Audiovox HR7DD PKG User manual

HR7DDPKG
Two 7" Monitors w/Built-in DVD Players
and Audio/Video Input Capability Mounted
in Vehicle Specific Headrests
Installation Manual
POWER SCREEN MODE AUXPLAY STOP SOURCE M1
POWER SCREEN MODE AUXPLAY STOP SOURCE M2

IMPORTANT
An LCD panel and/or video monitor may be installed in a motor ve-
hicle and visible to the driver if the LCD panel or video monitor is
used for vehicle information, system control, rear or side observation
or navigation. If the LCD panel or video monitor is used for television
reception, video or DVD play, the LCD panel or video monitor must
be installed so that these features will only function when the vehicle
is in ‘park’ or when the vehicle’s parking brake is applied.
An LCD panel or video monitor used for television reception, video
or DVD play that operates when the vehicle is in gear or when the
parkingbrakeis notapplied, mustbe installedtothe rearof thedriver’s
seat where it will not be visible, directly or indirectly, to the operator of
the motor vehicle.

The Materials included in this package
1. HR7DDPKGSystemMonitor
(Master1-#HR7DD(M1),OneMaster2-#HR7DD(M2) (2pcs)
2. RemoteControl(P/N136-3785) (1pc)
3. HR7DDSystemMain Cable(P/N112-3457) (1pc)
4. DualFrequencyIRHeadphone (P/NIR2CHS) (2pcs)
5. FMModulatorpackage (P/N136C3655) (1pc)
6. A/VAdapterCable (P/N 112B3227) (2pcs)
7. 3PinPowerWireHarnesswithchoke(P/N 112B3370) (1pc)
8. In-linePower Choke (P/N112B3493) (1pc)
-1-
M1 M2
1. 2.
4.
3.
5.
6.
7.
8.
M1 M2
+
V
OLUME
M1 ON LY

-2-
HR7DD PKG SYSTEM OVERVIEW
1) When both monitors are selected asAV1, there will be no sound output and screen will be black.
2) M1 will display all of the functions including the FM modulator selection with the comprehensive OSD. FM
functions may also be turned off by selecting the FM ON/OFF button on the remote control.
3) The HR7DDPKG system is supplied with two IR Headphones (P/N IR2CHS). The headphones have anA-B
switch that allow the users to select the audio from either the M1 (CHA) or the M2 (CH B).
4) Using different IR codes, M1 will only respond when the remote control set to M1and M2 will respond only
when the remote control set to M2. Each operates independently of the other.
5) There are1/8" Headphone JacksonM1 andM2that can beused with anystandard wired stereoheadphones.
These jacks are controlled by the volume up/down buttons on the remote control.
(NOTE: Besure tounplug the1/8" Headphoneplug and / orAUX input plug when opening either M1
or M2 to insert or remove a disc to prevent damage to the unit.
6) Pivot the screen until a comfortable viewing angle reached. The internal lock limits the screen to a
maximum adjustment of 30 degrees from closed position, the headrest itself can be tilted forward
to help achieve a comfortable viewing position.
9) Insert Disc 10) Eject Disc
Insert
Disc
Eject
Disc
Internal Lock
30 degrees
POW ER SCR EEN MODE AUXPLAYSTOP
AUX
Input
SOURCE M2 POW ER SCREEN MODEAUXPL AYSTOP SOURCE M1
POWER SCREEN MODE AUXPLAY STOP SOURC E M1 POWER SCREEN MODE AUXPLAY STOP
HEADPHONE
JACK
SOURCE M2
(M1/M2) (M1/M2)
The HR7DDPKG system contains two vehicle specific headrests. Each has a 7" Monitor and built-in
DVD Player. This system allows the users to either watch individual DVD’s or watch the same DVD
on both monitors. Both users can also share anA/V source connected to eitherAUX input. The full
function remote control can operate either unit by selecting MI or M2 on the remote.
Caution: Each monitor has anAUX input on the bottom right hand side of the screen. When the
AUX connector is plugged in to this input use care when pivoting the screen downwards. The
plug will limit screen travel. Excessive force can damage the screen and/or plug.

VEHICLE PREPARATION:
1) Readthe manual and get familiar with the electrical requirements and connections.
2) Preparethe vehicle by removing anyinteriortrim necessary to gain access to the vehicle'swiringas well as all
areas where interconnecting wire harnesses will be located. The best location for the HR7DDPKG System
components is:
a. Monitors: Vehicle specific Headrest (NOTE: The M1 should be installed in the passenger
position most used. Check with the customer before installing this system.)
b. FM Modulator: Near the car radio.
c. System Main Cable: Under seats where M1and M2 are located.
3) Locate an accessory power source (+12VDC present when the ignition key is in the accessory and run posi-
tions.0VDC should be present whenthe ignition key is intheOFF position), a constantpowersource (+12vdc)
at all times, regardless of the ignition key and a good ground. Generally, these wires can be found at the
ignition switch or fusebox. (NOTE: Installation of the large choke is only necessary if experiencing engine
noise.)
(NOTE: Ensurethat both the constant and accessorypoweris fused at the source. Failuretodo so may result
invehicle wiring damage.)
INSTALLATION: (see wiring diagram on page 4)
1) Run the wiring harnesses throughout the vehicle as necessary (Refer to the wiring diagrams on page 4.) Be
sure,that all the wiring is protectedfromsharp edges and is routed insucha manner that it will notbepinched,
when it is fully installed. Be sure to leave enough slack in the wiring at each component to allow sufficient
workingroom. Besuretoleaveenoughslackin the monitor cables to allow the headrest to move up or down,
and seat movement. Keep main harness and seatback harness away from the seat tracks
2) install the FMmodulatorinan area where there is access to the radio antenna connector. This may be behind
the radio or in a kickpanel.
3) Installthe Headrests:
a.Removevehicle’s originalheadrests.
b.Hold the HR7DDPKG headrest above the seat and insert the two cables into the headrest support
tube holes. Make sure that the headrest is in the correct position (display facing the rear).
c.Route the cables through the seat back and out the bottom of the seat.
d.Place the headrest tubes into the support tube holes while pulling the cables to remove
the slack. Be sure to leave enough slack in the monitor cables to allow the headrest to move up or
down.
e.Carefully remove clear shrink tubing making sure not to damage wires inside. (see 1 next page.)
4) Connect the terminals of the system main cable to the corresponding 2 pin terminals of M1 and M2 at the
bottom of the seats verifying that the wire colors for each connector match the wire colors of the mating
connector .
(NOTE: Keep in mind that there are two groups of 2 pin connectors with 10 different wire colors. Be sure to
install the correct connector to the correct color wires. Failure to do this could cause damage to the electrical
componentand or vehicle. On themaincable that attaches tothe M2 harness there willbe an unused connec-
tor(Green andBrown.)
5) Connect all the components together (electrically) and verify proper operation of all the system functions.
(NOTE: ThisisbestdoneBEFOREreassemblingthevehicle.)
6) After reassembling the vehicle, recheck the entire system to be sure it is functioning correctly. Make sure that
nowiringwaspinched,orconnected improperly during the final installation.
-3-

-5-
HR7DD PKG SYSTEM WIRING DIAGRAM
* NOTE: The component
may not be needed in all
vehicles. InstallonlyIf
experiencing engine noise
*

© Copyright 2004 Audiovox Electronics Corp. 150 Marcus Blvd. Hauppauge, NY 11788 128-7165
