonitor
To
constant
+12vdc
To
constant
+12vdc FactoryDoorajar
switchorBody
Controlcomputer
Factory Dome light circuit
PositiveSwitched Dome lighting
Negative Switched Dome lighting
To3 pin
connector
To
constant
To
constant
FactoryDoorajar
switchorBody
Factory Dome light circuit
Red / black - Lamp on
Black / red - Lampcommon
Violet / brown-LampAuto
Figure 4
Figure 5

15
E. Controls, Indicators, and Connectors
1. Unit View (Refer to Figure 6)
Figure 6
1)AV2In
2) HeadphoneJack
3) FM Modulator Switch
4) Auto/Off/On Dome Light Switch
5) Power and DomeLightConnector
6)AVIN RCAJacks(red,white,yellow)
7) AVOutput RCAJacks (red,white,yellow)
8)Power Button
9)Reverse Scan Button
10) StopButton
11) Forward Scan Button
12) Monitor Release Button
13) IR Sensor and IR Transmitter
14)Volume -
15) Picture
16)Volume +
17) Playbutton
18) DomeLights
19) Eject button
20) Disc Insertion Slot

16
2. Remote ControlView (Refer to Figure7)
1)Power Button
2)DisplayButton
3)Angle Button
4)SubtitleButton
5)A-B Button
6)Slow Button
7)Pause Button
8)ReverseScanButton
9)Stop Button
10)Picture Button
11)DVD/AV1/AV2
12)Zoom Button
13)Eject Button
14)Numeric Buttons
15)Audio Button
16)Repeat Button
17)MenuButton
18)Setup Button
19)Up/Down/Left/Right/Enter Buttons
20)ForwardScan Button Figure 7
21)Return Button
22)PlayButton
23)Skip- Button
24)Skip+ Button
25)Vol Down Button
26)VolUp+ Button
27)WideButton
F. Loading and Playing a Disc
a.Turn the power on bypressingthepower button on the unit or the
remote control. Select DVD usingthe DVD/AV1/AV2 button on the
remote.
b.Place a disc into the disc insertion slot with the label side facingup.
c.Playbackwill start automatically.
d. Pivot theLCD Screen for agood viewingangle.

17
POWER
PLAY
SLOW
PAUSE
STOP
FORWARD
REVERSE
UP/DOWN/LEFT/RIGHT
ENTER
NUMBERS
RETURN
MENU
REPEAT
A-B
DISPLAY
ANGLE
SUBTITLE
AUDIO
ZOOM
SETUP
DVD/AV1/AV2
EJECT
VOLUME-
VOLUME+
SKIP-
SKIP+
Turnthe uniton/off
Start Playback
Play at 1/2,1/4,1/8, or 1/16 normalspeed
Still Picture
(1time) Stopatthepresentplaying point /
(2 times) Stop playing
Scanforward at 2,4, 8,16,or 32timesnor-
mal speed
Scanbackwardat2, 4, 8,16,or 32times
normal speed
Used forMenu Navigation
Confirm item or setting
Select item or passwordsetting
Not usedinthis model
Display the root menu of the disc
Repeatplayback ofa title,chapter, ortrack
Repeataspecificportion frompointAto
point B ofthe disc
Displaydiscinformation (title,chapter, track,
time, etc.)
Change the angle ona scene
Select the subtitle languageand turnit on/
off
Selecttheaudio language
Enlargean imageto 2 ,3, or 4 times the
original size
Displaythesetupmenu to select andset
items, and exit the setup menu.
Source selectionDVD,AV1, AV2
Eject disc
Brightness/Contrast/Tint/Color
Reduce volume/Lower picture setting
Increase volume/Raise picture setting
Previouschapter/track
Nextchapter/track
G. BASICOPERATION

18
H.Setup
Press ‘SETUP todisplaytheMainscreenoftheSetup Menu.Press
‘SETUP again toexitthe Setup Menu and the unit will resumeitslast
playbackmode.
1) Press “SETUP”,the ‘GeneralSetup Page will be displayed.
a).Select ‘TVDisplay using the UP/DOWNbutton, and then press
RIGHTtoenterthesubmenu.Selectthe TVdisplaymode on the screen
using UP/DOWN,and press ENTER to confirm the setting. Press
LEFT toreturn.
*Normal/PS:Whentheplayer isconnectedto a normalTV,and a wide
picture is shown on the full screen.
*Normal/LB:When theplayerisconnected to a normalTV,andawide
picture is shown on the screen with a blackstrip at both the topand
bottom ofthe screen.
*Wide:Whenthe player is connectedto awidescreenTV, awide
picture is shown on the full screen.
Main Setup Menu Screen
TV DisplayScreen Display

19
b).Select ‘AngleMark usingtheUP/DOWNbuttton,andthenpressthe
RIGHTbutton to enterthesubmenu. Choose Angle Markon or off
using the UP/DOWNbutton and then press ENTER to confirmthe
setting. Press the LEFT button to return.
Angle Mark Screen Display
*On:Thescreenwillshow the angle mark icon.(*If an angle option is
available).
* Off:The screen will not display theAngle Mark
NOTE: Not all discs contain abovefeatures. The abovefeatures are
discdependent.
c).Select ‘OSD Lang using theUP/DOWN button, and then press the
RIGHT button to enter the submenu. Choose the desired OSD lan-
guageusingtheUP/DOWNbuttonand then pressENTERtoconfirm
the setting. Press the LEFT button to return.
OSD Lang ScreenDisplay

20
d).Select ‘Screen Saver usingthe UP/DOWN button,and then press
theRIGHTbuttonto enterthesubmenu.ChooseScreenSaveron or
offusingthe UP/DOWNbuttonand thenpressENTERto confirm the
setting. Press the LEFT button to return.
ScreenSaver ScreenDisplay
*On:Enables screensaver
*Off:Disables screensaver
*NOTE: The DVD playerwill enter the Screen Savermode after ap-
proximately three minutes ifthe same imageremainsonthe screen.
e). Select ‘Last Memory byUP/DOWNbutton.and then press the
RIGHT buttonto enter the submenu. Choose Last Memoryon or
off usingthe UP/DOWN button and then press ENTER to confirm
the setting. Press the LEFT button to return.
Last MemoryScreen Display
